Biostar A880G User guide

A880GU3Z/A880GZ UEFI BIOS Manual
i
UEFI BIOS Setup...................................................................................... 1
1 Main Menu ............................................................................................. 3
2 Advanced Menu...................................................................................... 4
3 Chipset Menu ....................................................................................... 18
4 Boot Menu............................................................................................. 26
5 Security Menu ...................................................................................... 28
6 Performance Menu .............................................................................. 29
7 Exit Menu ............................................................................................. 37

A880GU3Z/A880GZ UEFI BIOS Manual
1
UEFI BIOS Setup
Introduction
The purpose of this manual is to describe the settings in the AMI UEFI BIOS Setup
program on this motherboard. The Setup program allows users to modify the basic
system configuration and save these settings to NVRAM.
UEFI BIOS determines what a computer can do without accessing programs from a
disk. This system controls most of the input and output devices such as keybo ard,
mouse, serial ports and disk drives. BIOS activates at the first stage of the booting
process, load ing and executing the operating s ystem. Some add itional features, such
as virus and password pro tectio n or chipset fine-tuning options are also included in
UEFI BIOS.
The rest of this manual will to guide you through the options and settings in UEFI
BIOS Setup.
Plug and Play Support
This AMI UEF I BIOS supports the Plug and Play Vers ion 1.0A specificatio n.
EPA Green PC Support
This AMI UEF I BIOS s upports Version 1.03 of the EPA Green PC specification.
ACPI Support
AMI ACP I UEFI BIOS suppo rt Version 1.0/2. 0 of Advanced Configuration and
Power interface specification (ACPI). It provides ASL code for power
management and device configuration capabilities as defined in the ACPI
specification, developed by Microsoft, Intel and Toshiba.
PCI Bus Support
This AMI UEFI BIOS also suppo rts Vers ion 2.3 of the Intel PCI (Peripheral
Component Interconnect) local bus specification.
DRAM Support
DDR3 SDRAM (Double Data Rate III Synchronous DRAM) is supported.

A880GU3Z/A880GZ UEFI BIOS Manual
2
Supported CPUs
This AMI UEF I BIOS s uppo rts the Intel CPU.
Using Setup
When starting up the co mp uter, press
<Del> during the Power-On Self-Test
(POST) to enter the UEFI BIOS setup
utility.
In the UEFI BIOS setup utility, you will
see General Help description at the top
right corner, and this is providing a brief
description of the selec ted item.
Navigation Keys for that particular menu
are at the bottom right corner, and you can
use thes e keys to select item and change
the settings.
Notice
zThe default UEFI BIOS settings apply for most conditions to ensure optimum
performance of the motherboard. If the system becomes unstable after changing
any settings, please load the default settings to ensure s ystem’s compatibility and
stability. Use Load Setup Default under the Exit Menu.
zFor better system performance, the UEFI BIOS firmware is being continuously
updated. The UEFI BIOS information d escrib ed in this manual is fo r your reference
only. The actual UEFI BIOS information and settings on board may be slightly
different from this manual.
zThe content of this manual is subject to be changed without notice. We will not be
responsible for any mistakes fo und in this user’s manual and any s ystem damage that
may b e c aused by wro ng-settings.

A880GU3Z/A880GZ UEFI BIOS Manual
3
1 Main Menu
Once you enter AMI UEFI BIOS Setup Utility, the Main Menu will appear on the
screen providing an overview of the basic system information.
BIOS Information
Shows s ystem information including UEFI BIOS version, Project Code, Model
Name, Build Date, etc.
Total Memor y
Shows s ystem memory s ize, VGA shard memory will be excluded.
System Date
Set the system date. Note that the ‘Day’ automatically changes when you set the
date.
System Time
Set the s ystem internal cloc k.

