bioBidet BB-800 Technical Document

Installation Manual and
Operating Instructions
BB-800, 900, 1000
This Product should be installed according to this manual.
Please read this manual carefully and install properly.
Please keep this manual for future reference.
Please register Warranty for proper service.
PERSONLAL HYGIENE APPLIANCE
SUPREME BIDET SEAT (Electric Bidet)

Thank you for purchasing BIO BIDET Supreme Bidet Seat (Electric Bidet).
This unit was manufactured for household use.
2Installation Manual and Operating Instructions
Bio Bidet
SUPREME BIDET SEAT (Electric Bidet)

MAINTENANCE
WATER DRAINING
TROUBLE SHOOTING
SPECIFICATIONS
WARRANTY
INFORMATION TO THE USER
OPERATION (BASIC)
OPERATION (DETAILS)
INSTALLATION
SEPARATION OF THE UNIT FROM
THE TOILET BOWL
IMPORTANT SAFEGUARDS /
GENERAL CAUTIONS
CAUTIONS BEFORE INSTALLATION
CARTON CONTENTS / IDENTIFICATION
PREPARATION OPERATION INSTALLATION MAINTENANCE
Contents
4
6
8
9
10
14
17
18
19
20
21
22
23
3
SUPREME BIDET SEAT (Electric Bidet)
Installation Manual and Operating Instructions

4
IMPORTANT SAFEGUARDS / GENERAL CAUTIONS
1
The following terms are used in this manual to indicate hazards of varying degrees of severity
Indicates potentially hazardous situation which, if not avoided, may result in minor or
moderate injury or in damage to the product or other property.
Indicates potentially hazardous situation which, if not avoided,
could result in death or serious injury.
WARNING
Indicates an imminently hazardous situation which, if not avoided,
will result in death or serious injury.
DANGER
CAUTION
READ ALL INSTRUCTIONS BEFORE INSTALLATION AND USE
DANGER - To reduce the risk of electrocution
WARNING - To reduce the risk of burns, electrocution, fire, or injury to persons
PLEASE OBSERVE THE FOLLOWING PRECAUTION BEFORE USING THIS PRODUCT
Do not open the product to repair or remodel.
Only qualified service personnel should service this product.
Do not use attachments not recommended by the manufacturer.
Do not dismantle
Connect the product to cold water supply pipe
carrying potable water.
Do not connect to an industrial water supply line that
does not carry water of drinking quality.
This will negatively effect hygiene and performance.
Prohibited
About Low Temperature Burns-
A burn occurs when the skin has been exposed to high temperatures. However,
a low temperature burn may occur when the skin has been in contact with an
object at relatively low temperature (about 104 ℉/40℃). Close supervision is
necessary when this product is used by, children or people with sensitive skin.
Prohibited
If using any chemical toilet bowl cleaner, be sure to
wipe up any spills that splash onto Electric Bidet.
Do not use benzene or any acid chemical detergent.
Only neutral detergent permitted.
Prohibited
Bio Bidet
SUPREME BIDET SEAT (Electric Bidet)
Installation Manual and Operating Instructions

PREPARATION
5
Do not plug in the power cord before connecting
the water supply hose.
Prohibited
This product must be grounded.
An approved Ground Fault Circuit Iterrupt, must be used.
Grounding
Do not splash water on this product. Please provide
adequate ventilation to avoid damage to electronic
components due to high level of humidity.
it is necessary to provide adequate ventilation with a
fan, open door or open window when bathing.
Do not spray water
Do not touch the power cord with wet hands.
Do not reach for a product that has fallen into water.
Unplug immediately!
Wet hands prohibited
This product must be connected to a standard
voltage power source. Do not connect power
cord if the cord is damaged or broken.
Do not plug the unit into a loose electric outlet.
Observe at all times
Please disconnect the power cord when you clean
this product or detach it from toilet bowl.
Do not supply electrical power to the unit until the
plumbing work has been completed.
Observe at all times
Keep the electrical cord away from heated surfaces to
prevent a fire hazard. Also, keep any flammable materials
away at all times from the this product.
Use of fire prohibited
SUPREME BIDET SEAT (Electric Bidet)
Installation Manual and Operating Instructions

