IEI Technology NOVA-300 User manual

1
NOVA-300
Embedded 386SX SBC
@Copyright 1998
All Rights Reserved.
Manual first edition Aug.01,1998
The information in this document is subject to change without prior notice in order
to improve reliability, design and function and does not represent a commitment on
the part of the manufacturer.
In no event will the manufacturer be liable for direct, indirect, special, incidental, or
consequential damages arising out of the use or inability to use the product or
documentation, even if advised of the possibility of such damages.
This document contains proprietary information protected by copyright. All rights
are reserved. No part of this manual may be reproduced by any mechanical,
electronic, or other means in any form without prior written permission of the
manufacturer.
Trademarks
NOVA-300 is registered trademarks of Acquire Inc., PC/104 is trademarked of
PC/104 Consortium, IBM PC is a registered trademark of International Business
Machines Corporation. Intel is a registered trademark of Intel Corporation. AMI is
registered trademarks of American Megatrends, Inc. Other product names
mentioned herein are used for identification purposes only and may be trademarks
and/or registered trademarks of their respective companies.

3
Contents
1. Introduction ..........................................................3
2. Installation............................................................7
3. Connection.........................................................14
4. AMI BIOS Setup.................................................21
Appendix A. E2KEY Function ................................23
Appendix B. Watch-Dog Timer..............................25
Appendix C. Panel Support List.............................26

4
1
Introduction
Welcome to the NOVA-300 Embedded 386SX SBC. The NOVA-
300 is an with PC/104 form factor board, which comes equipped
with ALI 6117 (includes 386SX CPU) and advanced high-
performance multi-mode I/O, designed for the system
manufacturers, integrators, or VARs that want to provide all the
performance, reliability, and quality at a reasonable price.
An advanced high performance super AT I/O chip Windbond
W83877F and SMC FDC37C669 are used in the JUKI-730
board. Both on-chip UARTs are compatible with the NS16C550.
And one COM port can be set in RS232,RS422,or RS485.
The parallel port and IDE interface are compatible with IBM
PC/AT and XT architecture's, as well as EPP and ECP.
The LCD/CRT controller is HMC HM86508 which can provide
the LCD and CRT display at the same time. The LCD interface
connector is a 44-pin 2.0mm pitch type.
The most outstanding feature in the NOVA-300 is built-in
PC/104 expansion bus. Based on the PC/104 bus, you could
easily install over thousands of PC/104 modules from hundreds'
vendors in the world. The NOVA-300 has external power
connector that could let it connects with power supply directly. It
is more suitable for your standalone applications.
1.1 Specifications :

5
The NOVA-300 Embedded 386SX SBC provides the following
specification:
♦ System :
•CPU : ALI 6117,includes 386SX CPU
•DMA channels : 7
•Interrupt levels : 15
•Real-time clock/calendar : backup by lithium battery for over 10
years of data retention.
♦ Memory :
•RAM memory : 512KB to 32MB,only support single side 16-bit
SIMM.
•Shadow RAM memory :
System BIOS : 0F0000h ~ 0FFFFFh
♦ LCD/CRT Interface :
•Chipset : HM86508
•Resolution : Support up to 800 x 600 resolution for STN and TFT
LCD Flat Panel. And Support 1024x768 256 colors for CRT display.
•Display Memory : 1MB on board.
♦ Input/Output :
•IDE hard disk drive interface : Supports up to two IDE hard disk
drives. Can be disabled by BIOS Setup.
•Floppy disk drive interface : Supports two 2.88 MB, 1.44MB,
1.2MB, 720KB, or 360KB floppy disk drives. Can be disabled by
BIOS Setup.
•Two high speed Series ports : NS16C550 compatible UARTs with
send/receive 16-byte FIFOs, data rates are independently
programmable from 115.2K baud down to 50 baud. Modem control
circuitry.

6
•Multi-mode Parallel Port :
Standard mode - IBM PC/XT, PC/AT, PS/2 compatible bi-directional
parallel port.
Enhanced mode - Enhanced parallel port ( EPP) compatible with
IEEE 1284 specification.
High speed mode - Microsoft and Hewlett Packard extended
capabilities port ( ECP), compatible with IEEE 1248 specification.
♦ Industrial features :
•Watch-dog timer : can be set by 1,2,10,20,110,or 220 seconds
period. Reset or NMI was generated when CPU did not periodically
trigger the timer. Your program use hex 043 and 443 to control the
watch-dog and generate a system reset.
•PC/104 expansion bus : A 64-pin and 40-pin, industrial embedded-
PC bus standard.
•External power connector : 8-pin male connector ( Molex 26-60-
4080 or equivalent one)
•Keyboard connector : A 5-pin header on board
♦ General :
•Power Consumption : +5V @ 1.53A ( 40MHz,8MB RAM)
•Operating Temperature : 0°~ 55°C
•Humidity : 5% ~ 95%, non-condense
•Dimension: 180mm(W) x 122mm(L), standard AT form factor
1.2 What You Have
In addition to this User's Manual, the NOVA-300 package
includes the following items:
•NOVA-300 Embedded 386SX SBC

