Black & Decker BDXCTSH1 User manual

BDXCTSH1 Smart Thermostat
Installation & Operation Manual
Please read before returning this product for any reason.

i
USING THIS MANUAL
BEFORE INSTALLING AND USING THE BDXCTSH1 SMART THERMOSTAT,
please read these instructions carefully. This manual is intended as a reference
guide for the installation, configuration, and operation of your device. Save all
instructions in a safe place for future reference.
SAFETY ALERT SYMBOLS
This instruction manual uses the following safety alert symbols and text to
alert installers or users to hazards and risks of personal injury or property
damage.
DANGER: Indicates an imminently hazardous situation which, if
not avoided, will result in death or serious injury.
WARNING: Indicates an imminently hazardous situation which, if
not avoided, could result in death or serious injury.
CAUTION: Indicates a potentially hazardous situation which, if not
avoided, may result in minor or moderate injury.
(Used without one of the words above) indicates a safety related
message.
NOTICE: Indicates a practice not related to personal injury which, if not
avoided, may result in property damage.

ii
IMPORTANT SAFETY INSTRUCTIONS
WARNING: Read all safety warnings and all instructions.
Failure to follow the warnings and instructions may result in electric shock,
fire and/or serious injury.
WARNING: Never modify this product. Damage or personal injury could
result.
WARNING:
• Follow all applicable electrical codes and regulations regarding the
installation or replacement of a thermostat in the local jurisdiction.
In the absence of local requirements, follow ANSI/NFPA 70, National
Electric Code. In some cases, an authorized installer may be required.
Consult a qualified electrician or HVAC technician with any questions
about the installation of this product.
• DO NOT connect any of the terminals to voltage above 30 VAC.
The Thermostat uses 24 VAC nominal power.
• DO NOT cover any of the vents on the thermostat.
• DO NOT install this unit at an altitude of over 6550 feet (2000 meters).
• DO NOT install this unit in a bathroom or area of excessive moisture.
• DO NOT allow the unit to get wet. This temperature control device is
intended only for dry, closed living and oce spaces.
• DO NOT expose this device to temperatures below 14°F (-10°C) or
above 140°F (60°C).
• DO NOT operate or store this thermostat in areas where the relative
humidity exceeds 90%.
• DO NOT expose the unit to voltage fluctuations more than +/- 10%.
• DO NOT use solvents or aggressive cleaning agents. A dry, soft cloth is
recommended.
The manufacturer does not accept responsibility for any damage caused by
not following these instructions.

iii
CONTENTS
USING THIS MANUAL . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . i
IMPORTANT SAFETY INSTRUCTIONS . . . . . . . . . . . . . . . . . . . . . . . . . . ii
CONTENTS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . iii
CUSTOMER ASSISTANCE & SUPPORT . . . . . . . . . . . . . . . . . . . . . . . . . 1
IN THE BOX . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
INSTALLING THE BDXCTSH1 SMART THERMOSTAT . . . . . . . . . . . . . 2
DEVICE OVERVIEW . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
DISPLAY ELEMENTS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
SMART DEVICE APPLICATION – DOWNLOAD . . . . . . . . . . . . . . . . . . 12
THERMOSTAT PARAMETERS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
MANUAL OPERATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .18
APPENDIX A – THERMOSTAT WIRING SCHEMATICS . . . . . . . . . . . A-1
APPENDIX B – WARRANTY. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . B-1
APPENDIX C – COMPLIANCE: FCC/INDUSTRY CANADA . . . . . . . . C-1
APPENDIX D – THERMOSTAT SPECIFICATIONS . . . . . . . . . . . . . . . . . . D-1
APPENDIX E-ALTERNATEJUNCTIONBOXINSTALLLATION.....E-1
TRADEMARK ACKNOWLEDGEMENT

1
CUSTOMER SERVICE & SUPPORT
For any questions about operating this new BLACK+DECKER branded product, PLEASE CON-
TACT US FIRST… do not return this product to the retail store. The contact information for
support will vary depending on the country in which you purchased and utilize the product.
To obtain warranty service or other information for products purchased from CT Nova itself or
through its authorized reseller or agent and utilized in the U.S.A., please visit www.ctnovatech.
com. You will receive instructions on how to ship the products at your expense to an our
Authorized Service Center. To obtain service, you must include: (a) a copy of your receipt, bill
of sale or other comparable proof of purchase; (b) a written description of the problem; and,
most importantly; (c) your address and telephone number.
For further information needed on its features, please visit www.ctnovatech.com for frequently
asked questions and the electronic manual.
©2021 CT Nova US LLC
4700 Duke Drive Suite 200, Mason, OH 45040, USA
IN THE BOX
Installation & Operation Manual
BDXCTSH1 Smart Thermostat
with Mounting Plate
Mounting
Hardware
Wall Plate (if required)

2
INSTALLING THE THERMOSTAT
There are 5 steps to install the BDXCTSH1 Smart Thermostat.
1. Determine Wiring Configuration
2. Remove Old Thermostat
3. Install Thermostat Mounting Base
4. Connect Wires
5. Attach Display
TOOLS REQUIRED (Not included)
The following tools may be required for installation:
• #1 Phillips or flathead screwdriver
• Power drill with 3/16” bit
• Smartphone/camera to photograph existing wiring (optional)
• Screwdriver to disconnect wires from existing thermostat.
• Pencil
TURN OFF POWER TO HVAC
SYSTEM
Locate the HVAC panel breaker
and turn OFF the system. Before
removing the old thermostat,
initiate heating or cooling by
changing the temperature setting.
Ensure the HVAC system does not
respond.

