M7 SXF
ENGINEERING VALIDATION TEST REPORT
COVER SHEET
CHANGE CONTROL
Description of Change Revision Sections/Pages Affected Date
Initial Release 0.90 2001/10/24
0.91 2001/10/26
1.0 2001/12/3
Project: M7 SXF SiS 645 For Pentium 4 /478 ATX Motherboard
Date: 2002/1/29
Owner: Biostar Group
Contact: TEL: [phone] FAX: [phone]
Home Page: http://www.biostar.com.tw

2
CONTENTS
PRODUCT INFORMATION...................................................................... 4
Motherboard General Information.............................................................................. 4
Chipset Details............................................................................................................ 4
BIOS Details............................................................................................................... 4
CPU Supports.............................................................................................................. 4
Memory Supports........................................................................................................ 4
On-board Features and Devices.................................................................................. 4
Mechanical.................................................................................................................. 5
DESIGN REVIEW ....................................................................................... 7
Mainboard Voltage Measurement............................................................................... 7
Bus Clock.................................................................................................................... 7
REQUIRED BIOS DEFAULT SETTINGS............................................... 8
BIOS FEATURES SETUP......................................................................................... 8
CHIPSET FEATURES SETUP.................................................................................. 8
POWER MANAGEMENT SETUP ........................................................................... 8
PnP / PCI CONFIGURATION................................................................................... 9
INTEGRATED PERIPHERALS................................................................................ 9
PC Health Statues ..................................................................................................... 10
FUNCTIONALITY .................................................................................... 11
Setup Installation Test Of Operating System............................................................ 11
Basic On-board Function Test.................................................................................. 11
MS-DOS Operating .................................................................................................. 11
Windows ME Operating........................................................................................... 14
Windows2000 Operating.......................................................................................... 23
Windows XP (Home Edition ) Operating................................................................. 27
Windows XP (Professional ) Operating.................................................................... 28
Linux (Red Hat7.2) Operating.................................................................................. 30
RELIABILITY TEST................................................................................. 32
Motherboard General Information............................................................................ 32
Burn-in Step.............................................................................................................. 32
OVER CLOCK TEST................................................................................ 33
PERFORMANCE TEST............................................................................ 34
Windows Me (For DDR 333)................................................................................... 34
Windows ME............................................................................................................ 35
Windows2000........................................................................................................... 36
Windows XP............................................................................................................. 37
HARDWARE COMPATIBILITY LIST.................................................. 38
CPU........................................................................................................................... 38
CD-ROM................................................................................................................... 38
Camera Device.......................................................................................................... 39
DVD-ROM ............................................................................................................... 39
Display Card ............................................................................................................. 39
FDD........................................................................................................................... 40

3
HDD.......................................................................................................................... 40
Joystick ..................................................................................................................... 41
Keyboard................................................................................................................... 42
LAN Card.................................................................................................................. 42
LAN HUB................................................................................................................. 43
Memory..................................................................................................................... 43
Modem Card ............................................................................................................. 43
Mouse........................................................................................................................ 44
Monitor ..................................................................................................................... 44
Power Supply............................................................................................................ 45
Printer........................................................................................................................ 45
Scanner...................................................................................................................... 45
SCSI Card ................................................................................................................. 46
Sound Card................................................................................................................ 46
USB HUB ................................................................................................................. 46
ZIP/LS120................................................................................................................. 47
SOFTWARE COMPATIBILITY LIST................................................... 48
DOS........................................................................................................................... 48
Windows................................................................................................................... 48
Server........................................................................................................................ 48
THERMAL IMAGE TEST – Ver 0.91..................................................... 49
Motherboard General Information............................................................................ 49
THERMAL IMAGE TEST – Ver 1.0....................................................... 50
Motherboard General Information............................................................................ 50
FOUR CORNER TEST-Ver0.91............................................................... 51
Test Equipment & Environment............................................................................... 51
BCM Stress Test (30 min.) ....................................................................................... 51
FOUR CORNER TEST-Ver1.0................................................................. 52
Test Equipment & Environment............................................................................... 52
BCM Stress Test (30 min.) ....................................................................................... 52

