BLACKCUBE XW-2001 User manual

20V CORDLESS DRILL
Model: XW-2001

Dear customer,
Thank you for your purchasing of BLACKCUBE product in Toolplaza store.
In order to ensure the safe transportation of products,
we have been continuously optimizing packaging and striving to provide you
with the best products.
If the product you received is damaged or has quality problems.
Please contact us through Email below and attach product pictures of related
problems, we will reply to you as soon as possible, and provide you with
the best solution.
Email: [email protected]
Looking forward to your next purchase and wish you a happy life!
Best wishes
Toolplaza

Do not discard electrical appliances with household waste.
CONGRATULATIONS ON YOUR PURCHASE OF OUR PRODUCT. This instruction manual is intended
primarily to familiarise the operator with safety, installation, operation, maintenance, product storage and
troubleshooting and it provides important information. So keep it well so that other users can information in the future
too. Due to the constant development and adaptation to the latest demanding EU standards, technical and optical changes
can be made to the products without prior notice. Photos and drawings in this instruction manual may only be illustrative.
Therefore, no legal claims related to this instruction manual, in particular any slight minor deviations from the information
contained therein, can be applied if the product continues to meet all of the above mentioned standards and
declarations, and works as described. In case of confusion, contact the importer or retailer.
Before the first operation, please read the owner’s manual carefully!
The battery contains toxic substances.
Please dispose of batteries at your local battery disposal depot.
IPX1
T3,15A
Do not store or use the battery in
locations where the temperature may reach or exceed 50°C!
Do not throw the battery into fire.
Do not throw the battery into water.
Do not throw the battery into household waste.

5
14
13

Features
Gear selector
Bit holder (magn c)
Rot onal dire on switch/lock
ON/OFF switch/speed control
B ery charge level b on
B ery display LED
B ery pack
Release b n for b ery pack
LED work light
Chuck
Torque sel on ring
High-speed charger
Red charge control LED
Green charge control LED
Technical details
Cordless drill: XW-2001
Rated voltage: 20 V (DC)
Rated idle speed:
1st gear: n 00–400 rpm
2nd gear: n 0 0–1400 rpm
Chuck clamping
range : max. Ø 10 mm
Max. drill diameter:
Steel: 13 mm
Wood: 30 mm
Bery: XW-200102C
Type: LITHIUM ION
Rated voltage: 20 V (DC)
Capacity: 2.0 Ah

Cells 5
High-speed ba ery charger: XZ2150-2400KT
INPUT:
Rated voltage: 120V~ , 50 Hz(AC)
Rated power consump
ti
ti
ti
tion: 65 W
OUTPUT:
Rated voltage: 21.5 V (DC)
Rated current: 2.4 A
Charging me: approx. 60 min.
Protec on class: II / (double insula on)
Noise emission value:
Noise measurement value determined in accordance with EN ISO 4817 The A-rated noise level of
the power tool is typically as follows:
Sound pressure level: L pA = 71 dB(A) Uncertainty K: K pA = 5 dB
Sound power level: L WA = 82 dB(A) Uncertainty K: K WA = 5 dB
Vibr on emission value:
Total vibr on values (vector total of three dir ons) determined in accordance with EN 62841:
Drilling in metal: Vibr on emission value
a h,D : 1.3m/s 2 Uncertainty K = 1.5 m/s2
NOTE
The vibr on level speci ed in these instru ons has been measured in accordance with the
standardised measuring procedure speci d and can be used to make equipment comparisons.
The speci vibr on emission value can also be used to make an in al exposure e mate.
WARNING!
The vibr on level varies in accordance with the use of the power tool and may be higher than
the value speci in these instruc ons in some cases. Regular use of the electric tool in such a
way may cause the user to undere mate the vibr on. Try to keep the vib
r on loads as low as
possible. Measures to reduce the vibr on load are, e.g. wearing gloves and lim ng the working
e. Wherein all states of oper on must be included (e.g. es when the power tool is
switched o and times where the power tool is switched on but running without load).
WARNING! Read all safety warnings designated by the symbol and
all instru ons.
General Power Tool Safety Warnings

