Black & Decker HLVC315B11 User manual

www.blackanddecker.com.au
www.blackanddecker.co.nz
1 2
34
5
8
6
7
HLVC315B11
HLVC315J11
HLVC320B11
HLVC320J11

23
1
4
3
6 3
5
7
A
B
D E
4
3
C

3
ENGLISH
(Original instructions)
23
3
3
9
8
F G
H
Intended use
Your BLACK+DECKER HLVC315B11, HLVC315J11,
HLVC320B11, HLVC320J11 Dustbuster®handheld vacuum
cleaner has been designed for light dry vacuum cleaning
purposes. This appliance is intended for household use only.
Safety instructions
@Warning! Read all safety
warnings and all instructions.
Failure to follow the warnings
and instructions listed below
may result in electric shock, re
and/or serious injury.
9
9a
I
J

4
ENGLISH (Original instructions)
Warning! When using
battery-powered appliances,
basic safety precautions, including the
following, should always be followed to
reduce the risk of re, leaking batteries,
personal injury and material damage.
u Read all of this manual carefully
before using the appliance.
u The intended use is described in this
manual. The use of any accessory or
attachment or the performance of any
operation with this appliance other
than those recommended in this
instruction manual may present a risk
of personal injury.
uRetain this manual for future
reference.
Using your appliance
uThis appliance contains batteries
that are only replaceable by skilled
persons.
uDo not use the appliance to pick up
liquids or any materials that could
catch re.
uDo not use the appliance near water.
uDo not immerse the appliance in water.
uNever pull the charger lead to
disconnect the charger from the
socket. Keep the charger lead away
from heat, oil and sharp edges.
uKeep hair, loose clothing, ngers, and
all parts of body away from openings
and moving parts.
uDo not use without dust bag and/or
lters in place.
uThis appliance can be used by
children aged from 8 years and above
and persons with reduced physical,
sensory or mental capabilities or
lack of experience and knowledge
if they have been given supervision
or instruction concerning use of
the appliance in a safe way and
understand the hazards involved.
Children shall not play with the
appliance. Cleaning and user
maintenance shall not be made by
children without supervision.
Inspection and repairs
uBefore use, check the appliance for
damaged or defective parts. Check for
breakage of parts, damage to switches
and any other conditions that may
affect its operation.
uDo not use the appliance if any part is
damaged or defective.
uHave any damaged or defective parts
repaired or replaced by an authorized
repair agent.
uRegularly check the charger lead for
damage. Replace the charger if the
lead is damaged or defective.
uNever attempt to remove or replace
any parts other than those specied in
this manual.
Additional safety instructions
uWhen not in use, the appliance should
be stored in a dry place.
uChildren should not have access to
stored appliances.

5
ENGLISH
(Original instructions)
Residual risks
Additional residual risks may arise when
using the tool which may not be included
in the enclosed safety warnings. These
risks can arise from misuse, prolonged
use etc.
Even with the application of the
relevant safety regulations and the
implementation of safety devices, certain
residual risks can not be avoided. These
include:
uInjuries caused by touching any
moving parts.
uInjuries caused by touching any hot
parts.
uInjuries caused when changing any
parts or accessories.
uInjuries caused by prolonged use
of the appliance. When using any
appliance for prolonged periods
ensure you take regular breaks.
uHealth hazards caused by breathing
dust developed when using your
tool (example:- working with wood,
especially oak, beech and MDF.)
Batteries and chargers
Batteries
uNever attempt to open for any reason.
uDo not expose the battery to water.
uDo not expose the battery to heat.
uDo not store in locations where the
temperature may exceed 40°C.
uCharge only at ambient temperatures
between 10°C and 40°C.
uCharge only using the charger
provided with the appliance/tool.
Using the wrong charger could result
in an electric shock or overheating of
the battery.
uWhen disposing of batteries, follow
the instructions given in the section
"Protecting the environment".
uDo not damage/deform the battery
pack either by puncture or impact, as
this may create a risk of injury and re.
uDo not charge damaged batteries.
uUnder extreme conditions, battery
leakage may occur. When you notice
liquid on the batteries carefully wipe
the liquid off using a cloth. Avoid skin
contact.
uIn case of skin or eye contact, follow
the instructions below.
Warning! The battery uid may cause
personal injury or damage to property. In
case of skin contact, immediately rinse
with water. If redness, pain or irritation
occurs seek medical attention. In case of
eye contact, rinse immediately with clean
water and seek medical attention.
Chargers
Your charger has been designed for a
specic voltage.
Always check that the mains voltage
corresponds to the voltage on the rating
plate and the information in the technical
data table.
Warning! Never attempt to replace the
charger unit with a regular mains plug.
uUse your BLACK+DECKER charger
only to charge the battery in the
appliance/tool with which it was
supplied.

