P4 TSP –D2
ENGINEERING VALIDATION TEST REPORT
COVER SHEET
CHANGE CONTROL
Description of Change Revision Sections/Pages Affected Date
Initial Release 1.0 2003/10/04
1.1 2003/10/07
Project: P4TSP-D2
Date: 2003/10/07
Owner: Biostar Group
Contact: TEL: [phone] FAX: [phone]
Home Page: http://www.biostar.com.tw

2
CONTENTS
PRODUCT INFORMATION....................................................................4
Motherboard General Information.....................................................................4
Chipset Details........................................................................................................4
BIOS Details............................................................................................................4
CPU Supports..........................................................................................................4
Memory Supports...................................................................................................4
On-board Features and Devices..........................................................................4
Mechanical...............................................................................................................5
DESIGN REVIEW.....................................................................................7
Mainboard Voltage Measurement......................................................................7
Bus Clock.................................................................................................................7
REQUIRED BIOS DEFAULT SETTINGS.............................................. 8
BIOS FEATURES SETUP..................................................................................8
CHIPSET FEATURES SETUP..........................................................................8
POWER MANAGEMENT SETUP..................................................................8
PnP / PCI CONFIGURATION...........................................................................8
INTEGRATED PERIPHERALS.......................................................................9
PC Health Statues...................................................................................................9
Frequency / Voltage Control...............................................................................9
FUNCTIONALITY..................................................................................10
Setup Installation Test Of Operating System................................................10
Basic On-board Function Test ..........................................................................10
MS-DOS Operating .............................................................................................10
Windows ME Operating.....................................................................................13
Windows2000 Operating....................................................................................16
Windows XP (Home Edition ) Operating......................................................19
Windows XP (Professional ) Operating.........................................................24
Linux (Red Hat 9.0) Operating.........................................................................25
OVER CLOCK TEST ............................................................................. 27
Windows XP Home Edition (FSB:100 MHz)...............................................27
Windows XP Home Edition (FSB:133 MHz)...............................................28
Windows XP Professional (FSB:200 MHz)..................................................29
PERFORMANCE TEST.........................................................................30
Windows ME.........................................................................................................30
Windows 2000 Professional..............................................................................31
Windows XP Professional..................................................................................32
Display Card Performance ....................................................................................33
RELIABILITY TEST..............................................................................34

3
Motherboard General Information...................................................................34
Burn-in Step...........................................................................................................34
HARDWARE COMPATIBILITY LIST................................................35
CPU..........................................................................................................................35
CD-ROM................................................................................................................35
Camera Device......................................................................................................36
DVD-ROM.............................................................................................................36
Display Card..........................................................................................................37
FDD..........................................................................................................................37
HDD.........................................................................................................................38
Joystick....................................................................................................................40
Keyboard ................................................................................................................40
LAN Card...............................................................................................................41
LAN HUB..............................................................................................................41
Memory...................................................................................................................41
Modem Card..........................................................................................................43
Mouse......................................................................................................................43
Monitor....................................................................................................................44
Power Supply.........................................................................................................45
Printer......................................................................................................................45
Scanner....................................................................................................................45
SCSI Card...............................................................................................................46
Sound Card.............................................................................................................46
USB HUB & USB 2.0 DEVICE......................................................................46
ZIP/LS120..............................................................................................................47
SOFTWARE COMPATIBILITY LIST .................................................48
DOS..........................................................................................................................48
Windows.................................................................................................................48
FOUR CORNER TEST...........................................................................49
THERMAL IMAGE TEST..................................................................... 50
Motherboard General Information...................................................................50

