WINFIELD SP.Z.O.O. Maxtron MT-1 User manual

By WINFIELD SP.Z.O.O.
User’s Manual
For models
IMPORTANT !!!
READ CAREFULLY BEFORE USE

By Winfield Sp. z o.o. Page 1 of 16
TABLE OF CONTENTS
1
Foreword
P. 2
2
Duty of Care
P. 3
3
Name of parts
P. 4
4
Getting Started
P. 5
4.1
Take out the EPAC
4.2
Assembly Instruction
4.2.1
Attached the handle angle
4.2.2.1
Adjust the rim brake
4.2.3
Adjust the brake shoe
P. 6
4.2.4
The braking way
4.2.5
Adjust the seat height
4.2.6
Determination of seat height
4.2.7
Install the pedal
P. 7
4.2.8
Adjust chain tension
4.2.9
Quick release on front wheel
5
Lubrication
6
Operation of your EPAC
6.1
Install the battery onto the EPAC
P. 8
6.2
Lock the battery tightly
6.3
Switch on the battery by the ON-OFF key
6.4
Check remaining capacity in battery
6.5
The Handle bar display
6.5.1
LCD Display
P. 9
6.5.1.1
Trip distance
6.5.1.2
Speed indication
6.5.1.3
Front and back lights
6.5.1.4
Power assisting indication
6.5.1.5
Battery status indication
6.5.1.6
Auto power Off
6.5.1.7
Walk assist mode
P. 10
6.5.1.8
Error codes
6.5.2
LED Display
6.5.2.1
Walk assist mode
6.6
Pedal to get the EPAC started
6.7
Power assisting cut off or slow down
P. 11
7
Battery
7.1
Battery specification
7.2
Charging the battery
7.3
Riding range per charge
7.4
Remove the battery
8
The Charger
P. 12
9
Ride with Speed Gear
9.1
For model MT series
9.2
For model MC-3 series
9.3
For model MC-4 series
P. 13
10
Adjustments and Maintenance
11
Faults and Trouble-shooting
P. 14
12
List of parts should be checked regularly
P. 15
13
The Carrier
P. 16

By Winfield Sp. z o.o. Page 2 of 16
1. FOREWORD
The following operation manual is a guide to assist you. This manual is not a complete
document on all aspects for the maintenance and repair of your EPAC. The EPAC you
have purchased is not a complex object. However, it is recommended that you consult
an EPAC repair specialist if you have concerns as to your ability to assemble, repair, or
maintain this product.
It is important for you to understand the EPAC. By reading this manual completely before
the first ride, one will get better performance and enjoyment from this product. It's
helpful to extend the life of the EPAC.
This operational manual should remain an integral part of the product. Changes or any
copy actions in pictures, specifications and descriptions are strictly prohibited. When you
transfer the EPAC to others, please enclose with this manual as it contains the important
safety guidance and operation instructions
This booklet describes assembly and safe operation of your EPAC. Pictures are for
reference only and may show the similar component from another model.
Make sure the battery is fully re-charged every 3 months if it
is not in use
Store the battery in a dry and warm place. Ideal storage
temperature is 15oC - 30oC
Ensure the total payload including the luggage should not
exceed 130kg
This assembly and operation manual shall remain an integral
part of the EPAC. Anyone riding the EPAC shall carefully
read the safety guidance and operation instructions first.
The changes in the pictures, data, descriptions and
specifications under this manual may not be notified
separately with continuous improvement of our corporate
products.
Beware of National Legal requirements when the EPAC is
ridden on public. Especially safety requirement of road
condition and lighting. Never allow the reflectors to be
hidden by unnecessary objects.
DO NOT open the battery by non-authorized person. It might
cause danger to user and will void the battery warranty.
Always shut down/ remove the battery before maintenance.

