Omron V460-H Instruction Manual

Z479-E1-01
Programmable Controller CJ-series
General Ethernet (TCP/IP) Connection Guide
OMRON Corporation
Industrial Handheld DPM Reader
V460-H-series

About Copyrights and Trademarks
Microsoft product screen shots used with permission from Microsoft.
Windows is a registered trademark of Microsoft Corporation in the USA and other countries.
ODVA, EtherNet/IP are trademarks of ODVA.
Sysmac and SYSMAC are trademarks or registered trademarks of OMRON Corporation in
Japan and other countries for OMRON factory automation products.
Company names and product names in this document are the trademarks or registered
trademarks of their respective companies.

Contents
1. Related Manuals.......................................................................................... 1
2. Terms and Definitions................................................................................. 2
3. Restrictions and Precautions .................................................................... 3
4. Overview ...................................................................................................... 4
5. Applicable Products and Device Configuration ...................................... 5
5.1. Applicable Products............................................................................. 5
5.2. Device Configuration ........................................................................... 6
6. Ethernet Settings ........................................................................................ 8
6.1. Ethernet Communication Settings....................................................... 8
6.2. Example of Connection Check for Communications........................... 9
7. Connection Procedure.............................................................................. 10
7.1. Operation Flow .................................................................................. 10
7.2. Code Reader Setup............................................................................11
7.3. PLC Setup ......................................................................................... 15
7.4. Checking the Connection Status....................................................... 27
8. Initializing the System .............................................................................. 31
8.1. Ethernet Unit...................................................................................... 31
8.2. Code Reader ..................................................................................... 31
9. Software Part ............................................................................................. 32
9.1. Overview............................................................................................ 32
9.2. Error Judgment Processing............................................................... 37
9.3. Memory Map...................................................................................... 40
9.4. Ladder Program................................................................................. 44
9.5. Timing Chart ...................................................................................... 61
9.6. Error Code List................................................................................... 65
10. Revision History .................................................................................... 67

1. Related Manuals
1
1. Related Manuals
The following manuals are related to this document.
To ensure system safety, make sure to always read and follow the information provided in all
Safety Precautions and Precautions for Safe Use in the manuals for each device which is
used in the system.
Cat. No. Model Manual name
W420 CS1W-ETN21
CJ1W-ETN21
CJ-series
Ethernet Units Operation Manual
Construction of Networks
W421 CS1W-ETN21
CJ1W-ETN21
CJ-series
Ethernet Units Operation Manual
Construction of Applications
W446 ―CX-Programmer Operation Manual
W474 CJ2-CPU CJ Series
Instructions Reference Manual
Z461
V460-H Series
V460-H Industrial Handheld DPM Reader User
Manual
Z462
V460-H Series
V460-H Industrial Handheld DPM Reader
Communication Manual

2. Terms and Definitions
2
2. Terms and Definitions
Below is a list of terms used in this manual and their definitions.
Term
Description/Definition
IP Address Ethernet uses IP addresses to achieve communications.
Each IP address (specifically, Internet Protocol address) identifies a
specific node (host computer, controller, etc.) on an Ethernet network,
IP addresses must be set and managed so that they are not duplicated.
Socket A socket is an interface that allows you to directly use TCP or UDP
functions from the user program.
CJ Series Programmable Controllers support socket services in the
following ways.
• Manipulating dedicated control bits in the CPU Bus Unit Area in the
CIO Area
• Sending FINS commands (CMND instructions) to the Ethernet Unit
To use socket services, you need to establish a connection with a remote
node and disconnect it after use. In this document, processing for
establishing a connection is referred to as “socket open” or “TCP open”
and for disconnecting it as “socket close” or “close”. You can use the
socket services to send and receive arbitrary data to and from the remote
node.
Active and Passive When you open a TCP socket connection with nodes, open processing is
executed for each node.
The method to open a connection differs depending on whether the node
is to serve as a client or server.
In this document, processing to open a connection as a server is referred
to as “passive open” and as a client is referred to as “active open” or
“active open processing”
keep-alive Function When a remote node (server or client) does not respond for a set period
of time or longer in TCP/IP socket services, the keep-alive function sends
a communications frame to the node to check the connection status.
If the node does not respond to it, the function performs this check at a
certain interval, and closes the connection if it does not respond to all
check frames.
linger function This is a TCP socket option that sends RST data when the TCP socket is
closed. This enables immediate open processing using the same port
number, without waiting for the port to be opened.
If the linger option is not specified, the controller issues FIN data when
the TCP socket is closed and, after that, performs end control such as a
send data arrival check with the remote node for approximately 1 minute.
Therefore, TCP sockets with the same port number may not be used
immediately.