4
PRODUCT INFORMATION
Motherboard General Information
Vendor Biostar
Model Number P4TSP-D2
Version Number V1.0/V1.1
Platform AT ATX Micro ATX Flex ATX
Chipset Details
System Chipset Vendor Intel
North Bridge Revision 848P
South Bridge Revision ICH5
Audio Chipset Vendor CMEDIA
Audio Chipset Revision CMI9739A
LAN Chipset Vendor Realtek
LAN Chipset Revision RTL8100C
SATA Chipset ICH5 BIOS Details
BIOS Vendor AMI Award Phoenix Others
BIOS Revision Number 0811BFD
BIOS Memory Size 1M 2M 4M
Flash EPROM BIOS Yes No
CPU Supports
Type CPU CPU Frequency Front Side Bus Comments:
Socket 478 Intel Pentium 4 Max =2600MHZ Max =100MHZ
Socket 478 Intel Pentium 4 Max =3060MHZ Max =133MHZ
Socket 478 Intel Pentium 4 Max =3200MHZ Max =200MHZ
Socket 478 Celeron Max =2800MHZ Max =100MHZ
Memory Supports
Maximum Memory Support SDRAM (MB) DDR 2 (GB)
Number of Memory Slots DIMM 2 . RIMM .
Type of Memory Supported SDRAM RDRAM DDR RAM
Parity Support Yes No
ECC Support Yes No
On-board Features and Devices
No of PCI Full Length Slots 2 3 4 5
AMR Slot Support Yes No
CNR Slot Support Yes No
ACR Slot Support Yes No
Number of Shared Slots 1 None
100/133/200 MHz Front Side Bus Supports Yes No
Dual DDR 400 Support Yes No
PCI v2.2 Compliance Yes No

5
ATA-3 Compliance Yes No
ATAPI Compliance Yes No
Ultra DMA 100 Support Yes No
Ultra DMA 133 Support Yes No
ATA-100 Support Yes No
USB 1.1 Connector Support Yes No
USB 2.0 Connector Support Yes No
AGP (8X/4X) Slot Support Yes No
Support AGP SideBand Addressing Mode Yes No
Power on by LAN Support Yes No
Power on by Ring Support Yes No
Power on by Keyboard Support Yes No
Power on by Mouse Support Yes No
Infrared Support Yes No
Enhanced Parallel Port Yes No
DMI Compliance Yes No
Hardware Monitor Support Yes No
ACPI v1.0B/APM v1.2 Compliance Yes No
On-board Graphics Controller Yes No
On-board Audio Device Hardware AC97 CODEC No
On-board RAID Yes No
Other Function Support
Mechanical
Board Dimensions Length 30.4 cm Width 20.3 cm
Visual Inspection of Soldering Excellent Fair Poor
Visual Inspection of Layout Placement Connectors Quality
Screw Holes Line Up with Case Yes No Excellent Fair Poor
Power Connector placement in PCB Yes No Excellent Fair Poor
DIMM/RIMM Socket placement in PCB Yes No Excellent Fair Poor
CPU Socket placement in PCB Yes No Excellent Fair Poor
FAN Connector placement in PCB Yes No Excellent Fair Poor
FDD Connector placement in PCB Yes No Excellent Fair Poor
IDE Connector placement in PCB Yes No Excellent Fair Poor
Front Panel Connectors in PCB Yes No None Excellent Fair Poor
PS/2 Connectors Line Up in Case Yes No None Excellent Fair Poor
USB Port Connectors Line Up in Case Yes No None Excellent Fair Poor
COM Port Connectors Line Up in Case Yes No None Excellent Fair Poor
Printer Port Connectors Line Up in Case Yes No None Excellent Fair Poor
VGA Port Connectors Line Up in Case Yes No None Excellent Fair Poor
Audio Port Connectors Line Up in Case Yes No None Excellent Fair Poor
Game Port Connectors Line Up in Case Yes No None Excellent Fair Poor
AGP Slot(Card) Line Up in Case Yes No None Excellent Fair Poor

6
PCI Slots(Card) Line Up in Case Yes No None Excellent Fair Poor
AMR Slot(Card) Line Up in Case Yes No None Excellent Fair Poor
CNR Slot(Card) Line Up in Case Yes No None Excellent Fair Poor
ACR Slot(Card) Line Up in Case Yes No None Excellent Fair Poor
Daughter Card Slot in PCB Yes No None Excellent Fair Poor
Wake-on LAN connector in PCB Yes No None Excellent Fair Poor
CD Audio-in Connector in PCB Yes No None Excellent Fair Poor
AUX Audio-in Connector in PCB Yes No None Excellent Fair Poor
Other Jumper in PCB Yes No None Excellent Fair Poor
Comments:

