Layout of M7NCD Ultra
※NOTE: ●represents the first pin.

2
Component Index
A. 5V/5VSB Selection for Keyboard L. Front USB Header (JUSB1)
and mouse (JKBV1) M. Front USB Header (JUSB2)
B. Power Source Selection for USB N. Power Source Selection for USB
(JUSBV2) (JUSBV4)
C. Back Panel Connector O. Wake On LAN Header (JWOL1)
D. Frequency Selection (JCLK3) P. System FAN Header (JSFAN1)
E. North Bridge Fan Header (JNFAN1) Q. Clear CMOS Function (JCMOS)
F. Accelerated Graphics Port Slot R. Case Open Connector (JC1)
(AGP1) S. IDE Connectors (IDE1-2)
G. Front Audio Header (JF_AUDIO1) T. Floppy Disk Connector (FDD1)
H. PCI BUS Slots (PCI1-5) U. ATX Power Connector (JATXPWER1)
I. CD-ROM Audio-In Header (JCDIN1) V. DIMM Modules (DIMMA1)
J. Front Panel Connector (JPANEL1) W. DIMM Modules (DIMMB1-2)
K. Power Source Selection for USB X. CPU Fan Connector (JCFAN1)
(JUSBV1) Y. Serial ATA Connector (JSATA1-2)
a1. S/PDIF Out Connector (J_SPDIF1)

3
English
M7NCD Ultra Features
A. Hardware
CPU
Provides Socket-462.
Supports the AMD® processor up to XP 3200+.
Front Side Bus at 266/333/400 MHz.
Chipset
North Bridge: nFORCE2 SPP.
South Bridge: MCP.
High Speed 800Mb/s Hyper-Transport interface to the MCP.
Main Memory
Supports up to 3 DDR devices.
Supports 266/333/400MHz (without ECC) DDR devices.
High performance 128 bit DDR400 Twin Bank Memory Architecture.
Maximum memory size of 3GB.
Super I/O
Chip: Winbond W83627HF.
Slots
Five 32-bit PCI bus master slots.
One AGP: AGP3.0 8X interface at 533Mb/s.
Supports AGP 2X, 4X, 8X.
On Board IDE
Supports four IDE disk drives.
Supports PIO Mode 4, Master Mode and Ultra DMA 33/66/100/133 Bus Master
Mode.
Serial ATA Chip
Chip: VIA VT6420.
Supports 2 Serial ATA (SATA) ports.
Compliant with SATA 1.0 specification.
Data transfer rates up to 150 Mb/s.
On Board AC’97 Sound Codec
Chip: ALC650.
Compliant with AC’97 specification.
AC99 2.2/2.3 interface.
Supports 6 channels.

4
On Board Peripherals
a.Rearside
2 serial ports.
1 parallel port. (SPP/EPP/ECP mode)
Audio ports in horizontal position.
1 LAN port. (optional)
PS/2 mouse and PS/2 keyboard.
2 USB2.0 ports.
b.FrontSide
1 floppy port supports 2 FDDs with 360K, 720K, 1.2M, 1.44M and 2.88Mbytes.
4 USB2.0 ports.
1 front audio header.
Dimensions
ATX Form Factor: 24.4cm X 30.4cm (W X L)
B. BIOS & Software
BIOS
Award legal Bios.
APM1.2.
ACPI.
USB Function.
Software
Supports CPU SaviorTM, 9th TouchTM, FLASHER™, WinFlasherTM, StudioFun!TM
(optional) and WatchdogTM.
Offers the highest performance for Windows 98 SE, Windows 2000, Windows Me,
Windows XP, SCO UNIX etc.
Package contents
HDD Cable X1
FDD Cable X1
User’s Manual X1
USB Cable X1 (optional)
Rear I/O Panel for ATX Case X1 (optional)
Fully Setup Driver CD X1
StudioFun! Application CD X1 (optional)
Serial ATA Cable X1 (optional)
S/PDIF Out Cable X1 (optional)