A880GU3Z/A880GZ UEFI BIOS Manual
4
2 Advanced Menu
The Advanced Menu allows you to configure the settings of CPU, Super I/O, Power
Management, and other system devices.
Notice
zBeware of that setting inappropriate values in items of this menu may cause
system to malfunction.
PCI Subs ystem Settings

A880GU3Z/A880GZ UEFI BIOS Manual
5
PCI ROM Priority
In case of multiple option ROMs (Legacy and EFI Compatible), this item specifies
what PCI Optio n ROM to launc h
Options: Legacy ROM (Default) / EFI Compatible ROM
PCI Latency Timer
This item s ets the value to be programmed into PCI Latency Timer Register.
Options: 32 PCI Bus Clocks (Default) / 64 PCI Bus Clocks / 96 PCI Bus Clocks /
128 PCI Bus Clocks / 160 PCI Bus Clocks / 192 PCI Bus Clocks / 224
PCI Bus Clocks / 248 PCI Bus Clocks
VGA Palette Snoop
This item enables or disables VGA Palette Registers Snooping.
Options: Disabled (Default) / Enabled
PERR# Generation
This item enables or dis ables PCI Device to generate PERR#.
Options: Disabled (Default) / Enabled
SERR# Generation
This item enables or dis ables PCI Device to generate SERR#.
Options: Disabled (Default) / Enabled

A880GU3Z/A880GZ UEFI BIOS Manual
6
PCI Express Settings
Relaxed Ordering
This item enables or disables PCI Express Device Relaxed Ordering.
Options: Disabled (Default) / Enabled
Extended Tag
If this item is enabled, the system allows Device to use 8-bit Tag field as a requester.
Options: Disabled (Default) / Enabled
No Snoop
This item enables or disables PCI Express Device No Snoop option.
Options: Enabled (Default) / Disabled
Maximum Payload
This item sets Maximum Payload of PCI Express Device or allows System BIOS to
select the value.
Options: Auto (Default) / 128 Bytes / 256 Bytes / 512 Bytes / 1024 Bytes / 2048
Bytes / 4096 Bytes
Maximum Read Request
This item sets Maximum Read Request Size of PCI Express Device or allows
System BIOS to select the value.
Options: Auto (Default) / 128 Bytes / 256 Bytes / 512 Bytes / 1024 Bytes / 2048
Bytes / 4096 Bytes

A880GU3Z/A880GZ UEFI BIOS Manual
7
ASPM Support
This item sets the ASPM Level: Force LO – Force all links to LO State; Auto –
BIOS auto configures; Dis abled – Dis ables ASPM.
Options: Disabled (Default) / Auto / Force L0s
Extended Synch
If this item is enab led, the system allows generatio n of Extended Sync hro nization
patterns.
Options: Disabled (Default) / Enabled
Link Training Retry
This item defines number of retry attempt. The system will retrain the link if
previous training attempt was unsuccessful.
Options: Disabled (Default) / 2 / 3 / 5
Link Training Timeout (uS)
This item defines number of microsecond. The system will wait before polling “Link
Training” bit in Link Status register. Value range is from 1 to 100 uS.
Options: 100 (Default)
Unpopulated Links
In order to save power, the system will disable unpopulated PCI Express links if this
optio n is s e t “ Dis ab le Link”.
Options: Keep Link ON (Default) / Disable Link
ACPI Settings

A880GU3Z/A880GZ UEFI BIOS Manual
8
Enable Hibernation
This item enab les or d isab les s ystem ability to hibernate (OS/S4 Sleep State). This
option may be not effective in some OSes.
Options: Enabled (Default) / Disabled
ACPI Sleep State
This item selects the highest ACPI sleep state the system will enter when the
SUSPEND button is pressed.
Options: S1 (CP U Stop Clock) (Default) / S3 (Susp end to RAM) / Suspend
Dis abled
Lock Legacy Resources
This item allows you to enable or disable Lock Legacy Resources.
Options: Disabled (Default) / Enabled
Wake system with Fixed Time
This item enables or disables the system to wake on by alarm event. W hen this item
is enabled, the system will wake on the hr::min::sec specified.
Options: Disabled (Default) / Enabled
Wake up date
You can choose which date the system will boot up.
Wake up hour / Wake up minute / Wake up second
You can c hoose the system boot up time, input ho ur, minute and second to specify.
USB Device Wakeup from S3/S4
This item allows you to enable or disabled the US B res ume from S3/S4 function.
Options: Disabled (Default) / Enabled
PME Wake up from S5
The item enab les the system to wake fro m S5 using P ME event.
Options: Disabled (Default) / Enabled

