Vybra VS001-W User manual

MULTI-3-IN-1
Heater | Cooling Fan | Air Steriliser
Please read these instructions carefully before using the product.
VS001-W (White)
VS001-B (Black)
Made in China
5 Kingsway Andover UK Vybra

Important Safety Information
1
When using electrical appliances, basic precautions should
always be followed to reduce the risk of fire, electrical shock
and injury to persons, including the following:
WARNING
1.This product is only suitable for indoor use and should not
be used outdoors;
2. Non-professional personnel or unauthorized repair personnel
may not repair or modify the machine;
3. Before plugging in the power supply, please check if the rated
voltage matches the voltage in your home;
4. Keep at least 1.5 meters away from fire source or tinder, and
avoid direct sunlight;
5. Keep away from objects that are flammable, explosive, subject
to heat, deformation, discoloration or deterioration. Keep away
from places with severe dust;
6. Do not replace the power switch by the method of plugging
(unplugging) the power cord plug;
7. To avoid overheating,do not cover the heater;
8. Do not insert any wire or other foreign matter into any hole in
the machine to avoid electric shock;
9. Do not use the heater against the power outlet or under the
power outlet; The power outlet should be placed behind the
fan when the heater is in use；
10. Do not share the socket with other high-power appliances；

11. Do not use this heater around water at all, including
bathrooms or swimming pool areas；
12. This product must be equipped with a CE-UKCA-approved
fixed socket that is consistent with the rated working current；
Do not use a mobile multi-purpose socket；
13. Do no cover the heater at any time；
14. Do not connect the heater to any other timed programmer；
15.If the heater fails, turn off the power and unplug the
immediately；
16. Before use, check the power cord and the plug. If the power
cord is damaged, do not disassemble or replace the power cord.
It must be replaced by the manufacturer's maintenance depa
rtment or a similar professional；
17. Children, elderly people or patients who have lost their
ability to take care of themselves should use this appliance
under the supervision of an adult to prevent accidents.

scillating Angle: 0°
Timer:1- h
Basic Parameters
Product Description
2
Air outlet
Air duct
Body
Display
Air Inlet
Switch
Power button
Base Power Cable
Cover
Model No: VS001-W (White) VS001-B (Black)
Rated Voltage: 220-240V~
Rated Frequency: 50-60Hz
Output Power: 2000W(H)/30W(B)
This product uses PTC heating and heats via hot air which can quickly
increase the room temperature. There is no open flame. It is efficient
and energy saving.

Remote Introduction
3
①
②
③
④
⑤
⑥
⑦
⑧
⑨
Cool Mode Oscillating Air volume Air reduction
Warm Mode Strong Wind Timing Sleep Wind
Add Temperature Reduce temperature
Note: The main buzzer will make a “beep” sound when operating the remote
UV sterilisation

Press the timer button on the remote control to set 1 t ours
of timing.
Press Sleepmode button on the remote control.
The display show nd the wind speed become minimum.
Press again t it the sleep mode.
ou can als it the current mode by pressing the Wind Strength + button.
Press Turbo mode button on the remote control.
The display shows H and the wind speed become ma
Press again t it the turbo mode.
ou can als it the current mode by pressing the Wind Strength + button.
The device can be switched on and off by pressing the
"ON & OFF" button
Press the Oscillation button to turn on the oscillation function.
This fan can swing left and right 80.Press this button again to
stop oscillating.
Press the "+" button on the left side of the remote control
to increase the volume of air, press the "-" button on the
left side of the remote control to decrease the airflow.
Cool mode can be used for 9-level settings,
warm mode can be set for 4 levels.
In heat mode, press the temperature button on the right side
of the remote control to set the temperature(1-30℃).
Note:this button does not work in cool mode.
The display number in heat mode is red.
Press this button to activate the heat mode.
Note: In heat mode there is no strong mode and sleep mode.
In cooling mode, the LED lamp is blue.
Press this button to activate the cooling mode.
Note: The default start mode is the cooling mode.
Press this key to turn on the UV germicidal lamp,the display shows U.
UV lamp will be turn off after running 1 hour.
Press again to turn off the UV germicidal lamp.

