BIKEE BIKE LIGHTEST Reference manual

BIKEE BIKE LIGHTEST MOTOR REV12
IT
1
MANUAL
OF INSTALLATION AND USE
OF THE LIGHTEST SYSTEM
Please consider the environment before printing this manual.
Consider that Bikee Bike makes continuous improvements to the manual and
it would become a waste to print old versions

BIKEE BIKE LIGHTEST MOTOR REV12
IT
2
Summary
1. Introduction .......................................................................................................................................................................4
1.1 Thanks ..........................................................................................................................................................................4
1.2 Notes on the manual ...................................................................................................................................................4
1.3 Symbols ........................................................................................................................................................................5
1.4 Definitions ....................................................................................................................................................................5
1.5 Declaration of Conformity ...........................................................................................................................................6
1.6 Warnings ......................................................................................................................................................................8
2 Security ...............................................................................................................................................................................8
2.1 Safe use ........................................................................................................................................................................8
2.2 Protections and Pictograms .........................................................................................................................................8
3 Description ..........................................................................................................................................................................9
3.1 Intended use ................................................................................................................................................................9
3.2 Technical data ............................................................................................................................................................10
4 Intended use and unintended use ....................................................................................................................................10
4.1 Intended use and compatibility .................................................................................................................................10
4.2 Unintended use ..........................................................................................................................................................11
4.3 Residual risks ..............................................................................................................................................................11
4.4 Operations involving risks for the operator ...............................................................................................................12
4.5 Product integrity ........................................................................................................................................................12
4.6 Manual handling ........................................................................................................................................................12
4.7 Environmental and supported conditions .................................................................................................................13
4.8 Recharging the battery ..............................................................................................................................................13
5. Installation .......................................................................................................................................................................14
5.1 Package contents .......................................................................................................................................................15
5.2 Screw detail ................................................................................................................................................................18
5.3 Standard Mount (SHORT and MEDIUM) ....................................................................................................................19
5.4 Long and In Frame .....................................................................................................................................................19
5.5 Hybrid .........................................................................................................................................................................20
5.6 Pressfit adapter/bush assembly ..........................................................................Errore. Il segnalibro non è definito.
5.7 Assembling the crankset ............................................................................................................................................23
5.8 Chain guide assembly Torque sensor ........................................................................................................................24
5.9 Assembling the chain guide on the engine ................................................................................................................25
5.10 Adjusting the spacers on the pedal shaft ................................................................................................................27
5.11 Engine installation with Medium or Short ...............................................................................................................29
5.12 Engine installation with Long or Hybrid ...................................................................................................................31
5.13 Installing the motor with In-Frame brackets ...........................................................................................................35
5.14 Installing the wheel sensor ......................................................................................................................................39
5.15 Installation of signal wiring ......................................................................................................................................40
5.16 Installing the pedals .................................................................................................................................................42
5.17 Completing the front and rear chain guide .............................................................................................................44
5.18 Connectors ...............................................................................................................................................................46
6. Display ..............................................................................................................................................................................46
6.1 Overview of buttons ..................................................................................................................................................47
6.2 Switching on and off ..................................................................................................................................................47
6.3 Assistance management ............................................................................................................................................47
6.4 Main screen description ............................................................................................................................................48
6.5 Quick Directions .........................................................................................................................................................49
6.6 Menu navigation ........................................................................................................................................................50
6.7 Statistics screen description ......................................................................................................................................50

BIKEE BIKE LIGHTEST MOTOR REV12
IT
3
6.8 Reset statistics ...........................................................................................................................................................51
6.9 Settings screen description ........................................................................................................................................51
6.10 Torque sensor calibration ........................................................................................................................................53
7 Smartphone application ....................................................................................................................................................54
7.1 First start ....................................................................................................................................................................54
7.2 Main screen description ............................................................................................................................................56
7.3 Settings screen ...........................................................................................................................................................57
60 screen 59