WARNING! Read all safety warnings, instrucons, illustraons and
specicaons provided with this power tool. Failure to follow all instrucons listed below
may result in electric shock, re and/or serious injury.
Save all warnings and instrucons for future reference.
The term "power tool" in the warnings refers to your mains-operated (corded) power tool or
baery-operated (cordless) power tool.
1) Work area safety
a) Keep work area clean and well lit. Cluered or dark areas invite accidents.
b) Do not operate power tools in explosive atmospheres, such as in the presence of
ammable liquids, gases or dust. Power tools create sparks which may ignite the dust or
fumes.
c) Keep children and bystanders away while operang a power tool. Distracons can
cause you to lose control.
2) Electrical safety
a) Power tool plugs must match the outlet. Never modify the plug in any way. Do
not use any adapter plugs with earthed (grounded) power tools. Unmodi plugs
and matching outlets will reduce risk of electric shock.
b) Avoid body contact with earthed or grounded surfaces, such as pipes, radiators,
ranges and refrigerators. There is an increased risk of electric shock if your body is earthed or
grounded.
c) Do not expose power tools to rain or wet condions. Water entering a power tool
will increase the risk of electric shock.
d) Do not abuse the cord. Never use the cord for carrying, pulling or unplugging the
power tool. Keep cord away from heat, oil, sharp edges or moving parts. Damaged or entangled
cords increase the risk of electric shock.
e) When operang a power tool outdoors, use an extension cord suitable for
outdoor use. Use of a cord suitable for outdoor use reduces the risk of electric shock.
f) If operang a power tool in adamp locaon is unavoidable, use a residual current
device (RCD) protected supply. Use of an RCD reduces the risk of electric shock.
NOTE The term “residual current device (RCD)”can be replaced by the term “ground fault
circuit interrupter (GFCI)”or “earth leakage circuit breaker (ELCB)”.
3) Personal safety
a) Stay alert, watch what you are doing and use common sense when operang a
power tool. Do not use a power tool while you are red or under the inuence of
drugs, alcohol or medicaon. A moment of inaenon while operang power tools may
result in serious personal injury.
b) Use personal protecve equipment. Always wear eye protecon. Protecve
equipment such as a dust mask, non-skid safety shoes, hard hat or hearing protecon used for
appropriate condions will reduce personal injuries.
c) Prevent unintenonal starng. Ensure the switch is in the o-posion before
connecng to power source and/or baery pack, picking up or carrying the tool.
Carrying power tools with your nger on the switch or energising power tools that have the
switch on invites accidents.

d) Remove any adjusng key or wrench before turning the power tool on. A wrench
or a key leaached to a rotang part of the power tool may result in personal injury.
e) Do not overreach. Keep proper foong and balance at all mes. This enables beer
control of the power tool in unexpected situaons.
f) Dress properly. Do not wear loose clothing or jewellery. Keep your hair and
clothing away from moving parts. Loose clothes, jewellery or long hair can be caught in
moving parts.
g) If devices are provided for the connecon of dust extracon and collecon
facilies, ensure these are connected and properly used. Use of dust collecon can
reduce dust-related hazards.
h) Do not let familiarity gained from frequent use of tools allow you to become
complacent and ignore tool safety principles. A careless acon can cause severe injury
within a fracon of a second.
4) Power tool use and care
a) Do not force the power tool. Use the correct power tool for your applicaon. The
correct power tool will do the job beer and safer at the rate for which it was designed.
b) Do not use the power tool if the switch does not turn it on and o. Any power tool
that cannot be controlled with the switch is dangerous and must be repaired.
c) Disconnect the plug from the power source and/or remove the baery pack, if
detachable, from the power tool before making any adjustments, changing
accessories, or storing power tools. Such prevenve safety measures reduce the risk of
starng the power tool accidentally.
d) Store idle power tools out of the reach of children and do not allow persons
unfamiliar with the power tool or these instrucons to operate the power tool.
Power tools are dangerous in the hands of untrained users.
e) Maintain power tools and accessories. Check for misalignment or binding of
moving parts, breakage of parts and any other condion that may aect the power
tool’s operaon. If damaged, have the power tool repaired before use. Many
accidents are caused by poorly maintained power tools.
f) Keep cung tools sharp and clean. Properly maintained cung tools with sharp cung
edges are less likely to bind and are easier to control.
g) Use the power tool, accessories and tool bits etc. in accordance with these
instrucons, taking into account the working condions and the work to be
performed. Use of the power tool for operaons dierent from those intended could result in a
hazardous situaon.
h) Keep handles and grasping surfaces dry, clean and free from oil and grease.
Slippery handles and grasping surfaces do not allow for safe handling and control of the tool in
unexpected situaons.
5.Baery tool use and care
a) Recharge only with the charger specied by the manufacturer. A charger that is
suitable for one type of baery pack may create a risk of re when used with another baery
pack.
b) Use power tools only with specically designated baery packs. Use of any other
baery packs may create a risk of injury and re.