3. Restrictions and Precautions
3
3. Restrictions and Precautions
(1) Before building a system, understand the specifications of devices which are used in the
system. Allow some margin for ratings and performance, and provide safety measures
such as installing a safety circuit in order to minimize the risk in case of failure.
(2) To ensure system safety, make sure to read and follow the information provided in all
Safety Precautions and Precautions for Safe Use in the manuals for each device which is
used in the system.
(3) The user is encouraged to confirm the standards and regulations that the system must
conform to.
(4) It is prohibited to copy, to reproduce, and to distribute a part or the whole of this
document without the permission of OMRON Corporation.
(5) The information contained in this document is current as of November 2023.
It is subject to change for improvement without notice.
The following notations are used in this document.
Indicates a potentially hazardous situation which, if not avoided,
may result in minor or moderate injury, or may result in serious
injury or death. Additionally, there may be severe property
damage.
Indicates a potentially hazardous situation which, if not avoided,
may result in minor or moderate injury, or property damage.
Precautions for Safe Use
Precautions on what to do and what not to do to ensure safe usage of the product.
Precautions for Correct Use
Precautions on what to do and what not to do to ensure proper operation and performance.
Note
Additional information to read as required.
This information is provided to increase understanding or make operation easier.
Symbols
The filled circle symbol indicates operations that you must do.
The specific operation is shown in the circle and explained in
text.
This example shows a general precaution for something that
you must do.

4. Overview
4
4. Overview
This document describes the procedures for connecting the OMRON Industrial Handheld
DPM Reader products (V460-H Series) to a CJ Series Programmable Controller (hereinafter
referred to as the controller) via Ethernet and for checking their connections.
You can establish an Ethernet communication connection by understanding the setting
procedures and key points of setup through the Ethernet communications settings in the
“CX-Programmer Project File” prepared in advance.
In this project file, the Ethernet connection is checked by sending a read trigger command to
the code reader and receiving the read data from it.
Obtain the latest version of the CX-Programmer Project File from OMRON in advance.
Name Filename Version
CX-Programmer Project File
(Extension: cxp)
OMRON_V460_CJ_ETN(TCP)_V100.cxp Ver. 1.00
The purpose of this document is to describe the wiring methods, communication
settings, and setting procedures required to establish a connection for
communications with applicable devices. In addition, the program used in this
document is designed to check that the connection has been correctly
performed (connection check). Since t
he program is not intended for permanent
use on-site, full consideration is not given to functionality and performance.
When configuring an actual system, please refer to the wiring methods,
communication settings, and setting procedures described in this document to
design and create a program that meets your purpose.

5. Applicable Products and Device Configuration
5
5. Applicable Products and Device Configuration
5.1. Applicable Products
The applicable devices that are required to ensure a connection are as follows:
Manufacturer Name Model Version
OMRON Ethernet Unit CJ1W-ETN21
Same or later version as
indicated in section 5.2.
OMRON CJ2 Series CPU Unit CJ2-CPU
OMRON Code reader V460-H0PX
Note
From among the above applicable devices, this document uses the devices listed in section
5.2 for the connection check. When using devices that are not described in section 5.2, check
the connection according to this document.
Note
This document describes the procedures for establishing the communication connection of
the device, and does not describe the operation, installation and wiring method of the device.
For details on the above products (other than communication connection procedures), please
refer to the instruction manual for the product or contact OMRON.
Precautions for Correct Use
The connection and connection check procedures described in this document use the
devices listed in section 5.2, from among the above applicable devices.
You cannot use devices with versions earlier than the versions listed in section 5.2.
To use models that are not listed in section 5.2. or versions that are later than those listed in
section 5.2., check the differences in the specifications according to their instruction manuals
before operating the devices.

5. Applicable Products and Device Configuration
6
5.2. Device Configuration
The system components required for reproducing the connection procedures described in this
document are as follows.
Manufacturer
Name
Model
Version
OMRON
CPU Unit
CJ2M-CPU11
Ver. 2.0
OMRON
Ethernet Unit
CJ1W-ETN21
Ver. 1.5
OMRON
Power Supply Unit
CJ1W-PA202
---
OMRON
CX-One
CXONE-AL

C-V4
/ALD-V4
Ver. 4.