BIKEE BIKE LIGHTEST MOTOR REV12
IT
4
1. Introduction
1.1 Acknowledgments
Dear Customer,
First of all, we would like to congratulate you on your choice and thank you warmly for the trust you have shown.
This trust is well placed, because the very high technological level and the quality of the materials ensure the perfect functioning of the e-
bike conversion kit you have purchased.
Our organization also allows us to guarantee customers a continuous and accurate assistance and maintenance service.
Read the manual carefully, scrupulously follow the instructions contained therein, in order to obtain the maximum result in terms of safety
and system durability over time.
All the procedures useful for dealing with any reasonably foreseeable emergency situations that may occur during use are also listed.
1.2 Notes on the manual
This manual contains instructions for installation, use and maintenance of the Lightest engine. Bikee Bike Srl reserves the right to modify
this document at any time without notice, for this reason we invite the user to always check that they have the latest revision, available for
consultation at this link:
www.lightest.bike or www.bikeebike.it
The manual is made up of various sections, each of which deals with a series of topics, divided into chapters and paragraphs. The general
index lists all the topics covered in the entire manual. The numbering of the pages is progressive and each page shows the number of the
same. This manual is intended for the user in charge of installing, using and maintaining the e-bike kit, and relates to its technical life after
its production, use and possible sale.
In the event that it is subsequently transferred to third parties for any reason (sale, loan for use, or any other reason), the product must be
delivered complete with all documentation.
The information contained in this manual is not intended and cannot replace the knowledge and experience possessed by the user, who
is in any case exclusively responsible for the use for which the e-bike kit was designed. Before starting any operation on any unit, it is
necessary to have at least read the entire manual and then studied the topic relating to the operations to be carried out in depth.
This manual contains proprietary information and cannot be supplied, even partially, to third parties for any use and in any form, without
the prior written consent of the manufacturer.
The manufacturer declares that the information contained in this manual is consistent with the technical and safety specifications of the
e-bike kit to which it refers.
A certified copy of this manual is deposited in the technical file, kept at the Bikee Bike srl company
The manufacturing company does not recognize any documentation that has not been produced, released or distributed by itself or by its
authorized representative. This manual, like the entire technical file, will be kept by the manufacturer for the period established by law (10
years). During this period, a copy of the documentation accompanying the product may be requested at the time of sale. The entire
technical file remains available for this period exclusively to the supervisory authorities, who may request a copy. After this period, it will
be the obligation and responsibility of those who manage the product to ensure that both the product and the documentation comply
with the laws in force at the time of the inspection.

BIKEE BIKE LIGHTEST MOTOR REV12
IT
5
1.3 Symbols
Indicates a risk to the user or device. Scrupulously
respect the message.
Further information given in the margin of the
paragraph.
Tip for quick and correct use of the device.
Quick press
Indicates indispensable information, to be read,
understood and respected carefully
(less than 1 second)
Positive key + of the display
Long press
Negative key - of the display
(more than 3 seconds)
[1]
In square brackets there are the references to the
components present in the first image.
KB
Abbreviation for “Kit Bikee Bike”
BB
Abbreviation for “Central Movement”
thr
Abbreviation Throttle , accelerator
TS
extension
Abbreviation Torque Sensor, torque sensor
PAS
Abbreviation Pedal Assist (cadence based not torque
based)
1.4 Definitions
CE marking : process of preparation of the technical file, within which the documentation of everything that the
producer/manufacturer/importer/authorized representative has carried out or verified is collected, to create a safe product that complies
with European directives and standards.
CE marking : application of the CE mark on products released for free circulation using various methods and supports.
Release for free circulation: making available to a third party, in any form, a product (sale, rental, loan for use, gift, alienation, etc.)
Modification/adaptation : activities that change the situation of the product with respect to the original, defined by the manufacturer, this
activity determines the need to re-brand the product, in compliance with current laws.
Manufacturer : anyone who releases a product for free circulation by indicating only his name on the documents accompanying it.
Directive : document issued by the European central authority and which regulates the safety of a product category. It must be transposed
by every single State of the Union to have the force of law in that State.
Regulation : document issued by the central European authority which has the force of law throughout the territory of the European Union,
without the need for transposition by individual states.
Standard : document issued by a private institution and which has indicative value of a good way of operating, has legal value only if
supported by a specific government decree.
Harmonized standard : document issued by a private organisation, which is valid throughout the European territory and has the value of
law if subordinated to a Regulation. Compliance with a standard is always and only a "presumption" of compliance with the directive or
regulation to which it is harmonized.
Declaration of conformity : a document which must be issued and signed by the manufacturer and which must accompany each product
or batch of products.
CE label : indications that must be present on the product or on its packaging, which briefly indicates that the manufacturer has fulfilled
the safety obligations established by law.
CE certificate : document issued by a private body, certifying that a single sample has passed certain tests. The certificate can be imposed
by law or voluntary, but it never replaces the CE marking, as it makes no reference to mass production, it can therefore be supplementary,
never a substitute for the CE marking.
Machine : set of mechanical and non-mechanical elements of which at least one is mobile thanks to non-human or animal force, even if
without an applied energy source, but which is intended to be coupled with an energy source. The set of several machines, which then
become "almost machines", in turn becomes a machine. Lifting systems, even if manual, are also included in the machinery directive.
"Machines" are also defined as systems or systems in which there are machines, such as pumps or operational electric motors, or in any
case components that fall within the scope of the Machinery Directive.

