ENGLISH
45
GWC1820PC
BLOWER
Technical data
GWC1820PC
Input Voltage
VDC 18
No-Load Speed /min 10,000 - 12,500
Weight kg 1.5
Intended use
Your BLACK+DECKER GWC1820PC blower have been
designed for leaf clearing. This appliance is intended for
consumer use only.
Safety instructions
Warning! When using mains-powered/
cordless appliances, basic safety
precautions, including the following,
should always be followed to reduce the
risk of re, electric shock, personal injury
and material damage.
uRead all of this manual carefully before
operating the appliance.
uThe intended use is described in this
manual. The use of any accessory
or attachment or the performance
of any operation with this appliance
other than those recommended in this
instruction manual may present a risk
of personal injury.
uRetain this manual for future
reference.
Using your appliance
Always take care when using the
appliance.
uAlways use safety glasses or goggles.
uNever allow children or people
unfamiliar with the instructions to use
the appliance.
uDo not allow children or animals to
come near the work area or to touch
the appliance or power supply cord.
uClose supervision is necessary when
the appliance is used near children.
uThis appliance is not intended for use
by young or inrm persons without
supervision.
uThis appliance is not to be used as a
toy.
uOnly use the appliance in daylight or
good articial light.
uUse in a dry location only. Do not allow
the appliance to become wet.
uAvoid using the appliance in bad
weather conditions, especially when
there is a risk of lightning.
uDo not immerse the appliance in water.
uDo not open the body casing. There
are not user-serviceable parts inside.
uDo not operate the appliance in
explosive atmospheres, such as in the
presence of ammable liquids, gases
or dust.
uThe appliance is only to be used with
the power supply unit provided with the
appliance.
Residual risks.
Additional residual risks may arise when
using the tool which may not be included
in the enclosed safety warnings.
These risks can arise from misuse,
prolonged use etc.
Even with the application of the
relevant safety regulations and the
implementation of safety devices, certain
residual risks can not be avoided. These
include:
uInjuries caused by touching any
rotating/moving parts.
uInjuries caused when changing any
parts, blades or accessories.
uInjuries caused by prolonged use
of a tool. When using any tool for
prolonged periods ensure you take
regular breaks.

6
ENGLISH
uImpairment of hearing.
uHealth hazards caused by breathing
dust developed when using your
tool (example:- working with wood,
especially oak, beech and MDF.)
After use
uWhen not in use, the appliance should
be stored in a dry, well ventilated place
out of reach of children.
uChildren should not have access to
stored appliances.
uWhen the appliance is stored or
transported in a vehicle it should be
placed in the boot or restrained to
prevent movement following sudden
changes in speed or direction.
Inspection and repairs
uBefore use, check the appliance
for damaged or defective parts.
Check for breakage of parts and any
other conditions that may affect its
operation.
uDo not use the appliance if any part is
damaged or defective.
uHave any damaged or defective parts
repaired or replaced by an authorised
repair agent.
uNever attempt to remove or replace
any parts other than those specied in
this manual.
Additional safety instructions for
blowers
The intended use is described in this
manual. The use of any accessory
or attachment or performance of any
operation with this appliance other than
those recommended in this instruction
manual can present a risk of personal
injury and/or damage to property.
uTo protect your feet and legs while
operating the appliance, always wear
heavy duty footwear and long trousers.
uAlways switch off your product, allow
the fan to stop and remove the battery
when:
uYou leave your product unattended.
uClearing a blockage.
uChecking, adjusting, cleaning or
working on your product.
uIf the appliance starts to vibrate
abnormally.
uDo not place the inlet or outlet of
the vacuum near eyes or ears when
operating. Never blow debris in the
direction of bystanders.
uDo not use in the rain or leave
outdoors while it is raining.
uDo not cross gravel paths or roads
whilst your product is switched. Walk,
never run.
uDo not place your unit down on gravel
while it is switched on.
u Always be sure of your footing,
particularly on slopes. Do not overreach
and keep your balance at all times.
uDo not place any objects into the
openings. Never use if the openings
are blocked - keep free of hair, lint,
dust and anything that may reduce the
airow.
Warning! Always use your product in
the manner outlined in this manual. Your
product is designed to be used in an
upright mode and if it is used in any other
way it may result in injury. Never run your
product whilst lying on it’s side or upside
down.
uThe operator or user is responsible for
accidents or hazards occurring to other
people or their property.
uDo not use solvents or cleaning uids