6
CAUTION
Never operate this product if it is not
working properly, if it has been
dropped or damaged, or dropped into
water. Return the product to a service
center for examination and repair
Prohibited
Do not obstruct or
put anything into the
dry air outlet. Do not
apply excessive force
to the shower nozzle.
Prohibited
Do not strain or push the connected hose and tube connecter;
it may cause water leakage. Never drop or insert any object
into any opening or hose. Use proper plumbing suppliesif any
modification is to be made.
Prohibited
drain the water from unit and switch off the power if it is
not going to be used for an extended period of time.
Refer to page 19
Observe at all times
Do not stand or sit
on the seat cover lid.
It is not designed to
support a user’s
body weight.
Prohibited
Allow the seat
and lid to close
automatically
do not force the
seat and lid.
Prohibited
Use this product only as
described in the operating
instructions. Never use while
sleeping or drowsy.
Do not use while bathing.
Observe at all times
Be careful so that
this product does not
become stained with
excrement and urine.
Observe at all times
CAUTIONS BEFORE INSTALLATION
2
- SAVE THESE INSTRUCTIONS -
THIS PRODUCT MUST BE PLUGGED into a regular voltage Grounded GFCI outlet
(220-240V~ , 50/60Hz). The rated power consumption is 600-700W.
In locations where only a standard two-prong outlet is available, it is the responsibility
of the user to install a grounded three-prong outlet. Using a higher voltage is dangerous and may
result in a fire or other accident. This product is not responsible for damage resulting from the use of
it on other than specified voltage, or operating it without proper grounding.
WIRING REQUIREMENT
Bio Bidet
SUPREME BIDET SEAT (Electric Bidet)
Installation Manual and Operating Instructions

7
PREPARATION
(1) This product has a three-prong grounding plug, which must be plugged into an outlet that is
properly installed and grounded.
In the event of an electrical short circuit, grounding reduces the risk of electric shock by providing an
escape wire for the electric current. If repair or replacement of the cord or plug is necessary, do not connect
the grounding wire to either flat blade terminal. The wire with insulation having an outer surface that is
green with or without yellow stripes is the grounding wire.
Check with a qualified electrician or serviceman if the grounding instructions are not completely understood,
or if in doubt as to whether the product is properly grounded.
(2) If this product is used in a bathroom or in a shower room the supplied plug must be cut off
and the connection to the power supply has to be performed by a qualified electrician.
An ON / OFF switch should be installed.
This appliance has to be earthed.
GROUND INSTRUCTIONS
The use of an extension cord is not recommended or advised. If it is necessary to use an extension cord, use
only a three-prong extension cord (one to one), and a three slot built-in GFCI receptacle that will accept the
plug on this product. The marked rating of the extension cord should be equal to or greater than the electrical
rating of the unit (10amp). Consult a qualified electrician or service person if you are not sure whether the unit is
properly grounded.
IMPROPER GROUNDING CAN RESULT IN A RISK OF ELECTRIC SHOCK.
Electric wiring has to be done in accordance with all local codes,
or in the absence of local codes, with the National Electrical Codes.
DANGER
OPTIONAL GROUND INSTRUCTIONS
This Product must be on a separated circuit. No other
appliance should share the circuit with this product.
Sharing a circuit could cause the branch circuit fuse to blow
or the circuit breaker to trip. Continuous usage under these
conditions could result in fire or property damage.
WARNING
SUPREME BIDET SEAT (Electric Bidet)
Installation Manual and Operating Instructions

8
IDENTIFICATION
3
MAIN UNIT
1
ACCESSORIES
2
Feminine Wash Nozzle
Posterior Wash Nozzle
Simple Operation Panel
For
BB-1000
Digital Occupied Sensor
Drain / Unit Separation
Button
Operation LED Window
Heated Seat
Lid
Caution Label
Deodorizer
(Only BB-900, BB-1000)
Dryer Outlet
Control Panel for BB-800, 900
Remote
control
Remote control
Fixed Panel
Battery (2pcs)
1.5V AA
Parts for BB-1000 only
Washer (2 pcs) Cone Packing (2 pcs)
Mounting Bolts (2 pcs)
Installation Base (1 pc)
Nuts (2 pcs)
Installed Bolt Case
(2 pcs)
Water Supply Tube to
Toilet Fresh Water Tank
T-Valve and Washer
Nut to Water Tank
Water Supply Tube to Toilet Seat Deodorizer Filter Cartridge/
Carbon Deodorant
(BB-900 / 1000 Models)
User
Operating
Manual
Blackfkow Prevention
CHECK VALVE
Adaptor Valve
Operation
Guide
Bio Bidet
SUPREME BIDET SEAT (Electric Bidet)
Installation Manual and Operating Instructions
Turbo Wash Nozzle
Feminine Wash Nozzle
Posterior Wash Nozzle
Turbo Wash Nozzle
BB-800, 900
BB-1000