Warning
You might experience problems if there is an overlap of frequencies of the
remote control.
1.This bladeless heater may react when using a remote device for other
appliances.
2.When using the remote control of this bladeless heater, other electrical
appliances may react.
The switch on the remote will turn this fan to standby,
not complete shutdown. Use the switch on the
unit to completely power off when this fan not in use.
If this fan is not in use for a long time, please unplug from the wall.
The remote control should be
pointed at the remote control
signal receiver on the display
to maximis the remote control
signal.
ffective distance
Signal receiver
Remote Operation Introduction
4

Heating Mode Instructions
5
Press the warm mode button and the display shows the ambient
temperature.
Press temperature button to set the temperature and the display
will flash digitally which can be set to 1-30 °C.
Set temperature should be higher than the ambient temperature
so that the heating function will be turned on;
When the ambient temperature reaches the set temperature the
heating function will stop and turn into a cool breeze;
The ambient temperature is lower than the set temperature and
the heating function will automatically activate.
Ambient
Temperature
Set
Temperature
23℃25℃
Set temperature > ambient temperature: heating function on.
Set temperature ambient temperature: heating function stops
Note: The default setting temperature is 25 °C. In the warm mode,
when the ambient temperature is below 0 °C, the display only
shows 01, do not display negative temperature value.If the warm air
mode runs for over 9 hours, the machine will automatically stop running.
Restart by pressing the host power button or by using the remote control.
Warm mode: use remote to set temperature, host does not support this operation.

: Turn off
: Turn on
Power Button
Host
6
Inserte the plug into socket, turn on power switch and the
machine enters the standby state:
Click the power button of the host, the buzzer will prompt you to
click, and the fan will start running. Press and hold the power
button for 2 seconds, the buzzer will prompt you twice, and then
stop running after you release the hand.
Air Volume Shift
When host is in operation: click the main power button to switch
the air volume from 1 to 9.
Oscillating operation
Press and hold the power button for 1 second, the buzzer will
beep once and fan start oscillating.
Press and hold the power button for 1 second again, the buzzer
will beep once and fan stop oscillating.

Installation location and precautions
7
ocation
Please place the fan in a horizontal position. If there is a slope,
should on a soft surface to avoid fan falling over lease do not use
in high temperature and humidit bathroom, kitchen .
Do not cover,
high temperature
Do not place anything
within 1 meter
keep distance
Safety System his heater fan includes an overheat protection
sensor and an automatic fail-safe that cuts power to the unit if it's
accidentally tipped over or if it overheats. If this sensor is triggered,
unplug the machine and allow the fan to cool. Check and remove any
obstructions before restarting the heater fan.

Machine Malfunction analysis
Problem
The unit is plugged in but not working
emote does not work
If you are still experiencing problems with the unit, please connect with customer
service, do not disassemble, repair and install it yourself.
Cause Analysis
Check the plug is inserted into the socket correctly
Check the battery is not dead
Check the batteries are inserted correctly
Check the remote control is aligned with the signal receiver
8Battery installation method and troubles
hooting analysis
Please insert the battery correctly
battery cover
attery installation method
1pen the remote control
battery cover
2 ad two ne
dry batteries
3. Close the battery cover of
the remote control.

Do not use banana oil, flamable cleaning products or
metal objects to wipe the surface of the fan, which may
cause discoloration of the surface.
Unplug the power supply before performing maintenance.
Surface cleaning
Wipe the surface with a soft, dry cloth;
If especially dirty, dilute with a mild detergent and wipe with a soft cloth.
Then wipe with a dry soft cloth.
Air inlet/outlet
Use a soft brush or a vacuum cleaner to clean the
dust at the air inlet and outlet. Please clean it when
there is less dust. Too much dust is not healthy and
will reduce fan efficiency.
Remote contral
Gently wipe the surface of the remote with a soft,
dry cloth.
If the remote control is not going to be used for a
long period of time, please remove the battery
from the remote control.
Storage
Please avoid placing it in direct sunlight, high temperature and humidity;
Please keep out of reach of young children.
Maintenance
9
Do not put the fan in water, or spray with water for
cleaning or any other purpose.

Connect with APP
10
