TA790GX A3+ BIOS Manual
i
BIOS Setup .................................................................................................1
1 Main Menu...............................................................................................3
2Advanced Menu.......................................................................................7
3 PCIPnP Menu........................................................................................16
4 Boot Menu..............................................................................................19
5 Chipset Menu.........................................................................................21
6 T-S eries Menu........................................................................................30
7 Exit Menu...............................................................................................44

TA790GX A3+ BIOS Manual
1
BIOS Setup
Introduction
The purpose of this manual is to describe the settings in the AMI BIOS Setup
program on this motherboard. The Setup program allows users to modify the basic
system configuration and save these settings to CMOS RAM. T he power of CMOS
RAM is supplied by a battery so that it retains theSetup information when the power
is turned off.
Basic Input-Output System (BIOS) determines what a computer can do without
accessing programs from a disk. This system controls most of the input and output
devices such as keyboard, mouse, serial ports and disk drives. BIOS activates at the
first stage o f the booting process, loading and executing the operating system. Some
additional features, such as virus and password protection or chipset fine-tuning
options are also included in BIOS.
The rest of this manual will to guide you through the options and settings in BIOS
Setup.
Plug and Pla y Support
This AMI BIOS supports the Plug and Play Version 1.0A specification.
EPA Gre e n PC Sup por t
This AMI BIOS supports Version 1.03 of the EPA Green PC specification.
APM Support
This AMI BIOS supports Version 1.1&1.2 of the Advanced Power Man agement
(APM) speci fication. Power management features a re implemented via the System
Management Int errupt (SMI). Sleep and Suspend power man agement modes are
supported. Power to the hard disk drives and video monitors can also be managed by
this AMI BIOS.
ACPI Support
AMI ACPI BIOS support Version 1.0/2.0 of Advanced Configuration and Power
interface specifi cation (ACPI). It provides ASL code for power management and
device configuration capabilities as defined in the ACPI specification, developed by
Microsoft, Intel and Toshiba.

TA790GX A3+ BIOS Manual
2
PCI Bus Support
This AMI BIOS also supports Version 2.3 of the Intel PCI (Peripheral Component
Interconn ect) local bus speci fication.
DRAM S upp ort
DDR2 SDRAM (Double Data Rate II Synchronous DRAM) is supported.
Supported CP Us
This AMI BIOS supports the AMD CPU.
Using Setup
W hen starting up the computer, press
<Del> during the Power-On Self-Test
(POST) to enter the BIOS setup utility.
In the BIOS setup utility, you will see
General Help description at the top right
corner, and this is providing a brief
description of the selected item.
Navigation Keys for that particular menu
are at the bottom right corner, and you can
use these keys to select item and ch ange
the settings.
Noti ce
zThe default BIOS settings apply for most conditions to ensure optimum performance
of the motherboard. If the system becomes unstable after changing any settings,
please load the default settings to ensure system’s compatibility and stability. Use
Load Setup Default under the Exit Menu.
zFor better system perform ance, the BIOS firmware is being continuously updated.
The BIOS information described in this manual is for your reference only. T he actual
BIOS information and settings on board may be slightly different from this manual.
zThe content of this manual is subject to be changed without notice. We will not be
responsible for any mistakes found in this user’s manual and any system damage that
may be caused by wrong-settings.
General Help
Navigation Keys

TA790GX A3+ BIOS Manual
3
1 Main Menu
Once you enter AMI BIOS Setup Utility, the Main Menu will appear on the screen
providing an overview of the basic system inform ation.
BIOS SETU P U TILITY
Main Advan ced PCIPnP Boot Chipset T-Series
vxx .xx (C)Copyright 1985-200x, American Me gatrends, Inc.
S elect Screen
S elect Item
C hange Field
S elect Field
G eneral Help
S ave and Exit
Exit
+-
Tab
F1
F10
ESC
Use [ENTER], [TAB]
or [SHIFT-TAB] to
select a field.
Use [+] or [-] to
configure system Time.
System Overvie w
AMI BIOS
System Memory
[ : 00:00]
System Date [Tue 01/01/2008]
Floppy A
> Hard Drive C onfiguration
Version :01. 01.01
Build Date:01/ 01/08
Size :
System Time 00
Exit
AMI BIOS
Shows system information, including BIOS version and built date.
System Memory
Shows system memory size.
System Time
Set the system internal clock.
System Date
Set the system date. Note that the ‘Day’ automatically changes when you set the
date.

