Black Box JPMT1024-ANG Operator's manual

0118 965 6000 | www.blackbox.co.uk0118 965 6000 | www.blackbox.co.uk 0118 965 6000 | www.blackbox.co.uk
Page 5 Page 6
© Copyright 2011. Black Box Corporation. All rights reserved.
Black Box and the Double Diamond logo are registered trademarks of
BB Technologies, Inc. Any other trademarks mentioned in this manual
are acknowledged to be the property of the trademark owners.
BLACKBO
Angles ports
to the sides.
Helps to reduce stress on the ports.
Horizontal cable management is not required.
45° Side-Exiting Multimedia Panel
JPMT1024-ANG
Black Box Tech
Support: FREE! Live.
24/7. Tech support
the way it should be.
Great tech support is just 30 seconds
away at 724-746-5500 or blackbox.com.
Order :
Call 0118 965 6150
FREE technical support
24 hours a day, 7 days a week:
Call 0118 965 6000
Mailing address:
Black Box Network Services
464 Basingstoke Road
Reading, Berkshire, RG2 0BG
Web site: www.blackbox.co.uk
E-mail: [e-mail]
Customer
Support
Information
BLACKBOX®
45° Side-Exiting Multmedia Panel
JPMT1024-ANG
1. Specications
Size: Without rear base installed: 1.75”H (1U) x
19”W x 0.625”D (4.5 x 48.3 x 1.6 cm);
With rear base installed: 1.75”H (1U) x 19”W x
5”D (4.5 x 48.3 x 12.7 cm)
Weight: 1.5 lb. (0.7 kg)
2. Overview
2.1 Introduction
The 24-Port 45° Side-Exiting Multimedia Panel
angles ports to the sides, which helps reduce
stress on the ports and eliminates the need for
horizontal cable management. The rear of the
panel has an optional cable support bar that
provides support to horizontal cables accessing
the panel.
Direction of
IDC slot
Figure 5. IDC slot position.
6. Secure the back cables with the supplied cable ties.
NOTE: Do not overtighten the cables.
7. Figure 6 shows a completed installation.
Figure 6. Completed patch panel installation.

0118 965 6000 | www.blackbox.co.uk0118 965 6000 | www.blackbox.co.uk 0118 965 6000 | www.blackbox.co.uk
45° Side-Exiting Multmedia Panel 45° Side-Exiting Multmedia Panel45° Side-Exiting Multmedia Panel
Page 3Page 2 Page 4
JPMT1024-ANG JPMT1024-ANGJPMT1024-ANG
2.2 What’s Included
Your package should include the following items.
If anything is missing or damaged, contact Black Box
Technical Support on 0118 965 6000 or
[e-mail].
•(1) 45° Side-Exiting Multimedia Patch Panel
•(2) Side brackets
•(1) Rear cable bar
•(24) Cable ties
•(4) 10-32 screws
•(4) 12-24 screws
•This user’s manual
3. Installation Steps
1. Mount the panel on a 19-inch rack, as shown
in Figure 1.
Figure 1. Mounting the panel on a rack.
2. Attach each side bracket to the matching end of the
bar accordiing to the same marking. See Figure 2.
Slide in
Slide in
mark “L”
mark “R”
Figure 2. Attaching the side bracket.
3. Snap the rear cable bar into the patch panel, as
shown in Figure 3.
Figure 3. Attaching the rear wire manager.
4. Load the wired keystone jack into the patch panel.
Make sure the locking knob is locked rst before
sliding in the keystone jack or support tting. See
Figure 4.
NOTE: Ports 1–6 and 13–18 share the same orienta -
tion, while ports 7–12 and 19–24 are placed
in opposite positions. Be sure to follow the
directions during installation.
NOTE: For best connector loading sequences, start
from the sides and install toward the centre.
locking knob
latch
Figure 4. Loading the keystone jack or support tting.
5. Make sure the IDC slot of the keystone jack faces
toward the centre of the patch panel, as shown in
Figure 5.