7
2
Installation
This chapter describes how to install the NOVA-300. At first, the
layout of NOVA-300 is shown, and the unpacking information
that you should be careful is described. The jumpers and
switches setting for the NOVA-300's configuration, such as CPU
type selection, system clock setting, and interrupt IRQ setting for
serial ports and parallel port, are also included.
2.1 NOVA-300's Layout
< reference next page >

8

9
2.2 CPU Setting for NOVA-300
•CPU SPEED SETTING:

10
The system clock is generated by the AV9155C-02, and the
different CPU clock frequency can be selected by JP3 and
shown as following table:
JP3 1-2 3-4 5-6
8MHz OPEN CLOSE CLOSE
16Mhz CLOSE OPEN CLOSE
20MHz OPEN OPEN CLOSE
25MHz CLOSE CLOSE OPEN
40MHz CLOSE OPEN OPEN
2.3 System Memory DRAM
The system DRAM on board is divided into two banks, bank 0
and 1. The Bank 0 is the on board optional 4MB DRAM. Bank 1
is the one 72-pin SIMM. Based on the chipset function the 72-pin
SIMM only support single side 16-bit DRAM. There have two
jumpers for the related setting.
•JP1/JP2 : 4MB DRAM and 72-pin SIMM selection
Function JP1 JP2
On Board 4MB CLOSE CLOSE
72-pin SIMM OPEN OPEN
2.4 Watch-Dog Timer
The Watch-Dog Timer is enabled by reading port 443H. It should
be triggered before the time-out period ends, otherwise it will
assume the program operation is abnormal and will issue a reset
signal to start again, or activate NMI to CPU. The Watch-Dog
Timer is disable by reading port 043H. The Watch-Dog Timer
time-out period can be set 1,2,10,20,110 or 220 sec. by jumper
JP16.
•JP18 : Watch-Dog Active Type Setting

11
JP18 DESCRIPTION
2-3 RESET WHEN WDT TIME-OUT
1-2 ACTIVATE NMI TO CPU WHEN WDT TIME-OUT
OPEN DISABLE WDT
•JP16 : WDT TIME-OUT PERIOD
JP16 1-2 3-4 5-6 7-8
1sec OPEN OPEN CLOSE OPEN
2sec OPEN OPEN CLOSE CLOSE
10sec OPEN CLOSE OPEN OPEN
20sec OPEN CLOSE OPEN CLOSE
110sec CLOSE OPEN OPEN OPEN
220sec CLOSE OPEN OPEN CLOSE
2.5 DiskOnChip™Flash Disk
The DiskOnChip™Flash Disk Chip(DOC) is produced by M-
Systems. The DOC(MD-2200-xMB) is 32-pin DIP package.
Because the DOC is 100% compatible to hard disk and DOS.
Customer don‘t need any extra software utility. It is just “plug
and play”, easy and reliable.
Right now the DOC is available in 2MB to 72MB capacity.
•JP19 : DiskOnChip™
Memory Address Setting
Address 1-2 3-4 5-6
CE000 CLOSE OPEN OPEN
D6000 OPEN CLOSE OPEN
DE000 OPEN OPEN CLOSE
2.6 Clear CMOS Setup
If want to clear the CMOS Setup(for example forgot the
password you should clear the setup and then set the password
again.),you should close the JP31 pin 3-4 about 3 seconds, then
open again. Then take set back to close pin 2-3 for normal

12
operation mode.
•JP31 : Clear CMOS Setup (Reserve Function)
JP31 DESCRIPTION
2-3 Normal Operation
3-4 Clear CMOS Setup
2.7 Serial Port3(CN1) RS232/422/485 Setting
The Serial Port3 can be set in RS232 or RS422/ RS485
interface
by the Jumper JP20/JP23.If choose RS422/485 then will need
the JP21 to set again for RS422 or RS485.
•JP23 : COM3 RS-232 or RS-422/485 setting
Description JP23 JP20
RS-232 1-9 close
3-10 close
5-11 close
7-12 close
2-3
RS-422
or
RS-485
1-2 close
3-4 close
5-6 close
7-8 close
1-2
•JP21 : COM3 RS-422 or RS-485 setting
JP21 DESCRIPTION
2-3 RS-422
1-2 RS-485
2.8 BIOS Flash Chip Vpp Setting
There have two type of Flash chip are possible to be
installed,one is 5V Vpp and another one is 12V Vpp.
The Vpp is supplied when do the programming function.