TA790GX A3+ BIOS Manual
4
Floppy A
Select the type of floppy disk drive installed in your system.
Options: 360K, 5.25in / 1.2M, 5.25 in/ 720K, 3.5 in / 1.44M, 3.5 in /
2.88M, 3.5 in / None
Hard Drive Configuration
T he BIOS will automatically detect the presence of ID E/SAT A devices. There is a
sub-menu fo r each IDE/SAT A device. S elect a device and press <Enter> to enter
the sub-menu of detailed options.
BIOS SETUP UTILITY
Main
vxx.xx (C)Copyright 1985-200x, American Megatrends, Inc.
Select Screen
Select Item
Go to Sub Screen
General Help
Save and Exit
Exit
Enter
F1
F10
ESC
While entering setup ,
BIOS auto detects th e
presence of IDE
devices. This displa ys
the status of auto
detection of IDE
devices.
IDE Confuguration
> Primary IDE Slave
> SATA 1 Device
Hard Disk Write Protect [Disabled]
IDE Detect Time Out (Sec) [35]
> SATA 2 Device
> SATA 3 Device
> SATA 4 Device
> SATA 5 Device
> SATA 6 Device
> Primary IDE Master

TA790GX A3+ BIOS Manual
5
Primary IDEMaster/Slav e ; SATA 1/2/3/4/5/6 Device
BIOS SETUP UTILITY
Main
vxx.xx (C)Copyright 1985-200x, American Megatrends, Inc.
Select Screen
Select Item
Change Option
General Help
Save and Exit
Exit
+-
F1
F10
ESC
Select the type
of device connected
to the system.
Primary IDE Master
LBA/Large Mode [Auto]
Block (Multi-Sector Transfer)[Auto]
PIO Mode [Auto]
DMA Mode [Auto]
S.M.A.R.T [Auto]
32Bit Data Transfer [Enabled]
Device :
Type [Auto]
T he BIOS detects the information and values of resp ective devic es, and these
information and values are shown below to the name of the sub-menu.
Type
Select the type of the IDE/SATA drive.
Options: Auto (Default) / CDROM / ARMD / Not Installed
LBA/Large Mode
Enable or disable the LBA mode.
Options: Auto (Default) / Disabled
Block (Multi-Sector Transfer)
Enable or disable multi-sector trans fer.
Options: Auto (Default) / Disabled
PIO Mode
Select the PIO mode.
Options: Auto (Default) / 0 / 1/ 2 / 3 /4
DMA Mode
Select the DMA mode.
Options: Auto (Default) / SWDMA0 ~ 2 / MWDMA0 ~ 2 / UDMA0 ~ 5
S.M.A.R.T
Set the Smart Monitoring, Analysis, and ReportingTechnology.
Options: Auto (Default) / Disabled / Enabled

TA790GX A3+ BIOS Manual
6
32Bit Data Transfer
Enable or disable 32-bit data transfer.
Options: Enabled (Default) / Disabled
Hard Disk Write Protect
Disable or enable device write protection. This will be effective only if the device
is accessed through BIOS.
Options: Disabled (Default) / Enabled
IDE Detect Time Out (Sec)
Select the time out value for detecting IDE/SATA devices.
Options: 35 (Default) / 30 / 25/ 20 / 15 / 10 / 5 / 0