A880GU3Z/A880GZ UEFI BIOS Manual
9
Ring-In Wake up from S5
This item enables the system to wake from S5 using Ring-In event.
Options: Disabled (Default) / Enabled
PS2 Keyboard PowerOn
This item allows you to control the keyboard power on function.
Options: Disabled (Default) / Any Key / Stroke Key / Specific Key
Stroke Keys Selected
This item will show only when Keyboard PowerOn is s et “Stroke Key.”
Options: Wake Key (Default) / Power Key / Ctrl+F1 / Ctrl+F2 / Ctrl+F3 /
Ctrl +F4 / Ctrl+F5 / Ctrl+F6
Specific Key Enter
This item will s how only when Keyboard PowerOn is set “Specific Key.” Press
Enter to set Specific key.
PS2 Mouse PowerOn
This item allows you to control the mouse power on function.
Options: Disabled (Default) / Enabled
CPU Configuration

A880GU3Z/A880GZ UEFI BIOS Manual
10
Limit CPUID Max imum
When the computer is booted up, the operating system executes the CPUID
instruction to identify the processor and its capabilities. Before it can do so, it must
first query the processor to find out the highest input value CPUID recognizes. This
determines the kind of basic information CPUID can provide the operating system.
Options: Disabled (Default) / Enabled
PowerNow
This item allows you to enable or disable the PowerNow power saving technology.
Options: Enabled (Default) / Disabled
C1E
Enabling this feature will let your system utilize the AMD specific ACPI states to
save power consumption.
Options: Disabled (Default) / Enabled
SVM
This item allows you to enable AMD virtualization in CPU. This s ecure virtual mode
will let your run multiple OS (guest) on the same physical hardware by decoupling
OS and physical hardware with the hypervisor layer.
Options: Enabled (Default) / Disabled
Core C6 State
This item enables or disables Core C6 State. This feature will reduce power
consumed by CPU.
Options: Enabled (Default) / Disabled
Core per for mance boo st
This item enables or disables core performance boost.
Options: Enabled (Default) / Disabled
Core Leveling
This item set CPU Downcoring. When this item is set “Manual,” CPU Computer
Units can be adjustable.
Options: Auto (Default) / Manual

A880GU3Z/A880GZ UEFI BIOS Manual
11
SATA/IDE Configuration
The BIOS will automatically detect the presence of SATA devic es. There is a
sub-menu for each SATA device. Select a device and press <Enter> to enter the
sub-menu for detailed options.
.
USB Configuration

A880GU3Z/A880GZ UEFI BIOS Manual
12
Legacy USB Support
This item determines if the BIOS should provide legacy support for USB devices
like the keyboard, mouse, and USB drive. This is a useful feature when using such
USB devices with operating systems that do not natively support USB (e.g.
Microsoft DOS or Windows NT).
Options: Enabled (Default) / Disabled / Auto
EHCI Hand-Off
This is a workaround for OSes without EHCI hand-off support. The EHCI ownership
change should be claimed by EHCI driver.
Options: Disabled (Default) / Enabled
USB transfer time-out
This item sets the time-out value for Control, Bulk, and Interrupt transfers.
Options: 20 sec (Default) / 1 sec / 5 sec / 10 sec
Device reset time-out
This item sets USB mass storage device Start Unit command time-out.
Options: 20 s ec (Default) / 10 s ec / 30 s ec / 40 sec
Device power-up delay
This item sets maximum time which the device will take before it properly reports
itself to the Host Controller.
Options: Auto (Default) / Manual
Device power-up delay in seconds
Delay range is 1 ~ 40 seconds, in one second incremens.
Options: 5 (Default)

A880GU3Z/A880GZ UEFI BIOS Manual
13
SMART FAN Control
CPU Smart FAN
This item allows you to control the CPU Smart Fan function.
Options: Disabled (Default) / Auto / 4Pin / 3Pin
CPU FAN Calibrate
Press [ENTER] to calibrate CPU FAN.
Control Mode
This item provides several operation modes of the fan.
Options: Quiet / Aggressive / Manual
Fan Ctrl OFF(℃)
When CPU temperature is lower than this value, the CPU fan will keep lowest RP M.
Options: 10 (℃) (default)
Fan Ctrl On(℃)
When CPU temperature is higher than this value, the CPU fan controller will turn on.
Options: 20 (℃) (Default)

