BioOx Reactor 85 User manual

Reactor 85 / 300 / 650!
E-MANUAL
Air & Water Solutions, Inc. •P.O. Box 627, Nutley, New Jersey 07110 •[phone] •www.bioox.us

BioOx Reactor 85
of2 15

TABLE OF CONTENTS
THREE (3) YEAR LIMITED WARRANTY#4!
IMPORTANT SAFEGUARDS#6!
FINDING A PROPER LOCATION#7!
GENERAL INFORMATION#7!
TECHNICAL SPECIFICATIONS#8!
UNIT OVERVIEW & PARTS NAMES#9!
OPERATING PROCEDURE#10!
DOSAGE SCHEDULE#11!
ADDING BIOOX NATURAL MEDIA#12!
MAINTAINING YOUR UNIT#12!
TROUBLESHOOTING FOR THE BIOOX CLEAN AIR SYSTEM#14!
PREPARING FOR AN EXTENDED LEAVE#14!
CONTACT INFORMATION#15
BioOx Reactor 85
of3 15

THREE (3) YEAR LIMITED WARRANTY!
BioOx Reactor 85
of4 15
For the BioOX Reactor product line only
IMPORTANT: BY USING YOUR BIOOX REACTOR UNIT YOU ARE AGREEING TO BE BOUND BY THE
TERMS OF THE BIOOX THREE (3) YEAR LIMITED WARRANTY (“WARRANTY”) AS SET OUT BELOW. DO
NOT USE YOUR PRODUCT UNTIL YOU HAVE READ THE TERMS OF THE WARRANTY. IF YOU DO NOT
AGREE TO THE TERMS OF THE WARRANTY, DO NOT USE THE PRODUCT AND RETURN IT WITHIN THE
RETURN PERIOD STATED IN BIOOX'S RETURN POLICY TO THE AUTHORIZED DISTRIBUTOR WHERE
YOU PURCHASED IT FOR A REFUND.
HOW CONSUMER LAW RELATES TO THIS WARRANTY
THIS WARRANTY GIVES YOU SPECIFIC LEGAL RIGHTS, AND YOU MAY HAVE OTHER RIGHTS THAT VARY FROM STATE
TO STATE (OR BY COUNTRY OR PROVINCE). OTHER THAN AS PERMITTED BY LAW, BIOOX DOES NOT EXCLUDE, LIMIT
OR SUSPEND OTHER RIGHTS YOU MAY HAVE, INCLUDING THOSE THAT MAY ARISE FROM THE NONCONFORMITY OF A
SALES CONTRACT. FOR A FULL UNDERSTANDING OF YOUR RIGHTS YOU SHOULD CONSULT THE LAWS OF YOUR
COUNTRY, PROVINCE OR STATE.
WARRANTY LIMITATIONS SUBJECT TO CONSUMER LAW
TO THE EXTENT PERMITTED BY LAW, THIS WARRANTY AND THE REMEDIES SET FORTH ARE EXCLUSIVE AND IN LIEU
OF ALL OTHER WARRANTIES, REMEDIES AND CONDITIONS, WHETHER ORAL, WRITTEN, STATUTORY, EXPRESS OR
IMPLIED. BIOOX DISCLAIMS ALL STATUTORY AND IMPLIED WARRANTIES, INCLUDING WITHOUT LIMITATION,
WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE AND WARRANTIES AGAINST HIDDEN
OR LATENT DEFECTS, TO THE EXTENT PERMITTED BY LAW. IN SO FAR AS SUCH WARRANTIES CANNOT BE
DISCLAIMED, BIOOX LIMITS THE DURATION AND REMEDIES OF SUCH WARRANTIES TO THE DURATION OF THIS
EXPRESS WARRANTY AND, AT BIOOX'S OPTION, THE REPAIR OR REPLACEMENT SERVICES DESCRIBED BELOW. SOME
STATES (COUNTRIES AND PROVINCES) DO NOT ALLOW LIMITATIONS ON HOW LONG AN IMPLIED WARRANTY (OR
CONDITION) MAY LAST, SO THE LIMITATION DESCRIBED ABOVE MAY NOT APPLY TO YOU.
WHAT IS COVERED BY THIS WARRANTY?
Air & Water Solutions Inc. of P.O. Box 627, Nutley, New Jersey, U.S.A. 07110 (“Air & Water Solutions”) warrants the BioOx-
branded Reactor hardware product and the BioOx branded accessories contained in the original packaging against defects in
materials and workmanship when used normally in accordance with BioOx's published guidelines for a period of THREE (3)
YEARS FOR THE REACTOR HOUSING AND 90-DAYS FOR THE FANS AND PUMPS from the date of original retail purchase
by the end-user purchaser ("Warranty Period"). BioOx's published guidelines include but are not limited to information
contained in technical specifications, user manuals and service communications.