TA790GX A3+ BIOS Manual
7
2 Advanced Menu
The Advanced Menu allows you to configu re the settings of CPU, Super I/O, Power
Management, and other system devices.
Notice
zBeware of that setting inappropriate values in items of this menu may cause
system to malfunction.
BIOS SETU P U TILITY
Main Advan ced PCIPnP Boot Chipset T-Series
vxx .xx (C)Copyright 1985-200x, American Me gatrends, Inc.
S elect Screen
S elect Item
G o to Sub Screen
G eneral Help
S ave and Exit
Exit
Enter
F1
F10
ESC
Options for CPUAdvanced Setti ngs
WARNING: Setti ng wrong values in below sections
may c ause system to malf unction.
> SuperIO Conf iguration
> Smart Fan Co nfiguration
> Hardware Hea lth Configuration
> Power Config uration
> USB Configur ation
> CPU Configur ation
Exit
CPU Configuration
Thisitem shows the CPU information that the BIOS automatically detects.
BIOS S ETUP UTILITY
Advanced
vxx.xx (C)C opyright 198 5-200x, Amer ican Megatre nds, Inc.
S elect Screen
S elect Item
C hange Option
G eneral Help
S ave and Exit
E xit
+-
F1
F1 0
ES C
Enab le/Disable
Secu re Virtual M achine
Mode (SVM)
CPU C onfiguration
Modul e Version:
AGESA Version:
Physi cal Count:
Logic al Count:
AMD C PU
Revis ion:
Cache L1:
Cache L2:
Cache L3:
Speed : NB Clk:
ncHT Speed : Width I/O :
Able to Change Fre q :
uCode Patch Level :
Secur e Virtual Mac hine Mode [ Enabled]
Cool N Quiet [ Enabled]
ACPI SRAT Table [ Enabled]

TA790GX A3+ BIOS Manual
8
Secure Virtual Machine Mode
Virtualization Technology can virtually separate your system resource into several
parts, thus enhance the performance when running virtual machines or multi
interface systems.
Options: Enabled (Default) / Disabled
Cool N Quiet
This item allows you to enable or disable the Cool & Quiet power saving technology.
Options: Enabled (Default) / Disabled
ACPI SRAT Table
T he operating system scans the ACP I SRAT at boot time and uses the information to
better allocate memory and schedule software threads for maximum perform ance.
This item controls whether the SRAT is made available to the operating system at
boot up, or not.
Options: Enabled (Default) / Disabled
Advanced Clock Calibration
Advanced Clock Calibration (ACC) is an enhanced technology for overclocking,
needing support from both chipset and CPU. When enabled, it will improve the
stability of advanced overclocking greatly.
Options: Disabled (Default) / Auto / All Cores / Per Core
Value (All Cores ) / Value (Core 0)/ Value (Core 1) / Value (Core 2)/ Value (Core 3 )
This item shows only when “ Advanced Clock Calibration” is set to “All Cores” or
“Per Core”.
Options: -2% (Default) / 0% / +2% / +4% / +6% / +8% /+10% / +12% / -4% / -6%
/ -8% / -10% / -12%
C1E Support
This item allows you to configure the Enhanced Halt State (C1E) fun ction, which
may reduce the power consumption of your system when the system is idle.
Options: Disabled (Default) / Enabled
Core Leveling
This item allows you to activate Core Leveling function.
Options: Auto(Default) / Force Single Core / Force Dual Core / Force Tri Core /
Enable all Cores