BIKEE BIKE LIGHTEST MOTOR REV12
IT
6
1.5 Declaration of Conformity
The machine is accompanied by the declaration of conformity drawn up in compliance with the laws in force in the European territory.
Before using the machine in any form, check that the declaration of conformity is present.
If the machine is sold to third parties, all documentation must be delivered together with it.
Name Legal Representative
Matteo
Surname Legal Representative
Spaggiari
Company name
Bikee Bike Srl
Company headquarters
Legal: Via Zeni, 8 –38068 –Rovereto (TN)
Operational: Via Maestri del Lavoro 7/A, 46100 Mantua (MN)
VAT number
02334050222
Tel. Office
[phone]
E-mail
[email protected]
Website
www.lightest.bike
The undersigned Matteo Spaggiari
As legal representative of the Bikee Bike Srl company
with registered office: Via Zeni, 8 –38068 –Rovereto (TN)
VAT number: 02334050222
He declares
that the person responsible for managing the technical file is Eng. Matteo Spaggiari
furthermore declares
that the product: Ebike conversion kit consisting of gearmotor, battery and electronic drive
Model and code: LIGHTEST
Year of modification and new marking: 2023
Serial number: IDxxxxxxx ( xxxxxx number from 0 to 999999)
It was built respecting the following directives and standards:
1. Directive 2006/42 EC known as the Machinery Directive
2. Directive 2014/35/EU known as the “Low Voltage Directive”
3. Directive 2014/30/EU known as the "Electromagnetic Compatibility Directive"
4. Directive 2011/65/EC known as “ RoHS ”
5. Directive 2012/19/EU known as “WEEE”
6. Directive 2001/95/EC note “General product safety”
7. UNI EN 15194:2012 standard - Bicycles - Pedal-assisted electric bicycles - EPAC bicycles (applicable only for 250W versions)
And it is therefore compliant with current directives and regulations.
This declaration of conformity is issued under the sole responsibility of the manufacturer.
Date: 04/10/2023
Signature: ______________________________
The guarantee regulations, listed in full in the purchase contract, are valid only if the ebike kit is used in the conditions of intended use.
With the exception of the ordinary and extraordinary maintenance operations described in the MAINTENANCE section and carried out
with the procedures indicated, any repair or modification made to the product by the user or by unauthorized companies will void the
guarantee.
The guarantee does not extend to damages caused by inexperience or negligence in the use of the product, or by bad or omitted
maintenance.

BIKEE BIKE LIGHTEST MOTOR REV12
IT
7
The products we sell are covered by warranty regarding the following conditions:
1. The warranty is valid for a period of twenty-four (24) months on the product and 500 cycles on the battery.
2. The manufacturer undertakes to replace malfunctioning or incorrectly manufactured parts at its own discretion, only after careful
inspection and confirmation of poor construction.
3. The transport and/or shipping costs in the event of incorrect use of the guarantee are always charged to the buyer. Shipping costs
are charged to the manufacturer for the first 6 months of the product, after which they will be charged to the customer.
4. During the warranty period, the replaced products become the property of the manufacturer.
5. Only the original purchaser who has complied with the normal maintenance instructions contained in the manual can benefit
from this guarantee. Our warranty liability expires when: the original owner relinquishes ownership of the product, or
modifications have been made to the product.
6. The warranty does not cover damages resulting from excessive strain such as use of the product after a fault has been identified,
extreme off-road use, violent impacts or falls, the use of unsuitable operating methods as well as failure to observe of the use and
maintenance instructions.
7. The manufacturer assumes no responsibility for any difficulties that may arise in the resale or use abroad due to the provisions in
force in the country where the product was sold.
8. The defective product or part of it must be delivered to the manufacturer or to an authorized service center for replacement;
otherwise the replaced part will be charged to the buyer.
9. The guarantee is canceled if the product is opened (removal of the seal).
10. Only original parts and components are used.
11. The battery is kept above zero charge.
If it is deemed necessary to use the guarantee, please indicate the following data:
1. Engine ID (visible on the bottom fin of the engine).
2. Purchase date (presentation of the purchase document).
3. Detailed description of the problem.
Failure to comply with the methods of intervention and use of the product described in this documentation will invalidate the
terms of guarantee.