5
How to setup Jumper
The illustration shows how jumpers are setup. When the Jumper cap is placed on pins, the
jumper is “close”. If no jumper cap is placed on the pins, the jumper is ”open”. The
illustration shows a 3-pin jumper whose pin 1and 2 are “close” when jumper cap is placed
on these 2 pins.
Jumper close Jumper open Pin1-2 close
CPU Installation
Step1: Pull the lever sideways away from the socket and then raise the lever up to a
90-degree angle.
Step2: Look for the white dot/cut edge. The white dot/cut edge should point towards the
lever pivot. The CPU will fit only in the correct orientation.
Step3: Hold the CPU down firmly, and then close the lever.
Step4: Put the CPU fan on the CPU and buckle it. Connect the CPU fan power cable to
the JCFAN1. This completes the installation.
Step1 Step2 Step3 Step4

6
CPU Fan Header: JCFAN1
Pin No. Assignment
1 Ground
2 +12V
1
JCFAN1 3 Sense
System Fan Header: JSFAN1
Pin No. Assignment
1 Ground
2 +12V
1
JSFAN1 3 Sense
North Bridge Fan Header: JNFAN1
Pin No. Assignment
1 Ground
1
JNFAN1 2 +12V
DDR DIMM Modules: DIMMB1-2, DIMMA1
For Dual-channel DDR (128-bit) high performance, at least 2 or more
DIMM modules must be installed. (It has to be the combination of
DIMMA and DIMMB.) With only one DIMM installed, the memory
performs only at 64-bit.
DRAM Access Time: 2.5V Unbuffered DDR 266/333/400 MHz Type required.
DRAM Type: 64MB/ 128MB/ 256MB/ 512MB/ 1GBDIMM Module (184 pin)
Total Memory Size with Unbuffered DIMMs
DIMM Socket
Location DDR Module Total Memory Size (MB)
DIMMB1 64MB/128MB/256MB/512MB/1GB
*1
DIMMB2 64MB/128MB/256MB/512MB/1GB
*1
DIMMA1 64MB/128MB/256MB/512MB/1GB
*1
Max is
3GB
***Only for reference***

7
Installing DDR Module
1. Unlock a DIMM slot by pressing the
retaining clips outward. Align a DIMM on the slot
such that the notch on the DIMM matches the
break on the slot.
2. Insert the DIMM firmly and vertically into the slot
until the retaining chip snap back in place and the
Dimm is properly seated.
Jumpers, Headers, Connectors & Slots
Floppy Disk Connector: FDD1
The motherboard provides a standard floppy disk connector that supports 360K,
720K, 1.2M, 1.44M and 2.88M floppy disk types. This connector supports the
provided floppy drive ribbon cables.
Hard Disk Connectors: IDE1/ IDE2
The motherboard has a 32-bit Enhanced PCI IDE Controller that provides PIO
Mode 0~4, Bus Master, and Ultra DMA 33/ 66/ 100/ 133 functionality. It has two
HDD connectors IDE1 (primary) and IDE2 (secondary).
The IDE connectors can connect a master and a slave drive, so you can connect
up to four hard disk drives. The first hard drive should always be connected to
IDE1.
Peripheral Component Interconnect Slots: PCI 1-5
This motherboard is equipped with 5 standard PCI slots. PCI stands for Peripheral
Component Interconnect, and it is a bus standard for expansion cards. This PCI
slot is designated as 32 bits.
Accelerated Graphics Port Slot: AGP1
Your monitor will attach directly to that video card. This motherboard supports
video cards for PCI slots, but it is also equipped with an Accelerated Graphics Port
(AGP). An AGP card will take advantage of AGP technology for improved video
efficiency and performance, especially with 3D graphics.
Serial ATA Connector: JSATA1/ JSATA2
The motherboard has a PCI to SATA Controller with 2 channels SATA interface.
It satisfies the SATA 1.0 spec and can transfer data with 150Mb/s speed.