TA790GX A3+ BIOS Manual
9
S upe r IO Conf igur a t io n
BIOS S ETUP UTILITY
Advanced
vxx.xx (C)C opyright 198 5-200x, Amer ican Megatre nds, Inc.
S elect Screen
S elect Item
C hange Option
G eneral Help
S ave and Exit
E xit
+-
F1
F1 0
ES C
Allo ws BIOS to E nable
or D isable Flopp y
Cont roller
Confi gure ITE8718 Super IO Chi pset
Onboa rd Floppy Con troller [ Enabled]
Keybo ard PowerOn [ Disabled]
Mouse PowerOn [ Disabled]
Resto re on AC Powe r Loss [ Power Off]
Onboard Floppy Controller
Select enabled if your system has a floppy disk controller (FDC) installed on the
system board and you wish to use it. If you installed another FDC or the system uses
no floppy drive, select disabled in this field.
Options: Enabled (Default) / Disabled
Keyboard Pow erOn
This item allows you to control the keyboard power on function.
Options: Disabled (Default) / Specific Key / Stroke Key
Specific KeyEnter
This item will show only when Keyboard PowerOn is set “Specific Key.”
Stroke KeysSelected
This item will show only when Keyboard PowerOn is set “Stroke Key.”
Options: Ctrl+F1 (Default) / Wake Key / Power Key / Ctrl+F2 / Ctrl+F3 /
Ctrl +F4 / Ctrl+F5 / Ctrl+F6

TA790GX A3+ BIOS Manual
10
Mouse PowerOn
This item allows you to control the mouse power on function.
Options: Disabled (Default) / Enabled
Restore on AC Power Loss
This setting specifies how your system should behave after a power fail or interrupts
occurs. By choosing Disabled will leave the computer in the power off state.
Choosing Enabled will restore the system to the status before power failure or
interrupt occurs.
Options: Power Off (Default) / Power ON / LastState
Smart Fan Configuration
BIOS SETU P U TILITY
Advan ced
vxx .xx (C)Copyright 1985-200x, American Me gatrends, Inc.
S elect Screen
S elect Item
C hange Option
G eneral Help
S ave and Exit
Exit
+-
F1
F10
ESC
When you choice [Auto]
,[3Pin] or [4Pin],
please run the
calibration to define
the Fan parameters for
Smart Fan control
Smart Fan Conf iguration
CPU Smart Fan [Dis abled]
Smart Fan Cali bration
Control Mode
Fan Ctrl OFF( C)
o
Fan Ctrl On( C )
Fan Ctrl Start value
Fan Ctrl Sensi tive
o
CPU Smart Fan
This item allows you to control the CPUSmart Fan function.
Options: Disabled (Default) / Auto / 4-pin / 3-pin
Smart Fan Calibration
Choose this item and then the BIOS will auto test and detect the CPU/System fan
fun ctions and show CPU/System fan speed.

TA790GX A3+ BIOS Manual
11
Control Mode
This item provides several operation modes of the fan.
Options: Quiet / Performance / Manual
Fan Ctrl OFF(℃ )
If the CPU/System Temperature is lower than the set value, FAN will turn off.
Options: 0~127 (℃)
Fan Ctrl On(℃ )
CPU/System fan starts to work under smart fan function when arrive this set value.
Options: 0~127 (℃)
Fan Ctrl Start Value
When CPU/System temperature arrives to the set value, the CPU/System fan will
work under Smart Fan Function mode.
Options: 0~127 (℃)
Fan Ctrl Sensitive
Incr easing the value will raise the speed of CPU/System fan.
Options: 1~127
Hardware Health Configuration
This item shows the system temperature, fan speed, and voltage information.
Advanced
Hardw are Health Co nfiguration
H/W H ealth Functio n [ Enabled]
Shutd own Temperatu re [ Disabled]
SYS
CPU T emperature
CPU F an (JCFAN1)
CHIP Fan (JNFAN1)
Syste m1 Fan (JSFAN 1)
CPU V core
NB Vo ltage
+3.30 V
+5.00 V
+12.0 V
DDR V oltage
HT Vo ltage
Temperat ure
BIOS S ETUP UTILITY
vxx.xx (C)C opyright 198 5-200x, Amer ican Megatre nds, Inc.
S elect Screen
S elect Item
C hange Option
G eneral Help
S ave and Exit
E xit
+-
F1
F1 0
ES C
Enab les Hardware
Heal th Monitorin g
Devi ce.

