BitaTek GS100 User guide

2
BarCode Decode Setup Manual
Table of Contents
Setup Flow Chart ..............................................................................................................................7
Part I System Information.................................................................................................................8
Reset to default: ........................................................................................................................8
Display Firmware Version:.......................................................................................................8
Part II System Setting .......................................................................................................................9
2.1 Interface: .............................................................................................................................9
Part III Keyboard wedge parameters.................................................................................................9
3.1 Terminal Type:....................................................................................................................9
3.2 Language Selection:..........................................................................................................10
3.3 Function Key Emulation:..................................................................................................11
3.4 Keyboard Emulation:........................................................................................................11
3.5 ALT Mode: .......................................................................................................................12
3.6 Caps Lock : .......................................................................................................................12
3.7 Numeric Key:....................................................................................................................12
3.8 Inter-Character Delay：....................................................................................................12
3.9 Delay After Transmit (Keyboard Wedge):........................................................................13
3.10 Keyboard Speed:.............................................................................................................13
3.11 Keyboard Wedge Terminator: .........................................................................................13
Part IV USB Virtual COM Protocol:..............................................................................................13
4.1 Baud Rate：......................................................................................................................13
4.2 Data Bits: ..........................................................................................................................14
4.3 Stop Bits:...........................................................................................................................14
4.4 Parity Check:.....................................................................................................................14
4.5 Inter-Character Delay:.......................................................................................................15
4.6 Delay After Transmit:.......................................................................................................15
4.7 Response Delay Time: ......................................................................................................15
4.8 Flow Control:....................................................................................................................15
4.9 RS232- Interface Terminator:...........................................................................................15
Part V System Setting .....................................................................................................................16
5.1 Scan Mode: .......................................................................................................................16
5.2 Buzzer...............................................................................................................................18
5.2.1 Buzzer Frequency: .................................................................................................18
5.2.2 Duration .................................................................................................................18
5.2.3 Power up Buzzer:...................................................................................................18
5.2.4 Good Read Buzzer:................................................................................................18
5.3 String.................................................................................................................................19
5.3.1 Prefix and Suffix:...................................................................................................19
5.3.2 Insert Character Group (G1/G2): ...........................................................................19
5.3.3 Code Type Transmit：...........................................................................................20
5.4 Barcode Inverse：.............................................................................................................21

3
Part VI Barcode Type Setting:........................................................................................................21
6.1 UPC-A...............................................................................................................................22
6.1.1 Enable/Disable UPC-A: .........................................................................................22
6.1.2 Code ID setting: .....................................................................................................22
6.1.3 Convert UPC-A to EAN-13:..................................................................................22
6.1.4 Transmit Check Digit:............................................................................................22
6.1.5 Truncate Leading Zero:..........................................................................................22
6.1.6 Truncate Leading Digits:........................................................................................23
6.1.7 Truncate Ending Digits:.........................................................................................23
6.1.8 Insert Characters: ...................................................................................................23
6.1.9 Decode UPC-A Supplemental:...............................................................................23
6.2 UPC-E...............................................................................................................................23
6.2.1 Enable/Disable UPC-E:..........................................................................................23
6.2.2 Code ID setting ......................................................................................................24
6.2.3 Convert UPC-E to UPC-A:....................................................................................24
6.2.4 Transmit Check Digit:............................................................................................24
6.2.5Truncate Leading Zero:...........................................................................................24
6.2.6 Truncate leading digits:..........................................................................................24
6.2.7 Truncate Ending Digits:.........................................................................................24
6.2.8 Insert Characters: ...................................................................................................24
6.2.9 Decode UPC-E Supplementals: .............................................................................25
6.3 EAN-13.............................................................................................................................25
6.3.1 Enable/Disable EAN-13:........................................................................................25
6.3.2 Code ID Setting:.....................................................................................................25
6.3.3 Transmit Check Digit:............................................................................................25
6.3.4 Convert to ISBN/ISSN:..........................................................................................26
6.3.5 Truncate leading digits:..........................................................................................26
6.3.6 Truncate Ending digits:..........................................................................................26
6.3.7 Insert Characters: ...................................................................................................26
6.3.8 Decode EAN-13 Supplemental:.............................................................................26
6.4 EAN-8...............................................................................................................................27
6.4.1 Enable/Disable EAN-8:..........................................................................................27
6.4.2 Code ID Setting:.....................................................................................................27
6.4.3 Transmit Check Digit:............................................................................................27
6.4.4 Truncate Leading Digits:........................................................................................27
6.4.5 Truncate Ending Digits:.........................................................................................27
6.4.6 Insert Characters: ...................................................................................................27
6.4.7 Decode EAN-8 Supplemental:...............................................................................28
6.5 Code39..............................................................................................................................28
6.5.1 Enable/Disable CODE39: ......................................................................................28
6.5.2 Code ID Setting......................................................................................................28
6.5.3 Code 39 Check Digit Verification:.........................................................................28
6.5.4 Transmit Check Digit:............................................................................................29
6.5.5 Code 39 Full ASCII Conversion:...........................................................................29