3
INSTALLING THE THERMOSTAT
DETERMINE WIRING CONFIGURATION
If the BDXCTSH1 Smart Thermostat is being installed in a new system or if wiring
changes are required, refer to APPENDIX A for wiring configurations and skip to
“Install Mounting Plate”.
When replacing a thermostat and replication of the existing wiring is desired on
the BDXCTSH1 Thermostat, the following applies:
• Remove old thermostat to expose the wiring terminals
• Photograph the wiring for reference or,
• Use the Wire Color Record to note the wire color and function of each wire.
If the terminals of the existing thermostat are unmarked, determine the
wire functions for each color wire at the appliance.
Wire Color Record
NON-HP HP FAN COIL WIRE COLOR/DESCRIPTION
RC RC RC
RH RH RH
C C C
G G Gl
Y1 Y1 Gm
Y2 Y2 Gh
W1 OB WY
W2 AX Y/A
N/A LN /A

4
WARNING:
The BDXCTSH1 Thermostat IS NOT COMPATIBLE with supply
voltages above 30 VAC. If the old thermostat is connected
with thick wire and wire nuts or is labeled for voltages
higher than 30 VAC, DO NOT INSTALL the Thermostat.
Wrap wires around a pencil or similar object
to prevent them from falling into the wall void.
INSTALLING THE THERMOSTAT
REMOVE OLD THERMOSTAT
Remove the old thermostat from the wall, taking care not to allow the wires
to fall inside the void.

5
INSTALLING THE THERMOSTAT
INSTALL MOUNTING PLATE (with WALL PLATE if required)
Use the included screws and wall anchors (if required) to attach the Mount-
ing Plate to the wall, making sure the wires go through the center opening.
Note the correct position indicated by the UP arrows molded into the
plastic.
To cover paint or screw holes on the wall behind the thermostat, insert
the Wall Plate between the Mounting Plate and the wall as shown. Both
plates are secured with the same screws.
Note: See Appendix E
for optional junction
box mounting.
Note: Use 3/16” drill for wall
anchors if no stud is present.

6
INSTALLING THE THERMOSTAT
ATTACH WIRING
To insert a wire, flip up the locking lever that corresponds to the
labeled wire socket and slide the wire into the socket. Once the
wire is inserted, flip the lever down to lock the wire in position.
Pull gently on each wire after the locking lever is closed to make
sure it is secure. Inspect the wires for oxidation and integrity.
NOTICE: A factory supplied jumper is provided between RC and RH.
This should be removed in two transformer systems (See Appendix A).

7
INSTALLING THE THERMOSTAT
ATTACH DISPLAY TO MOUNTING PLATE
Slide the display over the Mounting plate and the LCD display will illuminate.

8
DEVICE OVERVIEW
BDXCTSH1 SMART THERMOSTAT KEYS
KEY DESCRIPTION BUTTON DESCRIPTION
FAN Change
Fan Speed INCREASE Increase Set Point
MODE Change
System Mode DECREASE Decrease Set Point

9
DEVICE OVERVIEW
SPECIAL KEY FUNCTIONS
KEYS TIME RESULT
< 3 seconds
Briefly press + and - keys to switch between
Programmable and Non-programmable
Thermostat.
3 seconds Hold + and – keys for 3 seconds to lock or unlock
key pad.
3 seconds Hold the Fan and Mode keys for 3 seconds to en-
ter or exit the Parameter Menu.
5 seconds
Hold the Mode button for 5 seconds to
initiate pairing with a Wi-Fi network and the
Black+Decker Application.
PARAMETERS AND MENU KEY FUNCTIONS
KEY DESCRIPTION
Scroll forward through the Parameter Menu
Scroll backward through the Parameter Menu
Select parameter value in the Parameter Menu

10
DISPLAY ELEMENTS
Text display (Menu Item, Time, Date, etc.)
Cloud Server/
Internet Connection
Steady = Wi-Fi and Cloud Server connected
1 Flash = Wi-Fi connected, No Cloud connection
2 Flashes = No Wi-Fi or Cloud Server connection
Thermostat Lock
Indicator Displayed when thermostat keys are disabled.
Schedule Indicator Displayed when thermostat schedule
is enabled.
Override Indicator Displayed when scheduled temperature
override is active.
Filter Warning
Indicator Displayed when air filter is clogged.