BIKEE BIKE LIGHTEST MOTOR REV12
IT
8
1.6 Warnings
If part of the documentation is even partially missing or illegible, consult the technical assistance before carrying out any further operation.
The personnel responsible for the installation, use and maintenance of the ebike kit must read the use and maintenance manual, paying
particular attention to the general safety regulations and the methods of execution contained in the sections relating to the operations
under their responsibility.
This chapter describes the general safety rules to be observed during any operation performed with the kit. The intervention procedures,
described in the following chapters, must be carried out respecting both the indicated execution methods and the general safety
regulations in this chapter.
Different countries may have different safety regulations. It is therefore specified that in all cases in which the rules of the manuals are in
conflict or reductive compared to the rules of the country in which the ebike kit is used, the rules of the country will still have priority over
those of the manuals.
The manufacturing company cannot be held responsible in any case for accidents or damages resulting from the use of the
product by personnel who are not adequately trained and delegated or who have made inappropriate use of it, as well as from
even partial failure to comply with the safety and security regulations. intervention procedures described in the manuals.
The lightest kit is intended for installation on bicycles and has external moving gears that mesh with the transmission chain,
typical of bicycles. Some of these exposed gears are driven by the motor and this inherently carries the risk of crushing,
stacking. It is absolutely forbidden to drive the vehicle with loose trousers or long skirts that could get caught in the gears , to
avoid this danger.
2 Security
2.1 Safe use
Since it would be impossible to describe all the operations that must not or cannot be performed, it is believed that all
operations (other than normal) that are not explicitly described in the documentation are to be considered infeasible.
During the use of the ebike kit, after having installed it on a bicycle that supports it, incorrect functioning situations may arise that are not
foreseen in the manuals. These anomalous situations can be caused by environmental factors or by fortuitous failures unforeseeable by
the manufacturer.
In the event of any unforeseen anomaly after having powered up the kit, it is necessary to:
1. Turn it off
2. Check for any errors using the “LIGHTEST ebike kit Control Pad” app.
3. Contact technical assistance immediately and communicate any errors found.
In case an unexpected anomaly occurs after connecting the kit to the battery charging system:
1. Disconnect the electrical network of the place to which it is connected.
2. Pull the charger plug out of the socket.
3. Contact Technical Support immediately.
If you think you need to carry out an operation or intervention not foreseen or by following a procedure other than those indicated in the
documentation, before proceeding, consult the manufacturer to verify its feasibility (the company data are given in the CONFIRMATION
DECLARATION section ) .
The manual must be kept by the user who has been assigned the task of installing, using and maintaining the kit. In the event of
deterioration or loss, the Customer may request a certified copy from the manufacturer, or it may be downloaded from the website
www.lightest.bike . We suggest that you keep a backup copy in a place where it cannot be damaged or lost.
To prevent dangerous situations, all users of the kit in question must carefully read the use and maintenance manuals, making
sure they understand the methods of use and intervention before starting to use it.
2.2 Protections and Pictograms
The engine pinion (engine and its parts) are protected by a cover, which requires specific equipment to be circumvented. This guard must
never be removed except for specific maintenance operations. At the end of the work carried out it must be reassembled correctly and its
stability must be checked.
Before, during and after use, the following pictograms must be observed.