7
DESIGN REVIEW
Mainboard Voltage Measurement
Voltage List Voltage SPEC Voltage Measured Result
Battery Voltage 3.0V 3.03 Pass
Battery Current 7uA 5.4 Pass
+5V 5.0V+-5% 5.02 Pass
+12V 12.0V+-5% 11.32 Pass
-5V -5.0V+-5% -5.0 Pass
-12V -12.0V+-10% -11.62 Pass
+3.3V +3.3V+-5% 3.21 Pass
Bus Clock
Clock Frequency Spec Value (MHz) Measured Value Pass/Fail
CPU and Clock Host FSB 400 Max100 99.6 Pass
FSB 533 130.7~133.3 132.6 Pass
FSB 800 198.941~200.06 199.2 Pass
Memory Clock 133 133.3 Pass
166 166.1 Pass
200 200.0 Pass
AGP Clock 66.67 66.67 Pass
PCI Clock 30.03~33.3 33.33 Pass
USB Clock Min 48 48.08 Pass
Reference Clock 14.31818 14.33 Pass
Clock Timing Spec Value Measured Value Pass/Fail
CPU Clock High Time FSB 400 3.94 ~ 6.12ns 5.04 Pass
FSB 533 2.96 ~ 4.59ns 3.74 Pass
CPU Clock Low Time FSB 400 3.94 ~ 6.12ns 5.00 Pass
FSB 533 2.96 ~ 4.59ns 3.78 Pass
CPU Clock Rising Time FSB 400 175~700ps 400 Pass
FSB 533 175~700ps 420 Pass
FSB 800 175~700ps 300 Pass
CPU Clock Falling Time FSB 400 175~700ps 420 Pass
FSB 533 175~700ps 220 Pass
FSB 800 175~700ps 320 Pass
PCI Clock High Time Min 12ns 14.2 Pass
PCI Clock Low Time Min 12ns 13.48 Pass
PCI Clock Rising Time Max 3ns 1.36 Pass
PCI Clock Falling Time Max 3ns 1.28 Pass
Comments:

8
REQUIRED BIOS DEFAULT SETTINGS
Lists Specification Result
BIOS FEATURES SETUP
Boot Seq / Floppy Setup Press Enter Pass
Cache Setup Press Enter Pass
Virus Warning Disabled Pass
Hype-Threading Technology Enabled Pass
Quick Power On Self Test Enabled Pass
Boot Up Numlock Status ON Pass
Gate A20 Option Fast Pass
Typematic Rate Setting Disabled Pass
Security Option Setup Pass
MPS Version Control For OS 1.4 Pass
OS Select For DRAM>64MB Non-OS2 Pass
Summary Screen Show Disabled Pass
CHIPSET FEATURES SETUP
DRAM Timing Selectable By SPD Pass
Memory Frequency For Auto Pass
System BIOS Cacheable Enabled Pass
Video BIOS Cacheable Enabled Pass
Memory Hole At 15M-16M Disabled Pass
Delay Prior to Thermal 16 Min Pass
AGP Aperture Size (MB) 128 Pass
Init Display First AGP Pass
POWER MANAGEMENT SETUP
ACPI Function Enabled Pass
ACPI Suspend Type S1 (POS) Pass
Power Management User Define Pass
Video Off Method DPMS Pass
Video Off In Suspend Yes Pass
Suspend Type Stop Grant Pass
Modem Use IRQ 3 Pass
Suspend Mode Disabled Pass
HDD Power Down Disabled Pass
Soft-off by PWR-BTTN Instant-off Pass
Intruder# Detection Disabled Pass
Wake-Up by PCI card Disabled Pass
Power On by Ring Disabled Pass
Resume by Alarm Disabled Pass
PnP / PCI CONFIGURATION
Reset Configuration Data Disabled Pass
Resources Controlled By Auto (ESCD) Pass

