Black Diamond Equipment 8800Series Manual

Extreme Networks, Inc.
3585 Monroe Street
Santa Clara, California 95051
[phone]
[phone]
http://www.extremenetworks.com
BlackDiamond 8800 Series Switches
Hardware Installation Guide
Published: June 2009
Part number: 100284-00 Rev. 03

BlackDiamond 8800 Series Switches Hardware Installation Guide
2
AccessAdapt, Alpine, Altitude, BlackDiamond, EPICenter, ExtremeWorks Essentials, Ethernet Everywhere, Extreme
Enabled, Extreme Ethernet Everywhere, Extreme Networks, Extreme Standby Router Protocol, Extreme Turbodrive,
Extreme Velocity, ExtremeWare, ExtremeWorks, ExtremeXOS, Go Purple Extreme Solution, ExtremeXOS ScreenPlay,
ReachNXT, Sentriant, ServiceWatch, Summit, SummitStack, Triumph, Unified Access Architecture, Unified Access
RF Manager, UniStack, the Extreme Networks logo, the Alpine logo, the BlackDiamond logo, the Extreme
Turbodrive logo, the Summit logos, and the Powered by ExtremeXOS logo are trademarks or registered trademarks
of Extreme Networks, Inc. or its subsidiaries in the United States and/or other countries.
sFlow is a registered trademark of InMon Corporation.
Specifications are subject to change without notice.
All other registered trademarks, trademarks, and service marks are property of their respective owners.
© 2008, 2009 Extreme Networks, Inc. All Rights Reserved.

BlackDiamond 8800 Series Switches Hardware Installation Guide 3
Table of Contents
Preface........................................................................................................................................... 9
Intended Audience ......................................................................................................................9
Conventions................................................................................................................................9
Related Publications .................................................................................................................10
Part 1: About the BlackDiamond 8800 Series Switches
Chapter 1: About the BlackDiamond 8800 Series Switches.............................................................. 13
Overview of the BlackDiamond 8800 Series Switches...................................................................13
Full-Duplex Support ..................................................................................................................14
Management Ports ....................................................................................................................14
External Compact Flash Memory Card .........................................................................................14
BlackDiamond 8806 Chassis .....................................................................................................15
BlackDiamond 8810 Chassis .....................................................................................................16
Chapter 2: BlackDiamond 8800 and 8900 Series Modules .............................................................. 19
Overview of the BlackDiamond 8800 and 8900 Series Modules ....................................................19
Management Switch Modules (MSM) ..........................................................................................20
Redundant MSM Activity .....................................................................................................20
MSM Physical Features........................................................................................................21
MSM LEDs .........................................................................................................................23
I/O Modules..............................................................................................................................24
BlackDiamond 8800 Original Series I/O Modules ...................................................................25
G24X I/O Module ..........................................................................................................25
10G4X I/O Module ........................................................................................................26
G48T I/O Module ..........................................................................................................27
G48P I/O Module ..........................................................................................................28
BlackDiamond 8800 a-Series I/O Modules.............................................................................29
G48Ta I/O Module.........................................................................................................30
G48Xa I/O Module.........................................................................................................31
10G4Xa I/O Module.......................................................................................................32
10G4Ca I/O Module.......................................................................................................33
BlackDiamond 8800 c-Series I/O Modules.............................................................................33
G48Tc I/O Module.........................................................................................................34
10G4Xc I/O Module.......................................................................................................35
10G8Xc I/O Module.......................................................................................................36
G24Xc I/O Module.........................................................................................................37
G48Xc I/O Module.........................................................................................................38
BlackDiamond 8800 e-Series I/O Modules.............................................................................39
G48Te I/O Module.........................................................................................................39
G48Pe I/O Module.........................................................................................................40
G48Te2 I/O Module.......................................................................................................41