BioOx Reactor 85
of5 15
WHAT IS NOT COVERED BY THIS WARRANTY?
This Warranty does not apply: (a) to consumable parts, such as batteries or protective coatings that are designed to
diminish over time, unless failure has occurred due to a defect in materials or workmanship; (b) to cosmetic damage,
including but not limited to scratches, dents and broken plastic on plugs or ports unless failure has occurred due to a
defect in materials or workmanship; (c) to damage caused by use with a third party component or product that does not
meet BioOx Product’s specifications (BioOx Product specifications are available at www.bioox.us under the technical
specifications for each product and also available from our distributors); (d) to damage caused by accident, abuse, misuse,
fire, liquid contact, improper maintenance, earthquake or other external cause; (e) to damage caused by operating the
BioOx Product outside BioOx’s published guidelines; (f) to damage caused by service (including upgrades and expansions)
performed by anyone who is not a representative of BioOx or a BioOx Authorized Service Provider (“BASP”); (g) to a BioOx
Product that has been modified to alter functionality or capability without the written permission of BioOx; (h) to defects
caused by normal wear and tear or otherwise due to the normal aging of the BioOx Product; ; or (i) if BioOx receives
information from relevant public authorities that the product has been stolen, and you cannot prove in any way that you are
the authorized user of the product (eg. by presenting proof of purchase).
YOUR RESPONSIBILITIES
YOU SHOULD PERFORM ROUTINE MAINTENANCE TO THE BIOOX REACTOR AS INSTRUCTED BY OUR PRODUCT
MANUAL. LACK OF MAINTENANCE CAN RESULT IN THE PREMATURE WEAR AND FAILURE OF YOUR UNIT AND MAY
RENDER THIS WARRANTY NULL AND VOID. Before receiving warranty service, BioOx or its agents may require that you
furnish proof of purchase details, respond to questions designed to assist with diagnosing potential issues and follow
BioOx's procedures for obtaining warranty service. Before submitting your BioOx Product for warranty service please
contact us at [phone].
HOW DO I OBTAIN WARRANTY SERVICE?
Please contact Air & Water Solutions at [email protected] or by calling 1 [phone] for warranty service.
LIMITATION OF LIABILITY
EXCEPT AS PROVIDED IN THIS WARRANTY AND TO THE MAXIMUM EXTENT PERMITTED BY LAW, BIOOX IS NOT
RESPONSIBLE FOR DIRECT, SPECIAL, INCIDENTAL OR CONSEQUENTIAL DAMAGES RESULTING FROM ANY
BREACH OF WARRANTY OR CONDITION, OR UNDER ANY OTHER LEGAL THEORY, INCLUDING BUT NOT LIMITED TO
LOSS OF USE; LOSS OF REVENUE; LOSS OF ACTUAL OR ANTICIPATED PROFITS (INCLUDING LOSS OF PROFITS ON
CONTRACTS); LOSS OF THE USE OF MONEY; LOSS OF ANTICIPATED SAVINGS; LOSS OF BUSINESS; LOSS OF
OPPORTUNITY; LOSS OF GOODWILL; LOSS OF REPUTATION; LOSS OF, DAMAGE TO, COMPROMISE OR
CORRUPTION OF DATA; OR ANY INDIRECT OR CONSEQUENTIAL LOSS OR DAMAGE HOWSOEVER CAUSED
INCLUDING THE REPLACEMENT OF EQUIPMENT AND PROPERTY, ANY COSTS OF RECOVERING, PROGRAMMING,
OR REPRODUCING ANY PROGRAM OR DATA STORED IN OR USED WITH THE BIOOX PRODUCT OR ANY FAILURE TO
MAINTAIN THE CONFIDENTIALITY OF INFORMATION STORED ON THE BIOOX PRODUCT. THE FOREGOING
LIMITATION SHALL NOT APPLY TO DEATH OR PERSONAL INJURY CLAIMS, OR ANY STATUTORY LIABILITY FOR
INTENTIONAL AND GROSS NEGLIGENT ACTS AND/OR OMISSIONS. BIOOX DISCLAIMS ANY REPRESENTATION THAT
IT WILL BE ABLE TO REPAIR ANY BIOOX PRODUCT UNDER THIS WARRANTY OR REPLACE THE BIOOX PRODUCT
WITHOUT RISK TO OR LOSS OF INFORMATION STORED IN THE BIOOX PRODUCT. SOME STATES (COUNTRIES AND
PROVINCES) DO NOT ALLOW THE EXCLUSION OR LIMITATION OF INCIDENTAL OR CONSEQUENTIAL DAMAGES, SO
THE ABOVE LIMITATION OR EXCLUSION MAY NOT APPLY TO YOU.

