INSTRUCTION MANUAL
1.5 CU. FT. COMPACT DRYER
Thank you for choosing BLACK+DECKER!
PLEASE READ BEFORE RETURNING THIS PRODUCT FOR
ANY REASON.
If you have a question or experience a problem with your BLACK+DECKER
purchase, go to www.blackanddecker.com/instantanswers
If you can’t find the answer or do not have access to the Internet, call
844-299-0879 from 10:30 a.m. to 6:30 p.m. EST Mon. - Fri. to speak with an
agent. Please have the catalog number available when you call.
SAVE THIS MANUAL FOR FUTURE REFERENCE.
CATALOG NUMBER
BCED15

Page 2

Thank you for purchasing our
BLACK+DECKER product. This
easy-to-use manual will guide you
in getting the best use of your
product.
Remember to record the model and
serial numbers. They are on a label
on the back of the product.
Staple your receipt to your manual.
You will need it to obtain warranty service.
Model number
Serial number
Date of purchase
PRODUCT REGISTRATION
CONTENTS
SAFETY INFORMATION
Important Safety Instructions..........................................................................................................................................4-7
Electrical Requirements..........................................................................................................................................................8
Power Supply Cord................................................................................................................................................................... 8
Use of Extension Cord with Dryers...............................................................................................................................8-9
SET UP & USE
Installation Guide .................................................................................................................................................................10-11
Parts & Features ........................................................................................................................................................................12
Operation................................................................................................................................................................................13-15
CARE & MAINTENANCE..........................................................................................................................16-18
TROUBLESHOOTING & WARRANTY
Troubleshooting.................................................................................................................................................................19-20
Limited Warranty......................................................................................................................................................................21
Page 3

Page 4
SAFETY INFORMATION
DANGER
DANGER - Immediate hazards
which WILL result in severe
personal injury or death
WARNING
WARNING - Hazards or unsafe
practices which COULD result in
severe personal injury or death
CAUTION
CAUTION - Hazards or unsafe
practices which COULD result in
minor personal injury
IMPORTANT SAFETY INSTRUCTIONS
WARNING
To reduce the risk of fire, electric shock, and/or injury to persons,
basic safety precautions should always be followed
when using electrical appliances.
When using electrical appliances, basic safety precautions should be
followed, including the following:
1. Read all instructions before using the appliance.
2. Risk of child entrapment and suocation; never allow children to operate, play
with, or crawl inside the appliance.
3. This appliance must be grounded. Connect only to a properly grounded outlet.
See the “ELECTRICAL REQUIREMENT” section found on page 8.
4. Install or locate the appliance only in accordance with the provided installation
instructions.
5. DO NOT place the dryer in steamy rooms or where the dryer is directly
exposed to rain. Moisture may destroy the electrical insulation causing an
electrical shock hazard.
6. Use the dryer only for its intended use as described in the user guide. This type
of dryer is specifically designed to dry clothes. It is not designed for industrial
or laboratory use.
7. As with any appliance, close supervision is necessary when used around children or
incapacitated persons.
8. DO NOT operate the dryer if it has a damaged power cord or plug, if it is not
working properly, or if it has been damaged or dropped in any manner.
9. The dryer should be serviced only by qualified service personnel. Contact the
nearest authorized service facility for examination, repair, or adjustment.
10. DO NOT cover or block any openings on the appliance.
11. DO NOT put your hand in the drum while it is moving. The rotating parts may
cause injury to your hand.
12. DO NOT immerse the power cord or plug in water.