9
PCI / VGA Palette Snoop Disabled Pass
INTEGRATED PERIPHERALS
OnChip IDE Device Press Enter Pass
OnBoard Device Press Enter Pass
SuperIO Device Press Enter Pass
PC Health Statues Write Actual Values
Shutdown Temperature Disabled
CPU FAN Control by Always On
SYS FAN Control by Always On
CPU Vcore 1.48V
AGP Voltage 1.47V
+3.3V 2.91V
+5V 5.02V
+12V 11.32V
5V(SB) 4.81V
Voltage Battery 3.21V
Current CPU Temperature 32 ℃
Current System Fan Speed 3200 RPM
Current CPU Fan Speed 4200 RPM
Show H/W Monitor in POST Disabled
Comments:
Frequency / Voltage Control
CPU Voltage Default Pass
DIMM Voltage 2.6V Pass
Auto Detect PCI Clk Enabled Pass
Spread Spectrum Enabled Pass
CPU Clock 100 Pass

10
FUNCTIONALITY
Setup Installation Test Of Operating System Pass/Fail
Windows ME Pass
Windows 2000 Professional Pass
Windows XP Home Edition Pass
Windows XP Professional Pass
Linux (Red Hat ) 9.0 Pass
Basic On-board Function Test
Test Platform MS-DOS Operating Comment
CPU P4 3.0GHZ
Memory Twinmos DDR400 256M*2
HDD Seagate 40G
CDROM BenQ 16X
Sound Card On board
Video Card Winfast A280
LAN Card Intel 82557
Test Item Pass/Fail
Clear CMOS with Jumper Pass
Cold Boot (Power Turn on ) Pass
CMOS Load Default Setup Pass
Memory Size Counter Check Pass
BIOS Lock Function Pass
Warm Boot (HW/SW Reset) Pass
System Configuration Review (CPU Type/Cache/SDRAM/HDD…) Pass
Power Fail Function Test Pass
Prompt Into DOS Mode Pass
Typing Some DOS Comment Pass
Run Scandisk Pass
PS/2 Keyboard Test Pass
USB Keyboard Legacy Support Test Pass
Boot Floppy Driver A Pass
FDISK Hard Disk Driver Pass
Format Hard Disk Driver Pass
Boot Hard Disk Driver C Pass
Power LED Check Pass
HDD LED Check Pass
Systems Speaker Pass
Buzz None
BIOS / Update BIOS Utility Test Pass
SMI Function Test ---
SMI Pin Function Test Pass

11
Power LED Flash Check Pass
Power On Control ---
Power On By RTC Test Pass
Power On By LAN Test Pass
Power On By Modem Test Pass
Boot Management ---
Boot Form CD-ROM Pass
Boot From LAN Pass
RTC Test ---
CMOS RTC Date Check Pass
Windows RTC Date Check Pass
CMOS RTC Time Out Test Pass
Windows RTC Time Out Test Pass
Memory Comparability Test ---
Bmem Memory Test (15 Times) Pass
Qaplus 7.0 Test ---
All Test Pass
Checkit 4.0 ---
System Board Test Pass
Memory Test Pass
Hard Disk Test Pass
Floppy Test Pass
Serial Port Test Pass
Parallel Port Test Pass
Modem Test Pass
Video Card Test Pass
Printer Test Pass
Keyboard Test Pass
AMIDiag 6.20 ---
System ---
Processor Test Pass
DMA Controller Test Pass
Interrupt Controller Test Pass
Timer Test Pass
Real Time Clock Test Pass
CMOS Validity Test Pass
Speaker Test Pass
PCI System Test Pass
Plug-n-Play Test Pass
Multimedia CPU Extensions Pass
DMI Test Pass
Memory ---
BIOS ROM Test Pass

12
Parity Test Pass
Pattern Test Pass
Extended Pattern Test Pass
Walking 1’s Test Pass
Walking 0’s Test Pass
Random Memory Test Pass
Address Test Pass
Refresh Test Pass
Data Bus Test Pass
Cache Memory Test Pass
Quick Memory Test Pass
IDE ---
IDE HDD Test Pass
IDE CD Test Pass
FDD ---
Floppy Controller Test Pass
Drive Speed Test Pass
Diskette Read Test Pass
Elevator Seek Test Pass
Disk Change Line Test Pass
KBD ---
Controller Test Pass
Scan/ASCII code test Pass
LED Test Pass
Clock Line Test Pass
Data Line Test Pass
Video ---
Video Controller Test Pass
VGA Controller Test Pass
Video Memory Test Pass
VESA Video Memory Test Pass
VESA Monitor Test Pass
Attribute Test Pass
Page Selection Test Pass
Color Test Pass
Text Mode Test Pass
Graphics Mode Test Pass
VESA Video Mode Test Pass
Misc. ---
Serial Port Test Pass
Parallel Port Test Pass
PS/2 Mouse Test Pass
APM Functionality Test Pass