9
OPERATION (BASIC)
4
•When you sit on this product, please sit down on the central position
in order to activate the sensor.
•After an extended wash, allow about three minutes for water to reheat.
Adjust the
osillation
funtion and
nozzle position
(5 levels)
Power Saving
mode button.
Simple Operation Pane l
Stop
Posterior Wash
Feminine Wash
BB-800, 900 Control Panel BB-1000 Remote Control
Adjust the water
pressure and
warm air dryer
temperature.
Adjust the
water and seat
temperature
(3 levels).
Adjust the
water and seat
temperature
(3 levels)
Adjust the
osillation
funtion and
nozzle position
(5 levels)
Adjust the water pressure and
warm air dryer temperature.
Power Saving
mode button.
OPERATION
SUPREME BIDET SEAT (Electric Bidet)
Installation Manual and Operating Instructions

10
OPERATION (DETAILS)
5
PREPARATION
1
SIT DOWN ON THE SEAT
• When you sit down on the seat, the ORANGE LED lamp on the control panel will light up.
• When the digital sensor on the seat is activated, the operation LED window on the main unit
will light“Occupied sensor”and simultaneously, Deodorizer fan will start to work.
(BB-900 / 1000 Models)
•See page 11 for details about changing the seat or water temperature.
•Check for any water leaks.
•Plug the unit into the proper power source and the LED power light will start flashing.
•Wait until the LED power light stops flashing and becomes solid red.
•The water tank will be filled after pushing a
“Wash”( , or , ) button.
•When the water tank is filling the buzzer“Beeps”continuously,
after the water tank is full the buzzer will end with“One Solid Beep”.
OPERATION
2
CLEANSING
•CLEANSING 1. (Posterior Wash)
1- Press “ Posterior Wash ” (, ). Automatically, the nozzle comes out and
sprays warm water to posterior.
2- Additional functions during your Posterior Wash experience are available. See Oscillation,
pg.12 and Massage, pg. 13 for details.
STOP
•Press this button to stop all operation.
•CLEANSING 2. (Feminine Wash)
1- Press“Feminine Wash”(
,
). Automatically, the nozzle comes out and
sprays warmwater to feminine area.
2- Additional functions during your Feminine Wash experience are available. See Oscillation,
pg.12 and Massage, pg. 13 for details.
• CLEANSING 3. (Turbo Wash)
1- Press“Turbo Wash” (, ) ,the nozzle spray is more
forcused to produce the effect of strong wash, to help stimulate bowel movement.
2- Press “ Water pressure - High & Low button”to adjust the water pressure.
Bio Bidet
SUPREME BIDET SEAT (Electric Bidet)
Installation Manual and Operating Instructions

11
WARM WATER TEMPERATURE
AND SEAT TEMPERATURE ADJUSTMENT
OPERATION
CLEANSING cont.
Room temperature approx. 93.2℉ (34 ℃ )98.6℉ (37 ℃ )104℉(40 ℃ )
SEAT TEMPERATURE
WATER TEMPERATURE
Room temperature approx. 93.2℉ (34 ℃ )98.6℉ (37 ℃ )105.8℉(41 ℃ )
•CLEANSING 3. (Turbo Wash)
1- Press“Turbo Wash”or continuously for 3 to 5 seconds. Automatically, the water
nozzle comes out and sprays a warm stream of water to the posterior center of the rectum.
2- If necessary, adjust“Position”of water stream with the ( , / , )buttons.
3- Press“Water pressure High & Low button”( , / , )to adjust the water pressure
to your desired comfort.
4- Press the“STOP”()button when you feel your abdomen is full or wait until
the“Turbo Wash”function stops, approximately 1 minutes.
5- You will shortly feel the urge to push the water out of your colon, push the water and feces
out as completely as you can.
6- Relax for a few minutes and be sure you feel your colon is empty and then use
the“Posterior Wash”and“Air Dry”function to finish.
WARM AIR DRYER
1- Press“Dry”(, ), warm, dry air is gently directed to washed area for about 3 minutes.
2- You may adjust the warm air temperature by pressing High( , ) and
Low( , ) buttons.
※This product memorizes the air temperature of prior use.
WATER PRESSURE ADJUSTMENT
•After sitting down on the this product, the LED lamp( ) for water
pressure on the Power Control will light at third or middle level( )
•Press high( , ) , or low( , ) to adjust the pressure of the water spray to
your desired comfort level
•The temperature of water and seat are adjustable to the desiredlevel by pressing
the“WATER”( , )and“SEAT”( , ) button.
CAUTION
DO NOT ALLOW CHILDREN TO USE THE TURBO WASH FUNCTION!
SUPERVISION IS STRONGLY RECOMMENDED FOR THE ELDERLY OR OTHER PERSONS
THAT MAY HAVE LIMITATIONS IN BODY MOVEMENT, ILLNESS OR DISABILITIES!
Observe at all times
SUPREME BIDET SEAT (Electric Bidet)
Installation Manual and Operating Instructions