13
Function JP24
5V Vpp 2-3
12V Vpp 1-2
2.9 Serial Port3/Port4 RI Pin Setting
The Port3 and Port4 can supply +5V or +12V power to the
serial devices via RI pin(Pin 9) of the COM port connector.
The max. current is 1A with fuse protection for the total two
connector’s 5V/12V output..
•JP9/JP29 : Port3(CN1),Pin 9
RI signal or 5V/12V output selection
Function JP9 JP29
RI Signal 2-3 1-2
5V 1-2 1-2
12V 1-2 2-3
•JP8/JP10 : Port4(CN2),Pin 9
RI signal or 5V/12V output selection
Function JP8 JP10
RI Signal 2-3 1-2
5V 1-2 1-2
12V 1-2 2-3
3

14
Connection
This chapter describes how to connect peripherals, switches and
indicators to the NOVA-300 board. You can access most of the
connectors from the top of the board while it is installed in the
chassis.
3.1 Floppy Disk Drive Connector
NOVA-300 board comes equipped with a 34-pin daisy-chain
driver connector cable. The detailed pin assignment of the
connector is specified as following table:
•CN5 : FDC CONNECTOR
PIN NO. DESCRIPTION PIN NO. DESCRIPTION
1GROUND 2REDUCE WRITE
CURRENT#
3GROUND 4N/C
5GROUND 6N/C
7GROUND 8INDEX#
9GROUND 10 MOTOR ENABLE A#
11 GROUND 12 DRIVE SELECT B#
13 GROUND 14 DRIVE SELECT A#
15 GROUND 16 MOTOR ENABLE B#
17 GROUND 18 DIRECTION#
19 GROUND 20 STEP#
21 GROUND 22 WRITE DATA#
23 GROUND 24 WRITE GATE#
25 GROUND 26 TRACK 0#
27 GROUND 28 WRITE PROTECT#
29 GROUND 30 READ DATA#
31 GROUND 32 SIDE 1 SELECT#
33 GROUND 34 DISK CHANGE#
3.2 IDE Disk Drive Connector
You can attach two IDE( Integrated Device Electronics) hard
disk drives to the NOVA-300 internal controller. The board
comes equipped with a 40-pin flat-cable connector. The detailed
pin assignment of the connector is specified as following table:

15
•CN4: IDE Interface Connector
PIN NO. DESCRIPTION PIN NO. DESCRIPTION
1RESET# 2GROUND
3DATA 7 4DATA 8
5DATA 6 6DATA 9
7DATA 5 8DATA 10
9DATA 4 10 DATA 11
11 DATA 3 12 DATA 12
13 DATA 2 14 DATA 13
15 DATA 1 16 DATA 14
17 DATA 0 18 DATA 15
19 GROUND 20 N/C
21 N/C 22 GROUND
23 IOW# 24 GROUND
25 IOR# 26 GROUND
27 N/C 28 BALE - DEFAULT
29 N/C 30 GROUND - DEFAULT
31 INTERRUPT 32 IOCS16#-DEFAULT
33 SA1 34 N/C
35 SA0 36 SA2
37 HDC CS0# 38 HDC CS1#
39 HDD ACTIVE# 40 GROUND
3.3 Parallel Port
This port is usually connected to a printer, The NOVA-300 includes an
on-board parallel port, accessed through a 26-pin flat-cable connector
CN12. The detailed pin assignment of the connector is specified as
following table:
•CN12 : Parallel Port Connector
PIN
NO. DESCRIPTION PIN NO. DESCRIPTION
1STROBE# 2DATA 0
3DATA 1 4DATA 2
5DATA 3 6DATA 4
7DATA 5 8DATA 6
9DATA 7 10 ACKNOWLEDGE