13
Device APM Test Pass
ACPI Test Pass
Comments:
Test Platform Windows ME Operating Comment
CPU P4 2.8GHZ
Memory Winbond DDR400 256M*2
HDD Seagate 40G
CDROM Samsung DVD-ROM 16X
Sound Card On board
Video Card Geforce4 Ti4200
LAN Card On board
Test Item Pass/Fail
System Comparability Test ---
Windows ME Setup Installation Test Pass
Supports Driver Installation Test Pass
System Properties Information Review (System Device Manager) Pass
Standby Mode Test Pass
Shut Down Test Pass
Restart Test Pass
Scandisk Test Pass
Reboot The Windows Test For Over Night Pass
Suspend To RAM (S3) Test ---
Standby Button for S3 (Enter) Pass
Power Button for S3 (Enter and Wake up) Pass
Enable Scheduled Task Runs at Specified time Test (RTC wake up) Pass
Power LED Flash check Pass
Onboard Audio For S3 Function Supports Test (Play CD/DVD) Pass
Hibernate(S4) Test ---
Standby Button for S4 (Enter) Pass
Power Button for S4 (Enter and Wake up) Pass
Enable Scheduled Task Runs at Specified time Test (RTC wake up) Pass
Device Comparability Test ---
PS/2 Connector Test ---
PS/2 Keyboard Test Pass
PS/2 Mouse Test Pass
COM Port Test ---
Add Serial Mouse PnP Test Pass
Add Modem PnP Test Pass
Print Port Test ---

14
Add Printer PnP Test Pass
FDD Connector Test ---
Create Windows ME Startup Disk Pass
Format 1.44 Floppy Driver Pass
IDE Connectors Test ---
CD-ROM Data Read Test Pass
DVD-ROM Data Read Test Pass
Ultra DMA 33/66/100/133 Hard Disk Test Pass
USB Ports Test ---
Add Keyboard PnP Test Pass
Add Mouse PnP Test Pass
PCI Slots Test ---
Add LAN Cards Test ---
Boot ROM Function Test Pass
Add LAN Card Test Pass
Login Server Test Pass
ADSL Link Test Pass
Add SCSI Cards Test ---
Add SCSI Cards For PnP Function Test Pass
Add Sound Card Test ---
Add Sound Cards For PnP Function Test Pass
Audio Drivers Setup Installation Test Pass
System Properties Information Review Pass
Audio Control Panel Function Test Pass
Game Port Test Pass
Sound Recorder Test Pass
Speaker Out Quality Test Pass
Playing Audio CD Test Pass
Playing Wave Test Pass
Playing MP3 Test Pass
CNR Slots Test ---
Add CNR Software Modem Card Test Pass
VGA Function Test ---
VGA Drivers Setup Installation Test Pass
Display Properties Information Review Pass
Run 3D Screen Saver Pass
VGA Resolution Test ---
Resolution Color Depth Optimal 75 Hz 85 Hz 100 Hz ---
640x480 16 bit √√√√Pass
640x480 32 bit √√√√Pass
800x600 16 bit √√√√Pass
800x600 32 bit √√√√Pass

