Binatone CVC-7100 User manual

Vacuum Cleaner for Dry Cleaning
Instruction Manual

A

3
ENGLISHРУССКИЙ
АЗА
ENGLISH......................................... 4
РУССКИЙ .....................................12
УКРАЇНСЬКА .................................20
АЗААЗА
АЗААЗА
АЗА .......................................... 28
УКРАЇНСЬКА

4
Vacuum Cleaner for Dry Cleaning
CVC7100, CVC7120, CVC7165,
CVC7190
This appliance is designed for collecting of house moss
and small particles rubbish.
Power supply: 220-240 V, ~50Hz.
Maximum Power: 1900 W for CVC-7190, 1650 W for CVC-7165,
1200 W for CVC-7120, 1000 W for CVC-7100.
Suction power: 420 W for CVC-7190, 390 W for CVC-7165,
CVC-7120, 370 W for CVC-7100.
The product has been certified in compliance with effective
technical regulations.
The manufacturer may in its own discretion and without any
additional notices change the configuration, appearance, manu-
facturing country and technical features of the model. Check when
receiving the product.
SAFETY MEASURES
When using your appliance, the following basic
safety precautions should always be followed:
XTo avoid electric shocks, do not immerse the
appliance, plug or power cord in water
or any other liquids. Do not place the appli-
ance where it could come into contact with wa-
ter or other liquids. Do not use the machine again
until it has been serviced by an authorized service center.
XDo not let children use the appliance without supervision.
XThis appliance is not intended for use by persons (including
children) with reduced physical, sensory or mental capabili-
ties, or lack of experience and knowledge, unless they have
been given supervision or instruction concerning use of the
appliances by a person responsible for their safety.
XIf the power cord plug does not fit to your wall socket,
consult a qualified electrician.
XUse of various adapters may result in damage to the
appliance and termination of warranty.
XAlways supervise the appliance while in use.
XAlways unplug before moving the appliance from one
place to another, cleaning and storing.
XNever pull the cord to disconnect the appliance, instead grasp
the plug and pull it to disconnect.
XDo not allow the cord or the machine itself to come in contact
with hot surfaces.
XPosition the appliance and the cord so that nobody can acci-
dentally overturn it.
XDo not use the appliance if it has been dropped, or it has a
damaged power cord or plug. Do not modify or repair the
machine yourself.
XDo not dismantle the appliance as improper assembly might
result in an electric shock during the subsequent use of the
equipment.
XRepairs should only be done by authorized service centers.

5
ENGLISH
XThis equipment is intended for household use only, not for
commercial or industrial use.
XPlease follow all the requirements of this guide.
XDo not use the appliance if it has mechanical defects (dents,
cracks etc.), get it checked by the nearest authorized service
center.
XTo avoid mechanical defects and damage, take care during
the appliance transportation.
SPECIAL SAFETY MEASURES
XDo not use the appliance in the immediately
surroundings of a bath, a shower or a swim
ming pool.
XDo not bend or pull the flexible hose, other
wise you can damage it.
XTake utmost care while using the vacuum
cleaner of steps.
XBefore cleaning carpets, remove from the floor all objects which
could damage the dust-collecting container or the filter.
Attention: Do not use this appliance for collecting liquids,
builders’ refuse, sharp or hot objects (e.g., crushed
glass, coals, ash). Do not use the appliance without
the filters installed.
DESCRIPTION
OF APPLIANCE PARTS
Fig. A:
1. Casing
2. Inlet hole for the hose
3. Flexible hose
4. Flexible hose handle
5. Hold-button for the hose (except CVC-7190)
6. Air flow power selector
7. Telescopic tube
8. Appliance handling handle
9. Key «ON/OFF»
10.Automatic power cord rewind button
11.Dust container
12.Dust container cover
13.Container hold-button
14.Dust container cover button
15.Upper lid of the dust container
16.Cyclone separator
17.Outlet HEPA filter
18.Inlet motor filter
19.Outlet hole
20.Multipurpose nozzle «Floor/ Carpet»
21.Nozzle for narrow spaces
22.Nozzle for furniture