TA790GX A3+ BIOS Manual
12
H/W Health Function
If you computer contains a monitoring system, it will show PC health status during
POST stage.
Options: Enabled (Default) / Disabled
Shutdow n Temperature
This item allows you to set up the CPU shutdown Temperature. This item is only
effective under Windows 98 ACPI mode.
Options: Disabled (Default) / 60 /140 / 65 /149 / 70 /158 / 75 /167℃℉℃℉℃℉ ℃℉
/ 80 /176 / 85 /185 / 90 /194℃℉℃℉℃℉
Power Configuration
BIOS S ETUP UTILITY
Advanced
vxx.xx (C)C opyright 198 5-200x, Amer ican Megatre nds, Inc.
S elect Screen
S elect Item
C hange Option
G eneral Help
S ave and Exit
E xit
+-
F1
F1 0
ES C
Sele ct the ACPI
stat e used for
Syst em Suspend.
ACPI Settings
Suspe nd mode [ S1 (POS)]
ACPI Version Featu res [ ACPI v1.0]
ACPI APIC support [ Enabled]
AMI O EMB table [ Enabled]
Headl ess mode [ Disabled]
RTC R esume [ Disabled]
RTC A larm Date(Day s)
T ime
USB W akeup From S3 /S4 [ Disabled]
Power On by PCIE/O nboard LAN [ Disabled]
Wake Up by PCI [ Enabled]
RTC A larm
Suspend mode
The item allows you to select the suspend type under the ACPI operating system.
Options: S1 (POS) (Default) Power on Suspend
S3 (STR) Suspend to RAM
S1 & S3 POS+STR
ACPI Version Features
T he item allows you to select the version of ACPI.
Options: ACPI v1.0 (Default) / ACPI v2.0

TA790GX A3+ BIOS Manual
13
ACPI APIC support
T his item is used to enable or disable the motherboard's APIC (Advan ced
Programmable Interrupt Controller). The APIC provides multiprocessor support,
more IRQs and faster interrupt handling.
Options: Enabled (Default) / Disabled
AMI OEMB table
Set this value to allowthe ACPIBIOS toadd a pointer to an OEMB table in the Root
System Description Table (RSDT) table.
Options: Enabled (Default) / Disabled
Headless mode
This is a server-speci fic feature. A headless server is one that operates without a
keyboard, monitor or mouse. To run in headless mode, both BIOS and operating
system (e.g. WindowsServer 2003) must supportheadless operation.
Options: Disabled (Default) / Enabled
RTC Resume
When “ Enabled”, you can set the date and time at which the RTC (real-time clock)
alarm awak ens the system from Suspend mode.
Options: Disabled (Default) / Enabled
RTC Alarm Date (Days)
You can choose which date the system will boot up.
RTC Alarm Time
You can choose the system boot up time, input hour, minute and second to specify.
USB Wakeup from S3/S4
This item allows you to enable or disabled the USB resume from S3/S4 function.
Options: Disabled (Default) / Enabled
Power On by PCIE/OnboardLAN
This item allows you control the wake on LAN (WOL) function.
Options: Disabled (Default) / Enabled

