10
ENGLISH (Original instructions)
J3 Beater bar Touch Button
Allows you to turn the beater bar function on and off.
J4 Power indicator
Allows you to monitor the level of power being used.
J5 BATTERYSENSOR Indicator
The LED battery indicator displays the remaining charge and warns you
when the battery is low. The final LED will flash continuously when ther
is only 1 minute of runtime remaining. All LEDs will flash when the unit is
discharged.
J6 FILTERSENSOR
Smart sensor technology automatically detects (the symbol will light red)
when the filter becomes clogged and needs to be cleaned
Note: The FILTERSENSOR LED will flash and the unit will
automatically shut down when there is any obstruction in the
flexible hose or filters which is causing the motor to overheat.
Disconnect and remove the blockage immediately.
Using the handle / wand (Fig. B, C, D, E)
uPress the handle / wand release button (11) to free the
handle / wand (3) from the chassis (12).
uFree the hose connector (9) from the chassis hose port
(13) as shown in figure B
uPress the chassis release button (12b) to release the hand
held vac (5) from the chassis (12) as shown in
figure C
uConnect the hose connector (9) to the flexible tube por
(3a) ensuring that the latch (9a) clicks securely into place
as shown in figure D
uExtend the crevice tool (4) as shown in figure E, until it
clicks in place.
uTo retract the crevice tool (4) press the tube extension
latch (3b) allowing it to return to its normal position.
Using the 3-in-1 accessory tool (Fig. F)
uThe 3-in-1 handle / wand (15) has three configurations
1. Brush mode.
2. Small crevice mode.
3. Upholstery mode.
uThe 3-in-1 handle / wand can be fitted eit er directly to the
hose connector 9 or to the extendable crevice tool (4) as
shown in figure .
Removing and clearing the beater bars
(Fig. G, H)
uTo remove the beater bar cassette (14a) from the floor
head (14) Depress the release button (14b) as shown in
figure G
uThe beater bar (18) can now be removed.
The end pieces are also removable allowing you to clear
the brushes from any hair or other debris that may have
accumulated as shown in figure H
Note: If an object gets caught in the beater bar it automatically
stops. Turn the unit off, remove object and continue.
Note: The CUA625BHP unit is supplied with a specialised pet
beater bar (18a) for cleaning pet hairs etc.
Charging (Fig. I)
uPlace the appliance into the charging base (7) as shown in
figure I .
uPlug the charging base (7) into an electrical outlet.
uSwitch the electrical outlet on. The LED charging indicator
will flash and increase in sections.
LEDs go out when fully charged.
uThe appliance must be charged for 6 hours.
Note: The Charging base is supplied with 2 screws and wall
plugs for securing it to a wall, providing extra stability, as
shown in figure I
Battery Sensor LED Patterns
Battery Fault (All LEDs)
Charger Fault (All LEDs)
Battery Hot (All LEDs)
Battery diagnostics
If the appliance detects a weak battery, the charging indicator
will flash at a fast rate when the power button is activated.
Proceed as follows:
uPlug in the charger. Switch on at the mains.
uLeave the appliance to charge.
If the appliance detects a damaged battery, the charging
indicator will flash at a fast rate when the appliance is o
charge. Proceed as follows:
uTake the appliance and the charger to be tested at an
authorised services centre.
Note: It may take as long as 60 minutes to determine that
the battery is defective. If the battery is too hot or too
cold, the LED will alternately blink, fast and slow, one
flash at each speed and repeat
Emptying the dust bowl (Fig. K, L, N)
uHolding the unit over a suitable waste receptacle, press
the dust bowl release button (6a) to release the dust bowl
lid (6) as shown in figure K
uPush the compacting handle (19) down to empty the
contents of the dust bowl (5a) as shown in figure L