By Winfield Sp. z o.o. Page 3 of 16
2. DUTY OF CARE
The safety of the bicycle can only be assured if all the necessary maintenance are taken.
The user has the duty of care and responsibility for scheduling these measures and
checking that they are implemented.
1. Your EPAC is designed for regular road for a single person. Using your EPAC for
extreme maneuvers, such as extreme off-road use, jumping, or carrying excessive
load will damage the EPAC and could cause serious injury.
2. Wears proper personal protective equipment, such as helmet
3. This EPAC is designed for total weight below 130kg
4. Never carry a passenger on the EPAC
5. Employs specialist staff only for maintenance and repair of the EPAC. Please read
the manual carefully. Do not use the EPAC before familiar with its performance. Do
not lend it to the one who does not know about its operation.
6. In the bad weather like rain or snow, the braking distance should be increased.
When the EPAC runs at the speed of 20km /h, the wet road condition might extend
the braking distance up to 15m. Please check and maintain the brake frequently to
ensure safety riding.
7. Check the tightness of the chain. The tightness should be around 15mm.
8. For the safety of you and other people, switch off the power when it is not in used
9. Check the air tension of the tire frequently. Low air pressure might cause extra
resistance which affects the riding range.
10. Onlyauthorized person is allowed toopen the battery. Otherwise, itmightcause danger
and the warranty will be voided.
11. It is forbidden to force the EPAC overloaded.
12. Cut off the power if there is any hesitation on the electrical parts.
13. Please pay attention to national legal requirements when the bicycle is to be ridden
on public roads (e.g. lighting and reflectors)
14. NO Tempering is allowed –Change of any parts which is non-original designed is
forbidden. It is risked having unexpected accident. Warranty will be voided for
any tempering of the EPAC or electrical system.
BATTERY DISPOSAL
NEVER throw batteries away in the trash directly. Take the
exhausted battery to a federally or state-approved battery recycle
center. Call your waste collection service to find out if they offer
disposal of batteries.

By Winfield Sp. z o.o. Page 4 of 16
3. Name of EPAC Parts
1. Handle bar and stem
2. Frame
3. Front light
4. Mudguard
5. Front wheel
6. Front fork
7. Battery
8. Pedal
9. Display
10. Gear shifter
11. Saddle/ seat
12. Seat post
13. Seat quick release
14. Carrier
15. Rear light
16. Motor
MAXTRON MC-3 series
MAXTRON MC-4 series
11
12
13
14
15
16
9 10
MAXTRON MT series
1
2
3
4
5
6
7
8
7
16

By Winfield Sp. z o.o. Page 5 of 16
4. Getting Started
4.1
Take out the EPAC
Unpack your EPAC carefully and save all packing material. Be sure to locate your charger, pedals,
keys and any small parts like nuts or screws inside the shipping carton. It might happen that some
small parts are fall at the very bottom of the carton box during transportation.
4.2
Assembly Instruction
The EPAC is fully assembled and inspected at the factory and then partially disassembled for
shipping. Only the front wheel, pedal, saddle and handle bar need to be assembled again at user’s
side.
4.2.1 Adjust the handlebar angle
Your handlebars have two main parts –the cross bar
itself and the stem. MC series stem can be adjusted to
tip the handlebar forward or back.
Handle stems are basically installed before delivery.
If your handle bar set has been removed for shipping
carton, then insert the stem until the minimum insertion mark into the frame. Adjust the grips
in the right place and the angle of the handle bar is comfortable.
Be sure your handlebars are centered and tightened before riding
Make sure the forks and the handlebars are facing forward and straight. You may stand in
front of the handlebar, vise the front wheel by your legs and hold the handlebar, adjust the
handlebar and the body of the bicycle to form an angle of 90 degree, see the picture.
Tighten the screws to hold the bar in place, ensuring all brake cables are clear. The
recommended torque is 200-300kgfcm
4.2.2.1 Adjust the rim brake
Always check that both your front and rear brakes are properly
adjusted before riding your EPAC.
Squeeze the brake arm together and slip the cable into the
trough. You may need to adjust the cable length by loosening
the nut and sliding the cable through to the proper position.
Tighten the nut back to hold the proper position.
4.2.2.2 Disc brake version (MT-11/ MT-12 series)
Please make sure the disc brake system is inspected and maintained by professional person
every 3 months.
Beware of sharp metal part in the carton. It might cause puncture wounds
We recommend that two peoples work together to assemble the EPAC
Insertion mark