TA790GX A3+ BIOS Manual
14
Wake Up by PCI
Enable / Disable PCI to generate a wake event.
Options: Enabled (Default) / Disabled
USB Configuration
This item shows the USB controller and using USB device information.
BIOS S ETUP UTILITY
Advanced
vxx.xx (C)C opyright 198 5-200x, Amer ican Megatre nds, Inc.
S elect Screen
S elect Item
C hange Option
G eneral Help
S ave and Exit
E xit
+-
F1
F1 0
ES C
Enab les support for
lega cy USB. AUTO
opti on disables
lega cy support i f
no U SB devices a re
conn ected.
USB C onfiguration
USB D evices Enable d:
Modul e Version - 2 .24.3-13.4
Legac y USB Support [ Enabled]
USB 2 .0 Controller Mode [ HiSpeed]
BIOS EHCI Hand-Off [ Enabled]
> USB Mass Storage Device Conf iguration
Legacy USB Support
This item determines if the BIOS should provide legacy support for USB devices
like the keyboard, mouse, and USB drive. T his is a useful fe ature when using such
USB devices with operating systems that do not natively support USB (e.g.
Microsoft DOS or Windows NT).
Options: Enabled (Default) / Disabled
USB 2.0 Controller Mode
This item allows you to select the operation mode of the USB 2.0 controller.
Options: HiSpeed (Default) USB 2.0-480Mbps
FullSpeed USB 1.1-12Mbps
BIOS EHCI Hand-Off
This item allows you to enable support for operating systems without an EHCI
hand-o ff feature.
Options: Enabled (Default) / Disabled

TA790GX A3+ BIOS Manual
15
USB Mass Storage Dev ice Configuration
BIOS SETUP UTILITY
Advanced
vxx.xx (C)Copyright 1985-200x, American Megatrends, Inc.
Select Screen
Select Item
Change Option
General Help
Save and Exit
Exit
+-
F1
F10
ESC
Number of seconds
POST waits for the
USB mass storage
device after start
unit command.
USB Mass Storage Device Configuration
USB Mass Storage Reset Delay [20 Sec]
Emulation Type [Auto]
Device #
USB Mass Storage Reset Delay
This item allows you to set the reset delay for USB mass storage device.
Options: 20 S ec (De fault) / 10 Sec / 30 Sec / 40 Sec
Emulation Type
This item allows you to select the emulation type of the USB mass storage device.
Options: Auto (Default) / Floppy / Forced FDD / Hard Disk / CDROM

TA790GX A3+ BIOS Manual
16
3 PCIPnP Menu
This section describes configuring the PCI bus system. PCI, or Personal Computer
Interconnect, is a system which allows I/O devices to operate at speeds nearing the
speed of the CPU itselfuses when communicating with itsown special components.
Notice
zBeware of that setting inappropriate values in items of this menu may cause
system to malfunction.
BIOS SETU P U TILITY
Main Advan ced PCIPnP Boot Chipset T-Series
vxx .xx (C)Copyright 1985-200x, American Me gatrends, Inc.
S elect Screen
S elect Item
C hange Option
G eneral Help
S ave and Exit
Exit
+-
F1
F10
ESC
Clear NVRAM during
System Boot.
Advanced PCI/P nP Settings
WARNING: Setti ng wrong values in below sections
may c ause system to malf unction.
Plug & Play O/ S [No]
PCI Latency Ti mer [64]
Allocate IRQ t o PCI VGA [Yes ]
Palette Snoopi ng [Dis abled]
PCI IDE BusMas ter [Ena bled]
> PCI Resource
Clear NVRAM [No]
Exit
Clear NV RAM
This item allows you to clear the data in the NVRAM (CMOS) by selecting “Yes”.
Options: No (Default) / Yes
Plug & P lay OS
When set to YES, BIOS will only initialize the PnP cards used for the boot sequence
(VGA, IDE, SCSI). The rest of the cards will be initialized by the PnP operating
system like Window™ 95. When set to NO, BIOS will initialize all the PnP cards.
For non-PnP operating systems (DOS, Netware™), this option must set to NO.
Options: No (Default) / Yes