c) When baery pack is not in use, keep it away from other metal objects, like
paper clips, coins, keys, nails, screws or other small metal objects, that can make a
connecon from one terminal to another. Shorng the baery terminals together may
cause burns or a re.
d) Under abusive condions, liquid may be ejected from the baery; avoid contact.
If contact accidentally occurs, ush with water. If liquid contacts eyes, addionally
seek medical help. Liquid ejected from the baery may cause irritaon or burns.
e) Do not use a baery pack or tool that is damaged or modied. Damaged or
modi baeries may exhibit unpredictable behaviour resulng in re, explosion or risk of
injury.
f) Do not expose a baery pack or tool to e or excessive temperature. Exposure to
re or temperature above 130 °C may cause explosion.
NOTE The temperature „130 °C”can be replaced by the temperature „265 °F”.
g) Follow all charging instrucons and do not charge the baery pack or tool
outside the temperature range specied in the instrucons. Charging improperly or at
temperatures outside the speci range may damage the baery and increase the risk of re.
6.Service
a) Have your power tool serviced by a qualied repair person using only idencal
replacement parts. This will ensure that the safety of the power tool is maintained.
b) Never service damaged baery packs. Service of baery packs should only be
performed by the manufacturer or authorized service providers.
Drill Safety Warnings
1) Safety instrucons for all operaons
a) Wear earprotectors when impact drilling. Exposure to noise can cause hearing loss.
b) Hold the power tool by insulated gripping surfaces, when performing an
operaon where the cung accessory or fasteners may contact hidden wiring or its
own cord. Cung accessory contacng a “live” wire may make exposed metal parts of the
power tools “live” and could give the operator an electric shock.
2) Safety instrucons when using long drill bits
a) Never operate at higher speed than the maximum speed rang of the drill bit. At
higher speeds, the bit is likely to bend if allowed to rotate freely without contacng the
workpiece, resulng in personal injury.
b) Always start drilling at low speed and with the bit p in contact with the
workpiece. At higher speeds, the bit is likely to bend if allowed to rotate freely without
contacng the workpiece, resulng in personal injury.
c) Apply pressure only in direct line with the bit and do not apply excessive
pressure. Bits can bend causing breakage or loss of control, resulng in personal injury.
For baery tools:
1) Instrucons regarding baery charging, informaon regarding ambient temperature range for
tool and baery use and storage, and the recommended ambient temperature range for the

charging system during charging;
2) For a baery-operated tool intended for use with a detachable baery pack or a
separable baery pack: instrucons indicang the appropriate baery packs for use, such as
by a catalog number, series idencaon or the equivalent;
3) Instrucons indicang the appropriate charger for use, such as by a catalog number, series
idencaon or the equivalent.
4)For baery tools with integral baery: instrucon, how the integral baery can be removed
safely from the tool aer the tool’s end of life, and informaon about the type of baery such as
Li-Ion, NiCd and NiMH.
WARNING!
■Hold the power tool by the insulated gripping surfaces when performing an operaon where
the screw or aached tool could come into contact with hidden wiring. Contact between the
screw or aached tool and a live wire may cause exposed metal parts of the power tool to
become live and give the operator an electric shock.
Safety guidelines for baery chargers
■This appliance may be used by children aged 8 years and above and by persons with limited
physical, sensory or mental capabilis or lack of experience and knowledge, provided that they
are under supervision or have been told how to use the appliance safely and are aware of the
potenal risks. Children must not play with the appliance. Cleaning and user maintenance tasks
may not be carried out by children unless they are supervised.
The charger is suitable for indoor use only.
WARNING!
■To avoid potenal risks, damaged mains cables should be replaced by the manufacturer or
the manufacturer’s customer service department or a similarly qualied person.
Before use
Charging the baery pack (see g. A)
CAUTION!
Always pull out the plug before you remove the baery pack from or connect the baery
pack to the charger.
■Never charge the baery packwhen the ambient temperature is below 10°C or above
40°C.
Connect the baery pack to the rapid baery charger (see Fig. A).
Insert the power plug into the socket. The control LED lights up red to indicate that the
appliance is charging.