Page 5
SAFETY INFORMATION
13. Keep the cord away from all heated surfaces.
14. DO NOT store or use gasoline or any other flammable vapors and liquids in the
vicinity of this or any other appliance. The fumes can create a fire hazard or
explosion.
15. When cleaning the surfaces of the door and the frame, use only mild, nonabrasive
soaps or detergents applied with a sponge or soft cloth. Never clean appliance
parts with flammable fluids. The fumes can create a fire hazard or explosion.
16. Do not tamper with controls.
17. Remove dryer door before discarding the dryer.
18. Do not dry clothing that has been soiled with solvents, cooking oils, gasoline,
flammable or explosive substances. Vapors could ignite or explode.
19. The lint filter and air intake filter should be cleaned before or after each use.
20. The dryer should be vented. The interior and exhaust vent should be cleaned
periodically by a qualified service professional.
21. Installation work must be done by qualified person(s) in accordance with
applicable codes and standards.
22. This appliance is not intended for use by persons (including children) with
reduced physical, sensory or mental capabilities, or lack of experience and
knowledge, unless they have been given supervision or instruction concerning use
of the appliance by a person responsible for their safety.
23. Do not allow children to play on or in the appliance. Close supervision of children
is necessary when the appliance is used near children.
24. INDOOR USE ONLY - this appliance is not intended for outdoor use.
25. Do not place near flame sources, such as candles.
26. Do not locate the appliance or cord near heat sources such as radiators, heaters,
air ducts or direct sunlight.
27. Do not run the cord under floor coverings. Instead, arrange the cord away from
trac areas where it will not become a trip hazard.
28. To disconnect the appliance, turn the appliance o, switch o the power outlet
and remove the plug from the power outlet.
29. Do not misuse the cord. Never carry the appliance by the cord or pull to
disconnect it from the outlet, instead grasp the plug and pull to disconnect.
30. Do not attempt to repair, disassemble or modify this appliance. The warranty
becomes void if not serviced or repaired by a qualified person.
31. Do not install in a tight fitting cabinet.
32. Do not use fabric softeners or products to eliminate static unless recommended
by the manufacturer of the fabric softener or product.
33. Do not use heat to dry articles containing foam rubber or similarly textured
rubber-like materials.

Page 6
SAFETY INFORMATION
WARNING
This dryer cannot be used upside down.
RISK OF FIRE
Install clothes dryer according to the manufacturers instructions and local codes.
Do not install a clothes dryer with flexible plastic venting materials. If flexible
metal (foil type) duct is installed, it must be of a specific type identified by the
appliance manufacturer as suitable for use with clothes dryers. Flexible venting
materials are known to collapse, be easily crushed and trap lint. These conditions
will obstruct clothes dryer airflow and increase the risk of fire.
To reduce the risk of severe injury or death, follow all installation instructions.
Connect to individual branch circuit.
This appliance must be grounded. In the event of malfunction or breakdown,
grounding will reduce the risk of electric shock by providing a path of least
resistance for electric current. This appliance is equipped with a cord having
an equipment-grounding conductor and grounded in accordance with all local
codes and ordinances.
34. Keep area around the exhaust opening and adjacent surrounding areas free from
the accumulation of lint, dust and dirt.
35. Ensure foreign objects do not find their way into the tub of the tumble dryer.
36. The door window may be hot after a long drying cycle. Please ensure children are
kept away from the machine.
37. After turning o the power supply to the tumble dryer, wait at least 2 minutes
before turning it back on again.
38. Please remove the transport packaging at the rear of the tumble dryer, prior to use.
CAUTION: If this appliance is supplied from a cord extension set or an electrical
portable outlet device, the cord extension set or electrical portable outlet device must
be positioned so that it is not subject to splashing or ingress of moisture.
SAVE THESE INSTRUCTIONS
HOUSEHOLD USE ONLY

Page 7
SAFETY INFORMATION
Oil aected items can ignite spontaneously, especially when exposed
to heat sources such as in a tumbler dryer. The items become warm,
causing an oxidation reaction in the oil. Oxidation creates heat. If the
heat cannot escape, the items can become hot enough to catch fire.
Piling, stacking or storing oil-aected items can prevent heat from
escaping and so create a fire hazard.
WARNING
To reduce the risk of fire, electric shock, or injury when using
your appliance, follow these basic precautions.
• Read all instructions before using the appliance.
• Risk of child entrapment.
• Child entrapment and suocation are not problems of the past. Junked or
abandoned, appliances are still dangerous, even if they will just sit in a garage for a
few days.
• Before you throw away your old appliance: Take o the door so that children may
not easily climb inside.
• Never allow children to operate, play with or crawl inside the appliance.
• Never clean appliance parts with flammable fluids. The fumes can create a fire
hazard or explosion.
• Do not place the dryer in steamy rooms or where the dryer is directly exposed to rain.
• Moisture may destroy the electrical insulation causing an electrical shock hazard.
• During spinning, don’t put your hand in the drum. Because the drum is rotating at
high speed, rotating parts may injure your hand.
• Do not store or use gasoline or any other flammable vapors and liquids in the vicinity
of this or any other appliance. The fumes can create a fire hazard or explosion.
SAVE THESE INSTRUCTIONS