4
PRODUCT INFORMATION
Motherboard General Information
Vendor Biostar
Model Number M7 SXF
Version Number V0.90/V0.91/V1.0
Platform AT ;ATX Micro ATX Flex ATX
FCC Logo Ok
CE Logo Ok Chipset Details
System Chipset Vendor SiS
North Bridge Revision SiS 645
South Bridge Revision SiS 961
Super I/O Chip Vendor Winbond
Super I/O Revision Number W83697HF
Clock Generator Vendor Cypress
Clock Generator Revision CY283420C
Audio Chipset Vendor Realtek
Audio Chipset Revision ALC201A BIOS Details
BIOS Vendor AMI ;Award Phoenix Others
BIOS Revision Number SXF0114X
BIOS Memory Size 1M ;2M 4M
Flash EPROM BIOS ;Yes No
CPU Supports
Type CPU CPU Frequency Front Side Bus Comments:
Socket 478 Intel Pentium 4 Max =2200 MHz Max =100 MHz
Memory Supports
Maximum Memory Support DDR RAM 1500 (MB)
Number of Memory Slots ;DIMM 3 .
Type of Memory Supported VCM SDRAM RDRAM ;DDR RAM
ECC Support Yes ;No N/A
On-board Features and Devices
No of PCI Full Length Slots 2 3 4 ;5
No of ISA Full Length Slots 1 2 3 4 ;None
AMR Slot Support Yes ;No
CNR Slot Support ;Yes No
ACR Slot Support ;Yes No
Number of Shared Slots ;1 None
100 MHz Front Side Bus Supports ;Yes No
PCI v2.2 Compliance ;Yes No
ATA-3 Compliance ;Yes No

5
ATAPI Compliance ;Yes No
Ultra DMA 33 Support ;Yes No
Ultra DMA 66 Support ;Yes No
ATA-100 Support ;Yes No
DDR 333 Support ;Yes No
USB Connector Support ;Yes No
AGP (2X/4X) Slot Support ;Yes No
Support AGP SideBand Addressing Mode ;Yes No
Power on by LAN Support ;Yes No
Infrared Support ;Yes No
Enhanced Parallel Port ;Yes No
DMI Compliance ;Yes No
Hardware Monitor Support ;Yes No
ACPI v1.0/APM v1.2 Compliance ;Yes No
On-board Graphics Controller Yes ;No
On-board Network Adapter 1Mb 10Mb ;100Mb (Optional) No
On-board Audio Device Hardware ;AC97 CODEC No
Mechanical
Board Dimensions Length 30.5 cm Width 24.4 cm
Visual Inspection of Soldering ;Excellent Fair Poor
Visual Inspection of Layout Placement Connectors Quality
Screw Holes Line Up with Case ;Yes No ;Excellent Fair Poor
Power Connector placement in PCB ;Yes No ;Excellent Fair Poor
DIMM/RIMM Socket placement in PCB ;Yes No ;Excellent Fair Poor
CPU Socket placement in PCB ;Yes No ;Excellent Fair Poor
FAN Connector placement in PCB ;Yes No ;Excellent Fair Poor
FDD Connector placement in PCB ;Yes No ;Excellent Fair Poor
IDE Connector placement in PCB ;Yes No ;Excellent Fair Poor
Front Panel Connectors in PCB ;Yes No None ;Excellent Fair Poor
PS/2 Connectors Line Up in Case ;Yes No None ;Excellent Fair Poor
USB Port Connectors Line Up in Case ;Yes No None ;Excellent Fair Poor
COM Port Connectors Line Up in Case ;Yes No None ;Excellent Fair Poor
Printer Port Connectors Line Up in Case ;Yes No None ;Excellent Fair Poor
VGA Port Connectors Line Up in Case Yes No ;None Excellent Fair Poor
Audio Port Connectors Line Up in Case ;Yes No None ;Excellent Fair Poor
Game Port Connectors Line Up in Case ;Yes No None ;Excellent Fair Poor
AGP Slot(Card) Line Up in Case ;Yes No None ;Excellent Fair Poor
ISA Slots(Card) Line Up in Case Yes No ;None Excellent Fair Poor
PCI Slots(Card) Line Up in Case ;Yes No None ;Excellent Fair Poor
AMR Slot(Card) Line Up in Case Yes No ;None Excellent Fair Poor
CNR Slot(Card) Line Up in Case ;Yes No None ;Excellent Fair Poor
ACR Slot(Card) Line Up in Case ;Yes No None ;Excellent Fair Poor