By Winfield Sp. z o.o. Page 6 of 16
4.2.3.1 Adjust the brake shoe
Adjust the brake shoe on either side by using an Allen wrench to
ensure the contact on the metal wheel rim, not on the tire. Be sure
they are straight and the distance between rim and the two brake
pads is 1-1.5mm.
The pads will be close when adjusted properly.
4.2.3.2 Disc brake version (MT-11/ MT-12 series)
Please make sure the disc brake system is inspected and
maintained by professional personnel every 3 months
4.2.4 The braking way
The EPAC is set that the left brake lever operates the rear brake
The right brake lever operates the front brake
The EPAC might keep sliding if the brake is not pressed strong enough.
Make sure the braking system is maintained properly
4.2.5 Adjust the Seat Height
The seat height can be adjusted by a quick release lever.
Pull the lever to release, then insert the seat post to at least the
minimum insertion line marked fully go into the frame, or a
comfortable height. Press the lever back until it touches the clamp
ring to hold the seat post position.
If it is too difficult to insert the seat post, extend the seat post gap
space by loosing the adjusting nut and lever together. Lock the seat
post tightly and ensure it is not movable when insertion is
succeeded.
Be aware that when the seat post is not tightened, it might case
danger to the rider. Recommended tightening force is > 20kgfcm
4.2.6 Determination of seat Height
From an ergonomic point of view, the seat height
should be set so that the heel touches the lowest point
of the pedal when the leg is outstretched.
Make sure the seat post Insertion mark is completely
inserted, or lower, into the frame to ensure safe riding
Adjusting nut
Lever
Seat post
Insertion mark

By Winfield Sp. z o.o. Page 7 of 16
4.2.7 Install the pedals
1. The right pedal attaches to the chain side crank arm with
(clockwise) thread
2. The left pedal attaches to the other arm and has a left-hand
(counter clockwise) thread.
Check your pedals before each ride to ensure that they are tight. If
you ride your EPAC with loose pedals, you may strip the threads
that hold the pedal to the crank. The tightening force at both sides
are 400kgfcm
4.2.8 Adjust Chain Tension
Chain tension of MT series
Chain tensioner is built in at the rear sprocket. It is well adjusted before ex-factory.
Chain tension of MC series
There should be approximately 0.5 inch of movement in the chain
up and down at a point half way between the front and rear
sprockets. If the chain is too long after long time use, it can be
adjusted by moving the rear wheel a little backward at the frame
dropout. Always remember to tighten the rear wheel screw.
Recommended torque is 300-400kgfcm
4.2.9 Quick release on front wheel
MT series has a quick release mechanism on front wheel. If rider need to remove the
wheel and re-attached. Please make sure the lever is pressed tightly when closing to the
locked position. It should touch the fork ends. Recommended tightening force is 15kgfcm
5. Lubrication
Do not over lubricate. If oil/grease gets on the wheel rims or the brake shoes, it will weaken
the brake performance and lead to longer stopping distance. Injury to the rider or to others
can be occurred.
Pedal
Every 6 months
Put 4 drops of oil where catch pedal axle goes into the pedal
Chain
Every 6 months
Put 1 drop of oil on each roller of the chain
B.B.
Every 6 months
Contact a professional technician
Motor
Every 1 year
Contact a professional technician
6. Operation of Your EPAC
Your EPAC is driven by a motor installed in the hub of the front or rear wheel. The motor is
powered by a 36V battery, which is installed on the EPAC. The amount of motor power is
controlled by rider according to the power-assisted model selected

By Winfield Sp. z o.o. Page 8 of 16
To start the operation, riders should:
6.1 Install the battery onto the EPAC
Make sure the dis-charging ports on the battery and on the frame are aligned at their right
position.
MT series MC series
6.2 Lock the battery tightly
MT series MC series
Make sure the battery is tightly locked onto the frame. If the battery is loose from the
frame, it might cause accident to rider.
6.3 Switch on the battery by pressing the ON/OFF Key
Press the ON/OFF button once.
It is available on MC series only
6.4 Check remaining capacity in battery
Consumer may read the remaining battery capacity by pressing either of the below
buttons. The more the LED lights, the higher the battery capacity
For MT series For MC series
6.5 The Handle bar display
MT series is using LCD display, whereas MC series is using LED display. Both displays
are installed on the handle bar. Riders may adjust it to a comfortable monitoring angle.
Make sure the cables are well connected

