BKI Combi-king TE Series Quick start guide

SERIES: TE, TG
Operation Manual
Combi-King® Combination
Oven Series

Dear Customer
Congratulations on the purchase of your new Combi-King Plus combination
oven. By purchasing your new oven you have entered into a new era of cooking.
With the new technology and simplicity built into your new Combi-King
combination oven you will receive excellent results in no time at all. This ease of
use will add up in training dollars saved by the simplicity of operation.
In using the Combi-King oven with one touch you will identify the relevant food
you then push start and you are cooking. With the simplicity of operation you
are guaranteed consistently produced products without setting times
temperatures and finishes.
For the Chef the Combi King offers a wide array of functions and steps that once
tested can be saved and recreated by his staff from the experienced to the first
time operator.
Please read the operations manual in full before starting up
the appliance to make sure all the benefits and safety
information is understood.
For more information culinary support and customer service please contact 1-
800-927-6887
BKI
2812 Grandview Drive
Simpsonville, SC 29680
US
http://www.bkideas.com
Appliance Model______________
S/N________________________
Dealer______________________
Installer_____________________
Date of Install_________________

BKI LIMITED WARRANTY
• 2 years standard warranty boiler plate
attached adjusted to 2 years
LIMITED WARRANTIES AND REMEDIES. Seller warrants that at the time of
shipment the Products will be free from defects in material and workmanship for
a period of no longer than TWO YEAR from the original installation by an
authorized representative or no longer than TWO YEAR AND THREE MONTHS
from the date of shipment from the factory. Defective conditions caused by
abnormal use or misuse lack of or improper maintenance damage by third parties
alterations by unauthorized personnel acts of God failure to follow installation
and/or operating instructions or any other events beyond the reasonable control
of the Seller will NOT be covered under this Warranty. The obligations of the
Seller under this warranty shall be limited to repairing or replacing (at the option
of the Seller) any part with the exception of lamps fuses door gaskets and glass
(which are not covered under this warranty) which is found defective in the
reasonable opinion of the Seller. Any part found defective by the Seller will be
repaired or replaced without charge F.O.B. factory Simpsonville South Carolina
or F.O.B. authorized BKI Distributor. Seller and/or its authorized representatives
will assume the normal replacement labor expense for the defective part for the
period of the warranty as stated above including reasonable (up to 100 mile or 2
hr round trip) travel time where replacement work is performed during standard
business hours and not subject to overtime holiday rates and/or any additional
fees. IN NO EVENT SHALL THE SELLER BE LIABLE FOR LOSS OF USE
LOSS OF REVENUE OR LOSS OF PRODUCT OR PROFIT OR FOR INDIRECT
INCIDENTAL SPECIAL OR CONSEQUENTIAL DAMAGES INCLUDING BUT
NOT LIMITED TO FOOD SPOILAGE OR PRODUCT LOSS. THIS
WARRANTY DOES NOT COVER GLASS BREAKAGE. THE ABOVE
WARRANTY IS EXCLUSIVE AND ALL OTHER WARRANTIES EXPRESS OR
IMPLIED ARE EXCLUDED INCLUDING THE IMPLIED WARRANTIES OF
MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE. Any
appliance replacement part with the exception of lamps fuses and glass which
proves to be defective in material or workmanship within
ninety (90) days of installation will be replaced without charge F.O.B. Factory
Simpsonville SC or F.O.B. authorized BKI Distributor. The user shall have the
responsibility and expense of removing and returning the defective part to the
Seller as well as the cost of reinstalling the replacement or repaired part.

Touch Control Combi Oven
1
Table of Contents
Table of Contents ................................................................................................ 1
1.0 Introduction .............................................................................................. 2
1.1 Intended Use ......................................................................................... 2
1.2 Safety Precautions ............................................................................... 3
1.3 Safety Signs and Messages ................................................................. 3
1.4 Safe Work Practices ............................................................................. 4
1.5 Specific Precautions ............................................................................ 5
1.6 General Safety Guidelines for Installers, Users, and Service
Technicians ........................................................................................... 6
1.7 Health and Sanitation Practices .......................................................... 7
2.0 Water Quality ............................................................................................ 8
3.0 Product Overview ..................................................................................... 9
4.0 Control Panel .......................................................................................... 10
5.0 Manual Cooking ..................................................................................... 12
5.1 Setting the Temperature: ................................................................ 13
5.2 Setting the Time: ............................................................................. 13
5.3 Power Vent (Convection Mode Only) ............................................ 14
5.4 Fan Speed ........................................................................................ 14
5.5 Probe Cooking ................................................................................ 15
5.9 Humidity Level (Combination Mode Only) .................................... 17
5.10 Humidity Level (Steam Mode Only) ............................................... 17
5.11 Pre-Heat ........................................................................................... 18
5.12 Oven Cool Down ............................................................................. 18
5.13 Rack Control .................................................................................... 19
6.0 Cleaning .................................................................................................. 20
6.1 Wash Program .................................................................................... 20
6.2 Cleaning Chemicals............................................................................ 21
6.3 Daily ..................................................................................................... 22
6.4 Weekly ................................................................................................. 23