8
Pin Assignment Pin Assignment
1 Ground 2 TX+
3 TX- 4 Ground
5 RX- 6 RX+
1
23
4
56
7
JSATA1/ JSATA2 7 Ground
Power Connectors: JATXPWER1
PIN Assignment PIN Assignment
1 +3.3V 11 +3.3V
2 +3.3V 12 -12V
3 Ground 13 Ground
4 +5V 14 PS_ON
5 Ground 15 Ground
6 +5V 16 Ground
7 Ground 17 Ground
8 PW_OK 18 -5V
9 +5V_SB 19 +5V
20
11
10
1
JATXPWER1
10 +12V 20 +5V
Front USB Header: JUSB1/ JUSB2
Pin Assignment Pin Assignment
1 +5V(fused) 2 +5V(fused)
3 USBP4- 4 USBP5-
5 USBP4+ 6 USBP5+
7 Ground 8 Ground
2
1
10
9
JUSB1/2 9 KEY 10 NA
Wake On LAN Header: JWOL1
Pin Assignment
1 +5V_SB
2 Ground
1
JWOL1 3 Wake up

9
Front Panel Connector: JPANEL1
Power Source Selection for Keyboard/ Mouse: JKBV1
JKBV1 Assignment Description
1
3
Pin 1-2 close
+5V
+5V for keyboard and mouse
1
3
Pin 2-3 close
+5V Standby
Voltage
PS/2 Mouse and PS/2 Keyboard are
powered with +5V standby voltage
Note: In order to power-on keyboard and mouse function, “JKBV1” jumper
cap should be placed on pin 2-3.
SPK
PWR_LED
HLED
SLP
RST
224
IR
123
IRON/OFF
(+) (-)
(+) (-)(+)
Pin Assignment Function Pin Assignment Function
1 +5V 2 Sleep Control
3 NA 4 Ground Sleep
Button
5 NA 6 NA NA
7 Speaker
Speaker
Connector
8 Power LED (+)
9 HDD LED (+) 10 Power LED (+)
11 HDD LED (-) Hard Drive
LED 12 Power LED (-)
POWER
LED
13 Ground 14 Power Button
15 Reset Control Reset
Button 16 Ground Power-on Button
17 NA 18 KEY
19 NA 20 KEY
21 +5V 22 Ground
23 IRTX
IrDA
Connector
24 IRRX
IrDA
Connector
JPANEL1

10
Power Source Selection for USB: JUSBV1/ JUSBV2/ JUSBV4
JUSBV1/JUSBV2/
JUSBV4 Assignment Description
1 3
Pin 1-2 close
+5V JUSBV1: 5V for JUSB1 port
JUSBV2: 5V for JUSBLAN1 port
JUSBV4: 5V for JUSB2 port
1 3
Pin 2-3 close
+5V Standby
Voltage JUSBV1: JUSB1 port powered with
standby voltage of 5V
JUSBV2: JUSBLAN1 port powered with
standby voltage of 5V
JUSBV4: JUSB2 port powered with
standby voltage of 5V
Note: 1. In order to power-on USB devices function, “JUSBV1/JUSBV2/
JUSBV4” jumper cap should be placed on pin 2-3 respectively.
2. For S3 mode, “JUSBV1/ JUSBV2/ JUSBV4” jumper cap should be
placed on pin 2-3 respectively.
Clear CMOS Jumper: JCMOS
JCMOS Assignment
1
3
Pin 1-2 Close
Normal Operation (default)
1
3
Pin 2-3 Close
Clear CMOS Data
The following procedures are for resetting the
BIOS password. It is important to follow these
instructions closely.