12
•Nozzle position is adjustable to the desired position by pressing“Front”( , ) or
“Rear”( , ) button from 1 to 5 positions.
After using this product, the nozzle will return to position 3.
OPERATION (DETAILS)
5
NOZZLE POSITION ADJUSTMENT
•The deodorizer fan is activated when this product is occupied.
When finished, the fan will stop after 1 minute.
•Air current for the deodorizer has 4 adjustable levels. While pressing the“STOP”( ) button,
press and“WATER”( , ) button to the desired air current level. See diagram:
DEODORIZER (BB-900, 1000 Models)
1 Level
OFF
Deodorizer
(Air Current)
Occupied 󱈇
Low Speed
After using 󱈇
Low Speed
Deodorizer
(Air Current)
Occupied 󱈇
Low Speed
After using 󱈇
High Speed
Deodorizer
(Air Current)
Occupied 󱈇
High Speed
After using 󱈇
High Speed
2 Level 3 Level 4 Level
(Level1~4)
(, )
+
•When using Posterior or Feminine Washing functions, pressing the“MOVE”( , )
button will provide a short-motion, front to back oscillating spray for a much wider cleansing
experience. Note: This funtion will not work during the“Turbo Wash”function.
• You may change the position of the Oscillating spray by pressing the “ MOVE ”( , )
button again and“Front”( , ) or“Rear”( , ) buttons simultaneously.
• Push the “ MOVE ”( , ) button again and the oscillation motion will stop automatically.
Auto-Setting of Oscillation Feature
•You can set this function to automatically oscillate whenever the seat is occupied and the Posterior or
Feminine washes are in operation.
Step 1: Do not sit on the this product.
Step 2: Press the“MOVE”( , ) button for 3 seconds or until you hear a single Chime.
Step 3: Sit on the this product and proceed with Posterior or Feminine Wash.
Note :In the automatic setting, you may still adjust the position of the Oscillating spray by pressing the
“Front”( , ) or“Rear”( , ) buttons.
Canceling the Automatic Oscillation function
Step 1: Do not sit on the this product.
Step 2: Press the“MOVE”( , ) button for 3 seconds or until you hear a double Chime.
OSCILLATION ( Nozzle Movement Function)
Bio Bidet
SUPREME BIDET SEAT (Electric Bidet)
Installation Manual and Operating Instructions

13
•When using the Posterior Wash or Feminine Wash functions, pressing the“MASSAGE”( , )
button will provide a pulsation spray.
•You may change the pressure of the spray by pressing the“High”( , ) button or
“Low”( , ) buttons.
•Push the“MASSAGE”( , ) button again and the pulsating action will stop automatically.
Auto-Setting of Massage Feature
•You can set this function to automatically pulsate whenever the seat is occupied and the Posterior
or Feminine washes are in operation.
Step 1: Do not sit on the this product.
Step 2: Press the“MASSAGE”( , ) button for 3 seconds or until you hear a single Chime.
Step 3: Sit on the this product and proceed with Posterior or Feminine Wash.
Note
:In the automatic setting, you may still adjust the pressure of the pulsating spray by
pressing the“high”( , ) or“low”( , ) functions.
Canceling the Automatic Oscillation function
Step 1: Do not sit on the this product.
Step 2: Press the“MASSAGE”( , ) button for 3 seconds or until you hear a double Chime.
MASSAGE (Rhythm Wash)
ECONOMY (Energy Save Mode)
- The ENERGY SAVER is not on when the LED light is off.
- Press button once to choose“ECONOMY 1”
- Press button again to choose“ECONOMY 2”
- Press button third time to turn“ECONOMY”off
✽The ECONOMY 1 : the water temperature will be kept at 90℉(32℃)
✽The ECONOMY 2 (SMART MODE) : this will lower the water temperature to 90℉(32℃) when it is not
being used, and raise the water temperature back to normal level during the time of use.
It takes about 4days for the unit to
“learn”
, and
“remember”
, the usage pattern of the user(s)
NOZZLE CLEANING (Automatically)
• This product has an automatic nozzle self-cleaning function that cleans the nozzle before and after each use.
CHIME SOUND ON/OFF SET
•While sitting on the this product, press“MOVE”( , ) button for 3 seconds and you can hear
the chime sound change to ON or OFF. (Remote model doesn’t have off function, BB-1000)
NOZZLE CLEANING (Manual)
•Nozzle can be cleaned manually by pressing“Posterior Wash”( / , ) button for 3 seconds
without being occupied on the seat and nozzle will come out without spraying water. After cleaning
the nozzle, Press“Stop”( , ) button to return nozzle to stand-by mode.
( , : in Simple Operation panel -Remote Model)
OPERATION
SUPREME BIDET SEAT (Electric Bidet)
Installation Manual and Operating Instructions