OMRON
Switching hub
W4S1-05C
Ver. 1.00
---
24 VDC power supply
(for switching hub)
---
---
OMRON
CX-Programmer
(Included with CX-One)
Ver. 9.72
OMRON
CX-Protocol
(Included with CX-One)
Ver. 2.03
OMRON
CX-Protocol Project File
(Ladder Program)
OMRON_V460_CJ_ETN(
TCP)_V1_00.cxp
Ver. 1.00
---
PC (OS: Windows 10)
---
---
---
USB cable
(USB 2.0-compliant B-type
connector)
---
---
OMRON Ethernet cable V430-WE-3M ---
---
LAN cable
(Standard Ethernet cable)
---
---
OMRON Code reader V460-H0PX Ver. 1.0
---
Single port PoE injector
98-9000311-01
---
CJ2M-CPU11
CJ1W-ETN21
Switching hub
(W4S1-05C)
USB cable
LAN cable 24 VDC power supply
PoE hub
Ethernet cable
V430-WE-3M
LAN
cable
PC
(OS: Windows 10,
CX-One Installed)
V460-H0PX

5. Applicable Products and Device Configuration
7
Precautions for Correct Use
Obtain the latest version of the above CX-Programmer Project File from OMRON in advance.
(Contact OMRON for information on how to obtain this file.)
Precautions for Correct Use
This document assumes that the USB is used to connect the PLC. For information on how to
install the USB driver, refer to the CX-Programmer Operation Manual (Cat. No. W446).
Note
Refer to the Industrial Switching Hub W4S1 Series User Manual (0969584-7) for power
supply specifications that can be used for 24 VDC power supply (for the switching hub).

6. Ethernet Settings
8
6. Ethernet Settings
This section shows the specifications of the communication parameter settings, variable
names and other information provided in this document.
Note
This document and the project file only cover the operations that you can perform using the
settings and commands described in this section. To use communication settings that are not
described here, you need to modify the project file.
6.1. Ethernet Communication Settings
The settings required to perform Ethernet communications are as follows.
6.1.1. Communications Settings for Setting PC and Code Reader
This document assumes that you use the settings below to set the code reader using a setting
PC.
Parameter name
Setting PC
Code reader
IP address 192.168.188.100 192.168.188.2 (default)
Subnet mask
255.255.0.0
255.255.0.0 (default)
Gateway Blank (default) 0.0.0.0 (default)
* For the use cases in this document, setting the gateway is unnecessary because the devices
are connected within the same segment of the network.
6.1.2. Communication Settings for Ethernet Unit and Code Reader
It is assumed that you use the settings below to connect the Ethernet Unit and the code
reader.
CJ1W-ETN21
Code reader
Unit number 0 (default) ---
Node address
01 (default)
---
Automatic setting --- OFF
IP address 192.168.188.1 192.168.188.2
Subnet mask 255.255.0.0 255.255.0.0 (default)
Port number (set by software part) 2001 (fixed)
* For the use cases in this document, setting the gateway is unnecessary because the devices
are connected within the same segment of the network.

6. Ethernet Settings
9
6.2. Example of Connection Check for Communications
This document assumes that you use a ladder program (also referred to as the software part)
to execute “socket open”, “send and receive”, and “socket close” from the PLC to the code
reader (V460 Series).
The controller sends a “read trigger” command to the code reader. The code reader sends the
read data back to the controller.
An overview of the operation is shown below.
CPU ETN Ethernet Code reader
User memory
Ladder program
I/O memory
D10000
to
D12000
Send/
receive
data,
etc.
specified
Socket communications
function
Socket open
Socket close
Read data
Receive data
storage area
Receives read data.
Press the trigger button
on the code reader to
read the code.
Reads
code.

7. Connection Procedure
10
7. Connection Procedure
This section describes the procedures for connecting the controller to an Ethernet network.
In this document, it is assumed that the controller and the code reader use the factory default
settings. For how to initialize the devices, refer to Section 8. Initializing the System.
7.1. Operation Flow
The procedures for connecting and setting up the Ethernet Unit are as follows.
7.2. Code Reader Setup
Set up the code reader.
▼
7.2.1. Setting the Parameters
Set the parameters for the code reader.

7.3. PLC Setup
Set up the PLC.
▼
7.3.1. Setting the Hardware Set the physical switches on the Ethernet Unit.
▼
7.3.2. Loading the Ladder Program
and Going Online with the
PLC
Start the programming tool “CX-Programmer”, load
the ladder program, and go online with the PLC.
▼
7.3.3. Creating the I/O Table Create the I/O table for the CPU Unit.
▼
7.3.4. Editing the Parameters Set the parameters for the Ethernet Unit.
▼
7.3.5. Transferring the Ladder
Program
Transfer the ladder program to the CPU Unit.

7.4. Checking the Connection Status Execute the transferred ladder program to check that
Ethernet communications work correctly.
▼
7.4.1. Executing the Ladder Program
and Checking the I/O Memory
Data
Execute the ladder program and, in the
CX-Programmer, check that the correct data is written
to the I/O memory of the PLC.