11
※Clear CMOS Procedures:
1. Remove AC power line.
2. Set the jumper to “Pin 2-3 Close”.
3. Wait for five seconds.
4. Set the jumper to “Pin 1-2 Close”.
5. Power on the AC.
6. Reset your desired password or clear the CMOS data.
Case Open Connector: JC1
Pin Assignment
1 Case Open Signal
1
JC1 2 Ground
CD-ROM Audio-In Header: JCDIN1
Pin Assignment
1 Left Channel Input
2 Ground
3 Ground
1
JCDIN1
4 Right Channel Input
Front Panel Audio Header: JF_AUDIO1
10
92 1
JF_AUDIO1
Pin Assignment Pin Assignment
1 Mic In/ Center 2 Ground
3 Mic Power/ Bass 4 Audio Power
5 Right Line Out/ Speaker
Out Right 6 Right Line Out/ Speaker
Out Right
7 Reserved 8 Key
9 Left Line Out/ Speaker
Out Left 10 Left Line Out/ Speaker Out Left
Digital Audio Connector: J_SPDIF1
Pin Assignment
1 +5V
2 SPDIF_OUT
1
J_SPDIF1 3 Ground

12
System Operation Mode: JCLK3
Note: When overclock function failed and system is unable to boot-up, please
follow the instruction below:
1. Turn off the system.
2. Closed the JCLK3 jumper.
3. Turn on the system.
4. Enter CMOS setup menu and load defaults settings.
5. Turn off the system.
6. Open the JCLK3 jumper.
7. Turn on the system.
Back Panel Connectors
JCLK3 Assignment
1
Pin 1-2 Close
User Mode (default)
(133/ 166/ 200 MHz)
1
Pin 1-2 Open
Safe mode
(100 MHz)

13
Deutsch
Spezifikationen von M7NCD Ultra
A. Hardware
CPU
Unterstützung für Sockel 462.
Unterstützung für den AMD® Prozessor bis zu XP 3200+.
FSB mit 266/333/400 MHz.
Chipsatz
Northbridge: nFORCE2 SPP.
Southbridge: MCP.
Hauptspeicher
Unterstützung für 3 DDR Geräte.
Unterstützung für 266/333/400MHz (ohne ECC) DDR Geräte.
128-Bit High-Performance DDR400 mit der Twin-Bank Architektur.
Die maximale Speichergröße ist 3GB.
Super I/O
Chip: Winbond W83627HF.
Serial ATA Chip
Chip: VIA VT6420.
Unterstützung für zwei Serial-ATA-Ports (SATA).
Entspricht der Spezifikation von SATA 1.0.
Datenübertragung bis auf maximal 1.5 Gb/s.
Slots
Fünf 32-Bit PCI-Bus-Slots.
Ein AGP-Slot: AGP3.0 8X Interface bei 533Mb/s.
Unterstützung für AGP2.0 2X, 4X und 8X.
Onboard-IDE
Unterstützung für vier IDE Diskettenlaufwerke.
Unterstützung für PIO Modus 4, Master Modus und Ultra DMA 33/66/100/133 Bus
Master Modus.
On-board AC’97 Sound Codec
Chip: ALC650.
Entspricht die Spezifikation von AC’97.
AC99 2.2/2.3 Interface.
Unterstützung für 6-Kanal.

14
Onboard-Peripheriegeräte
a.Rückwand
2 Seriell-Ports.
1 parallele Schnittstelle. (SPP/EPP/ECP-Modus)
1 horizontales Audio-Port.
1 LAN-Port. (optional)
Unterstützung für PS/2-Maus und PS/2-Tastatur.
2 USB2.0-Ports.
b.Vorderseite
1 Floppy-Port mit Unterstützung für 2 Diskettenlaufwerke.(360KB, 720KB, 1.2MB,
1.44MB und 2.88MB)
4 USB2.0-Ports.
1 Audio-Header für die Vonderseite
Abmessungen
ATX Form-Factor: 24.4 X 30.4cm (W X L)
B. BIOS & Software
BIOS
Award legal Bios.
APM1.2.
ACPI.
USB Funktion.
Software
Unterstützung für CPU SaviorTM, 9th TouchTM, FLASHER™, WinFlasherTM,
StudioFun!TM (optional) and WatchdogTM.
Unterstützung für die am meisten verbreiteten Betriebsysteme wie Windows 98SE,
Windows 2000, Windows ME, Windows XP and SCO UNIX usw.
Verpackungsinhalt
HDD Kable X1
FDD Kable X1
Benutzer Handbuch X1
USB Kable X1 (optional)
I/O-Rückwand für ATX Gehäuse X1 (optional)
Treiber CD für Installation X 1
StudioFun! Anwendung CD X1 (optional)
Serial ATA Kable X1 (optional)
S/PDIF Out Kable X1 (optional)