4
6.5.6 Transmit Start/End Character:................................................................................29
6.5.7 Min Code Length: (defult:00)................................................................................29
6.5.8 Max Code Length: (default:32H)...........................................................................29
6.5.9 Truncate Leading Digits:........................................................................................29
6.5.10 Truncate ending digits:.........................................................................................29
6.5.11 Insert Characters:..................................................................................................29
6.6 Codabar.............................................................................................................................30
6.6.1 Enable/Disable CODABAR...................................................................................30
6.6.2 Code ID setting ......................................................................................................30
6.6.3 Check Digit:...........................................................................................................30
6.6.4 Transmit Check Digit:............................................................................................30
6.6.5 Data Combine: .......................................................................................................31
6.6.6 Start/End Transmit Type:.......................................................................................31
6.6.7 Start/End Transmit:................................................................................................31
6.6.8 Min Code Length: (default:00) ..............................................................................31
6.6.9 Max Code Length: (default:32H)...........................................................................31
6.6.10 Truncate Leading Digits:......................................................................................31
6.6.11 Truncate Ending Digits: .......................................................................................31
6.6.12 Insert Characters: .................................................................................................31
6.7 Code93..............................................................................................................................32
6.7.1 Enable/Disable CODE93: ......................................................................................32
6.7.2 Code ID Setting:.....................................................................................................32
6.7.3 Check Digit:...........................................................................................................32
6.7.4 Transmit Check Digit:............................................................................................32
6.7.5 Min Code Length: (default:00) ..............................................................................33
6.7.6 Max Code Length: (default:32H)...........................................................................33
6.7.7 Truncate Leading Digits:........................................................................................33
6.7.8 Truncate Ending Digits:.........................................................................................33
6.7.9 Insert Characters: ...................................................................................................33
6.8 Code 128...........................................................................................................................33
6.8.1 Enable/Disable CODE128: ....................................................................................33
6.8.2 Code ID Setting:.....................................................................................................34
6.8.3 Check Digit:...........................................................................................................34
6.8.4 Transmit Check Digit.............................................................................................34
6.8.5 FNC2 Data Combine:.............................................................................................34
6.8.6 UCC/EAN128:.......................................................................................................34
6.8.7 FNC1 Transmit: .....................................................................................................34
6.8.8 Min Code Length: (default:00) ..............................................................................34
6.8.9 Max Code Length: (default:32H)...........................................................................35
6.8.10 Truncate Leading Digits:......................................................................................35
6.8.11 Truncate Ending Digits: .......................................................................................35
6.8.12 Insert Characters: .................................................................................................35
6.9 Interleaved 2 of 5 ..............................................................................................................35
6.9.1 Enable/Disable Interleaved 2 of 5:.........................................................................35