6
Daughter Card Slot in PCB Yes No ;None Excellent Fair Poor
Wake-on LAN connector in PCB ;Yes No None ;Excellent Fair Poor
Wake-on Modem connector in PCB Yes No ;None Excellent Fair Poor
CD Audio-in Connector in PCB ;Yes No None ;Excellent Fair Poor
AUX Audio-in Connector in PCB Yes No ;None Excellent Fair Poor
Telephony Connector in PCB ;Yes No None ;Excellent Fair Poor
Digital Video Connector Yes No ;None Excellent Fair Poor
Other Jumper in PCB ;Yes No None ;Excellent Fair Poor
Comments:

7
DESIGN REVIEW
Mainboard Voltage Measurement
Voltage List Voltage SPEC Voltage Measured Result
Battery Voltage 3.0V/7uA 3.23V/4.1uA Pass
+5V 5.0V+-5% 5.14 Pass
+12V 12.0V+-5% 12.02 Pass
-5V -5.0V+-5% -4.99 Pass
-12V -12.0V+-10% -12.30 Pass
+3.3V +3.3V+-5% 3.39 Pass
Bus Clock
Clock Frequency Spec Value (MHz) Measured Value
(MHz) Pass/Fail
CPU and Clock Host 100.00 100.00 Pass
DDRAM Clock 100.00 100.0 Pass
133.33 133.0 Pass
PCI Clock 33 33.33 Pass
AGP Clock 66.67 66.67 Pass
USB Clock 48 48.54 Pass
Reference Clock 14.31818 14.29 Pass
Clock Voltage Level Spec Value (v) Measured Value Pass/Fail
CPU and Host Clock Voltage Level 0.7v~1.2v 1.02 Pass
DDRAM Clock Voltage Level 2.5v 3 Pass
PCI Clock Voltage Level 3.3v 3.50 Pass
AGP Clock Voltage Level 3.3v 3.42 Pass
Reference Clock Voltage Level 3.3v 3.5 Pass
Clock Timing Spec Value (v) Measured Value Pass/Fail
CPU Clock High Time 100.00 Min 2.5ns 4.4 Pass
CPU Clock Low Time 100.00 Min 2.4ns 4.8 Pass
CPU Clock Rising Time 100.00 0.4ns~1.6ns 0.48 Pass
CPU Clock Falling Time 100.00 0.4ns~1.6ns 0.36 Pass
PCI Clock High Time Min.11ns 14.4 Pass
PCI Clock Low Time Min.11ns 14.3 Pass
PCI Clock Rising Time 1ns~4ns 0.7 Pass
PCI Clock Falling Time 1ns~4ns 0.6 Pass
Comments:

