BKE JS-30- /DIN_KK Series User manual

WARRANTY SWITCHING POWER SUPPLY
WARRANTY
The product was properly tested before the expedition from the factory. The manufacturer guarantees that
the product shall have the characteristics fixed in the contract and in the appropriate technical standards
provided that it will be used in the way described in the instructions. If during the guarantee period a failure
happens, which was not caused by the user or was caused by force majeure, then the user is entitled to a
free remedy if the product was handed over to the dealer or was sent to the manufacturer. The guaranty
claim is accepted as valid only of products, which are not mechanically damaged and provided with the
original certificate of guarantee. The guarantee period is 60 months since the taking over of the product by
the purchaser or since the date of installation by a speciali ed firm. The guarantee repair will be made free
of charge only when the certificate of guarantee and the proof of purchase are presented.
IDENTIFICATION OF PRODUCT
20307903
INSTALLATION AND USERS GUIDE
for Type
JS-30-XXX/DIN KK
Read these instructions before using the product
BKE a.s. U vý kumu 603, 664 62 Hrušovany u Brna BKE a.s. U vý kumu 603, 664 62 Hrušovany u Brna
tel: [phone] fax: [phone] e-mail: [e-mail] www.bke.cz tel: [phone] fax: [phone] e-mail: [email protected] www.bke.cz

TECHNICAL DATA OF PRODUCT INSTALLATION AND USERS GUIDE
DESCRIPTION AND USING
Switching power supply JS-30-XXX/DIN_KK is intended for power supply of controlling and
monitoring electronic devices in industrial area in settings with no danger of explosion with wide
range of operational temperature.
The Supply is placed in a 3M wide metal box with possibility of attachment to a DIN35 plinth.
Input and output connection is made with terminal boxes. Output networks are SELV type.
TECHNICAL PARAMETERS
Input voltage 230V AC (180-260V AC)
Input current 0,25A by 230V AC
Dielectric strentgh 3000V AC primary-secondary
Isolating resistivity more than 50MΩ
Outup parameters (voltage and current) are printed on the type label of power supply.
ENVIROMENTAL CONDITIONS
Operating temperature -40 až 70ºC
Humudity (non condensing) 10 to 80% RV
Installation altitude till 2000m
IP code IP20 (terminals IP00)
Weight 240g
Cooling natural
Dimensions 90x53x58mm (HxWxD)
Class of device Class I
Power derating from 60°C to 70°C – 1%/°C (linearly).
TECHNICAL STANDARDS
Safety EN 60950-1
EMC EN 61000-6-1 ed.2
EN 61000-6-3 ed.2
PACKING AND STOCKING
The product is delivered in a box made of white cardboard (particular packing). Instructions for
installation and tender are enclosed to the supply. The product is to be stocked in temperatures
from –40 to 80°C, in relative humidity to 90%, in areas where can be no ship ´s sweating on the
products. The product can´t be striked, exposed to mechanical shock and injurious gases.
INSTRUCTIONS FOR INSTALLATION
Connecting of the supply can be made only by qualified persons. Screw clamps make possible
connecting wire of crosscut from 0,5 to 2,5mm2. Operating position of the supply is random,
vertical is better. The product is intended for installation to an area with no danger of explosion.
CONNECTION
SETTING IN OPERATION
The Supply is intended for permanent operating, has a T1AH/250V fuse unit on input and there
is no need to have it secondary secured. Terminal of supply voltage must be possible to switch
off. After wiring output terminals of network and connecting input voltage is the Supply ready for
operating.
SERVICE AND REPAIRING
The product doesn´t require servicing or maintenance.
The product is to be repaired by the producer. Products for repairing are to be send in a box that
protects it from damage during delivering.
DURABILITY
Minimum effective life of the product is 50 000 hours.