Table of Contents
BlackDiamond 8800 Series Switches Hardware Installation Guide
4
BlackDiamond 8900 Series Modules.....................................................................................42
8900-G96T-c ...............................................................................................................42
8900-10G24X-c I/O Module...........................................................................................43
I/O Module LEDs.................................................................................................................44
Module LEDs ................................................................................................................44
Port LEDs on Non-PoE Modules......................................................................................44
Port LEDs on PoE Modules (G48P, G48Pe, and G48Tc or G48Te2 with S-POE Card) ..........45
Chapter 3: Power Supply Units for BlackDiamond 8800 Series Switches.......................................... 47
Overview of BlackDiamond 8800 Series Power Supplies ...............................................................47
Extreme Networks 700/1200 W AC PSU .....................................................................................48
LEDs..................................................................................................................................49
Power Supply Cords.............................................................................................................49
Fuse ..................................................................................................................................50
Specifications.....................................................................................................................50
Extreme Networks 600/900 W AC PSU .......................................................................................51
Minimum Software Required ................................................................................................51
LEDs..................................................................................................................................52
Power Supply Cords.............................................................................................................52
Fuse ..................................................................................................................................53
Specifications.....................................................................................................................53
Combining Different AC PSU Models...........................................................................................53
Extreme Networks 1200 W DC PSU ............................................................................................54
Minimum Software Required ................................................................................................55
LEDs..................................................................................................................................55
Part 2: Installing BlackDiamond 8800 Series Hardware
Chapter 4: Site Preparation............................................................................................................ 59
Planning Your Site ....................................................................................................................59
Meeting Site Requirements ........................................................................................................60
Operating Environment Requirements ...................................................................................60
Building and Electrical Codes.........................................................................................60
Wiring Closet Considerations ..........................................................................................61
Temperature .................................................................................................................61
Humidity ......................................................................................................................62
Chassis Spacing Requirements .......................................................................................62
Chassis Airflow Requirements.........................................................................................62
Electrostatic Discharge ..................................................................................................63
Rack Specifications and Recommendations ...........................................................................64
Mechanical Recommendations for the Rack .....................................................................64
Protective Grounding for the Rack...................................................................................64
Space Requirements for the Rack ...................................................................................65
Securing the Rack .........................................................................................................65
Evaluating and Meeting Cable Requirements ...............................................................................66
Cabling Standards ...............................................................................................................66
Cable Labeling and Record Keeping......................................................................................66
Selecting Cable...................................................................................................................67
Cable Distances ............................................................................................................67
RJ-45 Connector Jackets ...............................................................................................67
Cable for the 8900-G96T-c Module ................................................................................68

Table of Contents
BlackDiamond 8800 Series Switches Hardware Installation Guide 5
Installing Cable...................................................................................................................69
Fiber Optic Cable ..........................................................................................................70
Radio Frequency Interference...............................................................................................71
Meeting Power Requirements .....................................................................................................72
PoE Devices .......................................................................................................................72
Power Supply Requirements.................................................................................................72
AC Power Cable Requirements..............................................................................................73
Replacing the Power Cable.............................................................................................73
Uninterruptible Power Supply Requirements ..........................................................................73
Selecting a UPS ............................................................................................................74
Calculating Volt-Amperage Requirements.........................................................................74
UPS Transition Time .....................................................................................................74
Applicable Industry Standards....................................................................................................75
Chapter 5: Installing the BlackDiamond 8800 Series Chassis .......................................................... 77
Unpacking the BlackDiamond 8806 Chassis................................................................................78
Unpacking the BlackDiamond 8810 Chassis................................................................................81
Pre-installation Requirements ....................................................................................................84
Attaching the Mid-Mount Brackets..............................................................................................85
Rack-Mounting the BlackDiamond 8800 Series Chassis ...............................................................86
Grounding the BlackDiamond 8800 Series Chassis ......................................................................89
Initial Management Access ........................................................................................................91
Chapter 6: Installing Power Supply Units in the BlackDiamond 8800 Series Switches....................... 93
Safety ......................................................................................................................................93
PSU Compatibility.....................................................................................................................94
Combining Different AC PSU Models.....................................................................................94
Minimum Software Requirements .........................................................................................95
Power Supply Cords for AC Power Supplies..................................................................................95
Installing an Extreme Networks AC PSU ......................................................................................96
Required Tools and Equipment.............................................................................................97
Installing the PSU...............................................................................................................97
Removing or Replacing an Extreme Networks AC PSU ............................................................99
Installing an Extreme Networks 1200 W DC PSU .......................................................................100
Required Tools and Equipment...........................................................................................100
Installing the DC Wiring .....................................................................................................100
Installing a 1200 W DC PSU..............................................................................................101
Removing a 1200 W DC PSU .............................................................................................104
Chapter 7: Installing Modules and Establishing Initial Management Access.................................... 105
Module Slot Assignments.........................................................................................................105
Using 8900 Series Modules in the Dual-Use Slots................................................................106
Distinguishing an MSM from an I/O Module ...............................................................................106
Installing a BlackDiamond 8800 or 8900 Series Module ............................................................107
Connecting Network Interface Cables ........................................................................................110
Connecting and Disconnecting Cables on the 10G4Ca Module...............................................110
Connecting and Disconnecting Cables on the 8900-G96T-c Module.......................................111
Installing a Backup MSM.........................................................................................................111