8
REQUIRED BIOS DEFAULT SETTINGS
Lists Specification Result
BIOS FEATURES SETUP
Virus Warning Disabled Pass
CPU L1 & L2 Cache Enabled Pass
CPU L2 Cache ECC Checking Enabled Pass
Quick Power On Self Test Enabled Pass
First Boot Device Floppy Pass
Second Boot Device HDD-0 Pass
Third Boot Device LS120 Pass
Boot Other Device Enabled Pass
Swap Floppy Seek Disabled Pass
Boot Up Floppy Seek Enabled Pass
Boot Up NumLock Status On Pass
Gate A20 Option Fast Pass
Typematic Rate Setting Disabled Pass
Typematic Rate(Chars/Sec) 6 Pass
Typematic Delay(MSEC) 250 Pass
Security Option Setup Pass
APIC Mode Disabled Pass
MPS Version Control For OS 1.4 Pass
OS Select For DRAM>64MB Non-OS2 Pass
Report No FDD For WIN 95 No Pass
Video BIOS Shadow Enabled Pass
Full Screen LOGO Show Enabled Pass
Small Logo(EPA) Show Disabled Pass
CHIPSET FEATURES SETUP
Advanced DRAM Control Press Enter Pass
System Performance Normal Mode Pass
CAS Latency Setting 2.5T Pass
DRAM Addr/Cmd Rate AUTO Mode Pass
Prefetch Caching Enabled Pass
Memory Hole at 15M-16M Disabled Pass
AGP Aperture Size 64MB Pass
Graphic Window WR Combin Enabled Pass
POWER MANAGEMENT SETUP
ACPI Function Enabled Pass
ACPI Suspend Type S1(POS) Pass
Video Off Option Susp,Stby -> Off Pass
Video Off Method DPMS Supported Pass
Switch Function Break/Wake Pass
Modem Use IRQ Auto Pass

9
Hot Key Function As Power Off Pass
HDD Off After Disable Pass
Power Button Override Instant Off Pass
PM Wake Up Events Press Enter Pass
IRQ [3-7,9-15],NMI Enabled Pass
IRQ 8 Break Suspend Disabled Pass
RING Power Up Control Enabled Pass
MACPME Power Up Control Enabled Pass
PCIPME Power Up Control Enabled Pass
Power Up by Alarm Disabled Pass
X Month Alarm NA Pass
X Date(of Month) Alarm 0 Pass
X Time(hh:mm:ss)Alarm 0 0 0 Pass
PnP / PCI CONFIGURATION
Reset Configuration Data Disabled Pass
Resources Controlled By Auto(ESCD) Pass
X IRQ Resources Press Enter Pass
PCI/VGA Palette Snoop Disabled Pass
INTEGRATED PERIPHERALS
SIS OnChip IDE Device Press Enter Pass
Internal PCI/IDE Both Pass
IDE Primary Master PIO Auto Pass
IDE Primary Slave PIO Auto Pass
IDE Secondary Master PIO Auto Pass
IDE Secondary Slave PIO Auto Pass
Primary Master UltraDMA Auto Pass
Primary Slave UltraDMA Auto Pass
Secondary MasterUltraDMA Auto Pass
Secondary Slave UltraDMA Auto Pass
IDE Burst Mode Enabled Pass
SIS OnChip PCI Device Press Enter Pass
SIS-7012 AC97 AUDIO Enabled Pass
SIS-7013 S/W Modem Disabled Pass
SIS-900 10/100M ETHERNET Disabled Pass
X SiS-900 MAC Address Input Press Enter Pass
Onboard SuperIO Device Press Enter Pass
Onboard FDC Controller Enabled Pass
Onboard Serial Port 1 3F8/IRQ4 Pass
Onboard Serial Port 2 2F8/IQR3 Pass
UART Mode Select Normal Pass
RxD , TxD Active Hi,Lo Pass
IR Transmission Delay Enabled Pass
UR2 Duplex Mode Half Pass

10
Use IR Pins TR-RX2TX2 Pass
Onboard Parallel Port 378/IRQ7 Pass
Parallel Port Mode SPP Pass
EPP Mode Select EPP1.7 Pass
ECP Mode Use DMA 3 Pass
Game Port Address 201 Pass
Midi Port Address 330 Pass
Midi Port IRQ 10 Pass
USB Controller Enabled Pass
USB Keyboard Support Disabled Pass
IDE HDD Block Mode Enabled Pass
Init Display First PCI Slot Pass
AGP Auto Calibration Enabled Pass
IDE Access Interface Auto Pass
MAC Access Interface Embedded Bus Pass
USB1 Access Interface Embedded Bus Pass
USB0 Access Interface Embedded Bus Pass
Audio Access Interface Embedded Bus Pass
PC Health Statues Write Actual Values
CPU Warning Temperature Disabled
Current CPU Temperature 61°C / 141°F
Current CPUFAN Speed 4017 RPM
Current SYSFAN Speed 4963 RPM
CPU Voltage 1.68 V
3.3 V 3.28 V
+ 5 V 4.94 V
+12 V 11.43 V
Shutdown Temperature Disabled
Show H/W Monitor in POST 3 Sec
Comments:

