BK RESOURCES HS36TA-1 Instruction Manual

INFRARED STRIP HEATER MANUAL
OPERATING & SAFETY MANUAL

INFRARED STRIP HEATER MANUAL
2www.bk-resources.com | [e-mail]
WARNING
Improper installation, adjustment, alteration, ser-
vice or maintenance can cause
property damage, injury or death. Read the installa-
tion, operation and maintenance
instructions thoroughly before installing or servic-
ing this equipment.
FOR YOUR SAFETY
This unit must be serviced by qualied personnel
only. Service by unqualied personnel may lead to
electric shock or burn.
Do not operate this equipment unless you have read and
understand the content of
this manual! This manual contains important safety in-
formation concerning the
maintenance, use and operation of this product. Keep
this manual in a safe location
for future reference.

INFRARED STRIP HEATER MANUAL
3
4A Do-It Drive, Altamont, IL 62411 | P: 888-310-4393 | F: 618-483-9898 | F: 888-310-4394
• Attached toggle controls for simple operation
• Durable metal sheathed elements produce intense heat to keep foods at peak serving
temperatures without overcooking.
• Heavy-duty stainless steel construction; mounting brackets included for easy installation.
• Perfect for use in cafeteria, restaurant, or buet line
Toggle Controls
Toggle controls are simple to operate and provide one level of heat, so you can be sure your
sta does not overheat your foods. Since the controls have only one setting, this warmer is
extremely simple to use so that even new employees can get it up and running for the day.
Features
Part Number Electric Dimensions Mounting
HS24TA-1 120V,500W 6 3/4”X 2 3/4”X24” Angle Brackets
HS36TA-1 120V,850W 6 3/4”X 2 3/4”X36” Angle Brackets
HS48TA-1 120V,1100W 6 3/4”X 2 3/4”X48” Angle Brackets
HS60TA-1 120V,1400W 6 3/4”X 2 3/4”X60” Angle Brackets
HS72TA-1 120V,1725W 6 3/4”X 2 3/4”X72” Angle Brackets
INFRARED STRIP HEATER

INFRARED STRIP HEATER MANUAL
4www.bk-resources.com | [e-mail]
INSTALLATION INSTRUCTIONS

INFRARED STRIP HEATER MANUAL
5
4A Do-It Drive, Altamont, IL 62411 | P: 888-310-4393 | F: 618-483-9898 | F: 888-310-4394
WIRING DIAGRAM

INFRARED STRIP HEATER MANUAL
6www.bk-resources.com | [e-mail]
EXPLODED VIEW OF STANDARD
ON/OFF TOGGLE SWITCH UNIT

INFRARED STRIP HEATER MANUAL
7
4A Do-It Drive, Altamont, IL 62411 | P: 888-310-4393 | F: 618-483-9898 | F: 888-310-4394
PARTS LIST

INFRARED STRIP HEATER MANUAL
8www.bk-resources.com | [e-mail]
CARE & MAINTENANCE
The Infrared Strip Heaters are designed for maximum durability and performance with minimum
maintenance.
WARNING: ELECTRONIC SHOCK HAZARD
• Turn OFF power switch, unplug power cord/turn o power at circuit breaker, and allow unit to cool before
performing any cleaning, adjustments, or maintenance.
• DO NOT submerge or saturate with water. Unit is not waterproof. Do not operate if unit has been sub-
merged or saturated with water.
• This unit is not“jet-proof” construction. Do not use jet clean spray to clean this unit.
WARNING:
Use only light bulbs that meet or exceed National Sanitation Foundation (NSF) standards and are spe-
cically designed for food holding areas. Breakage of light bulbs not specially coated could result in
personal injury and/or food contamination.
The display light is an incandescent or optional halogen bulb that illuminates the warming area. These bulbs
have a special coating to guard against injury and food contamination in the event of breakage.
To replace a display light bulb:
1. Disconnect the power supply and wait until the unit has cooled.
2. Unscrew the light bulb from the unit and replace it with a new, specially-coated incandescent or optional
halogen bulb.
9. This appliance has electrical parts. Do not use it in areas where gasoline, paint, or ammable liquids are
used or stored
NOTICE
Use non-abrasive cleaners and cloths only. Abrasive cleaners and cloths could scratch the nish of the
unit,marring its appearance and making it susceptible to soil accumulation.
IMPORTANT - DO NOT use paper towel or glass cleaner to clean plastic surfaces. Paper towel and glass
cleaner may scratch the material. Wipe o plastic surfaces using a soft, clean, water-dampened cloth.
CLEANING
To preserve the nish of the strip heater, it is recommended that all surfaces be cleaned daily.
1. Turn o the unit and allow the unit to cool.
2. Wipe down all metal surfaces with a water-dampened, nonabrasive cloth. Stubborn stains may be re-
moved with a good stainless steel or non-abrasive cleaner. Clean hard to reach areas using a small brush and
mild soap.
3. Wipe dry the entire unit using a non-abrasive, dry cloth.
4. If equipped, clean the plastic sneeze guards using soft cleaning cloths, mild soap, and water. NOTICE: Do
not use paper towel or glass cleaner on plastic surfaces—scratching may occur.

INFRARED STRIP HEATER MANUAL
9
4A Do-It Drive, Altamont, IL 62411 | P: 888-310-4393 | F: 618-483-9898 | F: 888-310-4394
TROUBLESHOOTING GUIDE
SYMPTOMS POSSIBLE CAUSES REMEDY
Unit is turned“On”but there is no
heat.
No power to unit. Check circuit breaker and reset as necessary.
Switch is defective. Contact authorized Service agent
Wiring is open. Contact authorized Service agent
Heating element defective Contact authorized Service agent
Heat is inadequate.
Unit mounted too high above target area. Lower unit, putting eective heat closer to
target.
Excessive air movement around strip heater target area. Restrict or redirect air movement (air condi-
tioning duct or exhaust fan) away from unit.
Incorrect power supply (low).
Check power supply to unit, making sure it
matches rating on the unit. If power supply
is incorrect, change to match rating on unit
Control switches burn out.
Unit mounted improperly.
Check to see that installation is within speci-
cations for type/model. Increase mounting
height if too close.
Voltage supply too high
Check power supply to unit, making sure it
matches rating on unit. If power supply is
incorrect, change to match rating.
Control switches burn out.
Unit mounted improperly.
Move the unit the proper distance away
from walls,counters, and/or pass-through
shelves. Refer to the installation section for
guidelines.
Remote control enclosure is mounted too close to the heat zone. Move remote control enclosure away from
the heat zone
Switches used are not proper Contact authorized Service agent