BIKEE BIKE LIGHTEST MOTOR REV12
IT
9
Danger of crushing and
entanglement with moving
parts
Electrocution hazard,
disconnect power before
carrying out any maintenance
work
Prohibition to remove guards
Obligation to read the use and
maintenance manual
Warning signs that fulfill a safety function must not be removed, covered or damaged.
3 Description
3.1 Intended use
mid -drive technology , which places the engine in the bottom bracket of the bike, between
the pedals. New patented technology reduces engine size while increasing drive torque.
The engine transfers motion through the bike chain, thus being able to exploit all the gears
of the rear wheel by combining them with two front chainrings, a small one for climbs and
one for speed. These two characteristics transform each bike into an electric bike capable
of easily tackling climbs of up to 58% inclination.
Bikee Bike LIGHTEST is available in four power versions: 250W suitable for European
regulations, 500W for Switzerland and Canada, 749W and 1000W for the American market.
The product described in the manual is a kit for converting ordinary bicycles into powerful
electric bicycles in minutes.
It is forbidden to modify the control system of the product. Bikee Bike srl does not assume responsibility deriving from
inappropriate and unauthorized use of the product following tampering and/or negligence by a user.

BIKEE BIKE LIGHTEST MOTOR REV12
IT
10
3.2 Technical data
Drive unit dimensions
Width: 100mm
Length: 148mm
Height: 105mm
Power
250W
500W
750W
1000W
Drive unit weight:
1.75kg
Degree of protection
IP55
Full speed:
250W: 25Km/h
500W: 25Km/h
750W: 42km/h
1000W: 42km/h
Minimum - maximum voltage threshold
28V - 65V
4 Intended use and non-intended use
4.1 Intended use and compatibility
LIGHTEST was designed and built solely and exclusively to be used as a kit to convert a normal bicycle into an electric one (pedal
assistance). The compatible bicycles are the kit are:
1. Mountain Biking
2. City Bikes
3. Fat Bikes
4. Racing bike
5. Light cargo bikes (maximum total weight of 150kg, including rider weight)
Measure the two dimensions of depth [ B ] and diameter [ A ] and consult the table below to identify
the correct configuration of plates and accessories.
These dimensions cannot be measured with the bottom bracket installed, to avoid unpleasant
inconveniences disassemble it and carry out the measurements by sharing them with the company
Check the correct adapter on the website www.ligtest.bike.
Contact the company for support.
First name
Typology
Depth
Diameter
Compatibility
Bush code
BSA (English)
With fillet
68/73mm
34.8mm
Standard
No need
Italian
With fillet
70mm
36mm
Incompatible
BB30
Without fillet
68mm
73mm
42mm
Bushing required
Adapter
Press Fit 30
Without fillet
68mm
46mm
OSBB extension
Without fillet
68mm
46mm (carbon)
42mm (metal)
BB86
Without fillet
86.5mm
41mm
BB90
Without fillet
90.5mm
37mm
BB92
Without fillet
92mm
41mm
BBright Direct
Without fillet
79mm
42mm
BBright - PressFit
Without fillet
79mm
46mm
BB386EVO
Without fillet
86.5mm
46mm
PressFit GXP
With fillet
90mm
42mm
Fat
With fillet
100mm
34.8mm
Standard
No need
PressFit 41 ( Fat )
Without fillet
121mm
41mm
Bushing required
Adapter

BIKEE BIKE LIGHTEST MOTOR REV12
IT
11
4 .2 Unintended Use
No use other than those described in the "INTENDED USE" section (page 17) is intended.
It is also forbidden:
1. The use of the ebike kit for uses other than those envisaged.
2. Tamper with/modify the product.
3. Do not respect the power supply characteristics of the kit indicated in Technical data.
4. The replacement of parts and components of the machine with others not recognized by Bikee Bike srl
The re-use of any part of the kit after it has been put out of service relieves Bikee Bike srl from any liability deriving from its use.
Bike Bikee srl In no case can it be held responsible for accidents or damages resulting from unforeseen uses of the product.
4.3 Residual risks
Maintenance operations must be carried out following the instructions in this manual. Maintenance operations other than
those indicated in this manual release Bikee Bike srl from any liability.
Pictograms are applied to the kit components (see PROTECTIONS AND PICTOGRAMS ). They must be kept clean and restored whenever
they are removed or damaged.
In operations in areas with mobile mechanical parts it is necessary to provide for the use of personal protective
equipment (PPE) or even class I a gloves .
Access to the closed, protected or internal parts of the product must be carried out only for maintenance operations, only by
qualified personnel who have previously read the manual.
1. Do not introduce hands or objects held by hands where there are moving parts.
2. Do not wet the electrical connections with water or other liquids.
3. Make sure that the area in which maintenance operations are carried out has at least 200lux lighting.
4. It is necessary to carry out the maintenance described in the manual.
5. The MAINTENANCE section indicates the operations in which it is not necessary to disconnect the system from recharging
or disconnect the battery.
6. The removable casings have indications on the casing itself.
7. If you work on the transmission components, make sure that the kit is switched off, in order to avoid accidental operation
of the torque sensor lever which would start the engine.
8. If you work on electrical parts, make sure they are not live