By Winfield Sp. z o.o. Page 9 of 16
6.5.1 LCD display (MT series)
Press button for 2 seconds to get both the power and
control level on. Real-time Speed is defaulted to be showed
on the screen.
6.5.1.1 Trip distance
Press button to show these information in sequence:
1) Trip distance (TRIP, km)
2) Total Distance (ODO, km)
6.5.1.2 Speed Indication
Press and + buttons together for 2 seconds
can change the indicated information in sequence
of:
1) Real-time Speed (km/h)
2) Average Speed (AVG, km/h)
3) Maximum Speed (MAX, km/h)
6.5.1.3 Front and Back lights
Press “+“button for 2 seconds to turn on the back light of the display and the front
& rear light of the EPAC at the same time.
Press “+“button again for 2 seconds to turn off the backlight.
6.5.1.4 Power Assisting Indication
There are 10 power assisting bars on right hand side of
the display. Every 2 bars represent 1 assisting level.
Press + button to increase assisting power, or –
to reduce. The power range is from level 1 to level 5.
The more the number of bars, the higher the motor
power assist.
6.5.1.5 Battery Status Indication
The display shows the battery capacity in 5
levels. When the battery is in high voltage, the
word “FULL” at the top of 10 black bars at left
hand side of the display appears.
Letter “E” appears when battery level is low. Recharging
the battery is necessary
6.5.1.6 Auto Power Off
Press button for 2 seconds again can shut down the display.
When the EPAC is not in use for 10 minutes, the display will be shut down
automatically.

By Winfield Sp. z o.o. Page 10 of 16
6.5.1.7 Walk Assist Mode
Press -button continuously can activate the Walk
Assist mode. The EPAC goes at max. speed of 6km/h
without pedaling. Release the button will stop the
function. It can help to keep the EPAC moving during
a climbing condition.
Never ride on the EPAC with Walk Assist mode.
6.5.1.8 Error Codes
When the LCD display showing these
codes. They mean:
Error
Code
Definition
Actions to take
21
Current Error
Inspection if motor phrases short-circuits
22
Throttle Error
Inspect if throttle recover original state
23
Motor Error
Inspect if motor phrase is well-connected:
Inspect if cables between motor phase and controller
are well-connected.
24
Motor Hall Signal Error
inspect if motor phrase is well-connected
25
Brake Error
Inspect if brakes original state before display startup
30
Communication Error
Inspect if cables between display and controller are
well-connected
6.5.2 LED display (MC series)
There are 5-level power assisting. Press button for 2 seconds to get the power on.
Press + to increase motor assisting power, or –to
reduce. The power range is from level 1 to level 5 with
LED indication. The more the LED lighted, the higher the
motor power.
Press the button for 2 seconds to get the front and
rear light switched on.
Lights and power will be shut down when button is pressed for 2 seconds again.
6.5.2.1 Walk Assist Mode
Press -button continuously can activate the Walk Assist mode, which allow the EPAC
goes at max. speed of 6km/h without pedaling. Release the button will stop the function.
Never ride on the EPAC with Walk Assist mode.
6.6
Peddle to get the EPAC started
Electric-Assisting power is triggered when power on and pedal forward. The faster the
pedaling, the faster the EPAC.

By Winfield Sp. z o.o. Page 11 of 16
6.7
Power assisting cut off or slow down when:
- Pressing the brake lever.
- EPAC speed at assisting model reaches 25km/h
The higher the power assisting level is used, the easier the EPAC riding. Please
noted that it will cause more battery power consumption and shorten the power
assisting riding distance when high level of power assisting level is selected.
7. Battery
7.1 Battery Specification
7.2 Charging the Battery
Fully charge the battery before your first ride and re-charge after every operation
Connect the battery with charger before connecting to the wall outlet.
This is location of the charging plug
7.3 Riding range per charge
Under standard road conditions (concrete and cement road without resistance and
with temperature around 25oC, battery is fully charged), the riding range per charge
can be
With the lowest assisting mode (level 1), it can be run up to 100km
With the highest assisting mode (level 5), it can be run up to 45km
7.4 Remove the battery
There is a battery fixing lock on the battery (see below pictures). Open the lock
may take out the battery.
For MT series For MC series
Always to separate the battery from the EPAC for storage during winter.
Keep it in a warm and dry place.
MT series
MC series
Rated Voltage: 36V
Max. Charging voltage: 42V
Rated Capacity: 11.6ah
Cut off Voltage: 29V