Page 8
SAFETY INFORMATION
WARNING
Improper use of the grounding plug can result in a risk
of electric shock.
ELECTRICAL REQUIREMENTS
The electrical requirement is for a 120 volt, 60Hz, electric dryer only, 12 amps. It is
recommended that a separate circuit serving only the product be provided. The
product is equipped with a 3-wire cord having a 3-prong grounding plug. It must
be plugged into a wall receptacle that is properly installed and grounded.
This appliance must be grounded. In the event of an electrical short circuit,
grounding reduces risk of electric shock by providing an escape wire for the
electric current. The cord provided with this appliance is equipped with a
grounding wire and a grounding plug. The plug must be plugged into an outlet
that is properly installed and grounded.
Avoid the use of three prong adapters or cutting o the third grounding prong in
order to accommodate a two prong outlet. This is a dangerous practice since it
provides no eective grounding for the dryer and may result in shock hazard.
Consult a qualified electrician or serviceman if:
1) The grounding instructions are not completely understood.
2) You are unsure that the appliance is properly grounded.
3) You have any questions about the grounding or electrical instructions.
POWER SUPPLY CORD
1. Avoid the use of an extension cord because of potential safety hazards under
certain conditions. Have a qualified electrician or serviceman install an outlet
near the appliance.
2. If it is absolutely necessary to use longer cord sets or an extension cord,
extreme care must be exercised.
USE OF EXTENSION CORDS WITH DRYERS
Only use a grounded extension cord that is rated at least 12 amps and has a third-
wire ground. When a long extension cord is used to connect the dryer, a voltage
drop occurs. The longer the cord, the greater the voltage drop. This results in less
voltage being supplied to the dryer and increases the amount of current (amp)
draw or reduces performance. A heavier cord with a larger wire size will reduce
the voltage drop. Be sure to choose a cord that will supply enough voltage to
operate the dryer. The table below indicates appropriate gauge for extension
cords.

Page 9
SAFETY INFORMATION
Minimum Gauge for Cord Sets
Ampere Rating
Volts Total Length of Cord in Feet (meters)
120V 25(7.6) 50(15.2) 100(30.5) 150(45.7)
240V 50(15.2) 100(30.5) 200(61.0) 300(91.4)
More
Than
Not More
Than AWG
0 6 18 16 16 14
6 10 18 16 14 12
10 12 16 16 14 12
12 16 14 12 Not Recommended
WARNING: Keep electrical cords in good condition. Do not use worn, bare, or frayed
cords because they can cause electrical shock.
WARNING: Operating equipment at low voltage can cause it to overheat. Using an
excessively long extension cord can cause the cord to overheat.
NOTE: Neither BLACK+DECKER nor the dealer can accept any liability for damage
to the product or personal injury resulting from failure to observe the electrical
connection procedures.