BIKEE BIKE LIGHTEST MOTOR REV12
IT
12
4 .4 Operations involving risks for the operator
During commissioning operations, follow the general accident prevention regulations.
Already in the design phase, solutions were adopted aimed at making the use of the product safe in all phases of use: transport, activity
and maintenance. Nonetheless, not all possible risks for users and the environment have been eliminated, both for technological reasons
(device reliability) and management reasons (excessive difficulties in elimination), consequently the residual risks present are reported,
e.g.: shearing , electrocution, entanglement , crushing etc....
Never move the bike or perform maintenance operations with the kit switched on.
The lightest kit contains a lithium ion battery. Never move the bike or carry out interventions with the kit switched on
You should also pay attention to the following points relating to the battery:
1. Do not short circuit the positive and negative poles of the battery.
2. Do not disassemble or scratch the battery.
3. Do not expose the battery to high temperatures, near open flames or corrosive agents such as alkaline acids or frozen water.
4. If stored for a long time, keep the battery in a cool, dry place and charge the battery for two hours every 3 months of non-use.
5. Never store the battery completely discharged, charge it to 40/60% if a period of inactivity is foreseen.
6. Only use the original charger.
7. Charge the battery away from flammable objects or liquids.
4.5 Product Integrity
Upon receipt, check the integrity of the ebike kit and its parts. If you find any damage, lack, deformation or traces of shocks due to
transport, notify the company Bikee Bike srl before proceeding with the subsequent operations.
In particular, check the integrity of:
1. packing
2. Electric power cables
3. Engine shell
4. ON/OFF switch located on the battery
5. Battery shell
6. Signal connectors, power phases
Check that the packaging is not subject to external agents which could damage it or have damaged it.
4.6 Manual handling
The weight of the kit is shown on the plate glued to it and in this manual.
The kit and its assembled components can be moved manually. The shape and size of the components allow them to be gripped
comfortably and quietly in various ways.
Pay particular attention to the position of the back during a handling phase (see figure below)
Incorrect red position
Correct green position
Indicative values for maximum weight (in kg), frequent or occasional maintenance.
Men
Women
Age
Occasional
frequent
Occasional
frequent
16 - 18
19
14
12
9
18 - 20
23
17
14
10
20 - 35
25
19
15
11
35 - 50
21
16
13
10

BIKEE BIKE LIGHTEST MOTOR REV12
IT
13
Over 50
16
12
10
7
Pregnant women: First 6 months of pregnancy
10
5
Pregnant women: From the 7th month
0
0
4.7 Environmental and supported conditions
Temperature
1. Operating: -15°C to 40°C.
2. Non-operating: -15°C to 50°C.
3. During storage and before use: -15°C to 40°C.
Relative humidity (non-condensing)
1. Operating: 30% to 95% ±5 %.
2. Non-operating: 30% to 95% ±5 %.
3. During storage and before use: 30% to 80% ±5%.
4.8 Recharging the battery
The flat battery is signaled by the green LEDs on the battery turning off. It is also possible to check the battery charge level from the
smartphone app and from the LED indicators installed in it.
The lighting system (natural and/or artificial) of the kit charging area must ensure the following minimum lighting values: 200 lux.
1. The battery recharging area must meet the following requirements:
2. The connection with the electrical power supply line must be arranged in such a way as not to create interference with the
maneuvering spaces of the users who use the environment in which it is connected.
3. The chosen position must allow easy connection of the plug to the power line.
4. The connection cables must not rest on the floor.
5. The position must be chosen so that it cannot be hit by jets of steam, water or other liquids.
6. Make sure the connector and plug are not wet.
To recharge the battery it is necessary to follow the instructions below:
1. Open the rubber cover that contains the connector, located on the bottom of the battery
2. Connect the battery charger supplied with the kit to a power outlet and then insert the charge connector into the dedicated input.
A red light indicates that charging is in progress.
3. When the red light turns green, it indicates that the charging process is finished.
The battery must never be left discharged: this causes irreparable damage to the battery and voids the battery warranty. If
the battery is completely discharged, it must be recharged promptly.
If you want to store the battery for a long time, it is mandatory to check monthly that the charge is approximately 50%. If
the charge value drops below 40%, it is recommended to restore the charge up to approximately 60%.