14
INSTALLATION
6
CAUTION BEFORE INSTALLATION
•Do not connect to electricity before water connection.
• If you need an electric power system or extension, please consult a qualified electrician.
STEPS
Existing Flexible Tube
(The water supply hose)
Existing Flexible Tube
(The water supply hose)
DOUBLE CHECK VALVE MUST
COMPLYWITHTHE UK WATER
REGULATION
Thread from tank
(TEFLON tape is strongly recommended around threads to help prevent leakage)
1Removing the existing seat and lid.
•Release the nuts on both sides of existing toilet
seat to remove the seat and lid.
2
Remove existing supply pipe from the cistern tank and connect the tee to the cistern tank.
Connect the double check valve supplied to the tee and the 1/2”male-male adaptor to the
check-valve, connect existing supply pipe to the tee.
An approved double-check valve must be installed on the inlet connection to this device.
※Check for any water leaks.
3
Shut off the water supply to the
existing toilet tank by closing the
angle stop valve. Drain the toilet
tank completely by flushing toilet.
Remove the water supply hose to
toilet tank.
Bio Bidet
SUPREME BIDET SEAT (Electric Bidet)
Installation Manual and Operating Instructions

15
INSTALLATION
(TEFLON tape is strongly recommended around threads to help prevent leakage)
CHECK
VALVE
ADAPTOR
※Check for any water leaks.
Intallation Base
1. Put the 2 Bolts into the 2 Installed Bolt Cases
2. Place this Bolt assembly into the Installation
Base as shown.
3. Guide Arrows on the Installation Base should
face up and towards the Toilet Tank.
4. Place the Installation Base and guide the Bolts
into the 2 holes on the toilet bowl.
4
1. Slide the seat onto the installation Base centering
the unit with the guide arrows on the Base.
2. You will hear a click once the seat is securely
mounted to the Installation Base.
3. The seat will feel a little loose on the toilet bowl.
Adjust the fit from front to back and side to side for balance.
4. Tighten the nuts on both bolts securely.
6
1. Connect the flexible tube from male-male
Adaptor to the seat.
2. Open the water valve.
3. Check for leaks.
4. If there are no leaks and the surrounding
area is clean and dry, connect the power
cord to a ground protected power outlet.
7
1. Fit the cone packing and plastic washers onto
the bolts from below the toilet bowl as shown.
2. Loosely tighten nuts by hand.
5
Installation Base Assembly. Bolt and Nut Assembly.
Bio Bidet Shower Toilet Seat Assembly. Water Supply Tube Assembly.
Cone Packing
Washer
Nut
SUPREME BIDET SEAT (Electric Bidet)
Installation Manual and Operating Instructions
Bolt Case
Bolt

16
INSTALLATION
6
How to change the deodorant catalyst
Place 1.5V(AA) batteries properly
and shut the cover
Deodorant case
Deodorant
Cover
Adhesive Tape
Installation of Remote Control on wall or convenient surface. (BB-1000)
•Check the deodorant package.
•Follow the below photos to change the deodorant.
1
2Insert the new deodorant case into the unit.
1- Mount Fixed Panel to wall location.
Take off the cover on the adhesive on
Remote Control Fixed Panel or use
adhesive tape in order to adhere
Remote Control Fixed Panel on wall.
2- Then slide Remote Control on to
Remote Control Fixed Panel.
Deodorizer Installation.
Insert the deodorant cartrige into the unit.
(BB-900 / 1000 Models)
9
10
Bio Bidet
SUPREME BIDET SEAT (Electric Bidet)
Installation Manual and Operating Instructions