Page 10
SET UP & USE
INSTALLATION GUIDE
LOCATION
1. Examine the dryer after unpacking. Check for damage such as a misaligned
door, broken door or dent in the cavity. If any damage is visible, DO NOT install,
and call customer service.
2. Check to ensure that you have four (4) leveling legs.
3. Install the dryer on a flat, level surface. If the surface is uneven, adjust the
leveling legs.
4. Install the dryer away from direct sunlight; direct sunlight may aect the
acrylic coating, plastic and electrical components. The room temperature
should not fall below 32°F.
5. Check the ventilation. DO NOT block the air vents, especially when the dryer is
installed on a carpeted floor. If the air vents are blocked during operation, the
dryer may overheat and eventually fail. For proper ventilation, allow at least
5 inches of space between the dryer top, sides, rear, and adjacent surfaces.
Ensure adequate space for ventilation. It is recommended that the unit be
vented outdoors. (Ventilation Kit not included.) A ventilation kit with a 4”
diameter duct can be purchased at your local hardware store.
6. Install the dryer away from heating appliances and water taps. Keep the
dryer away from heat, steam, or splashing liquids. Never splash water onto
the control panel. These things can adversely aect the wiring and electrical
conduction contacts of the dryer.
ADJUSTING THE LEVELING LEGS
The dryer is shipped with a bag containing the user guide and
four leveling legs. See the illustration to the right to install and
adjust the leveling legs.
If the dryer is placed on an uneven or weak surface, noise or
vibrations will occur from the appliance. If the floor is uneven,
adjust the height level of the leveling legs accordingly. DO NOT
insert pieces of wood or any other objects under the legs.
Bottom View
Leveling Leg

Page 11
SET UP & USE
INSTALLING THE EXHAUST CONNECTOR
Install the exhaust connector as shown in the illustration by lining it up with the
connector on the back of the dryer and turning it clockwise so the tabs on the
exhaust connector fit into the slots on the connector:
• For a downward exhaust, join the sections (1) pointing downward.
• For an upward exhaust, join the sections (2) pointing upward.
NOTE: The dryer must be vented. A ventilation kit with a 4” diameter duct can be
purchased at your local hardware store.

Page 12
SET UP & USE
PARTS & FEATURES
Exhaust connector

Page 13
SET UP & USE
OPERATION
CONTROL PANEL
To operate the dryer:
1. Select the program.
2. Use default Time or set the time. (Unless using sensor dry).
3. Touch Start/Pause to start the dryer.
NOTE: ALWAYS make sure items being dried have gone through the Spin cycle in the
washing machine first. Do not put soaking wet clothes in the dryer.
Power
When the power cord is plugged into the power outlet, the power button will be
slightly illuminated. To operate the dryer, touch “power” and select the program. The
default program is High Temperature Drying. The time can be set for all programs
except Sensor Dry.
Programs
Touch “Program” to select from the dierent drying programs: High Temperature
Drying, Sensor Dry, Air Dry or Anti-Wrinkle)
High Temperature Drying:
This program is used to dry large items like sheets and bedding.
When this program is selected the light bar will illuminate red. The default time is 150
minutes. To change the default time select START/PAUSE. The maximum time is 200
minutes.
Sensor Dry:
This program will dry at high heat and the dryer will shut down automatically once
the clothing is dry.
When this program is selected the light bar will illuminate white. The time display
will indicate “IHS” The maximum time is 200 minutes. The time cannot be manually
selected in this program.

Page 14
SET UP & USE
Air Dry:
This program does not use heat. It is used to tumble dry items that cannot withstand
heat or to freshen clothing that may have been in storage
When this program is selected the light bar will illuminate blue. The default time will
display as 30 minutes.
Anti-Wrinkle:
This program will dry at a lower heat and is intended for smaller laundry loads that are
dicult to iron (examples: cotton shirts and linen). It is suggested to set the ‘‘TIMER’’
between 30-60 minutes, depending on the load size.
Once the program stops, the items will still contain moisture, making the ironing
process easier.
When this program is selected, the light bar is green, and the default time is displayed
as 90 minutes.
Timer
Every time “Timer” is pressed the time increases by 20 minutes increments, up to a
maximum of 200 minutes.
Once the Time Display reaches 200 minutes the remaining time will cycle back to 20
minutes.
Once the dryer is operating, the time cannot be changed. If you wish to change the
time during a program, touch start/pause to pause the dryer and then touch the
Timer key to change the time.
NOTE: The timer cannot be set while using the sensor dry program.
Start/Pause
Press to start or pause the dryer operation.
When the program and time are set, touch the button to start the dryer.
Touch to pause operation when the dryer is running to change the time or program.
DRYING TIME REFERENCE
NOTE: Drying times will usually vary according to load size, type of fabric, degree of
wetness etc.
Using High Temperature Drying it will take approximately 60 minutes for
smaller loads (approximately 1/7 full) and 200 minutes for larger loads
(approximately 2/3 full).
If clothes are still damp after completing the selected dry cycle, add more
drying time or a higher heat setting.
NOTE: This is a 120-volt dryer. Drying times will be longer than a 220-volt dryer.