15
1024x768 16 bit √√√√Pass
1024x768 32 bit √√√√Pass
1152x864 16 bit √√√√Pass
1152x864 32 bit √√√√Pass
Check Screen Have No Any Shadow Or Garbage Pass
Audio Function Test ---
Audio Drivers Setup Installation Test Pass
System Properties Information Review Pass
Audio Control Panel Function Test Pass
Sound Recorder Test Pass
Run MPG Files Pass
Speaker Out Quality Test Pass
Playing Audio CD Test Pass
Playing Wave Test Pass
Playing MIDI Test Pass
Playing Video Test Pass
Playing MP3 Test Pass
Onboard Audio For S1 Function Supports Test Pass
SPDIF Test Pass
Windows Utility Test ---
BCM Diagnostics ---
System Info Pass
DMI Info Pass
Processor Test Pass
Memory Test Pass
Audio Test Pass
Video Test Pass
Graphics Test Pass
Hard Disk Test Pass
Floppy Disk Test Pass
CD-ROM Test Pass
Stress Test –Loop 100 Pass
MS Mouse Pass
MS Joystick Pass
MS ScanDisk Pass
Winstone 2002 ---
Business Winstone 2002 Pass
Content Creation Winstone 2003 Pass
Winbench 99 V1.2 ---
Business Disk WinMark 99 Pass
Business Graphics WinMark 99 Pass
DirectDraw Tests Pass

16
Disk Inspection Tests Pass
Disk WinMark Pass
GDI/USER Inspection Tests Pass
High-End Disk WinMark 99 Pass
High-End Graphics WinMark 99 Pass
Video Tests Pass
3D Mark 2001 SE ---
3D Marks Pass
Demo Mode Pass
Others ---
Final Reality Pass
USBready Pass
WinDVD Pass
QUAKE III Pass
Comments:
Test Platform Windows2000 Operating Comment
CPU P4 3.0GHZ
Memory Twinmos DDR400 256M*2
HDD Seagate 40G
CDROM BenQ DVD-ROM 16X
Sound Card On board
Video Card Winfast A280
LAN Card On board
Test Item Pass/Fail
System Comparability Test ---
Windows 2000 Setup Installation Test Pass
Supports Driver Installation Test Pass
System Properties Information Review Pass
S1 , S3 , S4 Mode Test Pass
Shut Down Test Pass
Restart Test Pass
Scandisk Test Pass
Setup installation Microsoft Office 2000 Test Pass
Hibernate(S4) Test ---
Standby Button for S4 (Enter) Pass
Power Button for S4 (Enter and Wake up) Pass
Windows Set RTC Time out for S4 (Enter and Wake up) Pass
Enter S4 mode For 1/5/10/30/60/120 Minutes Then To Do Wake Up Test. Pass
Wake Up By LAN Test Pass

17
Wake Up By Ring Test Pass
Enable Scheduled Task Runs at Specified time Test (RTC wake up) Pass
Device Comparability Test ---
PS/2 Connector Test ---
PS/2 Keyboard Test Pass
PS/2 Mouse Test Pass
COM Port Test ---
Add Serial Mouse PnP Test Pass
Add Modem PnP Test Pass
Print Port Test ---
Add Printer PnP Test Pass
FDD Connector Test ---
Format 1.44 Floppy Driver Pass
IDE Connectors Test ---
Ultra DMA 33 Hard Disk Test Pass
Ultra DMA 66 Hard Disk Test Pass
Ultra DMA 100 Hard Disk Test Pass
CD-ROM Test Pass
DVD-ROM Data Read Test Pass
ZIP Device Driver Test Pass
LS120 Device Driver Test Pass
Onboard LAN Test ---
LAN Drivers Setup Installation Test Pass
Boot ROM Function Test Pass
Login Server Test Pass
Peer to Peer 10Mbps or 100Mbps Data Transfer Test Pass
Wake On LAN Test (Standby Mode) Pass
ADSL Link Test Pass
LAN Cards Test ---
Boot ROM Function Test Pass
RIS (Remote Install Service ) Function Test Pass
Login Server Test Pass
Peer to Peer 10Mbps or 100Mbps Data Transfer Test Pass
Wake On LAN Test . Pass
ADSL Link Test Pass
PCI Slots Test ---
Add SCSI Card Test Pass
Add LAN Card Test Pass
Wake On LAN Test (Standby Mode) Pass
Add Sound Card Test Pass
Add Modem Card Test Pass
Wake On Modem Test (Standby Mode) Pass
CNR Slots Test ---