5
6.9.2 Code ID Setting:.....................................................................................................35
6.9.3 Check Digit:...........................................................................................................36
6.9.4 Transmit Check Digit:............................................................................................36
6.9.5 Min Code Length: (default:00) ..............................................................................36
6.9.6 Max Code Length: (default:32H)...........................................................................36
6.9.7 Truncate Leading Digits:........................................................................................36
6.9.8 Truncate Ending Digits:.........................................................................................36
6.9.9 Insert Characters: ...................................................................................................36
6.10 Industrial 2 of 5...............................................................................................................37
6.10.1 Enable/Disable Industrial 2 of 5:..........................................................................37
6.10.2 Code ID Setting:...................................................................................................37
6.10.3 Check Digit:.........................................................................................................37
6.10.4 Transmit Check Digit:..........................................................................................37
6.10.5 Min Code Length: (default: 00) ...........................................................................37
6.10.6 Max Code Length: (default:32H).........................................................................37
6.10.7 Truncate Leading Digits:......................................................................................37
6.10.8 Truncate ending digits:.........................................................................................38
6.10.9 Insert Characters: .................................................................................................38
6.11 Matrix 2 of 5....................................................................................................................38
6.11.1 Enable/Disable Matrix 2 of 5: ..............................................................................38
6.11.2 Code ID Setting:...................................................................................................38
6.11.3 Check Digit: .........................................................................................................38
6.11.4 Transmit Check Digit:..........................................................................................39
6.11.5 Min Code Length: (default: 00)............................................................................39
6.11.6 Max Code Length: (default:32H).........................................................................39
6.11.7 Truncate Leading Digits:......................................................................................39
6.11.8 Truncate Ending Digits: .......................................................................................39
6.11.9 Insert Characters:..................................................................................................39
6.12 China Post Code..............................................................................................................39
6.12.1 Enable/Disable China post:..................................................................................39
6.12.2 Code ID Setting:...................................................................................................40
6.12.3 Check Digit:.........................................................................................................40
6.12.4 Transmit Check Digit:..........................................................................................40
6.12.5 Min Code Length: (default:00) ............................................................................40
6.12.6 Max Code Length: (default:32H).........................................................................40
6.12.7 Truncate Leading Digits:......................................................................................40
6.12.8 Truncate Ending Digits:.......................................................................................40
6.12.9 Insert Characters: .................................................................................................40
6.13 MSI/Plessey ....................................................................................................................41
6.13.1 Enable/Disable MSI/Plessey:...............................................................................41
6.13.2 Code ID Setting:...................................................................................................41
6.13.3 Check Digit:.........................................................................................................41
6.13.4 Transmit Check Digit:..........................................................................................42
6.13.5 Min Code Length: (default:00) ............................................................................42

6
6.13.6 Max Code Length: (default:32H).........................................................................42
6.13.7 Truncate Leading Digits:......................................................................................42
6.13.8 Truncate Ending Digits:.......................................................................................42
6.13.9 Insert Characters: .................................................................................................42
6.14 CODE 32.........................................................................................................................42
6.14.1 Enable/Disable CODE 32: ...................................................................................42
6.14.2 Code ID Setting:...................................................................................................43
6.14.3 Check Digit:.........................................................................................................43
6.14.4 Transmit Check Digit:..........................................................................................43
6.14.5 Truncate Leading Digits:......................................................................................43
6.14.6 Truncate Ending Digits:.......................................................................................43
6.14.7 Insert Characters: .................................................................................................43
6.15 CODE 11.........................................................................................................................44
6.15.1 Enable/Disable CODE 11:....................................................................................44
6.15.2 Code ID Setting:...................................................................................................44
6.15.3 Check Digit..........................................................................................................44
6.15.4 Transmit Check Digit...........................................................................................44
6.15.5 Min Code Length: (default:00) ............................................................................44
6.15.6 Max Code Length: (default:32H).........................................................................44
6.15.7 Truncate Leading Digits.......................................................................................45
6.15.8 Truncate Ending Digits ........................................................................................45
6.15.9 Insert Characters...................................................................................................45
6.16 RSS .................................................................................................................................45
6.16.1 Enable/Disable RSS-14 (GS1-Databar)...............................................................45
6.16.2 Enable/Disable RSS-14 (GS1-Databar) Limited..................................................45
6.16.3 Enable/Disable RSS-14 (GS1-Databar) Expanded ..............................................46
6.16.4 RSS-14 (GS1-Databar) to UPC/EAN ..................................................................46
6.17 Telepen............................................................................................................................46
6.17.1 Enable/Disable Telepen:.......................................................................................46
6.17.2 Code ID Setting....................................................................................................46
6.17.3 Check Digit:.........................................................................................................46
6.17.4 Transmit Check Digit:..........................................................................................47
6.17.5 Min Code Length: (default: 00) ...........................................................................47
6.17.6 Max Code Length: (default:32H):........................................................................47
6.17.7 Truncate Leading Digits.......................................................................................47
6.17.8 Truncate Ending Digits ........................................................................................47
6.17.9 Insert Characters...................................................................................................47
AppendixA.....................................................................................................................................48
Appendix B.....................................................................................................................................50
Appendix C –Default Setting Table...............................................................................................52

