Binatone MBP36 User manual

MBP36 - Quick Start Guide
For a full explanation of all features and instructions, please refer to the User's Guide.
1 Setting up your digital baby monitor
Connecting power supply for the Baby unit
A
• Connect the small plug of
the power adapter to the
baby unit and the other
end to the electrical
outlet.
• Only use the enclosed
adapter (5.9V DC/
1000mA).
Installing the battery pack for the Parent unit
B
Red
Black
• Insert the wire tab of the
rechargeable battery
pack into the contact
slot as shown above
and fit the battery pack
into the compartment.
Connecting power supply for the Parent unit
D
• Connect the small plug of
the power adapter to the
parent unit and the other
end to the electrical
outlet.
• Only use the enclosed
adapter (6V DC/500mA).
Fastening the cover for the Parent unit
C
Small cross head or Flat
end screw driver

2 Basic operation of the keys
3 General Information
If your product is not working properly...
1. Read this Quick Start Guide or the User’s Guide.
2. Visit our website: www.motorola.com
3. Contact Customer Service:
Parent unit
PON/OFF button Press and hold to switch on/off the unit.
+- UP/DOWN buttons Press to tilt the camera upward or downward. Press to adjust menu settings.
<> LEFT/RIGHT buttons Press to pan the camera left or right. Press to access different menu options.
MMENU button Press to open menu options or exit.
OOK button Press to confirm a selection.
VVIDEO button Press to turn on/off the LCD display.
TTALK button Press and hold to talk to your baby.
Baby unit
ON/OFF switch Push power switch to the right to switch on the unit. Push power switch to the left to switch off the unit.