By Winfield Sp. z o.o. Page 12 of 16
8. The Charger
Charger Specification
Input voltage: 100V-240V 50/60Hz, 90W
Output Voltage: 36V –2A
Normal charging time: 4-6 hours
Connections
1. Connect the charger to battery first
2. Then plug the power cord to AC power wall
outlet
3. The green LED lights means it is standby.
4. The red LED light during charging process.
5. When greed LED light is on again. The
battery is fully charged. Then unplug.
9. Ride with Speed Gear
Riders may adjust the gear shifter for a proper gear ratio according to road conditions, and
comfortable speed necessity. may adjust the gear shifter for a proper gear ratio according
to road conditions, and comfortable speed necessity. The derailleur should only be shifted
during pedaling. To keep the derailleur in adjustment. The derailleur / shifting and
pedaling are completely independent to the motor.
9.1 For models MT series
There is a SHIMANO ALTUS 8-speed rear derailleur installed
on the rear wheel.
Toggle the upper lever at the right ha nd side of the shifter,
the gear number going from 1 to 8. The higher the number,
the faster the EPAC per pedal, whereas lower number
provides comfortable riding feeling.
Toggle the lower lever to obtain opposite function.
9.2 For model MC-3 series
There is a SHIMANO NUXUS Inner-7 speed gear
installed on the rear wheel. Twist the shifter
clockwise or anti-clockwise to change the gear ratio
The higher the number, the faster the EPAC per pedal.
The battery charger temperature
may be a little high. Temperature
below 50 ℃is normal .
WARNING !!
➢ Do not connect the charger if any abnormal damage is observed.
➢ It is a must to charge the battery indoor and dry place, environment temperature
below 30oC.
➢ The charger is designed specifically for original EPAC battery. Connecting the
charger to any other battery might cause unexpected injury to persons and property.
➢ Consumers must follow the instruction contained on the label of the battery charger.
-
1
2

By Winfield Sp. z o.o. Page 13 of 16
9.3 For model MC-4 series
There is a SHIMANO NUXUS Inner-3 speed gear installed on the
rear wheel. Twist the shifter clockwise or anti-clockwise to change
the gear ratio.
The higher the number, the faster the EPAC per pedal.
10. Adjustments and Maintenance
- Do not use high pressure water streams to clean your EPAC, as water might seep
inside the motor or the wiring compartment and cause rusting of electric parts or short
circuits. Please use damp cloth with neutral detergent to clean the EPAC body. Do not
use alkali-based or acid based detergent such as rust cleaners as it may result in
damage and/or failure of the EPAC body.
- Avoid parking your EPAC outside when there is rain or snow. At the end of a trip where
there was rain or snow, bring the EPAC inside and use a clean, dry towel to eliminate
any wetness.
- The chain can throw excess oil onto the wheel rim. Wipe excess oil off the chain. Keep
all oil off the surfaces of the pedals where your feet rest.
- Using soap and hot water, wash all oil off the wheel rims, the brake shoes, the pedals,
and the tires. Rinse with clean water and dry completely before you ride the bicycle.
- Using a light machine oil (20W) and the following guidelines, lubricate the bicycle:

By Winfield Sp. z o.o. Page 14 of 16
11. Faults and Trouble-shooting
No
Faults
Causes
Troubleshooting
1
Battery gauge lights up but
bicycle does not operate
1)
Power cord is not properly plugged into
battery
1)
Properly plug in power cord to
battery
2)
Brake cut-off engaged or faulty
2)
Disengage brake cut-off or replace
3)
Speed sensor adjusted too low
3)
Adjust speed sensor
4)
Blown fuse
4)
Replace fuse
5)
Loose motor wire connector
5)
Check motor wire connector
6)
Loose connectors
6)
Check all connectors
7)
Broken wire
7)
Inspect all wires
8)
Throttle disengaged or faulty
8)
Engage throttle or replace
2
Bicycle operates but battery
gauge does not light up
1)
Loose connectors
1)
Check throttle connectors
2)
Damaged wires
2)
Inspect all wires
3)
Faulty battery gauge
3)
Replace battery gauge
3
EPAC has reduced speed
and/or range
1)
Speed sensor is not adjusted
1)
Adjust speed sensor
2)
Low batteries
2)
Charge batteries for recommended
time
3)
Faulty batteries
3)
Replace batteries
4)
Low tire pressure
4)
Inflate tires to recommended
pressure
5)
Brakes dragging against rim
5)
Adjust brakes and/or rim
4
Bicycle has intermittent
power
1)
Loose connectors
1)
Check all connectors
2)
Loose fuse
2)
Check fuse connector
3)
Damaged wires
3)
Inspect all wires
5
Charger light does not
operate
1)
Power outlet faulty
1)
Try another outlet
2)
Charger is not plugged to wall or
battery properly
2)
Check all plugs
3)
Charger light or charger is faulty
3)
Replace charger
6
Charger completes
charging in short time
abnormally
1)
Faulty charger
1)
Replace charger
2)
Faulty batteries
2)
Replace batteries
7
Chain jumping off freewheel
sprocket or chain ring
1)
Chain ring out of true
1)
Adjust if possible, or replace
2)
Chain ring loose
2)
Tighten mounting bolts
3)
Chain ring teeth bent or broken
3)
Repair or replace chain ring/set
4)
Rear or front derailleur side-to-side
travel out of adjustment
4)
Adjust derailleur travel
8
Gear shifter does not work
properly
1)
Derailleur cables sticking/ stretched/
damaged
1)
Lubricate/ tighten/ replace cables
2)
Front or rear derailleur not adjusted
properly
2)
Adjust derailleur
3)
Indexed shifting not adjusted
properly
3)
Adjust indexing
SAFETY WARNING!
Danger of wheel failure due to rim wear. Replace wheel immediately when any part of above
groove wears off.
After a tire change, refer to the tire markings for the permitted tire pressures and make sure
that they are observed. The tire pressure must not be exceeded the recommended level,
which is engraved on the tire.