Page 15
SET UP & USE
SORTING AND LOADING LAUNDRY
NOTE: Do not load your dryer more than approximately two thirds full to allow
space for the clothes to tumble.
For the best results, your laundry should be sorted properly. Separate the lint
shedders (e.g. chenille and terry cloth) from the lint collectors (e.g. synthetics,
flannels, velvets, and corduroys). Separate non-colorfast from light colored
items, heavy fabrics from lightweight fabrics, and permanent press from heavy,
bulky items.
Delicate clothes, especially those with ribbon or lace, should be placed in a nylon
mesh bag before drying to prevent tangling.
NOTE: Before drying, check all pockets. If nails, coins, or pins remain in pockets,
the objects may damage the dryer and/or clothes. Place your laundry into
the dryer evenly. Uneven laundry may cause noise or vibrations.
Clothes with zippers, buckles buttons or fasteners should be closed or turned
inside out to reduce the impact of noise between the metal and the dryer’s drum.
WARNING: DO NOT TUMBLE DRY. Read all permanent care labels carefully. If the
care label on the garment reads “Drip Dry”, “Line Dry”, or “Dry Flat”, DO NOT dry the
garments in the dryer. In addition, certain materials will melt or become dangerously
flammable if heated, while other garments may lose their shape. Other items that
should not be tumble dried are the following:
1. Garments that have been dry cleaned at home.
2. Garments made from wool, unless the garment manufacturer recommends it.
3. Garments with fiber glass materials.
WARNING: Garments containing vinyl, rubber, plastic or similar materials, including
bras, tennis shoes, rubber galoshes, bath mats, rugs, bibs, baby pants, plastic bags,
pillows,etc., as they may melt or burn. Under certain circumstances, some rubber
materials, when heated, can produce fire by spontaneous combustion.

Page 16
CARE AND MAINTENANCE
FABRIC CARE
• For optimum results, load the dryer with clothes of similar fabric, weight and
construction.
• Check for stains that may not have been removed in washing. The dryer heat
may permanently set some stains.
• Separate dark and light colored items, like you do when washing laundry.
• DRYING TlME: The drying time depends on many factors, such as the type of
fabric. ln addition, the drying duration is dependent on how dry you want the
laundry to be when taken out of the dryer.
• DRYER ADDED FABRIC SOFTENERS: Certain dryer added fabric softeners may
cause damage to automatic dryers. Therefore, only use fabric softeners with
written assurance from the manufacturer that their softeners can safely be used
in your dryer.
• OVERDRYING GARMENTS: It is possible to overdry the garments, especially if
the timer has been set too long. This can cause the fabrics to wrinkle, shrink, or
feel harsh. Synthetic materials can also become charged with static electricity.
NOTE: Refer to the Fabric Care Chart below for commonly used fabric care
symbols.
NOTE: Always remove the laundry load from the dryer as soon as possible.
FABRIC CARE CHART
Fabric Care Symbol Definition
Dry flat
Can be hung to dry
Dry on clothes hanger
Tumble dry, normal heat
Tumble dry, reduced heat
Do not tumble dry