11
FUNCTIONALITY
Setup Installation Test Of Operating System Pass/Fail
Windows 98 Second Edition Pass
Windows NT 4.0 Workstation Pass
Windows ME Pass
Windows 2000 Professional Pass
Windows 2000 Server Pass
Windows XP Home Edition Pass
Windows XP Professional Pass
Linux (Red Hat 7.2) Pass
Basic On-board Function Test
Test Platform MS-DOS Operating Comment
CPU Pentium 4 1.8 GHz
Memory Nanya 512 M *1
HDD QUANTUM 40G
CDROM TEAC 40X
Sound Card Onboard
Video Card Onboard
LAN Card Intel 82557 , 82559
Test Item Pass/Fail
Clear CMOS with Jumper Pass
Cold Boot (Power Turn on ) Pass
CMOS Load Default Setup Pass
Memory Size Counter Check Pass
BIOS Lock Function Pass
Warm Boot (HW/SW Reset) Pass
System Configuration Review (CPU Type/Cache/SDRAM/HDD…) Pass
Prompt Into DOS Mode Pass
Typing Some DOS Comment Pass
Run Scandisk Pass
PS/2 Keyboard Test Pass
USB Keyboard Legacy Support Test Pass
Boot Floppy Driver A Pass
FDISK Hard Disk Driver Pass
Format Hard Disk Driver Pass
Boot Hard Disk Driver C Pass
Power LED Check Pass
HDD LED Check Pass
Systems Speaker Pass
Buzz None
SMI Function Test ---

12
SMI Pin Function Test Pass
Time Out Function Test Pass
Power LED Flash Check Pass
Power On Control ---
Power On By RTC Test Pass
Power On By LAN Test Pass
Power On By Modem Test Pass
Boot Management ---
Boot Form CD-ROM Pass
Boot From SCSI HDD Pass
Boot From ATAPI ZIP/LS120 Drive Pass
Boot From LAN Pass
RTC Test ---
COMS RTC Date Check Pass
Windows ME RTC Date Check Pass
Windows ME RTC Time Out Test Pass
Memory Comparability Test ---
Bmem Memory Test (15 Times) Pass
Qaplus 7.0 Test ---
All Test Pass
Checkit 4.0 ---
System Board Test Pass
Memory Test Pass
Hard Disk Test Pass
Floppy Test Pass
Serial Port Test Pass
Parallel Port Test Pass
Modem Test Pass
Video Card Test Pass
Printer Test Pass
Keyboard Test Pass
AMIDiag 6.0 ---
System ---
Processor Test Fail (Utility issue)
DMA Controller Test Pass
Interrupt Controller Test Pass
Timer Test Pass
Real Time Clock Test Pass
CMOS Validity Test Pass
Speaker Test Pass
PCI System Test Pass
Plug-n-Play Test Pass
Multimedia CPU Extensions Fail