7
ENGLISH
to clean your product. Use a blunt
scraper to remove grass and dirt.
uReplacement fans are available from a
Black & Decker service agent. Use on
Black & Decker recommended spare
parts and accessories.
uKeep all nuts bolts and screws tight to
make sure that the appliance is in a
safe working condition.
Safety of others
uThis appliance can be used by
children aged from 8 years and above
and persons with reduced physical,
sensory or mental capabilities or
lack of experience and knowledge
if they have been given supervision
or instruction concerning use of
the appliance in a safe way and
understand the hazards involved.
Children shall not play with the
appliance. Cleaning and user
maintenance shall not be made by
children without supervision.
uChildren should be supervised to
ensure that they do not play with the
appliance.
Additional safety instructions for
batteries and chargers
Batteries
uNever attempt to open for any reason.
uDo not expose the battery to water.
uDo not store in locations where the
temperature may exceed 40 °C.
uCharge only at ambient temperatures
between 10 °C and 40 °C.
uCharge only using the charger
provided with the tool.
uWhen disposing of batteries, follow
the instructions given in the section
"Protecting the environment".
Chargers
uUse your BLACK+DECKER charger
only to charge the battery in the tool
with which it was supplied. Other
batteries could burst, causing personal
injury and damage.
uNever attempt to charge non-
rechargeable batteries.
uHave defective cords replaced
immediately.
uDo not expose the charger to water.
uDo not open the charger.
uDo not probe the charger.
$The charger is intended for
indoor use only.
Read the instruction manual
before use.
Electrical safety
#Your charger is double insulated;
therefore no earth wire is
required. Always check that the
mains voltage corresponds to the
voltage on the rating plate. Never
attempt to replace the charger
unit with a regular mains plug.
uIf the supply cord is damaged, it must
be replaced by the manufacturer or an
authorised BLACK+DECKER Service
Centre in order to avoid a hazard.

8
ENGLISH
Labels on appliance
The following warning symbols are found on the appliance
along with the date code:
Read the manual prior to operation.
Wear safety glasses or goggles when
operating this appliance.
NWear suitable ear protectors when operating
this appliance.
Always remove the battery from the
appliance before performing any cleaning or
maintenance .
KBeware of ying objects. Keep bystanders
away from the cutting area.
RDo not expose the appliance to rain or high
humidity.
Features
This appliance includes some or all of the following features.
1. On / Off Switch
2. Tube
3. Power command button.
Tube assembly
Note: Ensure the sweeper is switched off and the battery is
removed before attaching or removing the sweeper tube. The
tube must be assembled to the housing before use.
uTo attach the tube to the sweeper, line up the tube with the
sweeper housing as shown in Figure A.
uPush the tube into the sweeper housing until the lock
button (4) engages the lock hole (5) in the tube.
To install battery pack
uInsert battery pack into tool until an audible click is heard
as shown in Figure B. Make sure battery pack is fully
seated and fully latched into position.
To remove battery pack
uDepress the battery release button (6) in the back of the
battery pack and pull battery pack out of tool assembly as
shown in Figure C.
Operation
Warning! Always wear safety glasses. Wear a lter mask
if the operation is dusty. Use of gloves, long pants and
substantial footwear is recommended. Keep long hair and
loose clothing away from openings and moving parts. THIS
SWEEPER IS FOR HOUSEHOLD USE ONLY.
uHold the sweeper with one hand as shown in Figure
D and sweep from side to side with the nozzle several
inches above the ground. Slowly advance keeping the
accumulated pile of debris in front of you.
Switching on and off
Warning! Use both hands to grip the product rmly when
switching on.
Warning! Do not point unit discharge at self or bystanders.
uTo switch the sweeper on, slide the on/off switch forward
as shown in Figure E.
uTo switch the sweeper off, slide the on/off switch back as
shown in Figure F.
POWERCOMMAND feature
The POWERCOMMAND feature (3) is located on the
GWC1820PC tool handle as shown in Figure G. It allows you
to optimise the tools performance and boost the power as
needed.
uSwitch the blower on.
uTo activate the “Boost” mode, press and hold the
POWERCOMMAND button down.
uTo deactivate the “Boost” mode, release the
POWERCOMMAND button.
uOperate in “Normal” mode for most sweeping needs.
(Longer runtime will be achieved.)
uActivate “Boost” mode as needed to clear heavy or wet
debris.
Troubleshooting
Problem Possible cause Possible solution
Unit will not start. Battery not installed
properly.
Check battery
installation.
Battery not charged. Check battery charging
requirements.
Battery will not charge. Battery not inserted into
charger.
Insert battery into
charger until green LED
appears.
Charger not plugged in. Plug charger into a
working outlet. Refer to
“Important Charging
Notes” for more details.
Check current at
receptacle by plugging
in a lamp or other
appliance.
Check to see if
receptacle is connected
to a light switch which
turns power off when
you turn out the lights.