6
23.Turbo brush (except CVC-7165)
24.Accessory bracket (except CVC-7100)
BEFORE USE
Vacuum cleaner assembly
Flexible hose connection
Insert plastic base of the flexible hose (3) in
the inlet hole (2) until it clicks.
For model CVC-7190: turn the hose (3)
right when it is pushed into the bottom, a click of
inserting sound may be heard.
Flexible hose disconnection
Press the hold-button (5) and pull out the hose.
For model CVC-7190: rotate the hose contra clockwise
and pull out it.
Application of nozzles and working parts
XBy pressing the tube length control button, pull-out the tele-
scopic tube (7) as required. The tube length could very in the
range of 50–80 cm for CVC-7100 and 60–100 cm for other
models.
XInsert the flexible hose (3) in the telescopic tube (7).
XPut the required nozzle on the telescopic tube:
Multipurpose nozzle «Floor/Carpet» (20)
You can change the operating mode of the nozzle: with an
extended brush – for cleaning carpets, and without the brush –
for flat surfaces.
High-efficiency turbo-brush (23) is designed for conve-
nient and fast collecting of house moss and animal-hair.
Nozzles for narrow spaces and furniture (21,22): you
may use a crevice nozzle for cleaning hard-to-reach places, and
a special brush for cleaning upholstery.
The nozzles for narrow spaces and furniture (21,22) can be
stuck in the corresponding clips on the accessory bracket (24).
OPERATING INSTRUCTION
Using the appliance
1. Before using the appliance, select the re-
quired length of the power cord: yellow mark
at the power cord indicates the optimum
length of the power cord, whilst the red mark
indicates the maximum length.
Attention: Red mark is the limiter of the power cord
maximum length.
2. Connect the appliance to the power grid whose voltage shall
correspond to the voltage rating indicated on the appliance.
Use only grounded sockets.
3. Press «ON/OFF» (9) to switch on the vacuum cleaner. Press

7
ENGLISH
«ON/OFF» (9) once again to switch off the vacuum cleaner.
4. For a prompt changing of the vacuum cleaner power, you can
use the air flow power selector (6), installed at the flexible
hose handle (4).
5. Press the automatic hose coiling button to wind up the power
cord (10). Hold the power cord by hand to prevent the power
cord damage when it’s coiled up quickly.
Protective device of motor (for models CVC-
7190, CVC-7120, CVC-7100)
There is a temperature controller designed in the body of
cleaner motor, which can automatically cut off the power supply
of motor to prevent overheating or damage.
If the temperature controller is cut off,
1. Stop the cleaner immediately, pull out the power plug.
2. Make the cleaner cool for 30 minutes.
3. Check and remove the hair roll or other roll-like rubbish block-
ing the air inlet, clean the dust container and replace the filters
when necessary.
4. Put the mains plug in the socket.
5. Turn the appliance on with the «ON/OFF» button.
Your vacuum cleaner advantages
Your vacuum cleaner is furnished with the highly-efficient HEPA
(High Efficiency Particle Absorption) H10 filter. These filters
ensure the utmost thorough and hygienic cleaning of premises.
Attention: Do not use the vacuum cleaner without the
filters installed, otherwise the suction power could
drop and the motor could be damaged. Timely clean
filters to extend the vacuum cleaner service life (ref. to
«Cleaning and Maintenance» sections).
CLEANING
AND MAINTENANCE
XAlways turn off the appliance and pull the
plug of the cord from the electric wall outlet
before cleaning.
XWipe the appliance body (1) with a damp
lint free cloth. Do not use the appliance till it
becomes completely dry. Do not use alco-
hol, gasoline or any other similar substance
for cleaning the appliance. Also abrasive cleaning materials
should not be used.
XWhen the appliance is not in use any longer, wait until it
completely cools down, and then, by pressing the automatic
power cord rewind button (10), wind up the power cord.
XYou may store the appliance either in horizontal position. You
may also fix the hose by inserting the boss of the multipurpose
nozzle (20) into a special hold-groove at the appliance casing.