Table of Contents
BlackDiamond 8800 Series Switches Hardware Installation Guide
6
Verifying the Module Installation ..............................................................................................112
Displaying Slot Status Information ......................................................................................112
Removing a BlackDiamond 8800/8900 Series Module ...............................................................112
Blank Front Panels..................................................................................................................114
Installing a Blank Front Panel ............................................................................................114
Removing a Blank Front Panel............................................................................................115
Installing or Removing an External Compact Flash Memory Card..................................................117
Initial Management Access ......................................................................................................118
Connecting Equipment to the Console Port ..........................................................................118
Logging In for the First Time ..............................................................................................118
Part 3: Installing BlackDiamond Switch Accessories
Chapter 8: Installing BlackDiamond 8800 Series Module Options .................................................. 123
Installing an S-POE Daughter Card ...........................................................................................123
Removing an S-POE Card.........................................................................................................125
Installing an Option Card in the MSM-48c or 8900-MSM128 .....................................................126
Removing an MSM Option Card ................................................................................................128
Chapter 9: BlackDiamond AC Power Cord Retainers ...................................................................... 129
BlackDiamond 8810 AC Power Cord Retainer ............................................................................129
Installing the BlackDiamond 8810 AC Power Cord Retainer ..................................................129
Disconnecting a BlackDiamond 8810 AC Power Cord ...........................................................131
BlackDiamond 8806 AC Power Cord Retainer ............................................................................132
Installing the BlackDiamond 8806 AC Power Cord Retainer ..................................................132
Removing the BlackDiamond 8806 AC Power Cord Retainer..................................................134
Chapter 10: BlackDiamond PSU Covers ........................................................................................ 135
Required Tools........................................................................................................................135
BlackDiamond 8806 PSU Cover ...............................................................................................135
Installing the BlackDiamond 8806 PSU Cover .....................................................................136
Removing the BlackDiamond 8806 PSU Cover.....................................................................137
BlackDiamond 8810 PSU Cover ...............................................................................................138
Installing the BlackDiamond 8810 PSU Cover .....................................................................138
Removing the BlackDiamond 8810 PSU Cover.....................................................................140
Chapter 11: BlackDiamond Cable Management ............................................................................. 141
About BlackDiamond Cable Management ..................................................................................141
Using the Cable Holders and Cable Clips...................................................................................141
Connecting Cable Holders ..................................................................................................142
Connecting Cable Clips ......................................................................................................143
Part 4: BlackDiamond Maintenance Procedures
Chapter 12: Replacing BlackDiamond 8800 Series Chassis Components........................................ 147
Replacing the Fan Tray ............................................................................................................147
Pre-Installation Requirements ............................................................................................147
Removing the Fan Tray ......................................................................................................147

