Binary B-230-HDSPLTR-1x4 User manual

Source | Mute | 2ch
(HDMI Out Audio)
INSTALLATION
MANUAL
HDMI 1x4 Splitter
B-230-HDSPLTR-1x4
HDMI OUT 3
HDMI OUT 2 HDMI IN
HDMI OUT 4
HDMI OUT 1
B-230-HDSPLTR-1x4
HDMI OUT 4 HDMI OUT 3 HDMI OUT 2 HDMI OUT 1
HDMI IN

2

IMPORTANT SAFETY INSTRUCTIONS
1. Read and follow all instructions and warnings in this manual. Keep for future
reference.
2. Do not install near any heat sources such as radiators, heat registers, stoves
or other apparatus (including ampliers).
3. Do not install the unit near water or where moisture is present.
4. Clean with a dry cloth.
5. Unplug this apparatus during lightning storms or when unused for long
periods of time.
6. Protect the power cord from being walked on or pinched particularly at plug,
convenience receptacles, and the point where it exits from the apparatus.
7. Refer all servicing to qualied service personnel. Servicing is required when
the apparatus has been damaged in any way, such as when the power-supply
cord or plug is damaged, liquid has been spilled or objects have fallen into
the apparatus, the apparatus has been exposed to rain or moisture, does not
operate normally, or has been dropped.
8. To completely disconnect this equipment from the AC mains, disconnect the
power supply cord plug from the AC receptacle.
CAUTION: To reduce the risk of electrical shock, inspect the premises carefully. Do
not use the unit if proper equipment grounding cannot be veried.
3
The lightning flash with arrowhead symbol,
within an equilateral triangle, is intended
to alert the user to the presence of uninsulated
dangerous voltage within the product’s enclosure
that may be of sufficient magnitude to constitute a
risk of electric shock to persons.
The exclamation point within an equilateral
triangle is intended to alert the user
to the presence of important operating and
maintenance (servicing) instructions in the literature
accompanying the appliance.
CAUTION
CAUTION: TOREDUCE THE RIS K OF
ELECTRICAL SHOCK.
DONOT REMOVE COVER. NO US ER
SERVICEABLE PARTS INSI DE.
REFER S ERVICI NG TO QUALI FI ED
SERVICE PERS ONNEL.

CONTENTS
1. Product Overview......................................................................................................5
2. Contents........................................................................................................................5
3. Features.........................................................................................................................5
4. Device Layout..............................................................................................................6
5. Installation and Connections ................................................................................7
6. EDID Conguration ..................................................................................................8
7. Specications...............................................................................................................9
8. Contacting Tech Support ........................................................................................10
9. Warranty .......................................................................................................................10
4

1. PRODUCT OVERVIEW
Welcome to Binary™. This product is engineered to provide years of exceptional
reliability. We appreciate your business, and we stand committed to providing our
customers with the highest degree of quality and service in the industry.
This HDMI Splitter supports HDMI 1.4, 10.2 Gbps Bandwidth, WUXGA, and 1080P
Deep Color.
2. CONTENTS
• (1) HDMI Splitter, 1X4
• (1) 5V DC power adapter
• (1) Installation Manual
3. FEATURES
• Auto EDID congured
• Multiple Cascade - When needed this unit can cascade (daisy chain) to allow
installation exibility
• 10.2 Gbps Bandwidth - Supports 7.1 channel surround sound, DTS-HD Master
Audio and TrueHD high bit rate audio, plus Deep Color Full HD 1080p color
• Supports HDMI or DVI inputs
• HDCP 1.4 compliant
5

4. DEVICE LAYOUT
EDID
UPDATE
ON
OFF POWER IN OUT 1 OUT 2 OUT 3 OUT 4
1 2 3 4
On
O
HDMI OUT 4HDMI OUT 3HDMI OUT 2HDMI OUT 1 HDMI IN
+5 VDC
A. HDMI Output 1- 4
Connect HDMI cables to local display
B. HDMI Input
Connect HDMI cable from source
C. Power Supply (5V DC)
Connect the included 5V power supply to this port
EDID
UPDATE
ON
OFF POWER IN OUT 1 OUT 2 OUT 3 OUT 4
1 2 3 4
On
O
HDMI OUT 4HDMI OUT 3HDMI OUT 2HDMI OUT 1 HDMI IN
+5 VDC
D. Power On/Off Switch
Lights up blue when power is on and lights up red when in stand-by.
E. Update (mini USB port)
To connect mini USB cable when updating rmware
F. Power LED
Indicates that device is receiving power
G. Input LED
Indicates signal transfer over the input port
H. LEDs for Outputs 1 through 4
Indicates signal transfer over output ports
I. Dip Switches
AUTO EDID selects the lowest common EDID between the four output ports
to send to the source
Output EDID reports the EDID from output 1 to the source
B C
A
D E G
F I
H
6

5. INSTALLATION AND CONNECTIONS
HDMI OUT 4HDMI OUT 3HDMI OUT 2HDMI OUT 1 HDMI IN
+12 VDC
1. Place the unit where it will be installed.
2. Connect the HDMI cable from the source to the HDMI IN of the splitter.
3. Connect the HDMI cable from the HDMI OUT of the splitter to the Display/
Receiver to the devices.
4. Connect the power to the B-230-HDSPLTR-1x4.
5. Turn on the source and devices.
7
HDMI
Source
B-230-HDSPLTR-1x4
TVTV TV TV
AC
Power

6. EDID CONFIGURATION
Resolution DIP Switch Position
1 2 3 4
Auto Down Down Down Down
From Output #1 Up Up Up Up
1080i@60Hz 24-Bit 7.1 ch Up Up Up Down
1080i@60Hz 24-Bit 2ch Down Up Down Up
1080p@60Hz 24-Bit 7.1 ch Down Down Up Down
1080p@60hz 24bit 2ch Up Up Up Down
1080p@60Hz 24-Bit 3D 2ch Down Up Up Up
1080p@60Hz 24-Bit 3D 7.1 ch Up Down Down Down
8

7. SPECIFICATIONS
Technical
HDMI Compliance HDMI 1.4
HDCP Compliance HDCP 1.4
Video Bandwidth 10.2 Gbps
Input TMDS Signal 1.2V (peak-to-peak)
Input DDC Signal 5V (peak-to-peak, TTL)
ESD Protection (1) Human body model: ±15kV (air-gap discharge) &
±8kV (contact discharge) (2) Core chipset — ±8kV
Connections
HDMI 5x HDMI Type A
(19-pin female)
Controls
DIP switch 1 See EDID CONFIGURATION on page 8
Mechanical
Housing Metal enclosure
Dimensions (L x W x H mm) 147.64 x 71.44 x 25.40
Weight 1.1 lbs.
Power Supply 5V DC, 1A
Power Consumption 6W (max)
Operation Temperature 32–104°F
Storage Temperature -4–140°F
Relative Humidity 20–90% RH (no condensation)
Certications and
Compliance
Product: CE, FCC, RoHS
Power Supply: CE, FCC, RoHS, UL
9

8. CONTACTING TECH SUPPORT
866.838.5052
For SnapAV customers, snapav.com
For Aisle 8 customers, onaisle8.com
9. WARRANTY
2 Year Limited Warranty
This Binary product has a 2-Year limited warranty. This warranty includes parts and
labor repairs on all components found to be defective in material or workmanship
under normal conditions of use. This warranty shall not apply to products that
have been abused, modied or disassembled. Products to be repaired under this
warranty must be returned to SnapAV or a designated service center with prior
notication and an assigned return authorization number (RA).
10

11

Rev: 170421-1015
© 2017 Binary