13
SMBus Test Fail (Utility issue)
Memory ---
BIOS ROM Test Pass
Parity Test Pass
Pattern Test Pass
Extended Pattern Test Pass
Walking 1’s Test Pass
Walking 0’s Test Pass
Random Memory Test Pass
Address Test Pass
Refresh Test Pass
Data Bus Test Pass
Cache Memory Test Pass
IDE ---
IDE HDD Test Pass
IDE CD Test Pass
FDD ---
Drive Speed Test Pass
Random R/W Test Pass
Sequential R/W Test Pass
Elevator Seek Test Pass
Disk Change Line Test Pass
KBD ---
Controller Test Pass
Scan/ASCII code test Pass
Keyboard LED Test Pass
Keyboard Clock Line Test Pass
Keyboard Data Line Test Pass
Video ---
Video Memory Test Pass
Attribute Test Pass
Page Selection Test Pass
Color Test Pass
Text Mode Test Pass
Graphics Mode Test Pass
VESA Video Mode Test Pass
VESA Video Memory Test Pass
VESA Monitor Test Pass
Misc. ---
Serial Port Test Pass
Parallel Port Test Pass
PS/2 Mouse Test Pass
APM Functionality Test Pass

14
Device APM Test Pass
ACPI Test Pass
I82557 Ethernet chip Pass
Comments:
Test Platform Windows ME Operating Comment
CPU Pentium 4-1.8 GHz
Memory SAMSUNG 128M X3
HDD IBM ATA100/ 76.8 G
CDROM TEAC 40X
Sound Card Onboard
Video Card ASUS V3800M
PCI Modem Lucent Modem
ACR Card Archtek /Modem + HPNA
CNR Card Lectron PCTel Modem
LAN Card Intel 82559
Test Item Pass/Fail
System Comparability Test ---
Windows ME Setup Installation Test Pass
Supports Driver Installation Test Pass
System Properties Information Review (System Device Manager) Pass
Standby Mode Test Pass
Shut Down Test Pass
Restart Test Pass
Scandisk Test Pass
Enable DMA Mode For IDE Device Test Pass
Disk Defragmenter Test Pass
Setup installation Microsoft Office 2000 Test Pass
Reboot The Windows Test For Over Night Pass
Suspend To RAM (S3) Test ---
Standby Button for S3 (Enter) Pass
Power Button for S3 (Enter and Wake up) Pass
Windows Set RTC Time out for S3 (Enter and Wake up) Pass
Enter S3 mode For 1/5/10/30/60/120 Minutes Then To Do Wake Up Test. Pass
Wake Up By LAN Test Pass
Wake Up By Ring Test Pass
Enable Scheduled Task Runs at Specified time Test (RTC wake up) Pass
Power LED Flash check Pass
Onboard Audio For S3 Function Supports Test (Play CD/VCD/DVD/AVI) Pass
Hibernate(S4) Test ---

15
Standby Button for S4 (Enter) Pass
Power Button for S4 (Enter and Wake up) Pass
Windows Set RTC Time out for S4 (Enter and Wake up) Pass
Enter S4 mode For 1/5/10/30/60/120 Minutes Then To Do Wake Up Test. Pass
Wake Up By LAN Test Pass
Wake Up By Ring Test Pass
Enable Scheduled Task Runs at Specified time Test (RTC wake up) Pass
Memory Comparability Test ---
Running AVI Files With Multi Stress Pass
Winstone 99 Test Pass
3D Mark 2001 Test (Continue loop 10) Pass
BCM Memory Test Pass
Device Comparability Test ---
PS/2 Connector Test ---
PS/2 Keyboard Test Pass
PS/2 Mouse Test Pass
COM Port Test ---
Add Serial Mouse PnP Test Pass
Add Modem PnP Test Pass
Print Port Test ---
Add Printer PnP Test Pass
Add ZIP Device Test Pass
LL5 Cable test (Data Transfer test) Pass
IrDA Function Test ---
Add IR Printer Test Pass
Peer to Peer Data Transfer Test (Ir-In/Ir-Out) Pass
FDD Connector Test ---
Create Windows ME Startup Disk Pass
Format 1.44 Floppy Driver Pass
IDE Connectors Test ---
CD-ROM Data Read Test Pass
DVD-ROM Data Read Test Pass
Format ZIP Driver With Floppy A Type Pass
Format ZIP Driver With Removable Device Type Pass
LS120 Device Driver Test Pass
PIO Mode 4 Hard Disk Test Pass
Ultra DMA 33 Hard Disk Test Pass
Ultra DMA 66 Hard Disk Test Pass
Ultra DMA 100 Hard Disk Test Pass
ZIP Device Driver Test Pass
USB Ports Test ---
Add Keyboard PnP Test Pass
Add Mouse PnP Test Pass