TA790GX A3+ BIOS Manual
17
PCI Latency Timer
This item controls how long a PCI device can hold the PCI bus before another takes
over. T he longer the latency, the longer the PCI device can retain control of the bus
before handing it over to another PCI device.
Options: 64 (Default) / 0-255
Allocate IRQ to PCI VGA
This item allows BIOS to choose a IRQ to assign for the PCI VGA card.
Options: Yes (Default) / No
Palette Snooping
Some old graphic controllers need to “ snoop” on the VGA palette and then map it to
their display as a way to provide boot information and VGA compatibility. This item
allows such snooping to take place.
Options: Disabled (Default) / Enabled
PCI IDE BusMaster
This item is a toggle for the built-in driver that allows the onbo ard IDE controller to
per form DMA (Direct Memory Access) trans fers.
Options: Enabled (Default) / Disabled
PCI Resource
BIOS SETUP UTILITY
PCIPnP
vxx.xx (C)Copyright 1985-200x, American Megatrends, Inc.
Select Screen
Select Item
Change Option
General Help
Save and Exit
Exit
+-
F1
F10
ESC
Available: Specified
IRQ is available to be
used by PCI/PnP
devices.
Reserved: Specified
IRQ is reserved for
use by Legacy ISA
devices.
PCI Resource
IRQ3 [Available]
IRQ4 [Available]
IRQ5 [Available]
IRQ7 [Available]
IRQ9 [Available]
IRQ10 [Available]
IRQ11 [Available]
IRQ14 [Available]
IRQ15 [Available]
DMA Channel 0 [Available]
DMA Channel 1 [Available]
DMA Channel 3 [Available]
DMA Channel 5 [Available]
DMA Channel 6 [Available]
DMA Channel 7 [Available]
Reserved Memory Size [Disabled]

TA790GX A3+ BIOS Manual
18
IRQ3/4/5/7/9/10/11/14/15
These items will allow you to assign each system interrupt a type, depending on the
type of device using the interrupt. The option “Available” means the IRQ is going
to assign automatically.
Options: Available (Default) / Reserved
DMA Channel 0/1/3/5/6/7
These items will allow you to assign each DMA channel a type, depending on the
type of device using the channel. The option “ Available” means the channel is
going to assign automatically.
Options: Available (Default) / Reserved
Reserved Memory Size
Thisitem allows BIOS to reserve cert ain memory size for speci fic PCI device.
Options: Disabled (Default) / Enabled

TA790GX A3+ BIOS Manual
19
4 Boot Menu
This menu allows you to setup the system boot options.
BIOS S ETUP UTILITY
Main Advanced PCIPnP Boot Chips et T-Series
vxx.xx (C)C opyright 198 5-200x, Amer ican Megatre nds, Inc.
S elect Screen
S elect Item
G o to Sub Scr een
G eneral Help
S ave and Exit
E xit
En ter
F1
F1 0
ES C
Spec ifies the
Boot Device
Prio rity sequenc e.
Boot Settings Conf iguration
> Har d Disk Drives
> Rem ovable Drives
> CD/ DVD Drives
Quick Boot [ Enabled]
Full Screen LOGO S how [ Enabled]
AddOn ROM Display Mode [ Force BIOS]
Bootu p Num-Lock [ ON]
Inter rupt 19 Captu re [ Enabled]
Ignor e Memory Erro r Messages [ Disabled]
BOOT SUCCESS BEEP [ Enabled]
> Boo t Device Prio rity
Exit
Boot De vice Priorit y
Items in this sub-menu specify the boot device priority sequence from the available
devices. The number of device items that appears on the screen depends on the
number of devi ces installed in the system.
Options: Removable / Hard Disk / CDROM / Legacy LAN / Disabled
Hard Disk Drives
T he BIOS will attempt to arrange the hard disk boot sequence automatically. You
can also ch ange the booting sequence. T he number of device items that app ears on
the screen depends on the number of devices installed in the system.
Options: Pri. Master / P ri. Slave / Sec. Master / Sec. Slave / USB HDD0 /
USB HDD1 / USB HDD2 / Bootable Add-in Cards
Removable Dri ves
T he BIOS will attempt to arrange the removable drive boot sequence automatically.
You can also change the booting sequence. The number of device items that
appears on the screen depends on the number of devices installed in the system.
Options: Floppy Disks / Zip100 / USB-FDD0 / USB-FDD1 / USB-ZIP0 /
USB-ZIP1 / LS120