15
Einstellung der Jumper
Die Abbildung verdeutlicht, wie Jumper eingestellt werden. Pins werden durch die
Jumper-Kappe verdeckt, ist der Jumper ”geschlossen”. Keine Pins werden durch die
Jumper-Kappe verdeckt, ist der Jumper “geöffnet”. Die Abbiildung zeigt einen 3-Pin
Jumper dessen Pin1 und Pin2 ”geschlossen“ sind, bzw. es befindet sich eine
Jumper-Kappe auf diesen beiden Pins.
Jumper geschlossen Jumper geöffnet Pin1-2 geschlossen
Installation der CPU
Schritt 1: Ziehen Sie den Hebel seitlich vom Sockel weg. Heben Sie den Hebel dann
in 90-Grad-Winkel nach oben.
Schritt 2: Suchen Sie nach der scharfen Kante, die auf Drehpunkt des Hebels
weisen muss. Die CPU passt nur, wenn sie richtig ausgerichtet ist.
Schritt 3: Drücken Sie die CPU fest in den Sockel und schließen Sie den Hebel.
Schritt 4: SteckenSieIhren CPU-Lüfteraufdie CPU.Schließen SiedieStromversorgungsstecker
fürCPU-Lüfter an JCFAN1 an. Dann beenden Sie die Installation.
Schritt 1 Schritt 2 Schritt 3 Schritt 4

16
CPU-Lüfter Headers: JCFAN1
Pin Belegung
1 Masse
2 +12V
1
JCFAN1 3 Sensor
System-Lüfter Headers: JSFAN1
Pin Belegung
1 Masse
2 +12V
1
JSFAN1 3 Sensor
Northbridge-Lüfter Header: JNFAN1
Pin Belegung
1 Masse
1
JNFAN1 2 +12V
DDR-DIMM-Modules: DIMMB1-2, DIMMA1
Für Dual-Kanal DDR (128-Bit) High-Performance, muss man mindestens
2 oder mehr DIMM-Module installieren. (Es ist unbedingt, daß man DIMMA
mit DIMMB als ein Paar benutzt.) Wenn man nur ein DIMM installiert,
funktioniert der Spreicher nur 64-Bit.
DRAM-Zugriffszeit: 2.5V nicht registrierter DDR 266/333/400 MHz Typ
erforderlich.
DRAM Typen: 64MB/ 128MB/ 256MB/ 512MB/ 1GB DIMM-Module (184-Pin)
Gesamt Speichergröße von nicht registrierter DIMMs
DIMM-Sockel
Standort DDR-Modul Speichergröße
DIMMB1 64MB/128MB/256MB/512MB/1GB
*1
DIMMB2 64MB/128MB/256MB/512MB/1GB
*1
DIMMA1 64MB/128MB/256MB/512MB/1GB
*1
maximal
3GB
**Nur als Referenz***