7
Setup Flow Chart
Note:
1. Scan “firmware version barcode”, the Version No. will be displayed on monitor.
2. The default settings are shown with < > and bold in the following sections.
Scan “End”barcode
Scan “Start
Configuration”barcode
“Start Configuration”
Scan the barcode you
like to change
to change
Scan two HEX digits in
Appendix A to represent
one ASCII code.
Hex or ASCII Code
Scan “End
Configuration”barcode
Reset to default
YES
NO

8
Part I System Information
Reset to default:
Reset to factory default settings. The default settings are shown with < > and bold.
Display Firmware Version:
Scan barcode to display firmware version.
Start Configuration
Reset to default
Firmware Version
End Configuration

9
Part II System Setting
2.1 Interface:
Start Configuration
< USB Keyboard >
< USB Virtual COM >
End Configuration
Part III Keyboard wedge parameters
3.1 Terminal Type:
Start Configuration
< IBMAT >
Reserved
Reserved
Reserved
Reserved
Reserved

10
Reserved
Reserved
End Configuration
3.2 Language Selection:
Start Configuration
American
Italian
Spanish
France
Germany
Japanese
Reserved
Reserved
End Configuration

11
Note:
Scan the barcode to select local keyboard language, if your keyboard language can't be found,
please turn on ALT Mode which is an alternate way to find your language.
3.3 Function Key Emulation:
Start Configuration
< Disable >
Enable
3.4 Keyboard Emulation:
< Disable >
Enable
End Configuration
Note 1:
If the setting of Function Key Emulation is “Enable”, when barcode reader scans the applicable
barcode in Appendix B, it represents the function key is enabled in applications.
Note 2:
Key Board Emulation is to emulate PC keyboard. If no installation of PC keyboard, recommend to
enable this function to assist you in turning on the PC normally.

12
3.5 ALT Mode:
Start Configuration
< Disable >
Enable
3.6 Caps Lock :
< Disable >
Enable
3.7 Numeric Key:
< Disable >
Enable
End Configuration
Note 1:
ALT Mode can emulate most of local keyboard languages in Microsoft system.
Note 2:
The barcode reader can emulate to enable/disable Caps Lock key.
Note 3:
The barcode reader can emulate to enable/disable Numeric Key.
3.8 Inter-Character Delay：
Start Configuration

13
Enable (00H, 00-64H*1msec)
3.9 Delay After Transmit (Keyboard Wedge):
Enable (00H, 00-0AH*100msec)
3.10 Keyboard Speed:
Enable (00H, 00-08H)
3.11 Keyboard Wedge Terminator:
None
< CR >
TAB
ESC
End Configuration
Note:
Keyboard Wedge Terminator is to set up the termination character of barcode reader output to
adapt to applications.
Part IV USB Virtual COM Protocol:
4.1 Baud Rate：
Start Configuration
1200bps

14
2400bps
4800bps
< 9600bps >
19200bps
38400bps
4.2 Data Bits:
7 Digits
< 8 Digits >
4.3 Stop Bits:
< 1 Digit >
2 Digits
4.4 Parity Check:
< None >
Odd
Even
Mark