9
ENGLISH
Problem Possible cause Possible solution
Battery will not charge. Surrounding air
temperature too hot or
too cold.
Move charger and tool
to a surrounding air
temperature of above
40 degree F (4.5°C) or
below 105 degree F
(+40.5°C).
Protecting the environment
ZSeparate collection. Products and batteries
marked with this symbol must not be disposed of
with normal household waste.
Products and batteries contain materials that can be
recovered or recycled reducing the demand for raw materials.
Please recycle electrical products and batteries according to
local provisions.
Batteries
ZAt the end of their useful life, discard batteries with
due care for our environment:
uRun the battery down completely, then remove it from the
tool.
uNiCd, NiMH and Li-Ion batteries are recyclable. Place
the battery(s) in a suitable packaging to ensure that the
terminals cannot be short-circuited. Take them to any
authorised repair agent or a local recycling station.
uDo not short-circuit the battery terminals.
u Do not dispose of the battery(s) in a re as this may result
in a risk of personal injury or an Explosion.
Service Information
BLACK+DECKER offers a full network of company-owned
and authorized service locations throughtout Asia. All
BLACK+DECKER Service Centers are staffed with trained
personnel to provide customers with efcient and reliable
product service.
Whether you need technical advice, repair, or genuine factory
replacement parts, contact the BLACK+DECKER location
nearest to you.
Note
uBLACK+DECKER's policy is one of continuous
improvement to our products and, as such, we reserve the
right to change product specications without prior notice.
u Standard equipment and accessories may vary by country.
u Product specications may differ by country.
uComplete product range may not be available in all
countries. Contact your local BLACK+DECKER dealers for
range availability.

10
简体中文
5
简体中文
45
GWC1820PC
吹风机
技术参数
GWC1820PC
输入电压 伏特直流 18
空载转速 /分10,000 - 12,500
重量 千克 1.5
设计用途
您的 BLACK + DECKER GWC1820PC 吹风机专为园林或庭院
清理树叶而设计。本设备仅供消费者使用。
安全说明
警告！使用主电源供电/无线的设备时，请
务必始终遵守下列基本安全预防措施，
从而降低火灾、触电、人身伤害和材料损
坏等风险。
u 使用设备前，请仔细阅读本手册。
u 本手册描述了设备的设计用途。如果
配件或附件的使用，或本设备的操作
超出本手册建议的范围，则可能出现
人身伤害的危险。
u 请保存好本手册，以备将来查阅。
使用设备
使用本设备时请务必小心。
u 请务必佩戴安全眼镜或护目镜。
u 切勿让不熟悉说明的儿童或人员使用
本设备。
u 请勿让儿童或动物靠近工作区域或触
碰设备或电源线。
u 在附近有儿童的情况下使用本设备
时，必须保持密切关注。
u 在没有他人监督的情况下，小孩或体
弱者不适宜使用本设备。
u 请勿将本设备用作玩具。
u 仅在日光或良好的人造光线下使用本
设备。
u
仅在干燥的地方使用。请勿让设备
变湿。
u 避免在恶劣天气条件下使用本设备，
尤其是在有雷击危险的情况下。
u 请勿将本设备浸泡在水中。
u 请勿打开设备外壳。这些组件内没有
可供用户维修的零件。
u 请勿在易爆环境（例如存在易燃液体、
气体或粉尘的环境）中操作设备。
u 本设备只能使用随附的电源装置。
剩余风险。
使用工具时，可能出现本安全警示之外
的其他剩余风险。
这些风险可能来自使用不当、使用时间
过长等。
尽管遵守了相关的安全法规并采用了安
全装备，某些剩余风险仍然是无法避免
的。这些风险包括：
u 接触旋转/运动部件时所导致的伤害
风险。
u 更换部件、锯片或配件时所导致的伤
害风险。
u 长期使用工具所导致的伤害。长期使
用工具时，请确保定时休息。
u 听力损伤。
u 吸入工具使用过程中产生的粉尘导致
的健康危害（例如，锯切木材，特别是
橡木、山毛榉和中密度纤维板时）。
使用后
u 不使用时，应将设备存放在干燥、通风
良好且儿童无法触及的地方。
u 切勿让儿童接触存放的设备。
u 使用车辆存放或运输设备时，应将设
备置于行李箱中或进行固定，以防止
在车辆突然变速或转向时发生移动。