16
Add Printer PnP Test Pass
Add Scanner PnP Test Pass
Add Camera PnP Test Pass
Add Modem PnP Test Pass
Add Joystick PnP Test Pass
Add ZIP PnP Test Pass
Add LAN PnP Test Pass
LAN Port Test (Optional) ---
Boot ROM Function Test Pass
Login Server Test Pass
Peer to Peer 10Mbps or 100Mbps Data Transfer Test Pass
Playing AVI Files By The LAN Pass
Setup Installation Winstone 2001 By The LAN Pass
Setup Installation Winbench 99 By The LAN Pass
Setup Installation 3D Mark2001 By The LAN Pass
ADSL Link Test Pass
PCI Slots Test ---
Add LAN Cards Test ---
Boot ROM Function Test Pass
Login Server Test Pass
Peer to Peer 10Mbps or 100Mbps Data Transfer Test Pass
Power On By LAN Test Pass
Wake On LAN Test (Standby Mode) Pass
Shut Down By The LAN Test Pass
Playing AVI Files By The LAN Pass
Setup Installation Winstone 2001 By The LAN Pass
Setup Installation Winbench 99 By The LAN Pass
Setup Installation 3D Mark2001 By The LAN Pass
Add Token Ring LAN Card Test Pass
ADSL Link Test Pass
Add SCSI Cards Test ---
Add SCSI Cards For PnP Function Test Pass
Setup installation the Windows from SCSI HDD Pass
Scandisk Test Pass
Disk Defragmenter Test Pass
System Properties Information Review (System Device Manager) Pass
Setup installation Microsoft Office 2000 Test Pass
Reboot The Windows Test For Over Night Pass
Add Sound Card Test ---
Add Sound Cards For PnP Function Test Pass
Audio Drivers Setup Installation Test Pass
System Properties Information Review Pass
Audio Control Panel Function Test Pass

17
Game Port Test Pass
Sound Recorder Test Pass
Run MPG Files Pass
Speaker Out Quality Test Pass
Playing Audio CD Test Pass
Playing Wave Test Pass
Playing MIDI Test Pass
Playing Video Test Pass
Playing MP3 Test Pass
CNR Slots Test ---
Add Modem Card Test Pass
Add CNR Software Modem Card Test Pass
Connect Performance Check Pass
Internet Explorer Test Pass
Netscape Browser Test Pass
Connect to ISP For 12 hours Pass
Download Files From Internet ISP Server (Over 10MB) Pass
Modem Fax Function Test (Transmit a fax to Fax Machine) Pass
Modem Fax Function Test (Transmit a fax to Modem) Pass
Modem Fax Function Test (Receive a fax from Fax Machine) Pass
Modem Fax Function Test (Receive a fax from Modem) Pass
Send & Receive e-mail Test Pass
Recording a MP3 File From Internet ISP Server Pass
Voice Pass
ACR Slots Test ---
Modem Function Test Pass
LAN Function Test Pass
Home PNA Function Test Pass
ADSL Link Test Pass
VGA Function Test ---
VGA Drivers Setup Installation Test Pass
Display Properties Information Review Pass
Change Resolution / Color Test Pass
Speedy 1.0 Pass
Run 3D Screen Saver Pass
Run 3D Mark2001 Pass
Run XL-R8R Pass
VGA Resolution Test ( Monitor : ViewSonic GF775 /AGP: GF2 GTS Pro) ---
Resolution Color Depth Optimal 75 Hz 85 Hz 100 Hz ---
640x480 256 √√√√Pass
640x480 16 bit √√√√Pass
640x480 32 bit √√√√Pass