Table of Contents
BlackDiamond 8800 Series Switches Hardware Installation Guide 7
Installing the Replacement BlackDiamond Fan Tray .............................................................149
Replacing the PSU/Fan Controller.............................................................................................150
Pre-installation Requirements.............................................................................................150
Removing the PSU/Fan Controller .......................................................................................151
Installing the Replacement PSU/Fan Controller ....................................................................153
Chapter 13: Repacking a BlackDiamond 8800 Series Chassis ....................................................... 155
Safety Information ..................................................................................................................155
Required Tools and Equipment.................................................................................................156
Repacking the BlackDiamond 8810 Chassis ..............................................................................156
Repacking the BlackDiamond 8806 Chassis ..............................................................................160
Part 5: Appendixes
Appendix A: Safety Information .................................................................................................... 165
Considerations Before Installing ...............................................................................................165
Installing Power Supply Units...................................................................................................166
Maintenance Safety.................................................................................................................166
General Safety Precautions ......................................................................................................167
Cable Routing for LAN Systems ..........................................................................................167
PoE Devices .....................................................................................................................168
Selecting Power Supply Cords ..................................................................................................168
Battery Replacement and Disposal............................................................................................169
Fiber Optic Ports—Optical Safety .............................................................................................169
GBIC, SFP (Mini-GBIC), XENPAK, and XFP Regulatory Compliance .......................................170
Appendix B: Technical Specifications .......................................................................................... 177
BlackDiamond 8810 Switch.....................................................................................................177
BlackDiamond 8806 Switch.....................................................................................................179
Modules for BlackDiamond 8800 Series Switches......................................................................181
Power Supplies for BlackDiamond 8800 Series Switches ............................................................183
Connector Pinouts...................................................................................................................184
Index .............................................................................................................................................. 1

Table of Contents
BlackDiamond 8800 Series Switches Hardware Installation Guide
8

BlackDiamond 8800 Series Switches Hardware Installation Guide 9
Preface
This guide provides the required information to install Extreme Networks® BlackDiamond®8800 series
switches. This guide also contains information about site preparation, switch functionality, and switch
operation.
See the ExtremeXOS 12.3 Concepts Guide and the ExtremeXOS 12.3 Command Reference Guide for
information about configuring Extreme Networks BlackDiamond 8800 series switches.
NOTE
If the information in the installation note or release note shipped with your Extreme Networks switch differs from the
information in this guide, follow the installation note or release note.
Intended Audience
This guide is intended for use by network administrators responsible for installing and setting up
network equipment. It assumes a basic working knowledge of:
●Local area networks (LANs)
●Ethernet concepts
●Ethernet switching and bridging concepts
●Routing concepts
●Simple Network Management Protocol (SNMP)
Conventions
Table 1 and Table 2 list conventions used in Extreme Networks customer documentation.
Table 1: Notice Icons
Icon Notice Type Alerts you to...
Note Important features or instructions.
Caution Risk of personal injury, system damage, or loss of data.
Warning Risk of severe personal injury.