IMPORTANT SAFEGUARDS!
BioOx Reactor 85
of6 15
Please read safety guidelines before operating the unit.
1. Do not operate in explosive atmospheres. Fan motor is not explosion-proof.
2. Do not operate if pump or fan cords are damaged.
3. Do not allow children to climb on unit. Anchor unit to wall or support if necessary.
4. To protect against shock, plug fan electrical cord into ground fault circuit interrupter (available at hardware
stores).
5. To prevent accidental knockdown, keep away from general foot traffic, children, and pets. Secure to a solid
support if necessary.
6. Do not tip. Operating while unbalanced or while lying on side can result in electrical shock.
7. Do not stick fingers or objects through fan or remove top fan assembly when fan is moving or plugged in.
Moving fan may cause injury.
8. Do not place objects on top of unit.
9. Do not move the unit unless the electric cords for the fan and the pump have been disconnected and water has
been emptied from the water reservoir (tank).
10. Do not operate unit on wet surface. Never handle the pump or fan motor plugs and cords with wet hands or
when standing on wet surface.
11. During operation, maintain the water level of the tank. Water level should not be allowed to go below water
pump level. If there is not enough water to circulate in the reservoir, the pump may be damaged and the
cleaning efficiency reduced. Maintain water level between maximum and minimum lines.
12. Do not stop water circulation by the pump. Stagnant water can cause unpleasant smell and a harbor for insects.
When not in use, drain water and allow unit to dry for storage. Just add water and BioOx® Natural Media to
start up when ready.
13. Do not intentionally introduce any form of pollutant directly into unit, i.e. smoke, hazardous or non-hazardous
liquid, solvents, solids, sprays, etc. to test the unit’s capabilities. The only substances that can be added directly
to the unit are: water and BioOx Natural Media.
14. Wash hands with soap and water after handling BioOx Natural Media.
WARNING: TO REDUCE THE RISK OF FIRE OR ELECTRIC
SHOCK, DO NOT DISMANTLE FAN OR PUMP SYSTEM.!
NO USER-SERVICEABLE PARTS INSIDE.!
REPAIRS SHOULD BE DONE BY AUTHORIZED SERVICE
PERSONNEL ONLY.