15
Space
4.5 Inter-Character Delay:
Enable (00H, 00-64H*1msec)
4.6 Delay After Transmit:
Enable (00H, 00-0AH*100msec)
4.7 Response Delay Time:
Enable (00H, 00-0AH*100msec)
End Configuration
Note:
Response Delay Time is the time of barcode reader waiting for host to response. The delay
time=setting data*100(ms).
4.8 Flow Control:
Start Configuration
< None >
RTS/CTS
ACK/NAK
Xon/Xoff
4.9 RS232- Interface Terminator:
None

16
< CR+LF >
CR
LF
TAB
STX/ETX
EOT
End Configuration
Note:
RS232- Interface Terminator is to set up the termination character of barcode reader output to
adapt to applications.
Part V System Setting
5.1 Scan Mode:
Start Configuration
Trigger Mode
< Auto Off Mode >
Continuous/Trigger Off Mode

17
Test Mode
Continuous Mode
Continuous/Timeout Off Mode
Flash Mode
Continuous/No Trigger
End Configuration
Note:
Trigger Mode: Press trigger to turn on scanner. To turn off the scanner, just release trigger or
after barcode decoded.
Auto off Mode: Press trigger to turn on scanner. Scanner will be automatically off when time out
or after barcode decoded.
Continuous (Trigger Off) Mode: Press trigger to activate continuous scan mode. Scanner will
keep scanning and decoding barcodes. If the same barcode is scanned, it will only decode once.
Press trigger again to turn off the scanner.
Test Mode: Press trigger to activate test mode, scanner will scan and decode barcodes
continuously until trigger is pressed again.
Continuous Mode: Press trigger to activate continuous scan mode, scanner will keep scanning
and decoding barcodes. If the same barcode is scanned, it will only decode once and the red LED
is always on.
Continuous (Timeout Off) Mode: Press trigger to activate test mode. Scanner will scan and
decode barcodes continuously until trigger is pressed again. If the scanner doesn’t decode during
timeout, then the red LED will be off.
Flash Mode: Press trigger to activate continuous scan mode, the red LED will be on for 3 seconds
and then off for 3 seconds. If the decoding is correct, the red LED will be off immediately and
then proceed next flash cycle.
Continuous /No trigger Mode: When turn on barcode reader, it will activate Continuous /No
trigger mode automatically.

18
5.2 Buzzer
5.2.1 Buzzer Frequency:
Start Configuration
< High >
Medium
Low
5.2.2 Duration
< Long >
Medium
Short
5.2.3 Power up Buzzer:
Disable
< Enable >
5.2.4 Good Read Buzzer:
Disable
< Enable >
End Configuration

19
5.3 String
5.3.1 Prefix and Suffix:
Start Configuration
Set up prefix (00H)
Set up suffix (00H)
End Configuration
Note:
The maximum characters can be set as prefix and suffix are 10 ASCII characters, if the setting is 0
means there is no prefix or suffix.
Formats of prefix and suffix are as follows:
Prefix string
Barcode data
Suffix string
The steps to setup prefix and suffix:
Scan “Enter to Setup” and “Prefix” barcode.
Find the ASCII code in appendix B.
Scan the desired barcode to set as prefix/suffix.
Scan “End” barcode.
Scan “End Configuration Setup”.
5.3.2 Insert Character Group (G1/G2):
Start Configuration
Insert Character Position G1(00H)
Insert Character Position G2(00H)

20
End Configuration
Note:
Up to 10ASCII codes can be inserted in a group. When the setting is zero, no codes will be
inserted.
Steps to insert characters：
Scan “Start Configuration”and then Scan “G1” barcode for the Barcode you want to use.
Scan ASCII code barcode in appendix B.
Scan “End Configuration”
Repeat step 2 and step 3 if you wish to setup G2 Insert Character.
Scan “End Configuration”
Position to insert character: Choose a position to insert characters, when the setting is zero,
non-zero characters will not be inserted.
Scan “Start Configuration”
Scan “Insert Character Position”for G1,
Scan ASCII code barcode in appendix B.
Scan “End Configuration”
Repeat the steps to insert character position for G2.
Scan “End Configuration”
5.3.3 Code Type Transmit：
Start Configuration
< Disable >
Enable
End Configuration
Note:
To transmit Code Type, you have to enable Code Type Transmit. The format is Code Type ID +
Barcode Data.