Touch Control Combi Oven
2
1.0 Introduction
1.1 Intended Use
BKI Combi-King Plus combination oven are solely intended for use in commercial applications
especially in commercial kitchens.
The units may only be used for cooking food using the correct racks containers baking sheets
and slide in pans. Roll in rack dollies and cassettes must only be supplied for correct operation
only by BKI.
Units may only be used with purest quality drinking water for unit protection. The owner of the
oven should test water for filtration needs. Water quality needs can be found in the manual under
“Water Quality”
Your new Combi-King oven should not be used for the following purposes among others:
• As a dishwasher
• As a Smoker oven
• Drying towels paper or dishes
• As a storage container
• Heat brines oils or other chemicals
• Heating closed containers (i.e. can goods)
• Heating Flammable liquids
• Deep Frying
• Cleaning air filters or equipment parts

Touch Control Combi Oven Safety Precautions
3
1.2 Safety Precautions
Always follow recommended safety precautions listed in this manual. Below is the safety alert
symbol. When you see this symbol on your equipment be alert to the potential for personal injury
or property damage.
1.3 Safety Signs and Messages
The following Safety signs and messages are placed in this manual to provide instructions and
identify specific areas where potential hazards exist and special precautions should be taken.
Know and understand the meaning of these instructions signs and messages. Damage to the
equipment death or serious injury to you or other persons may result if these messages are not
followed.
This message indicates an imminently hazardous situation which if not
avoided will result in death or serious injury.
This message indicates a potentially hazardous situation which if not
avoided could result in death or serious injury.
This message indicates a potentially hazardous situation which if not
avoided may result in minor or moderate injury. It may also be used to
alert against unsafe practices.
This message is used when special information instructions or
identification are required relating to procedures equipment tools
capacities and other special data.

Touch Control Combi Oven
4
1.4 Safe Work Practices
Beware of High Voltage
This equipment uses high voltage. Serious injury can occur if you or any
untrained or unauthorized person installs services or repairs this
equipment. Always Use an Authorized Service agent to Service Your
Equipment
Beware of Hot Surfaces.
Do Not Touch.
The door on this unit reaches temperatures that can cause burns. Use
caution when opening and closing the door. Do not touch any of the
surfaces when the unit is heated.
Keep this manual with the Equipment
This manual is an important part of your equipment. Always keep it near
for easy access. If you need to replace this manual contact:
BKI
Technical Services Department
2812 Grandview Drive
Simpsonville SC 29680
Or call toll free: 1-800-927-6887
Outside the U.S. call 864-963-3471
Protect Children
Keep children away from this equipment. Children may not understand
that this equipment is dangerous for them and others.
NEVER allow children to play near or operate your equipment.
911
Be Prepared for Emergencies
Be prepared for fires injuries or other emergencies.
Keep a first aid kit and a fire extinguisher near the equipment. You must
use a 40-pound Type BC fire extinguisher and keep it within 25 feet of
your equipment.
Keep emergency numbers for doctors ambulance services hospitals
and the fire department near your telephone.
Know your respo
nsibilities as an Employer
• Make certain your employees know how to operate the equipment.
• Make certain your employees are aware of the safety precautions on
the equipment and in this manual.
• Make certain that you have thoroughly trained your employees about
operating the equipment safely.
• Make certain the equipment is in proper working condition. If you
make unauthorized modifications to the equipment you will reduce
the function and safety of the equipment as well as void the warranty.