BIKEE BIKE LIGHTEST MOTOR REV12
IT
14
5 . Installation
In operations in areas with mobile mechanical parts it is necessary to provide for the use of
personal protective equipment (PPE) or even class I a gloves .
CAN see the video of the installation of the kit at the link:
https://www.youtube.com/watch?v=iLcN42IK4Uc
Or alternatively scan the code on the side
Always and only use original components supplied by the manufacturer.
Other elements can damage the system and cause injury to the user.
It is absolutely forbidden to use cranksets not supplied by the manufacturer.
The safety free wheel is missing in the cranksets not supplied by the manufacturer, therefore using the motor without this
safety device causes serious injury to the user.
Bikee Bike does not recommend long journeys immediately after installation, even if the kit has been installed by expert
personnel. It is in fact very likely that adjustments will be necessary which would become complicated.
It is recommended to run in for at least 100km in the vicinity to guarantee the reliability of the installation.

BIKEE BIKE LIGHTEST MOTOR REV12
IT
15
5 .1 Contents of the package
The components available in the kit are listed below, for simplicity all the possible components are listed and the asterisk indicates the
accessories present only if expressly identified on the purchase order.
165mm square or ISIS cranks (pair) (screws included depending on version)
Chainring BCD104 with screws, with number of teeth depending on the order
Freewheel[3], Spider[5], 2 drilled spacers[4,5]
Pinion[14], Seeger 15mm[13], screw M8[12]. The number of teeth on the pinion varies according to the order.

BIKEE BIKE LIGHTEST MOTOR REV12
IT
16
Bushing for screw, plastic pinion, TSN standard, long and inframe levers, M6x0.75mm nut
Rear chain guide rod
Adapter bushings for pressfit bottom brackets. Sizes vary based on movement.
Cable covers
Front chain guide, sprocket cover
Wheel Sensors, various models depending on the chassis and engine versions. Spoke magnet

BIKEE BIKE LIGHTEST MOTOR REV12
IT
17
Motor connection cables Display. Standard type on the left and SuperHero (with brake attachment, accelerator) on the right.
Accelerators Half, lever, full
Sensor changed
Brake sensors (pair) with magnets and stickers

BIKEE BIKE LIGHTEST MOTOR REV12
IT
18
5 .2 Screw detail
Below are the screws available in the kit, for simplicity all the possible screws are listed and the asterisk indicates the screws that may be
missing or reduced in quantity as they are linked to accessories that are not always included.
[A] 2x Nut M6x1mm
[B] 8x M4 Self-locking Nut
[C] 2x Self-locking nut M3
[D] 1x Nut M6x0.75mm
[E] 9x 4x12mm Countersunk
Screw
[F] 5x 4x16mm Countersunk
Screw
[G] 6x 4x20mm Countersunk
Screw
[H] 4x Screw 3x20mm
Countersunk
[I] 2 or 3 depending on the version Countersunk screw 6x90mm
[J] 2 or 3 depending on the version Screw 6x120mm
Countersunk
[K] 2x Screw 4x16mm
[L] Adjustment Spacer Washer
25x35mm
[M] 2x Washers M4
[N] 2x Washers M6
[O] 4x 6x20mm Countersunk
Screw
[P] 3x 10mm milled spacer
[P] 3x 5mm Spacer
[P] 3x 10mm Spacer

BIKEE BIKE LIGHTEST MOTOR REV12
IT
19
5 .3 Standard Mount (SHORT and MEDIUM)
5.4 Long and In-Frame

BIKEE BIKE LIGHTEST MOTOR REV12
IT
20
5.5 Hybrids