11
Heating/Cooling Modes – Press to change
OFF – The SMARTSTAT
will not activate heating
or cooling*
AUTOMATIC CHANGEOVER
– The SMARTSTAT will activate
heating or cooling appliance based
on the room temperature.
HEAT – The SMARTSTAT
will activate heating
appliance based on the
room temperature.
EMERGENCY HEAT – The SMARTSTAT
displays this with the element to
indicate that emergency heat is active.
COOL – The SMART-
STAT will activate cooling
appliance based on room
temperature.
* If freeze protection is active, the heating
appliance will be activated to maintain a
minimum temperature.
Fan Mode
FAN – Press to change between automatic mode and manual.
Temperature Displays
SET POINT – Displays the current
target set point temperature.
Displays the current room temperature.

12
SMART DEVICE APPLICATION
Before setting up the thermostat, download the BLACK+DECKER
HOME application on your IOS or Android device. After download-
ing the application, follow the steps in the BLACK+DECKER Home
Application Guide to connect the thermostat.
The BDXCTSH1 Thermostat is designed for remote operation
using a smart device application.

13
This page intentionally left blank.

14
THERMOSTAT PARAMETERS
To access the BDXCTSH1 Smart Thermostat menu parameters manually,
hold down the Mode and Fan buttons for 3 seconds. The following is a
list of the available parameters.
MENU
TEXT OPTIONS DESCRIPTION
HVAC
CON 1H
Conventional System
1-Stage Heating
CON 2H 2-Stage Heating
CON 1H1C 1-Stage Heating & 1-Stage Cooling
CON 2H1C 2-Stage Heating & 1-Stage Cooling
CON 1H2C 1-Stage Heating & 2 Stage Cooling
CON 2H2C 2- Stage Heating & 2 Stage Cooling
CON 1C 1-Stage Cooling
CON 2C 2-Stage Cooling
PUMP 1H
Heat Pump System
1-Stage Heating
PUMP 1C 1-Stage Cooling
PUMP 1H1C 1-Stage Heating & 1-Stage Cooling
PUMP 2H 2-Stage Heating
PUMP 2C 2-Stage Cooling
PUMP 2H2C 2-Stage Heating & 2-Stage Cooling
PUMP 2H1C 2-Stage Heating & 1-Stage Cooling
PUMP 3H2C 3-Stage Heating & 2-Stage Cooling

15
MENU
TEXT OPTIONS DESCRIPTION
HVAC
(Cont.)
DF 2H1C
Dual
Fuel
2-Stage Heating & 1-Stage Cooling
DF 3H2C 3-Stage Heating & 2-Stage Cooling
FC2 1H
Fan Coil System
2-Pipe, 1-Stage Heating
FC2 1C 2-Pipe, 1-Stage Cooling
FC2 1H1C 2-Pipe, 1-Stage Heating & 1-Stage Cooling
FC2 2H 2-Pipe, 2-Stage Heating
FC2 2H1C 2-Pipe, 2-Stage Heating & 1-Stage Cooling
FC4 MANUAL 4-Pipe, Manual Heating/Cooling Changeover
FC4 AUTO 4-Pipe, Auto Heating/Cooling Changeover
Fan
Type
Gas Gas-fired equipment
Electric Electric powered equipment
HP Type HP b Changeover Valve Defaults to Heating
HP o Changeover Valve Defaults to Cooling
Temp
Format
Fahrenheit US Customary System of Temperature Units
Celsius Système international Metric Temperature Units
Time
Format
12 12 Hour Clock (am/pm)
24 24 Hour Clock
THERMOSTAT PARAMETERS

16
THERMOSTAT PARAMETERS
MENU
TEXT OPTIONS DESCRIPTION
Frost
Protection
NO Call for heat will be initiated if temperature drops
below 41°F (5°C) NO = Disable, YES = Enable
YES
Temp
Calibration
-6F (-3.0C)
to
6F (3.0C)
Calibrate temperature reading by osetting the dis-
play by -6°F to 6°F (-3.0°C to 3.0°C) in 1°F (0.5°C)
increments. Default = 0
Backlight
Color
NO Backlight (Always = White)
YES Backlight (O = White, Heat = Red, Cool = Blue)
Backlight
Timeout
NO Constant Backlight
YES Backlight timeout after 20 seconds
Auto
Recovery
NO Gradually increases set point after setback
NO = Disable, YES = Enable
YES
Span
0.5F (0.25C)
to
3.0F (1.5C)
Control variable that aects thermostat response
time. A larger number slows response time.
Deadband
4F / 2C Allowable temperature dierence between Auto
mode heating and cooling set points.
Default = 4°F (2.0°C)
3F / 1.5C
2F / 1C
Setback
Oset
4F / 2C Dierence between the set point in non-program-
mable mode and the setback temperature. Used to
reduce energy usage.
8F / 4C
12F / 6C