Preface
BlackDiamond 8800 Series Switches Hardware Installation Guide
10
Related Publications
The Extreme Networks ExtremeXOS®switch documentation set includes:
● ExtremeXOS 12.3 Concepts Guide
● ExtremeXOS 12.3 Command Reference Guide
● ExtremeXOS 12.3 Release Notes
● BlackDiamond 10808 Switch Hardware Installation Guide
● BlackDiamond 12800 Series Switches Hardware Installation Guide
● BlackDiamond 20808 Switch Hardware Installation Guide
● Summit Family Switches Hardware Installation Guide
● Extreme Networks Pluggable Interface Modules Installation Guide
Documentation for Extreme Networks products is available from the Extreme Networks website at the
following location:
http://www.extremenetworks.com/services/documentation
You can select and download the following Extreme Networks documentation from the Documentation
Overview page:
●Software User Guides
●Hardware User Guides
You can find archived user guides for software at:
http://www.extremenetworks.com/services/documentation/swuserguides.asp
You can also find archived installation guides for hardware at:
http://www.extremenetworks.com/services/documentation/hwuserguides.asp
Table 2: Text Conventions
Convention Description
Screen displays This typeface represents information as it appears on the screen, or command
syntax.
The words “enter”
and “type”
When you see the word “enter” in this guide, you must type something, and then
press the Return or Enter key. Do not press the Return or Enter key when an
instruction simply says “type.”
[Key] names Key names appear in text in one of two ways:
• Referenced by their labels, such as “the Return key” or “the Escape key”
• Written with brackets, such as [Return] or [Esc]
If you must press two or more keys simultaneously, the key names are linked with a
plus sign (+). Example:
Press [Ctrl]+[Alt]+[Del].
Words in italicized type Italics emphasize a point of information or denote new terms at the place where
they are defined in the text.

1About the BlackDiamond 8800 Series Switches

BlackDiamond 8800 Series Switches Hardware Installation Guide 13
1About the BlackDiamond 8800 Series Switches
This chapter describes the Extreme Networks BlackDiamond 8800 series switches and includes the
following sections:
●Overview of the BlackDiamond 8800 Series Switches on page 13
●Full-Duplex Support on page 14
●Management Ports on page 14
●External Compact Flash Memory Card on page 14
●BlackDiamond 8806 Chassis on page 15
●BlackDiamond 8810 Chassis on page 16
For information about installing the BlackDiamond switches, see Chapter 2, “Installing the
BlackDiamond 8800 Series Chassis.”
Overview of the BlackDiamond 8800 Series Switches
The BlackDiamond switches are chassis-based, Ethernet service core switches designed for core
applications.
The features of these switches include:
●Hot-swappable I/O modules that include Gigabit Ethernet copper ports (10/100/1000) and Gigabit
Ethernet fiber ports (SFP), or 10 Gigabit Ethernet ports (SFP+ or XFP)
●Management Switch Fabric Modules (MSMs) that provide the active switching fabric and CPU
control subsystem
●Redundant, load-sharing, hot-swappable power supplies
●Field-replaceable, hot-swappable fan trays
●Auto-negotiation for half-duplex or full-duplex operation on 10/100/1000 Mbps ports
●Load sharing on multiple ports
The BlackDiamond 8800 series switches include two chassis models:
●BlackDiamond 8806 chassis, with slots for installing one or two management modules and up to five
I/O modules
●BlackDiamond 8810 chassis, with slots for installing one or two management modules and up to
nine I/O modules
Two series of modules are available for the BlackDiamond 8800 series switches:
●8800 series
Provides high port density and scalability for mid-sized networks
●8900 series
Provides greater port density and increased backplane bandwidth for large networks

About the BlackDiamond 8800 Series Switches
BlackDiamond 8800 Series Switches Hardware Installation Guide
14
The specific capabilities of the switch are determined by the module series installed in the chassis. For
more information about individual I/O modules and management modules (MSMs), see Chapter 3.
For more information about configuring a BlackDiamond switch, see the ExtremeXOS 12.3 Concepts
Guide and the ExtremeXOS 12.3 Command Reference Guide.
Full-Duplex Support
Extreme Networks switches provide full-duplex support for all ports. Full-duplex support means that
frames can be transmitted and received simultaneously, effectively doubling the bandwidth available on
a link. Most ports on an Extreme Networks switch will auto-negotiate duplex operation in the default
configuration. Gigabit Ethernet fiber ports and 10-Gigabit Ethernet ports operate only in full-duplex
mode in accordance with technical standards.
Management Ports
Each BlackDiamond management switch fabric module (MSM) has a 10/100BASE-TX Ethernet
management port. This port allows you to communicate directly with the central processing unit (CPU)
of the switch. You can plug an Ethernet cable directly from your laptop into the management port for
direct access into the switch. This access allows you to view and locally manage the switch
configurations.
External Compact Flash Memory Card
All MSMs in the BlackDiamond 8800 series include a compact flash slot next to the console port. This
slot accepts a compact flash memory card, which can be used to download a new version of
ExtremeXOS and for other functions, including capturing debug information and core dump files. See
the ExtremeXOS 12.3 Concepts Guide for more information regarding the use of the external compact
flash memory card.
The external compact flash slot supports third-party compact flash cards.
NOTE
You must use an industrial-grade compact flash card in the external compact flash slot of the MSM.