By Winfield Sp. z o.o. Page 15 of 16
12. List of parts should be checked regularly
Before every ride, it is important to carry out the following safety checks:
1) Brakes
- Ensure front and rear brakes work properly
- Ensure brake shoe pads are not over worn and are correctly positioned in relation
to the rims.
- Ensure brake control cables are lubricated correctly adjusted and display no
obvious wear.
- Ensure brake levers are lubricated and tightly secured to the handlebar.
2) Wheels and Tires
- Ensure tires are inflated to within the recommended limit as displayed on the tire
sidewall.
- Ensure tires have thread and have no bulges or excessive wear.
- Ensure rims run true and have no obvious wobbles or kinks.
- Ensure all wheel spokes tight and not broken.
- Check that axle nuts are tight. If your bicycle is fitted with quick release axles,
make sure locking levers are correctly tension and in the closed position.
3) Steering
- Ensure handlebar and stem are correctly adjusted and tightened, and allow proper
steering.
- Ensure that the handlebars are set correctly in relation to the forks and the
direction of travel.
- Check that the headset locking mechanism is properly adjusted and tightened.
- If the bicycle is fitted with handlebar end extensions. Ensure they are properly
positioned and tightened
4) Frame and Fork
- Check that the frame and fork are not bent or broken.
- If either are bent or broken, they should be replaced.
5) Chain
- Ensure chain is oiled, clean and runs smoothly.
- Please go to the qualified technician for adjusting the correct chain tension
- Extra care is required in wet or dusty conditions.
6) Bearings
- Ensure all bearings are lubricated, run freely and display no excess movement,
grinding or ratting.
- Check headset, wheel bearing, pedal bearings and bottom bracket bearings.
-
7) Cranks and pedals
- Ensure pedals are securely tightened to the cranks.
- Ensure cranks are securely tightened to the axle and are not bent.
8) Derailleurs
- Check that front rear mechanisms are adjusted and function properly.
- Ensure control levers are securely attached
- Ensure derailleurs, shift levers and control cables are properly lubricated
9) Accessories
- Ensure that all reflectors are properly fitted and not obscured
- Ensure all other fittings on the EPAC are properly and securely fastened, and
functioning.
- Ensure the rider is wearing a helmet

By Winfield Sp. z o.o. Page 16 of 16
13. The rear carrier
The carrier is installed by Winfield. But please noted that the total maximum loading of is
15kg. Please make sur the permissible load of the EPAC should not be exceeded.
It is not allowed to carrier a second passenger, nor attach a child seat.
1) Maximum load capacity of the carrier is 15kg. Do not put weight on carrier exceed
the limit.
2) Always pack and tie the luggage safely on the carrier
3) Do not carry a second passenger nor attach a child seat, nor a trailer.
4) Do not modify nor tamper the carrier
5) Fasteners should be secured and checked frequently.
6) The EPAC may behave differently (particularly with regard to steering and
braking) when the luggage carrier is loaded.
7) Make sure the rear reflector/ light can be seen, even luggage is loaded on the
carrier.
WARNING!
As with all mechanical components, EPAC is subjected to wear and high stresses.
Different materials and components may react to wear or stress fatigue in different
ways. if the design life of a component has been exceeded, it my suddenly fail,
possibly causing injuries to the rider. Any form of crack, scratches or change of
coloring in highly stressed areas are indicate that the life of the component has been
reached and it should be replaced.
CAUTION !
If any safety-critical components need to be changed. Please go to authorized
retailer for changing genuine replacement.