Touch Control Combi Oven Specific Precautions
5
1.5 Specific Precautions
Equipotential Ground Plane
When a high current flows through a conductor differences in potential
appear between the conductor and nearby metallic surfaces near the
appliance. As a result sparks may be produced between the appliance and
surrounding metal surfaces. These sparks could cause serious injury
damage or fire.
BKI provides an Equipotential ground terminal for the connection of a bonding
conductor after the installation of the appliance per lEC60417-1. This
terminal is located on the inside of the Power Entry Supply box near the Earth
connection and is marked with this symbol.
Disconnect power before servicing.
Improper installation adjustment alteration service or maintenance can
cause property damage injury or death. Read the installation operating and
maintenance instructions thoroughly before installing or servicing this
equipment.
Don not connect Combi Steamer-oven drain connection to any drain material
that cannot sustain 140° Fahrenheit.
For Your Safety
Do not store or use gasoline or other flammable vapors or liquids in the
vicinity of this or any other appliance.
All service must be performed by a qualified BKI authorized technician.
This manual is a part of your new Combi-King Plus combination oven. You
must keep and maintain it for the entire life span of your combi and pass it on
to the next owner of the unit.
Retain this manual for reference keep it where you can use it.
This manual may be subject to ne technical developments modifications and
unforeseen errors.
Do not operate or attempt to operate this appliance or any accessories
without reading completely and fully understanding this manual.

Touch Control Combi Oven General Safety Guidelines for Installers, Users,
and Service Technicians
6
1.6 General Safety Guidelines for Installers, Users, and Service Technicians
• Read understand and follow the instructions and heed and obey the warnings of the
Installation Manual the Operator’s Manual and the labels on the Combi accessories and
supporting products.
• Improper installation maintenance cleaning or modifications to the Combi can lead to
injury or death of the operator(s) and equipment and property damage.
• Steam – To avoid steam burns open the Combi door by turning the handle to the horizontal
(“airing”) position and waiting for the steam and condensate to clear. Then stand back and
to the hinge side of the door and slowly open the door. Never breathe steam superheated
steam or hot air. Note: The cooking program is interrupted whenever the door is opened.
• Heat – The Combi cooking containers shelves and inner door and anything else inside
the cooking compartment are HOT as are many of the component parts. Wear DRY
heatproof gloves or mitts.
• Exhaust Vents – The top of the Combi and the gas and steam exhaust vents are very hot
during operation and remain hot for some time. Never breathe gas or steam from the
exhaust vents. Use extreme caution when working on or near this area and component
parts.
• Scalds – Do not place containers with liquid contents or contents that become liquid on
oven racks higher than you can see into the containers. Cover containers (individual or on
trolleys) containing hot or hot liquid items to help prevent spills during transport. Observe
and heed and obey and obey the additional warnings and warning labels posted on the
Combi
• Grease Spatter – Hot grease will spatter and cause burns if sprayed with water. Locate
fryers and similar appliances outside the range of the Combi hand shower.
• Electric Shock – Use the hand shower only on the inside of the oven. Use of the hand
shower hoses power cleaners or pressure washers on the outside of the Combi can
cause electric shock and / or damage electrical and electronic components.
• Cleaning and Daily Maintenance – Wait for the Combi to cool before cleaning and
performing daily maintenance. Do NOT spray water in a hot cooking compartment. Do not
use hoses power cleaners or pressure washers or harsh or abrasive cleaning agents
inside OR outside the cooking compartment.
• Cleaning Agents – Use only BKI approved cleaning and descaling products. Follow the
instructions and heed and obey the warnings on the labels. Other products can damage the
Combi cause injury or present heath hazards.
• Wear SHOES/BOOTS appropriate to the work area to help protect feet and to help prevent
slips and falls.
• Use non-slip draining anti-fatigue FLOOR MATS (not included) rated for use in wet
greasy and dry work areas to help prevent slipping and / or falling injuries. Obtain the best
mats for your needs from your local supplier.

Touch Control Combi Oven
7
1.7 Health and Sanitation Practices
BKI Combi Ovens are manufactured to comply with health regulations and are tested and certified
to UL

cUL

and NSF

standards. You must operate the equipment properly using only quality
products and use meat thermometers to insure meats are thoroughly cooked.
Food Handling
• Wash hands thoroughly in warm soapy water after handling raw poultry or meats.
• Clean and sanitize all utensils and surfaces that have been in contact with raw products.
Clean and sanitize the meat forks or baskets between cooking.
• Never place cooked meats on the same surfaces used to prepare raw meats unless the
area has been thoroughly cleaned and sanitized.
Storage of Raw Meats
• Designate an area or shelf strictly for the storage of all raw meats to be used in the
rotisserie.
• Raw product must always be stored at temperatures below 38° F. (3° C.).
• Never store or mix raw foods above cooked foods as this is a health hazard. The drippings
from raw foods contaminate cooked or processed foods.
• All chicken and chicken parts to be stored overnight must be thoroughly iced down and
refrigerated.
Coding Cooked Foods
• All products cooked during the day should be sold the same day.
NOTE:. Follow your company’s procedures for the handling of any leftover product.
Storage of Prepared Foods
• Cold foods should be kept at or below 38° F. (3° C.).
• Hot foods must be maintained to meet local health codes usually a minimum 145° F.
(63°C.).