BlackDiamond 8806 Chassis
BlackDiamond 8800 Series Switches Hardware Installation Guide 15
BlackDiamond 8806 Chassis
The BlackDiamond 8806 chassis includes the following physical features:
●One 6-slot chassis with backplane
●Four dedicated I/O module slots, labeled 1, 2, 5, and 6
●One dedicated MSM slot, labeled 3/A
●One dual-use slot for either an I/O module or MSM, labeled 4/B. (Certain restrictions apply to the
use of slot 4/B. For more information see “Using 8900 Series Modules in the Dual-Use Slots” on
page 106.)
●Power supply bay that accommodates up to six power supplies, accessed from the front of the unit
●One fan tray, accessed from the front right of the unit
●One connector for an ESD-preventive wrist strap
Depending on the MSMs and I/O modules installed, the BlackDiamond 8806 chassis can support up to
128 gigabits per second of bandwidth per slot.
Figure 1 shows the front of a BlackDiamond 8806 chassis equipped with two MSMs and three I/O
modules.
Figure 1: Front of the BlackDiamond 8806 Chassis
Figure 2 shows the rear panel of the BlackDiamond 8806 chassis.
EX_127
ESD wrist strap
connector
MSM slot
Power supplies
Fan tray
I/O module
slots
Power cord
connectors
I/O module or MSM slot
I/O module
slots

About the BlackDiamond 8800 Series Switches
BlackDiamond 8800 Series Switches Hardware Installation Guide
16
Figure 2: Rear Panel of the BlackDiamond 8806 Chassis
The rear panel of the BlackDiamond 8806 chassis provides:
●Chassis serial number
●Ethernet MAC address of the switch
●Symbols of safety certification
●Access to the PSU/fan controllers
●Attachment point for optional chassis ground
BlackDiamond 8810 Chassis
The BlackDiamond 8810 chassis includes the following physical features:
●One 10-slot chassis with backplane
●Eight dedicated I/O module slots, labeled 1, 2, 3, 4, 7, 8, 9 and 10
●One dedicated MSM slot, labeled 5/A
●One dual-use slot for an I/O module or MSM, labeled 6/B. (Certain restrictions apply to the use of
slot 4/B. For more information see “Using 8900 Series Modules in the Dual-Use Slots” on page 106.)
●Power supply bay that accommodates up to six power supplies, accessed from the front of the unit
●One fan tray, accessed from the front right of the unit
●One connector for an ESD-preventive wrist strap
Depending on the MSMs and I/O modules installed, the BlackDiamond 8810 chassis can support up to
80 gigabits per second of bandwidth per slot.
EX_128A
Grounding point
PSU /fan
controllers

BlackDiamond 8810 Chassis
BlackDiamond 8800 Series Switches Hardware Installation Guide 17
Figure 1 shows the front of a BlackDiamond 8810 chassis equipped with two MSMs and three
I/O modules.
Figure 3: Front of the BlackDiamond 8810 Chassis
Figure 2 shows the rear panel of the BlackDiamond 8810 chassis.
Figure 4: Rear Panel of the BlackDiamond 8810 Chassis
ASP04
2
E
SD wrist strap
connector
MSM module slot
Power supplies
Fan tray
I/O module slots
Power cord
connectors
I/O module slots
ASP044B
Grounding point
PSU/Fan
controllers