8
XIf you do not use the appliance, store it in a safe, dry place, out
of children’s reach.
Attention: When the cleaner is placed idle not in use, it
should not be put directly in the sun.
Dust-collecting container cleaning
Regularly clean the dust-collecting container.
1. Before starting cleaning the dust-collecting container, discon-
nect the appliance from the power grid. Disconnect the flex-
ible hose (3) (ref. to «Before Use» section).
2. Remove the dust-collecting container (11) by pressing the
container hold-button (13) and by pulling the handle. For
model CVC -7165 the container hold-button is located on the
appliance base. For models CVC -7190, CVC-7120 the con-
tainer hold-button is located on the dust container. For model
CVC -7100 the container hold-button is located on the dust
container handle.
3. Put the dust-collecting container (11) over the rubbish bin (bag),
press down the releasing button of the dust container (14).
4. Use a damp soft cloth to wipe the container.
5. When it is necessary, open the container (11) by turning the
upper lid of the dust container (15) until the position «Latch
Open». Clean the cyclone separator (16) with a soft brush
and wipe it with a damp soft cloth.
Attention: Before the re-installation, make sure the dust-
collecting container is completely dry.
Warning: Regular cleaning of the filters is required to
extend the appliance service life. If the appliance is
frequently used, it’s recommended to clean the filters
at least after each 3-5 the dust-collecting container
cleanings. Despite the HEPA filters are highly-
efficient, they also needs replacement (approximately,
once a year or each half-year of continuous operation
of the vacuum cleaner).
Replacement of outlet HEPA filter
XDisconnect the appliance from the power grid.
XRemove the outlet hole protective screen (19) at the casing
and then remove the filter (17).
For model CVC-7100: the outlet HEPA filter is located on the
wheel. Lift the protective cover. Remove the filter.
For model CVC-7120: at the back of the cleaner, locate the
release catch for HEPA filter cover. Slide the catch to the right
and remove the cover.
For model CVC-7165: Turn the cleaner and locate the outlet
HEPA filter cover on the underside of the cleaner body. Turn the
lock clockwise and lift the protective cover. Remove the filter.
XInstall the new filter.
XClose the protective cover of the filter.

9
ENGLISH
For model CVC-7190: a distinctive click will be the indication of
correct installation.
For model CVC-7165: turn the lock contra clockwise.
Attention: If the filter is improperly mounted, the protective
screen will fail to close.
Cleaning of inlet motor filter
Disconnect the appliance from the power grid.
For model CVC-7165: at the back of the cleaner, locate the
release catch for the inlet motor filter cover. Slide the catch to
the right and remove the cover.
For model CVC-7190: remove the dust-collecting container
(11) (ref. to «Dust-collecting container cleaning» sec-
tion).
Locate the catch for the inlet motor filter cover (18) on the internal
surface of the cleaner body. Press the catch.
For models CVC-7120, CVC-7100:
Locate the catch on the external part of the dust-collecting bag (11).
XRemove the filter.
XRemove plastic protective enclosure of the filter.
XUse soft brush to clean the filter and plastic protective enclo-
sure. The filter components can be flushed with warm flowing
water. Before re-installation, make sure the filter components
are completely dry.
XAssemble the filter and put it in its place.
XClose the cover of the filter.
For model CVC-7190: install the dust-collecting container (11)
in its working position (11) (ref. to «Dust-collecting con-
tainer cleaning» section).
Attention: It is normal that the filter may change color
which cannot affect its filtration performance.
Any other activities shall be performed at an authorized ser-
vice center.
If you do not use the appliance, place it in a box and store in
a safe and dry place, out of reach of children.
AFTER-SALES SERVICE
If your appliance does not operate or does
not operate properly, contact an authorized
service center for consultancy or repair.
The warrantee does not cover:
–product packing, consumables and ac-
cessories (hoses, nozzles, filters, etc.).
– mechanical damages and natural wear of the product;
– failures due to overloading, improper or careless maintenance,
penetration of liquids, dust, insects and other foreign matters
inside the product, exposure of plastic and other not thermal-
resistant components to high temperatures, force-majeure cir-
cumstances (accidents, fire, flooding, power grid failure, light-
ning stroke, etc.);

10
Vacuum cleaner/ Пылесос
No: CVC7190
Max. power/ Макс.мощность: 1900W
Nominal power/Номинальная мощность: 1400W
Consumption power/Мощность всасывания: 420W
220240V ~50Hz
Made in China / Сделано в КНР
– damages caused by:
XNon-fulfillment of the above-mentioned precautions and op-
erating manuals.
XApplication in commercial purposes (application of the product
beyond personal daily living needs).
XConnection to a grid with a voltage which differs from that
indicated on the appliance.
XUnauthorized repair or replacement of the components of the
appliance, performed by an unauthorized person or service
center.
DISPOSAL
The appliance should be disposed of in accor-
dance with waste disposal regulations in your coun-
try and with the least damage to the environment.
Only ecologically safe materials are used in
the packaging of our products and the cardboard
and paper can be disposed of with normal paper
waste.
Vacuum cleaner/ Пылесос
No: CVC7165
Max. power/Максимальная мощность: 1650W
Nominal power/Номинальная мощность: 1400W
Consumption power/Мощность всасывания: 390W
220240V ~50Hz
Made in China / Сделано в КНР
ME 10
ME 10