Page 17
CARE AND MAINTENANCE
CARE AND MAINTENANCE
WARNING: Unplug the power cord before cleaning any part of the dryer.
UNIT
The dryer should be cleaned regularly, including the control panel, with a soft
cloth and non-abrasive household detergents. The use of harsh detergent or
abrasives is not recommended. Do not pour water on the dryer or control panel.
Use a soft cloth to dry the surfaces. Failure to maintain the dryer in a clean
condition could lead to deterioration of the surface which could adversely affect
the life of the appliance and possibly result in a hazardous situation.
LINT FILTER ASSEMBLY
The lint filter assembly should be cleaned before or after each use. Refer to the
chart below to clean each part of the lint filter assembly.
Lint Filter Assembly
1Remove the lint filter by using the four (4) grip holes in the filter assembly to
rotate the filter (in either direction) until you feel a bump, then pull it outward.
NOTE: The lint filter assembly must be installed when operating the dryer.
2The lint filter assembly consists of three
(3) parts: exhaust vent shroud, lint
filter, and exhaust filter.
3 Separate the three (3) parts of the
assembly and clean the individual
pieces using a soft brush or a vacuum
cleaner. Do not damage the filter
assembly.
4Reassemble the filter assembly in the
following order: exhaust filter - lint filter
- exhaust vent shroud. Align the entire
assembly with the recessed
position in the back of the drum and
press firmly until the entire filter
assembly is secured.
WARNING
Regularly clean the lint trap. Hot Surface.
Do not touch the intake during the drying
cycle due to high temperatures.

Page 18
Air Intake Filter
1Remove the air intake filter by pulling outward while holding the filter housing
by its top and bottom.
NOTE: The air intake filter must be installed when operating the dryer.
2The air intake filter consists of two (2)
parts: filter housing and air intake filter.
3Remove the air intake filter inside the
filter housing. Clean the filter using a
soft brush or a vacuum cleaner.
4Reassemble the air intake filter inside
the filter housing, then reinstall the
filter housing by pushing the housing
upwards with your thumb until the
latch is secured to the dryer.
CARE AND MAINTENANCE
AIR INTAKE FILTER
The air intake filter should be cleaned before or after each use. Refer to the chart
below to clean the air intake filter.
WARNING: Unplug the power cord before cleaning any part of the dryer.

Page 19
The control panel does not
illuminate
• The dryer is not plugged in.
• The circuit breaker tripped or a fuse blew. Check for
blown circuit fuse or tripped main circuit breaker in
your house.
The dryer does not operate • The dryer is not plugged in.
• The circuit breaker tripped or a fuse blew. Check for
a blown circuit fuse or tripped main circuit breaker
in your house.
• The door is not closed.
The dryer drum does not rotate • The dryer is not plugged in.
• The circuit breaker tripped or a fuse blew. Check for
a blown circuit fuse or tripped main circuit breaker
in your house.
• The door is not closed.
The laundry is not completely
dry
• Verify the Program and time settings used.
• Clean the filter.
• Reduce the laundry load in the dryer. Do not over-load
the dryer.
• Dry these items further
• Ensure the items are not knotted or twisted together.
• The dryer is not located in a properly ventilated area.
• Make sure your washer’s spin cycle is extracting water
properly.
TROUBLESHOOTING & WARRANTY
Troubleshoot your problem by using the chart below. If the dryer still does not work
properly, contact BLACK+DECKER customer service center or the nearest authorized
service center.
WARNING: Users must never troubleshoot internal components.

Page 20
BEFORE YOU CALL FOR SERVICE
IF THE APPLIANCE FAILS TO OPERATE:
A) Check to make sure that the dryer is plugged in securely. If it is not, remove
the plug from the outlet, wait 10 seconds and plug it in again securely.
B) Check for a blown circuit fuse or a tripped main circuit breaker. If these seem
to be operating properly, test the outlet with another appliance.
IF NONE OF THE ABOVE SOLVES THE PROBLEM, CONTACT A QUALIFIED
TECHNICIAN. DO NOT TRY TO ADJUST OR REPAIR THE APPLIANCE
YOURSELF.
IMPORTANT
DO NOT RETURN THIS PRODUCT TO THE STORE
If you have a problem with this product, please contact the
BLACK+DECKER Customer Satisfaction Center at
844-299-0879 or service@equitybrands.com
DATED PROOF OF PURCHASE, MODEL # AND SERIAL #
REQUIRED FOR WARRANTY SERVICE
TROUBLESHOOTING & WARRANTY
Table of contents
Languages:
Other Black & Decker Dryer manuals