About the BlackDiamond 8800 Series Switches
BlackDiamond 8800 Series Switches Hardware Installation Guide
18
The rear panel of the BlackDiamond 8810 chassis provides:
●Chassis serial number
●Ethernet MAC address of the switch
●Symbols of safety certification
●Access to the PSU/fan controllers
●Attachment point for optional chassis ground

BlackDiamond 8800 Series Switches Hardware Installation Guide 19
2BlackDiamond 8800 and 8900 Series Modules
This chapter describes modules for the BlackDiamond 8800 series switches and includes the following
sections:
●Overview of the BlackDiamond 8800 and 8900 Series Modules on page 19
●Management Switch Modules (MSM) on page 20
●I/O Modules on page 24
Overview of the BlackDiamond 8800 and 8900 Series
Modules
Modules available for the BlackDiamond 8800 series switches include management switch modules
(MSMs) and I/O modules. A BlackDiamond module consists of a printed circuit board mounted on a
metal panel that acts as the insertion vehicle in the BlackDiamond 8800 series switches. The module
carrier also includes ejector/injector levers and captive retaining screws at each end of the module front
panel. LEDs on the module front panel provide information about the operating status of the modules.
The BlackDiamond 8800 series switches support the modules listed in Table 3.
In general, modules from different series can be used in the same BlackDiamond 8800 series chassis;
however, certain restrictions apply. Table 4 shows supported and unsupported module series
combinations.
Table 3: Modules for the BlackDiamond 8800 Series Switches
MSMs I/O Modules
Currently
Available
Models
8800 Series 8900 Series 8800 e Series 8800 c Series 8900 Series
MSM-48c 8900-MSM128 G48Te2 G48Tc 8900- 10G24X-c
G48Xc 8900-G96T-c
G24Xc
10G4Xc
Legacy
Models
8800 Series** 8800 original
series* 8800 a
series** 8800 e series**
MSM-G8X G24X G48Ta G48Te
MSM-48 G48T G48Xa G48Pe
G48P 10G4Xa
10G4X 10G4Ca
* These modules have been designated as end-of-sale (EoS).
** These modules are planned for EoS later in 2009.

BlackDiamond 8800 and 8900 Series Modules
BlackDiamond 8800 Series Switches Hardware Installation Guide
20
CAUTION
Do not attempt to combine modules from the BlackDiamond 8800 series and BlackDiamond 12800 series product
lines. When a BlackDiamond 8800 series switch is running, ExtremeXOS software will not recognize an installed
BlackDiamond 12800 series module.
Management Switch Modules (MSM)
The following MSMs are available for the BlackDiamond 8800 series switches:
●8800 series MSMs
■MSM-G8X
■MSM-48
■MSM-48c
●8900-MSM128
The MSMs provide the active switching fabric and CPU control subsystem for the switch. One MSM is
required for switch operation; however, adding a second MSM to the chassis increases reliability and
throughput.
A compact flash slot allows you to insert an external compact flash memory card. (See “External
Compact Flash Memory Card” on page 14 for more information about Extreme Networks-supported
compact flash cards.)
Redundant MSM Activity
The BlackDiamond 8800 series switches can run with a single MSM installed. When you install an
additional MSM, one MSM operates as the primary MSM and the other becomes the backup
(secondary) MSM. The primary MSM is responsible for upper-layer protocol processing and system
management functions. Packet handling is distributed among the CPUs of all installed MSMs.
Table 4: BlackDiamond 8000 Series Module Compatibility
8800 Series
Modules
8900 Series Modules
8900-
MSM128
8900-
10G24X-c 8900- G96T-c
MSM-G8X No Yes* Yes*
MSM-48 No Yes* Yes*
MSM-48c No Yes* Yes*
8800 original
series I/O
Yes Yes Yes, except for
10G4X
8800 a series I/O Yes Yes Yes
8800 c series I/O Yes Yes Yes
8800 e series I/O Yes Yes Yes
* ExtremeXOS 12.3.1 or later is required on the MSM in order to
recognize the 8900 series I/O modules.