17
INSTALLATION
SEPARATION OF UNIT FROM THE TOILET BOWL
7
Switch off power supply.
Shut off the Water Supply Valve.
Push the button on the right side of the unit to
completely drain the water from water tank.
Separate the unit from toilet as following photos.
Do not turn unit upside down.
•When you pull the unit while pushing the drain button, the unit will separate from the installation base.
1
2
3
4
SUPREME BIDET SEAT (Electric Bidet)
Installation Manual and Operating Instructions

18
MAINTENANCE
8
•When the“Posterior Wash ( / , )”button is pressed
for 3 seconds without occupying the seat, the nozzle can be
cleaned with a soft toothbrush.
•After cleaning the nozzle, push the“Stop ( ,)”
button once again, and the nozzle retracts itself.
( : in Simple Operation panel -Remote Model)
1) Close the water shut off valve.
2) Flush the toilet to empty the water reservoir.
3) Unscrew the water filter nut.
4) Clean the strainer with a small brush or water.
5) Re-screw the water filter nut.
6) Open the water shut off valve.
This product will not operate
properly if the strainer is clogged.
Please clean the strainer regularly.
BB-800, 900
( : in Simple Operation panel -Remote Model)
CLEANING THE NOZZLE
•When you clean the this product, do not use“thinner ” ,“benzene ” or
toilet bowl cleaner. It may cause damage to the surface of unit.
•Use a wet cloth when you clean the this product.
•Do not spray water directly on to the this product.
•When you clean the this product, switch off power supply.
CLEANING THE BODY OF UNIT
CLEANING THE STRAINER
Bio Bidet
SUPREME BIDET SEAT (Electric Bidet)
Installation Manual and Operating Instructions
BB-1000

19
MAINTENANCE
WATER DRAINING
9
MAINTENANCE FOR WINTER SEASON
DRAINING THE WARM WATER TANK IN THE UNIT
If you do not intend to use the this product for 14 days or longer,
drain the water from the product warm water tank.
1) Disconnect the power plug.
2) Close the water shut off valve.
3) Press the drain lever until the water is
completely drained from the unit’s water tank.
4) To re-supply water after draining,
open the water shut off valve.
Do not drink the drained water.
Do not insert finger into the drain hole.
Before draining, switch off power and wait 30 minutes until the unit has cooled down.
Check the power is ON or OFF.
1
Keep the water temperature on“Middle or High Level”to prevent water from freezing.
2
If you do not intend to use the unit for 14 days or longer, switch the power off
and drain the water.
3
SUPREME BIDET SEAT (Electric Bidet)
Installation Manual and Operating Instructions

20
TROUBLE SHOOTING
10
Trouble Cause Remedy
1.The water tank is not filled.
2.The shut off valve is closed.
3. Freezing inside the main unit
or the water supply pipe.
1.Power is switched off.
2.The seat is not occupied.
3.The battery of remote
controller is exhausted.
(Only BB-1000 model)
1.Check the water supply system
1.The water pressure level is set to
“LOW”.
2.The strainer is clogged.
1.The water temperature is set to
“LOW”.
2.Continuous operation has
depleted the supply of warm
water.
1.The seat & dryer temperature is
set to“LOW”.
1. Wait about one minute.
2.Press the desired washing
button once again.
3.Turn on the shut off valve to
open.
4.Heat the room (for about two
hours). Operating the unit while
parts are frozen will cause a
malfunction.
1.Switch power on.
2. Check the power supply
system in your house.
3.Occupy the seat (The unit has
an occupied sensor).
4.Replace the battery.
1. If water is leaking from the
main unit, call the service
center or the place you
purchased.
1.Set the water pressure to
“HIGH”.
2.Clean the strainer.
1.Set the water temperature to
“HIGH”.
2. Wait about three minutes.
1. Set the seat & dryer
temperature to“HIGH”.
The washing water
does not spray
The unit is not
operating
Water is leaking
The washing water
pressure is weak
The washing water
is not warm
The seat and dryer
is not warm
Bio Bidet
SUPREME BIDET SEAT (Electric Bidet)
Installation Manual and Operating Instructions