7. Connection Procedure
11
7.2. Code Reader Setup
Set up the code reader.
Precautions for Correct Use
Use a PC (personal computer) to set the parameters for the code reader.
Note that you may need to change the PC settings depending on the condition of your PC.
7.2.1. Setting the Parameters
Set the parameters for the code reader.
Set the IP address of your PC to 192.168.188.100 and its subnet mask to 255.255.0.0.
1
Connect the cord reader and the
switching hub to the PoE
injector with cables.
2
Connect the PC to the switching
hub with a LAN cable.
Connect 24 VDC power supply
(for the switching hub) to the
switching hub.
3
Set the IP Address of the PC.
For the IP address, enter
192.168.188.100. For the
subnet mask, enter 255.255.0.0.
For the procedure to open the
screen on the right, please refer
to step 4.
LAN cable
24 VDC power supply
V460-H0PX
Ethernet
cable
Switching hub
W4S1-05C
LAN cable
PoE hub

7. Connection Procedure
12
4
Static connection (Setting the fixed IP address)
(1) Click the Start Button at the lower left corner of the screen, and then click Settings.
(2) Select Windows Settings – Network & Internet.
(3) Under Change your network settings, click Change adapter options.
(4) In Network Connections, right-click on the Ethernet icon and select Properties.
(5) In the Ethernet Properties Dialog Box, select Internet Protocol Version 4 (TCP/IPv4),
and click the Properties Button. Set the IP Address of the PC to 192.168.188.100.
(6) Click the OK Button.
5
Start your browser and enter
http://192.168.188.2.
“Google Chrome” is the
recommended browser.
6
When the WebLink
HH
startup
screen is displayed, go to step
8.
If you cannot access by
WebLinkHH, go to step 7.
7
If the WebLink
HH
startup screen does not appear, it means that communications are not
established between the code reader and the PC. Please check the following.
• The code reader and the PC have a proper physical (cable) connection.
→ Refer to steps 1 and 2 for checking the connection.
• The IP Addresses of the PC and code reader are set correctly.
→ Refer to step 4 for setting the IP address of the PC.
For other measures that can be taken, please refer to What should I do if I can’t connect to
WebLinkHH? in Q&A –Section 8 of the V460-H Industrial Handheld DPM Reader User Manual
(Cat. No. Z461).

7. Connection Procedure
13
8
The WebLink
HH
screen
appears.
9
Click on the gear icon on the
upper right of the screen and
select Advanced.
10
The Advanced Settings Screen
appears.
Select the Communications
Tab and check the settings
shown in the red frame for
Ethernet.
To use the defaults, you do not
need to change the settings.
If you need to change the IP
address, for example when
connecting multiple code
readers, change the IP Address
setting as necessary.

7. Connection Procedure
14
11
Click on the icon shown in the
red frame to save the settings to
the code reader.
12
Finally, check the version
number of the code reader.
Click on the gear icon on the
upper right of the screen and
select About WebLink.
13
You can check the current
version of the code reader in
About WebLinkHH.
Update the code reader to the
latest version as needed.

7. Connection Procedure
15
7.3. PLC Setup
Set up the PLC.
7.3.1. Setting the Hardware
Set the physical switches on the Ethernet Unit.
Precautions for Correct Use
Turn OFF the power supply before setting the hardware.
1
Confirm that the power supply to
the PLC is OFF.
* If the power supply is ON, you
may not be able to proceed with
the subsequent step of the
procedure.
2
Check the position of the
physical switches on the front of
the Ethernet Unit as shown in the
figure on the right.
3
Set the Unit No. switch to 0.
4
Set the Node address switches
to the default values as follows.
NODE No. x161: 0
NODE No. x160: 1
* Set the IP Address to
192.168.188.1.
* By default, the first three octets
are fixed to “192.168.188”. The
value set by the Node address
switches determines the fourth
octet of the node’s IP address.

7. Connection Procedure
16
7.3.2. Loading the Ladder Program and Going Online with the PLC
Start the programming tool “CX-Programmer”, load the ladder program, and go online with the
PLC.
Install the Tool Software and USB driver on the PC beforehand.
Obtain the “ladder program” to use from the OMRON website.
1
Connect the PC and the PLC
with a USB cable, and turn ON
the power supply to the PLC.
2
Start the CX-Programmer.
3
Select Open from the File
Menu.
4
Select the CX-Programmer
Project File of the version
specified in 5.2. Device
Configuration
(OMRON_V460_CJ_ETN
(TCP)_V100.cxp) and click
Open.
* Please consult your OMRON
representative and obtain the
CX-Programmer Project File
(Ladder Program) to use.
5
After the loading of the ladder
program is completed, select
Programs in the project
workspace.
(Project Workspace)

7. Connection Procedure
17
6
Select Change Model from the
PLC Menu.
7
The Change PLC Dialog Box is
displayed. Select the PLC type
(CJ2M in the figure on the right)
from the Device Type pull-down
menu, and click Settings.
8
The Device Type Settings
Dialog Box is displayed. Select
the CPU type (CPU11 in the
figure on the right) from the CPU
Type pull-down menu, and click
OK.