FINDING A PROPER LOCATION
GENERAL INFORMATION!
BioOx Reactor 85
of7 15
To find a proper place to set up your BioOx-85 unit, it should be:
1. In a good location to draw in major air pollutants;
2. Away from frequent movements of people, especially children or pets
3. Away from dangerous or flammable sources.
The fan cord should be plugged into a ground fault circuit interrupter (available at hardware stores) and
shipped with new units.
If your unit has an automatic watering option: Automatic watering attachment should be connected to a water
source by a licensed plumber. Connection and attachment should be inspected periodically to assure proper
working order and to avoid possible overflow, leaks, spills or floods.
The BioOx-85 is an air cleaning unit, which biologically oxidizes organic chemicals and contaminants and
removes dust and other particles from the air. This unit is specially designed for the removal of indoor air
pollutants. The BioOx-85 has been pre-loaded with BioOx Natural Media (biomass) which are able to eliminate
a broad spectrum of organic pollutants as their carbon source (oxidation).
For the unit to operate efficiently, it must be provided with water and oxygen for biological oxidation to take
place. Oxygen is sufficiently supplied from the surrounding air drawn in to the unit. Water is pumped from the
reservoir and distributed over the top of the cartridge where it continually washes the cartridge element. While
the unit is operating, the amount of water is gradually reduced. Because of this loss of water, you must add
water to the unit periodically.

TECHNICAL SPECIFICATIONS!
BioOx Reactor 85
of8 15
Model No.
Reactor 85
Nominal contaminant destruction, lbs/day
10
Area of influence* square feet
600
Continuous Operation
YES
Air flow ft3/min
100
Water flow (GPM)
5 gpm
Fan speed (RPM)
1750 rpm
Container Vol (G)
10 G
Rating
AC 110V 60HZ
Power consumption
24 Watts
Dimensions (D x H)
13” (D) x 25” (H)
Noise levels
34 db
Dry Weight
16 lbs
• External dimensions are approximate.!
• In extremely high-altitudes or severely cold areas, the product may not perform as specified.
Avoid using product in such areas or in other extreme conditions.!
• This product is not suitable for use in countries or regions with different power supply voltages
or frequencies.!

UNIT OVERVIEW & PARTS NAMES!
BioOx Reactor 85
of9 15
Air Water Inlet Tray
Fan & fan assembly
Water Reservoir Tank
Water Pump Unit!
(Inside Unit)
Tee connection
Pump disconnect fitting
Water recirculation tray
BioStack cartridge/core pipe
Pump sits at bottom of reservoir

OPERATING PROCEDURE
BioOx Reactor 85
of10 15
1. Add water and BioOx® Natural Media to the BioOx-85 at the Air/Water Inlet. (See photographs below).
Fill to Maximum Water Line. Plug the water pump cord into your electric outlet (120 volts). Make sure
water is circulating by listening for the sound of water flowing or seeing the water flow through the
Water/Air Inlet cover. (The water level should drop slightly as water pumps up to the water box).!
2. Plug the fan cord into the electric outlet (120 volts). Place hand near fan, making sure air is flowing out.
The BioOx-85 should now be operating automatically.!
3. Maintain the water level above the water pump and between the Minimum and Maximum Water Level
Lines at all times.!
4. Check water level daily. Add water periodically to maintain water level . Allowing the water level to get
too low will damage the pump.!
5. Add BioOx® Natural Media regularly. We recommend adding 4 oz. every month, depending on your
particular air quality. During peak periods, add more BioOx Media or add more often (every week).
Add water at air/water inlet
Add BioOx Media at air/water inlet

DOSAGE SCHEDULE!
BioOx Reactor 85
of11 15
Model
BioOx Media
Initial
Dosage
BioOx Media
Weekly
Dosage
BioOx Media
weekly
COVID Dosage
BioOx 85
250ml
+30 ml / week
+60 ml / week
BioOx 300
600 ml
+60 ml / week
+120 ml / week
BioOx 650
1250 ml
+120 ml / week
+240 ml / week
BioOx 5000
3000 ml
+240 ml / week
+480 ml / week
Monthly Dosages
Model
BioOx Media
Initial
Dosage
BioOx Media
Monthly
Dosage
BioOx Media
Monthly
COVID Dosage
BioOx 85
250ml
+125 ml / month
+250 ml / month
BioOx 300
600 ml
+250 ml / month
+500 ml / month
BioOx 650
1250 ml
+500 ml / month
+1000 ml / month
BioOx 5000
3000 ml
+1000 ml / month
+2000 ml / month
Weekly Dosages
(Recommended)
WARNING: Choose either WEEKLY or MONTHLY routine. DO NOT USE BOTH.
PLEASE MAKE SURE TO ONLY FOLLOW THE SCHEDULE FOR YOUR MODEL NO.
USING A LOW DOSAGE CAN RESULT IN SUB-OPTIMAL PERFORMANCE.
USING TOO HIGH A DOSAGE WILL NOT ADVERSELY AFFECT PERFORMANCE.