17
Installation von DDR-Modul
1. Öffnen Sie einen DIMM-Slots, indem Sie
die seitlich Chips nach außen drücken.
Richten Sie das DIMM-Modul so über dem
Slot aus, dass das Modul mit der Kerbe in
den Slot passt.
2. Drücken Sie das DIMM-Modul in den Slot,
bis die seitlichen Clips zuschnappen und
das Modul fest sitzt.
Jumpers, Headers, Anschlüsse & Slots
Diskettenanschluss: FDD1
Das Motherboard enthält einen standardmäßigen Diskettenanschluss, der 360K-,
720K-, 1.2M-, 1.44M- und 2.88M-Disketten unterstützt. Dieser Anschluss
unterstützt die mitgelieferte Bandkabel des Diskettenlaufwerks.
Festplattenanschlüsse: IDE1 und IDE2
Das Mainboard hat einen 32-Bit Enhanced PCI IDE-Controller, der die Modi
PIO0~4, Bus Master sowie die Ultra DMA/33/66/100/133- Funktion zur Verfügung
stellt. Dieser ist mit zweii HDD-Anschlüssen versehen IDE1 (primär) und IDE2
(sekundär).
Die IDE-Anschlüsse können eine Master- und eine Slave-Festplatte verbinden, so
dass bis zu 4 Festplatten angeschlossen werden können. Die erste Festplatte
sollte immer an IDE1 angeschlossen werden.
Peripheral Component Interconnect Slots: PCI1-5
Dieses Motherboard ist mit 5 standardmäßigen PCI-Slots ausgestattet. PCI steht
für Peripheral Component Interconnect und bezieht sich auf einem Busstandard für
Erweiterungskarten, der den älteren ISA-Busstandard in den meisten
Schnittstellen ersetzt hat. Dieser PCI-Slot ist für 32 bits vorgesehen.
Accelerated Graphics Port Slot: AGP1
Ihr Monitor wird direkt an die Grafikkarte angeschlossen. Dieses Motherboard
unterstützt Grafikkarten für PCI-Slots, aber es ist auch mit einem Accelerated
Graphics Port ausgestattet. AGP-Karten verwenden die AGP-Technologie, um die
Wirksamkeit und Leistung von Videosignalen zu verbessern, besonders wenn es
sich um 3D-Grafiken handelt.
Serial ATA Anschlüsse: JSATA1/ JSATA2
Auf diesem Motherboard wird VIA VT6420 als Serial-ATA-Raid-Controller bedient.

18
Dieser Chip bietet zwei Serial-ATA-Kanäle sowie einen Parallel-ATA-Kanal für bis
zu zwei Geräte. Es entspriecht der Speczifikation von SATA 1.0.
Pin Belegung Pin Belegung
1 Masse 2 TX+
3 TX- 4 Masse
5 RX- 6 RX+
1
23
4
56
7
JSATA1/ JSATA2 7 Masse
Anschlüsse für die Vorderseite: JPANEL1
Front USB Header: JUSB1/2
Pin Belegung Pin Belegung
1 +5V(geschmelzt) 2 +5V(geschmelzt)
3 USBP4- 4 USBP5-
5 USBP4+ 6 USBP5+
7 Masse 8 Masse
2
1
10
9
JUSB1/2 9 Schlüsse 10 Kein
SPK
PWR_LED
HLED
SLP
RST
224
IR
123
IRON/OFF
(+) (-)
(+) (-)(+)
Pin Belegung Funktion Pin Belegung Funktion
1 +5V 2 Sleep Control
3 Kein 4 Masse Schlafen-
Knopf
5 Kein 6 Kein Kein
7 Lautsprecher
Lautsprecher
Anschluss
8 Power LED (+)
9 HDD LED (+) 10 Power LED (+)
11 HDD LED (-) Festplatte
LED 12 Power LED (-)
Power-
LED
13 Masse 14 Power-Knopf
15 Reset Control Zurücksetzn-
Knopf 16 Masse Power-On
Knopf
17 Kein 18 Schlüsse Kein Pin
19 Kein 20 Schlüsse
21 +5V 22 Masse
23 IRTX
IrDA-
Anschluss
24 IRRX
IrDA
Anschluss
JPANEL1