6
ENGLISH (Original instructions)
Other batteries could burst, causing
personal injury and damage.
uNever attempt to charge
nonrechargeable batteries.
uIf the supply cord is damaged, it must
be replaced by the manufacturer or an
authorised BLACK+DECKER Service
Centre in order to avoid a hazard.
uDo not expose the charger to water.
uDo not open the charger.
uDo not probe the charger.
uThe appliance/tool/battery must be
placed in a well ventilated area when
charging.
Electrical safety
Your charger has been designed for a
specic voltage. Always check that the
mains voltage corresponds to the voltage
on the rating plate. Never attempt to
replace the charger unit with a regular
mains plug.
Symbols on the charger
Read all of this manual carefully
before using the appliance.
#
This tool is double insulated;
therefore no earth wire is
required. Always check that the
power supply corresponds to
the voltage on the rating plate.
$The charging base is intended
for indoor use only.
Labels on appliance
The following symbols appear on this ap-
pliance along with the date code.
Read all of this manual care-
fully before using the appli-
ance
S003AQS1500015
Only use with charger
S003AQS1500015
Features
This tool includes some or all of the following features.
1. On/Off switch
2. Main handle
3. Dust bowl
4. Extendable extra wide nozzle
5. Crevice nozzle accessory
6. Brush accessory
7. Charger jack plug (HLVC315J11 and HLVC320J11 only)
8. Charger Base (HLVC315B11 and HLVC320B11 only)
Operation (Fig. A)
uTo turn on slide the On/Off switch (1) forward as shown in
gure A.
uSlide the On/Off switch backward, the appliance stops
working.
Using the Extendable wand (Fig. B, C)
uSlide the extra wide nozzle (4) from out of the dust bowl
(3) as shown in gure B.
uRotate the two end pieces to form the vacuuming head as
illustrated in gure C.
uRotate the two wings closed and then push nozzle back
into place.
Note: If the extendable tool pulls completely out from the dust
bowl it can be pressed back in and will lock into positon.
Attaching Accessories
uIf you need to use the accessory brush (6), insert the
brush into the air inlet as shown in gure D and then start
the appliance.
uIf you need to use the accessory crevice nozzle (5), insert
the crevice nozzle into the air inlet as shown in gure D
and then start the appliance.
Charging (Fig. E, F)
Charging the battery via charger base
(HLVC315B11 and HLVC320B11 only) (Fig. F)
uMake sure that the appliance is switched off. The battery
will not be charged with the on/off switch (1) pressed.
uPlace the appliance on the charging bracket (8).
uPlug in the charger. Switch on at the mains.

7
ENGLISH
(Original instructions)
Warning! Do not charge the battery at ambient temperatures
below 10 °C or above 40 °C.
Charging the battery via charger jack plug
(HLVC315J11 and HLVC320J11 only) (Fig. E)
uMake sure that the appliance is switched off. The battery
will not be charged with the on/off switch (1) pressed.
uInsert the charger jack plug into the charging port.
uPlug in the charger. Switch on at the mains.
uThe LED indicator wiil light up.
uWhile charging, the charger may become warm. This is
normal and does not indicate a problem. The appliance
can be left connected to the charger indenitely.
Warning! Do not charge the battery at ambient temperatures
below 10 °C or above 40 °C.
Cleaning the lters (Fig. G, H, I, J)
uRotate the dust bowl (3) in a counterclockwise direction to
release from the appliance body as shown in gure G.
uTake out the lter assembly (9) from the dust bowl (3).
uThe prelter (9) and lter (9a) can be seperated and
rinsed with water and should be dried afterwards.
uDispose of the dirt inside the dust bowl as shown in gure
J. The dust bowl can be rinsed by water.
However it needs to be dried afterwards.
Replacing the lters
The lters should be replaced every 6 to 9 months and
whenever worn or damaged.
Replacement lters are available from your BLACK+DECKER
dealer
Storage
The unit can be safely stored using the charging station.
Maintenance
Your BLACK+DECKER corded/cordless appliance/tool has
been designed to operate over a long period of time with a
minimum of maintenance. Continuous satisfactory operation
depends upon proper tool care and regular cleaning.
Warning! Before performing any maintenance on corded/
cordless power tools:
uSwitch off and unplug the appliance/tool.
uOr switch off and remove the battery from the appliance/
tool if the appliance/tool has a separate battery pack.
uOr run the battery down completely if it is integral and then
switch off.
uUnplug the charger before cleaning it. Your charger does
not require any maintenance apart from regular cleaning.
uRegularly clean the ventilation slots in your appliance/tool/
charger using a soft brush or dry cloth.
uRegularly clean the motor housing using a damp cloth. Do
not use any abrasive or solvent-based cleaner.
Protecting the environment
ZSeparate collection. Products and batteries
marked with this symbol must not be disposed of
with normal household waste.
Products and batteries contain materials that can be
recovered or recycled reducing the demand for raw materials.
Please recycle electrical products and batteries according to
local provisions. Further information is available at
www.2helpU.com
Note:
uBLACK+DECKER’s policy is one of continuous
improvement to our products and, as such, we reserve the
right to change product specications without prior notice.
uStandard equipment and accessories may vary by coun-
try.
u Product specications may differ by country.
uComplete product range may not be available in all coun-
tries. Contact your local BLACK+DECKER dealers for
range availability.
Technical data
HLVC315B11, HLVC315J11 HLVC320B11, HLVC320J11
Voltage
(Vdc)
12 12
Battery 1.5Ah 2.0Ah
Weight
(Kg)
0.71 0.71
Charger S003AQS1500015 S003AQS1500015
Approx
charge
time (h)
10 13.5
Input
Voltage
(Vac)
100 - 240V 100 - 240V
Output
Voltage
(Vdc)
15 15
Current
(mA)
150 150
Australia & New Zealand
Stanley Black & Decker
www.blackanddecker.com.au
www.blackanddecker.co.nz
Tel.[phone] (Aust) or Tel. [phone] (NZ)
810 Whitehorse Road Box Hill VIC 3128, Australia

NA013496 02/2021