16
11 BUSY 12 PAPER EMPTY
13 PRINTER SELECT 14 AUTO FORM FEED #
15 ERROR# 16 INITIALIZE
17 PRINTER SELECT LN# 18 GROUND
19 GROUND 20 GROUND
21 GROUND 22 GROUND
23 IOW# 24 GROUND
25 GROUND
3.4 Serial Ports
The NOVA-300 offers four high speed NS16C550 compatible UARTs
with Read/Receive 16 byte FIFO serial ports. These ports let you
connect to serial devices or a communication network. One DB-9
connector and thee 10-pin headers are provides by the NOVA-300. The
detailed pin assignment of the connectors are specified as following
tables:
•Port1(CN17) : 2x5-pin Header
PIN NO. DESCRIPTION PIN NO. DESCRIPTION
1DCD 6DSR
2RXD 7RTS
3TXD 8CTS
4DTR 9RI
5GND 10 N/C
•Port2(CN14) : 2x5-pin Header at RS-232 mode
PIN NO. DESCRIPTION PIN NO. DESCRIPTION
1DCD 6DSR
2RXD 7RTS
3TXD 8CTS
4DTR 9RI
5GND 10 N/C
•Port3(CN1) : 2x5-pin Header at RS-422/485 mode
PIN NO. DESCRIPTION PIN NO. DESCRIPTION
1TX- 6RX+
2TX+ 7RX-
38
49
510

17
•Port3(CN1) and Port4(CN2) : 2x5-pin Header
PIN NO. DESCRIPTION PIN NO. DESCRIPTION
1DCD 6DSR
2RXD 7RTS
3TXD 8CTS
4DTR 9RI or 5V/12V
5GND 10 N/C
3.5 IrDA Infrared Interface Port
The NOVA-300 built-in IrDA port which support Serial
Infrared(IR) or Amplitude Shift Keyed IR(ASKIR) interface.
When use the IrDA port have to set SIR or ASKIR model in the
BIOS’s Port2 setup. Then the normal RS-232 Port2 will be
disabled.
•CN6 : IrDA Connector
PIN NO. DESCRIPTION
15V
2N/C
3IR-RX
4GND
5IR-TX
3.6 Keyboard/Mouse Connector
The NOVA-300 provides keyboard and mouse connectors,both
are 5-pin heard connector.
.
.
•CN18 : 5-pin Header Keyboard Connector
PIN NO. DESCRIPTION
1KEYBOARD CLOCK
2KEYBOARD DATA
3N/C
4GROUND
5+5V

18
•CN16 : 5-pin Header Mouse Connector
PIN NO. DESCRIPTION
1MOUSE CLOCK
2MOUSE DATA
3N/C
4GROUND
5+5V
3.7 External Switches and Indicators
There are many external switches and indicators for monitoring
and controlling your CPU board. These features are completely
optional install them if you need them. The detailed pin
assignment of the connectors is specified as following table:
•CN7 : RESET BUTTON
PIN NO. DESCRIPTION
1EXTERNAL RESET
2GROUND
•CN11 : IDE LED connector
PIN-NO DESCRIPTION
1+5V
2HDD ACTIVE#
•CN8 : POWER LED & KEYLOCK
PIN NO. DESCRIPTION
1POWER LED ANODE
2KEY
3GROUND
4KEYLOCK
5GROUND
3.8 External Power Connector
The NOVA-300 has an on-board external power connector CN21.
The CN21 is compatible to EBX form factor board’s power
connector. The power connector type is Molex 26-60-4080 or
equivalent one. The max, rating for each pin is 7A.
•
CN21 : EXTERNAL POWER CONNECTOR

19
PIN NO. DESCRIPTION
1+5V
2Ground
3Ground
4+12V
5N/C
6Ground
7+5V
8-12V
3.9 External Speaker
The NOVA-300 has its own buzzer, you also can connect to the
external speaker through the connector CN3.:
•CN3 : SPEAKER
PIN NO. DESCRIPTION
1+5V
2SPEAKER SIGNAL
3.10 PC/104 Connection Bus
The NOVA-300's PC/104 expansion bus let you attach any kind
of PC/104 modules. The PC/104 bus is already become the
industrial embedded PC bus standard, so you could easily install
over thousands of PC/104 modules from hundreds of venders in
the world.
NOTE : NOVA-300 allows directly plug in PC/104
module,don‘t need PC/104 Connection Kit.
3.11 LCD Interface Connector
The NOVA-300 provides a 2x22-pin connector for the LCD flat
panel interface.
•CN20: LCD Interface Connector
PIN NO. DESCRIPTION PIN NO. DESCRIPTION
1+12V 2+12V

20
3GND 4GND
5+5V 6+5V
7FPVEE 8GND
9P0 10 P1
11 P2 12 P3
13 P4 14 P5
15 P6 16 P7
17 P8 18 P9
19 P10 20 P11
21 P12 22 P13
23 P14 24 P15
25 P16 26 P17
27 P18 28 P19
29 P20 30 P21
31 P22 32 P23
33 GND 34 GND
35 SHFCLK 36 FLM
37 M38 LP
39 GND 40 ENABLK
41 GND 42 N/C
43 FPVDD 44 5V
4