A880GU3Z/A880GZ UEFI BIOS Manual
14
Fan Ctrl Start Value
This item sets CPU FAN Start Speed Value.
Options: 50 (Default)
Fan Ctrl Sensitive
The bigger the numeral is, the higher the FAN speed is.
Options: 30 (Default)
Super IO Configuration
Restore AC Power Loss
This setting specifies how your system should behave after a power fail or interrupts
occurs. Power Off: Leaving the system in power-off status after power recovers.
Power O N: Po we ring o n the s ystem immed ia tely when po wer retur ns. Last S tat e: 1.
Leaving the system in power-off if the system shuts down at DC off status; 2.
Powering on the system immediately if the system shuts down at DC on status.
Options: Power Off (Default) / Power On / Last State

A880GU3Z/A880GZ UEFI BIOS Manual
15
Serial Port 0 Configuration
Serial Port
This item enables or d isables S erial Port (COM).
Options: Enabled (Default) / Disabled
Change Settings
This item s elects an optimal setting for Super IO device.
Options: Auto (Default) / IO= 3F 8h; IRQ=4 / IO=3F8h; IRQ=3,4, 5, 6,7,10, 11,12 /
IO=2F8h; IRQ=3,4, 5,6,7,10,11,12 / IO=3E8h; IRQ=3,4,5,6,7,10,11,12 /
IO=2E8h; IRQ=3,4,5,6,7,10,11,12
Parallel Por t Configuration

A880GU3Z/A880GZ UEFI BIOS Manual
16
Parallel Port
This item enables or disables Parallel Port (LPT/LPTE).
Options: Enabled (Default) / Disabled
Change Settings
This item allows you to select an optimal setting for Super IO device.
Options: Auto (Default) / IO=378h; IRQ=5 / IO=378h; IRQ=5, 6, 7, 9, 10, 11, 12 /
IO=278h; IRQ=5, 6, 7, 9, 10, 11, 12 / IO=3BCh; IRQ=5, 6, 7, 9, 10, 11,
12
Device Mode
This item allows you to determine how the parallel port should function.
Options: Standard Parallel Port Mode (Default) (Using Parallel port as Standard
Printer Port) /
EPP Mode (Using Parallel Port as Enhanced Parallel Port) /
ECP Mode (Us ing Parallel port as Extended Capabilities Port) /
ECP Mode & EPP Mode (Using Parallel port as ECP & EPP mode)
CIR Controller Configuration
CIR Controller
This item enables or disables CIR Controller.
Options: Disabled (Default) / Enabled
Change Settings
This item s elects an optimal setting for Super IO device.
Options: Auto (Default)

A880GU3Z/A880GZ UEFI BIOS Manual
17
H/W Monitor
Shutdown Temperature
This item allows you to set up the CPU shutdown Temperature.
Options: Disabled (Default) / 70 /158 / 75 /167 / 80 /176 / 85 /185℃℉℃℉℃℉℃℉
/ 90 /194℃℉

A880GU3Z/A880GZ UEFI BIOS Manual
18
3 Chipset Menu
This section describes configuring the PCI bus system. PCI, or Personal Computer
Interconnect, is a system whic h allows I/O devic es to operate at speeds nearing the
speed of the CPU itself uses when communicating with its own special components.
Notice
zBeware of that setting inappropriate values in items of this menu may cause
system to malfunction.
AMD 880 Configuration

A880GU3Z/A880GZ UEFI BIOS Manual
19
Internal Graphics Configuration
Internal Graphics Mode
This item allows you to select the memory mode used for internal graphics devic e.
Opt io ns: UMA (Default) / Dis able
UMA Frame Buffer Size
This item allows you to choose the UMA frame buffer size for internal graphics.
Options: Auto (Default) / 32MB / 64MB / 128MB / 256MB / 512MB/1024MB
GFX Engine Clock Override
This item allows you to control the internal GFX engine clock override function.
Options: Disabled (Default) / Enabled
GFX Engine Clock
This item allows you to set the internal GFX engine c lock.
Options: 560 (Default) / Min: 150, Max: 1200
Surround View
This item allows you to control the Surround View Function.
Options: Auto (Default) / Dis abled / Enabled
FB Location
This item allows you to set the FB-DIMM location.
Options: Above 4G (Default) / Under 4G
AMD 880 HD Audio
This item allows you to control the northbridge HD azalia (HDMI audio) function.
Options: Enabled (Default) / Disabled