18
Add Modem Card Test Pass
VGA Function Test ---
VGA Drivers Setup Installation Test Pass
Display Properties Information Review Pass
VGA Resolution All Test Pass
Screen Saver Test Pass
Check Screen Have No Any Shadow Or Garbage Pass
Playing MPEG Files Test Pass
Playing VCD Test Pass
Playing DVD Test(With WinDVD 4) Pass
Audio Function Test ---
Audio Drivers Setup Installation Test Pass
System Properties Information Review Pass
Speaker Out Quality Test Pass
R/L Channel Check Pass
CD-In Function Check Pass
Line-In Function Check Pass
Mic-In Function Check Pass
Audio Control Panel Function Test Pass
Sound Recorder Test Pass
Playing Audio CD Test Pass
Playing Wave Test Pass
Playing MIDI Test Pass
Playing Video Test Pass
Playing MP3 Test Pass
Game Port Test Pass
Windows2000 Utility Test Pass/Fail
BCM Diagnostics ---
System Info Pass
DMI Info Pass
Processor Test Pass
Memory Test Pass
Audio Test Pass
Video Test Pass
Graphics Test Pass
Hard Disk Test Pass
Floppy Disk Test Pass
CD-ROM Test Pass
Stress Test –Loop 100 Pass
MS Mouse Pass
MS Joystick Pass
BurnIn Test ---
CPU-Maths Pass

19
CPU-MMX/SSE Pass
Memory (RAM) Pass
2D Graphics Pass
3D Graphics Pass
Hard Disk Test Pass
Floppy Disk Pass
Network Test Pass
CD-ROM Pass
Winbench 99 (1.2) ---
Business Disk WinMark 99 Pass
Business Graphics WinMark 99 Pass
DirectDraw Tests Pass
Disk Inspection Tests Pass
Disk WinMark Pass
GDI/USER Inspection Tests Pass
High-End Disk WinMark 99 Pass
High-End Graphics WinMark 99 Pass
Winstone 2003 ---
Business Winstone 2002 Pass
Content Creation Winstone 2003 Pass
SYSMark2002 ---
Internet Content Creation Pass
Office Productivity Pass
Others ---
PC-MARK 2002 Pass
XL-R8R Pass
3D MARK2001SE E330 Pass
Game Test ---
3D Pinball Pass
Freecell Pass
Minesweeper Pass
Solitaire Pass
Age of Empire Pass
Comments:
Test Platform Windows XP (Home Edition ) Operating Comment
CPU P4 2.4GHZ
Memory GM DDR400 512M*2
HDD Maxtor 40G
CDROM ASUS DVD-ROM 16X
Sound Card Onboard

20
Video Card Radeon 9500
LAN Card Onboard
Test Item Pass/Fail
System Comparability Test ---
Windows XP Setup Installation Test Pass
Supports Driver Installation Test Pass
Standby Mode Test Pass
Shut Down Test Pass
Restart Test Pass
Scandisk Test Pass
S3 and S4 Mode Test Pass
Setup installation Microsoft Office 2000 Test Pass
System Information Review ---
Hardware Resources Pass
Components Pass
Software Environment Pass
Internet Setting Pass
Net Diagnostics Pass
System restore Pass
File Signature Verification Utility Pass
DirectX Diagnostics Tool Pass
Hardware Device Manager review Pass
System Event Review Pass
Suspend To RAM (S3) Test ---
Standby Button for S3 (Enter) Pass
Power Button for S3 (Enter and Wake up) Pass
Suspend Test (Microsoft Utility) Pass
Wake Up By LAN Test Pass
Wake Up By Ring Test Pass
Enable Scheduled Task Runs at Specified time Test (RTC wake up) Pass
Power LED Flash check Pass
Onboard Audio For S3 Function Supports Test (Play CD/VCD/DVD/AVI) Pass
Hibernate(S4) Test ---
Standby Button for S4 (Enter) Pass
Power Button for S4 (Enter and Wake up) Pass
Windows Set RTC Time out for S4 (Enter and Wake up) Pass
Wake Up By LAN Test Pass
Wake Up By Ring Test Pass
Enable Scheduled Task Runs at Specified time Test (RTC wake up) Pass
Device Comparability Test ---
PS/2 Connector Test ---
PS/2 Keyboard Test Pass