ADDING BIOOX NATURAL MEDIA
MAINTAINING YOUR UNIT!
BioOx Reactor 85
of12 15
Add BioOx Natural Media to your unit according to the dosage schedule above. We recommend keeping a log
of the dates you add BioOx Media to your unit. Use only BioOx® Natural Media. To order BioOx Media, call Air
& Water Solutions at [phone] or email us at [email protected].
To add BioOx® Natural Media to your Reactor unit:
1. Shake bottle containing BioOx® Natural Media well.
2. BioOx can be added directly to unit or can be added to water before pouring into unit.
3. Pour BioOx Media into unit’s air/water inlet. Be sure not to overflow reservoir when adding with water.
4. Be sure pump and fan are running.
(ONLINE MAINTENANCE VIDEO AVAILABLE AT: https://bit.ly/2HkhhDZ )
Depending on your particular indoor air quality, we recommend cleaning your BioOx Clean Air System every 2-6
months. (In heavily contaminated areas, clean every month). Accumulation of sludge and particles in the
reservoir can cause damage to the pump and lower the unit’s cleaning ability. Clogged openings in the water
box can cause a water overflow.
To maintain your unit: Check water level daily. Add BioOx Natural Media monthly. Clean regularly.
To clean your unit:
1. Unplug the unit: both fan and pump from electrical power.
2. Remove fan assembly and set aside to clean
blades.
3. Wipe blades with a soft brush or damp cloth. Do not
spray water or cleaner directly on the fan motor.

BioOx Reactor 85
of13 15
6. Gently lift pump out of core pipe.
(Be careful not to damage core pipe when lifting.)
7. Clean the head of the pump under running water.
Wipe with cloth if needed.
8. Run water through the water line, clearing any
buildup.
4. Lift out air/water inlet tray by gently squeezing openings.
Wipe or wash with damp cloth.
5. Disconnect the pump line from the tee connection fitting.
(You may have to twist side-to-side as you’re pulling the
fitting apart)
9. Remove tee connection and run under water to clean.

12. Reassemble, fill with water, add BioOx Natural Media, and start up.
TROUBLESHOOTING FOR THE BIOOX CLEAN AIR
SYSTEM
PREPARING FOR AN EXTENDED LEAVE
When leaving for a few days: disconnect pump and fan from electricity (turn off).
When not in use for a week or longer: disconnect fan and pump from electricity and drain out water from the
reservoir.
When not in use for several months: disconnect from electricity and drain out water from reservoir. Clean unit and
allow to dry. You can store the BioOx Clean Air System for years in this manner. When ready to use, refill with water,
add BioOx Natural Media and startup.
BioOx Reactor 85
of14 15
10. Loosen debris accumulation in water box with
brush. (It is best to remove debris into drain or
garbage so that it does not re- clog the openings
on the water box.
11. Rinse reservoir with water and drain debris.
If water flow slows or ceases OR if water consumption decreases to almost nothing: check for a malfunctioning
pump or for clogged openings on the water circulation tray. This indicates that the unit needs cleaning.
To check if the pump is working:
1. Unplug the water pump and the fan from electrical outlet.
2. Lift off fan assembly.
3. Plug water pump in and look into water box to see if water is flowing.

CONTACT INFORMATION
BioOx Reactor 85
of15 15
Questions or comments regarding the
BioOx Clean Air System should be
directed to:
Air & Water Solutions, Inc.
P.O. Box 627
Nutley, New Jersey 07110
301-246-0151
[email protected]
www.bioox.us