18
800x600 256 √√√√Pass
800x600 16 bit √√√√Pass
800x600 32 bit √√√√Pass
1024x768 256 √√√√Pass
1024x768 16 bit √√√√Pass
1024x768 32 bit √√√√Pass
1152x864 256 √√√none Pass
1152x864 16 bit √√√none Pass
1152x864 32 bit √√√none Pass
1280x1024 256 √√√none Pass
1280x1024 16 bit √√√none Pass
1280x1024 32 bit √√√none Pass
Check Screen Have No Any Shadow Or Garbage Pass
Playing MPEG Files Test Pass
Playing VCD Test Pass
Playing DVD Test Pass
3D Winbench 2000 ---
3D Performance Pass
3D Processing Pass
3D Quality Pass
3D WinMark Pass
Playing *.AVI files (Stress Test for Over Night) Pass
Audio Function Test ---
Audio Drivers Setup Installation Test Pass
System Properties Information Review Pass
Audio Control Panel Function Test Pass
CD-In Function Check Pass
Game Port Test Pass
Line-In Function Check Pass
Mic-In Function Check Pass
R/L Channel Check Pass
Sound Recorder Test Pass
Run MPG Files Pass
Speaker Out Quality Test Pass
Telephony Function Supports Pass
Playing Audio CD Test Pass
Playing Wave Test Pass
Playing MIDI Test Pass
Playing Video Test Pass
Playing MP3 Test Pass
Onboard Audio For S1 Function Supports Test Pass
Audio Winbench99 (Based onboard Sound controller) ---

19
Direct Sound CPU Util 44.1 kHz 16bit Static ---
Hardware Voices 0
Voice 8 0
Voice 16 0
Voice 32 0.0851
DirectSound CPU Util , 44.1 kHz , 16 bits Streaming ---
Hardware Voice 0
Voice 8 0
Voice 16 0
Voice 32 0.37
DirectSound CPU Util , 22 kHz , 8 bits Static ---
Hardware Voice 0
Voice 8 0
Voice 16 0
Voice 32 0
DirectSound CPU Util , 22 kHz , 8 bits Steaming ---
Hardware Voice 0
Voice 8 0
Voice 16 0
Voice 32 0
DirectSound3D CPU Util , 44.1 kHz , 16 bits Static ---
Hardware Voice 0
Voice 8 0
Voice 16 0.0055
Voice 32 0.35
DirectSound3D CPU Util , 44.1 kHz , 16 bits Streaming ---
Hardware Voice 0
Voice 8 0
Voice 16 0
Voice 32 0.9
DirectSound3D CPU Util , 22 kHz , 8 bits Static ---
Hardware Voice 0
Voice 8 0
Voice 16 0
Voice 32 0
DirectSound3D CPU Util , 22 kHz , 8 bits Streaming ---
Hardware Voice 0
Voice 8 0
Voice 16 0
Voice 32 0
Windows Utility Test ---
BCM Diagnostics ---
System Info Pass

20
DMI Info Pass
Processor Test Pass
Memory Test Pass
Audio Test Pass
Video Test Pass
Graphics Test Pass
Hard Disk Test Pass
Floppy Disk Test Pass
CD-ROM Test Pass
Stress Test –Loop 100 Pass
MS Mouse Pass
MS Joystick Pass
MS ScanDisk Pass
PC-Doctor For Windows ---
CPU Test Pass
Hard Driver Test Pass
Floppy Test Pass
LS-120 Driver Test Pass
CD-ROM/DVD Test Pass
ZIP Driver Test Pass
Memory Test Pass
PCI Test Pass
Video Test Pass
AGP Test Pass
COM Loopback Pass
PCMCIA Test Pass
Serial Port Internal Test Pass
Parallel Port Internal Test Pass
Parallel Port Loopback Pass
USB Test Pass
CMOS Test Pass
Keyboard Test Pass
AVI Video Test Pass
Microphone Test Pass
Audio Test Pass
Mouse Test Pass
Monitor Test Pass
Printer Test Pass
Joystick Test Pass
BurnIn Test ---
CPU-Maths Pass
CPU-MMX/SSE Pass
Memory (RAM) Pass
