Bita-International HC61 User manual
Android is a trademark of Google LLC.
BITA-INTERNATIONAL CO., LTD
Handheld Computer
HC61 User Manual
1
Content
Content.......................................................................................... 1
Statement.......................................................................................... 3
Chapter 1 Product intro ..................................................................... 4
1.1 Intro....................................................................................... 4
1.2 Precaution before using battery............................................. 5
1.3 Charger................................................................................. 6
1.4 Notes .................................................................................... 7
Chapter 2 Installation instructions...................................................... 8
2.1 Appearance ............................................................................. 8
2.2 Install Micro SD and SIM cards.............................................. 10
2.3 Battery charge ....................................................................... 11
2.4 Buttons and function area display .......................................... 12
Chapter 3 Call function.................................................................... 13
3.1 Calling numbers..................................................................... 13
3.2 Contacts ................................................................................ 13
3.3 SMS and MMS....................................................................... 13
Chapter 4 Barcode reader-writer ..................................................... 14
Chapter 5 RFID reader.................................................................... 16
5.1 NFC ....................................................................................... 16
Chapter 6 Other functions ............................................................... 17
6.1 PING tool ............................................................................... 17
6.2 Bluetooth ............................................................................... 18
6.3 GPS....................................................................................... 19
6.4 Volume setup......................................................................... 20
6.5 Sensor ................................................................................... 21
6.6 Keyboard ............................................................................... 22
3
Statement
2020 by Bita-International Co., Ltd. All rights reserved.
No part of this publication may be reproduced or used in any form, or
by any electrical or mechanical means, without permission written
from Bita-International. This includes electronic or mechanical means,
such as photocopying, recording, or information storage and retrieval
systems. The material in this manual is subject to change without
notice.
The software is provided strictly on an “as is” basis. All software,
including firmware, furnished to the user is on a licensed basis. Bita-
International grants to the user a non-transferable and non-exclusive
license to use each software or firmware program delivered
hereunder (licensed program). Except as noted below, such license
may not be assigned, sublicensed, or otherwise transferred by the
user without prior written consent of Bita-International. No right to
copy a licensed program in whole or in part is granted, except as
permitted under copyright law. The user shall not modify, merge, or
incorporate any form or portion of a licensed program with other
program material, create a derivative work from a licensed program,
or use a licensed program in a network without written permission
from Bita-International.
Bita-International reserves the right to make changes to any software
or product to improve reliability, function, or design.
Bita-International does not assume any product liability arising out of,
or in connection with, the application or use of any product, circuit, or
application described herein.
No license is granted, either expressly or by implication, estoppel, or
otherwise under any Bita-International intellectual property rights. An
implied license only exists for equipment, circuits, and subsystems
contained in Bita-International products.
4
Chapter 1 Product intro
1.1 Intro
Bita-International HC61 is a new generation rugged handheld
computer with robust performance. Built with AndroidTM 9 OS and
Qualcomm Octa-Core processor, it supports numeric/QWERTY
keypad, abundant accessories like trigger handle, and features
powerful removable battery. And it delivers optional barcode
scanning, RFID, NFC, etc. This mobile computer can fulfill
applications in logistics, warehousing, retail, etc.
5
1.2 Precaution before using battery
Do not leave battery unused for long time, no matter it is in
device or inventory. If battery has been used for 6 months
already, it should be check for charging function or it should be
disposed correctly.
The lifespan of Li-ion battery is around 2 to 3 years, it can be
circularly charged for 300 to 500 times. (One full battery charge
period means completely charged and completely discharged.)
When Li-ion battery is not in used, it will continue discharge
slowly. Therefore, battery charging status should be checked
frequently and take reference of the related battery charging
information on the manuals.
Observe and record the information of a new unused and non-
fully charged battery. On the basis of operating time of new
battery and compare with a battery that has been used for long
time. According to product configuration and application
program, the operating time of battery would be different.
Check battery charging status at regular intervals.
When battery operating time drops below about 80%, charging
time will be increased remarkably.
If a battery is stored or otherwise unused for an extended
period, be sure to follow the storage instructions in this
document. If you do not follow the instructions, and the battery
has no charge remaining when you check it, consider it to be
damaged. Do not attempt to recharge it or to use it. Replace it
with a new battery.
Store the battery at temperatures between 5 °C and 20 °C
(41 °F and 68 °F).
6
1.3 Charger
The charger type is GME10D-050200FGu, output voltage/current is
5V DC/2A. The plug considered as disconnect device of adapter.
7
1.4 Notes
Note:
Using the incorrect type battery has danger of explosion.
Please dispose the used battery according to instructions.
Note:
Due to the used enclosure material, the product shall only be
connected to a USB Interface of version 2.0 or higher. The
connection to so called power USB is prohibited.
Note:
The adapter shall be installed near the equipment and shall be
easily accessible.
Note:
The suitable temperature for the product and accessories is 0-10℃
to 50℃.
Note:
CAUTION RISK OF EXPLOSION IF BATTERY IS REPLACED BY
AN INCORRECT TYPE. DISPOSE OF USED BATTERIES
ACCORDING TO THE INSTRUCTIONS.
8
Chapter 2 Installation instructions
2.1 Appearance
HC61 back and front appearances are showing as follows:
9
Buttons instruction
SCAN
Volume
+/-
Main
Keyboard
POWER
Type-C
Port
10
2.2 Install Micro SD and SIM cards
The cards sockets are showing as follows:
11
2.3 Battery charge
By using USB Type-C contact, the original adaptor should be used for
charging the device. Make sure not to use other adaptors to charge
the device.
12
2.4 Buttons and function area display
HC61 has main keyboard that contains
10 numeric keys+2 symbolic keys, 4 direction keys, 2 Android functio
n keys, ENTER/ESC/TAB/ALT/CTRL/BACK/DELETE, 10 user-
defined function keys (reuse with letter keys), 1 POWER key, 1 SCA
N key, 1 Alt key, 27keys, 37 keys or 47keys in total.
Side keys: 2 SCAN keys+2 volume keys+1 user-defined key, 2D
scanning module locates on the top. HD camera and flashlight locate
at rear. NFC identification surrounds the camera.
13
Chapter 3 Call function
3.1 Calling numbers
1. Click icon .
2. Click number key to input phone numbers.
3. Click icon to call.
4. Click icon to end call.
3.2 Contacts
1. Click contacts to open contacts list.
2. Click icon to add new contacts.
3. Click icon to import/export contacts.
3.3 SMS and MMS
1. Click to open message window.
2. Click to input message receiver and contents.
3. Click to send out messages.
4. Click to add attachment pictures and videos.
14
Chapter 4 Barcode reader-writer
1. In App Center, to open 2D barcode scan test.
2. Press “SCAN” button or click scan key to start scanning, the
parameter “Auto interval” can be adjusted.
Caution: Please scan codes in correct way otherwise the
scanning will be failed.
2D code:
15
Max. radiant power: 0.6mW
Wave length: 655nM
IEC 60825-1 (Ed.2.0).
21CFR 1040.10 and 1040.11 standard.
16
Chapter 5 RFID reader
5.1 NFC
Click App Center, open “NFC” to read and write tag information.
17
Chapter 6 Other functions
6.1 PING tool
1. Open “PING” in App Center.
2. Setup PING parameter and select external/internal address.
18
6.2 Bluetooth
1. Open “BT Printer” in App Center.
2. In the list of detected devices, click the device that you want to
pair.
3. Select printer and click “Print” to start printing contents.
19
6.3 GPS
1. Click “GPS” in App Center to open GPS test.
2. Setup GPS parameters to access GPS information.