Touch Control Combi Oven ater Quality
8
2.0 Water Quality
As with all steam related products water filtration and regular filter replacements may be necessary
with the combi. It is strongly recommended to have a water analysis performed prior to installing the
combi. Poor water quality can have a big impact on cook quality performance and longevity of the
combi. Varying combinations of pH; alkalinity; hardness; chlorides; total dissolved solids; and other
chemical characteristics when subjected to high temperatures will cause water to have a tendency
to either scale or corrode.
There are a number of different water filter/treatment systems out there and each has its own
benefits and specialties. Below are a couple different styles and their benefits. Multiple styles may
need to be used to get the water to proper levels.
) Particle Filter
When the water contains sand iron particles or suspended matter we recommend a 5-15 µm
(micrometer) particle filter:
B) ctive Carbon Filter
When the level of chlorine (Cl
2
) in the water exceeds 0.5 mg/L (= ppm) (information available from
the water company) an active carbon filter should be installed.
C) Phosphate dditive System
A Phosphate Additive (Feeder) System is recommended for steam generator units only when a
moderate level of scale (not containing chloride) is experienced. System recommended
Kleensteam from Everupure.
D) Ion Exchange System
An ion exchange system is recommended for a steam generator based unit when a high level of
scale (not containing chloride) is experienced and for a spritzer based unit when the any scale (not
containing chloride) is experienced.. Systems recommended: Claris from Everpure (H+ Ion
Exchanger). Sodium ion exchangers (as used in dishwashers) must not be used.
E) Blended Reverse Osmosis (RO)
When the water has a chloride Cl- concentration above 20 mg/L (= 20 ppm) a blended RO system
should be installed to avoid corrosion.
Note: Make sure a minimum conductivity of 20 µS/cm (microSiemens) remains in the water for
steam generator units.
Water quality must conform to the below requirements. If water does not meet the minimum quality
if damage to the oven is determined to be due to water quality it will be considered non-warranty
and not covered under the stated warranty policy.
BKI Minimum Water Quality Requirements
Hardness (CaCO3) = Less than 7.5 GPG (Grains per Gallon)
TDS (Total Dissolved Solids) = Less than 100.0 mg/L (Milligrams per Liter)
Free Chlorine = Less than 0.5 mg/L (Milligrams per Liter)
Chlorides = Less than 20 mg/L (Milligrams per Liter)
Chloramines = Less than 0.5 mg/L (Milligrams per Liter)
Total Alkalinity = Less than 20 mg/L (Milligrams per Liter)
Total Silica = Less than 10 mg/L (Milligrams per Liter)
pH level = 7.0 to 8.0
Conductivity (Boiler Models only) = Minimum of 20 µS/cm (microSiemens per cm)

Touch Control Combi Oven Product Overview
9
3.0 Product Overview
1. Control Panel
2. Door Handle
• Left to vent position
• Right to open
3. Oven Lights
• On the door
4. Hose Reel
• Behind the door on table top units
5. Side Panel
• Removable for service access
6. USB Port
7. Core Temperature Port
• Removable on table top unit only
8. Legs
• 4” adjustable for table tops
• 6” adjustable for floor models
9. Rating Plate (on Back Corner)
• Contains the following information:
o Model Number
o Serial Number
o Voltage
o Power Consumption
o Amp Draw
o Breaker Size
o Phase
o Frequency
10. Door Trip Tray
• Behind Door
• Built in Trolley on Floor Models
11. Control Panel ir Filter
1
1
2
2
3
3
4
4
5
5
6
6
7
7
8
8
9
9
10
10
11
11

Touch Control Combi Oven Control Panel
10
4.0 Control Panel
ON/ OFF button
Manual cooking and menu
building section (touch to
open)
Pre-planned recipes
(touch to open)
Service/cleaning section
(touch to open)
Start/Stop Button
Return Button
Menu Button
Light Button
Master Knob

Touch Control Combi Oven Control Panel
11
Control Panel
ON/OFF Button:
Turns the unit on/off. Press and hold for 3 seconds. On steam generator units it
fills and drains the steam generator.
Light Button:
Toggles cavity light on and off. The light will automatically switch off after 45
seconds.
Menu Button:
Returns to the main menu.
Return Button:
Returns to previous screen.
ST RT/STOP Button:
Start/stops the cooking program.
Master Knob:
Used for entering and changing parameters. The knob can be pressed to select a
function or confirm a parameter. The knob can turn freely in either direction
turning clockwise will increase values.

Touch Control Combi Oven Manual Cooking
12
5.0 Manual Cooking
From initial Menu push “Manual cooking” which will bring you to the manual
screen.
Push the fan icon on the screen that opens a selection with the four cooking mode
choices:
= Convection = Combination Convection/Steam = Steam
= Hold
Select the mode by pressing the desired icon.
Operating ranges:
Convection - 122° F (50° C) to 572° F (300° C)
Combi - 122° F (50° C) to 518° F (270° C)
Steam - 122° F (50° C) to 248° F (120° C)
The screen will show the chosen mode and you are now ready to adjust the
cooking parameters.

Touch Control Combi Oven Setting the Temperature:
13
5.1 Setting the Temperature:
Select the temperature setting on display by pushing the temperature screen.
choose the temperature by turning the Master Knob. Confirm by pressing Master
Knob or the display.
5.2 Setting the Time:
The oven can be programmed for cooking cycles that vary from 1 minute to 120
minutes. The oven also has an infinite setting.
Select the time setting on the display by pressing the time screen then turning the
Master Knob until you reach correct cooking time. To set infinite time turn the
Master Knob counterclockwise until “INF” appears.
To set the time push the Master Knob or the display.
Upon completion of cooking time the oven automatically stops taking itself to
“stand-by" mode and emits a warning signal for about 15 seconds.

Touch Control Combi Oven Power Vent (Convection Mode Only)
14
5.3 Power Vent (Convection Mode Only)
The power vent is used for evacuating humidity during cooking cycles and cooling
in between cooking steps. The butterfly valve will open or close as programmed.
The vent is always in the closed position unless activated and opened. It must be
programmed in Convection only. In Steam and Combi modes it is controlled by
the oven.
Select the power vent on the display by pressing the vent box. Pressing the box
toggles the vent open and closed.
5.4 Fan Speed
To select the fan speed setting for the convection fan(s) push the fan box on the
screen. Move the boxes to the right or left to increase to speed 6 or decrease to
speed 1 using the Master Knob. Push the Master Knob or the fan box to confirm
the choice.

Touch Control Combi Oven Probe Cooking
15
5.5 Probe Cooking
To select Core Probe or ∆T cooking press Core/∆T box
That opens a selection window with two options: = Core = ∆t.
Select the wanted mode by pressing the display.
5.6 Core Temperature Probe
For core probe cooking the core temperature determines the cooking time based
on the temperature measured by the core probe. To set the core probe
temperature (the finished internal temperature of the food product being cooked)
select the probe temperature on the display by pressing the probe symbol then
turning the Master Knob until the desired finished internal cooking temperature is
reached. Confirm by pressing Master Knob or the display. The cooking stops the
moment the temperature of the product being cooked reaches the set core
temperature.

Touch Control Combi Oven Delta T
16
5.7 Delta T
For ∆t cooking the temperature in the cooking chamber is based on the
temperature measured by the core temperature probe. Setting a ∆t value equal to
100°F for example the temperature in the chamber will be maintained constantly
100°F above what is detected at the core of the product. Cooking will stop when
temperature of the product being cooked measured by the core probe reaches
the set value. Set both the ∆t and core probe temperature by selecting the icon
and turning the Master Knob until the desired temperature is reached. Confirm by
pressing Master Knob or the display.
5.8 dd Moisture (Convection Mode Only)
In a cooking mode it is possible to manually inject humidity into the cooking
chamber using the Humidifier function. This is accomplished by keeping the add
moisture key pressed for as long as moisture is desired in the cooking chamber.

Touch Control Combi Oven Humidity Level (Combination Mode Only)
17
5.9 Humidity Level (Combination Mode Only)
In combination convection-steam cooking mode it is possible to set the percentage
of humidity present in the cooking chamber by pressing the humidity percentage
box and rotating the Master Knob to increase or decrease moisture by 5 % form
5% to 100%. Confirm by pressing Master Knob or the display.
5.10 Humidity Level (Steam Mode Only)
Selecting the steam cooking mode the STEAM TUNER function activates. With
the indicator bar in the central position it indicates optimal steam regulation in the
cooking chamber and guarantees 100% humidity saturation in the cooking
chamber. It is possible to adjust the quantity of steam forced into the chamber by
pressing the + or – keys on the STEAM TUNER based on the desired type of
cooking. Moving the selector indicator bar towards + will produce a “wetter” steam
(for example for cooking potatoes for puree); moving it towards - causes the steam
to be more “dry” (for example when preparing fish and delicate products).