The green control LED indicates that the charging process is complete and the baery
pack is ready.
Insert the baery pack back into the appliance (see Fig. B).
Aaching/disconnecng the baery pack to/from the appliance
Inserng the baery pack:
Push the rotaon direcon switch into the middle posion (lock) (see Fig. C). Allow the
baery pack to click into the handle (see Fig. B).
Removing the baery pack:
Press the release bun and remove the baery pack (see Fig. D).
Checking the baery charge level
Press the baery charge level bun to check the charge level of the baery (see Fig. E).
The status/remaining charge will be shown on the baery display LED as follows:
GREEN/RED/ORANGE = maximum charge/performance
RED/ORANGE = medium charge/performance
RED = low charge –charge the baery
Changing tools
Your cordless drill has a fully automac spindle lock .
When the motor is stopped, the power train locks so that the chuck can be opened by turning
it . Aer you have aached the desired tool and ghtened it by turning the chuck , you
can connue working (see Fig. F). The spindle lock is automacally released when the motor
starts (ON/OFF switch pressed).
Torque selecon ring/drill seng
You can set the torque using the torque selecon ring (see Fig. G).
Select a low level for small screws or somaterials.
Select a high level for large screws, hard materials or removing screws.
Select the drill seng for drilling work by adjusng the torque selecon ring to the
posion (see Fig. H).
2 speed gearbox
CAUTION!
Only operate the gear selecon switch when the appliance is at a standsll. Otherwise the
appliance can be damaged.
In rst gear (gear selector switch in posion: 1) (see Fig. I)
you can reach a speed of approx. 400 rpm and a high torque. This seng is suitable for all
screwing jobs.
In second gear (gear selector switch in posion: 2) (see Fig. J)
you can reach a speed of approx. 1400 rpm for carrying out drilling work.
Operaon
Switching on and o
Switching on:
To start the appliance, press the ON/OFF switch and keep it pressed in (see Fig. K).
The LED work light lights up when the ON/OFF switch is depressed lightly or fully. This

allows for illuminaon of the work area in low lighting.
Switching o:
Release the appliance's ON/OFF switch to switch othe appliance.
Adjusng the rotaonal speed
The ON/OFF switch has a variable speed control. Pressing the ON/OFF switch lightly yields
a low speed. Increasing pressure increases the speed (see Fig. K).
NOTE
The integrated motor brake ensures rapid stoppage.
Changing the direcon of rotaon
Change the direcon of rotaon by pressing the rotaonal direcon switch towards the
leor right (see Fig. L).
Tips and tricks
Tip! This symbol indicates proper behaviour!
Before operaon, check whether the screw or drill bit is correctly posioned, i.e. centred in
the
drill chuck.
Screw bits are labelled according to their dimensions and their shape. If you are uncertain,
always check whether the bit ts ghtly in the screw head without any free play.
Torque:
Smaller screws/bits can be damaged if you set the torque or rotaonal speed too high.
Hard screw joints (in metal):
Parcularly high torques occur, for example, in metal screw joints made using drive sockets.
Select a low rotaonal speed.
Soscrew joints (e.g. in sowood):
Again, use a low rotaonal speed, to avoid e.g. damaging the surface of the wood upon
contact with the screw head. Use a countersink.
When drilling in wood, metal and other materials, observe the following:
Use a high speed for drill bits with small diameter and a low speed for drill bits with large
diameter.
Select a low speed for hard materials and a high speed for somaterials.
Secure or fasten the workpiece in a clamp or vice (if possible).
Mark the spot where you want to drill using a centre punch or nail. Select a low rotaonal
speed when starng.
Pull the rotang drill bit from the hole repeatedly to remove dust and chips and clear the
hole.
Drilling in metal:
Use a metal drill (HSS). For opmum results, cool the drill bit with cung oil. Metal drill bits
can also be used to drill into plascs. Start with a 3 mm diameter drill bit and then increase the
size unl the desired hole diameter is achieved.
Drilling in wood:
Use a wood drill with a lathe centre; for deep holes, use an auger bit; for large-diameter
holes, use a Forstner bit. Small screws can be screwed directly into sowood.

Maintenance and cleaning
WARNING! RISK OF INJURY! Always switch the appliance oand remove
the baery before carrying out any work on the appliance.
The cordless drill is maintenance-free.
■The appliance must always be kept clean, dry and free from oil or grease.
■Never allow liquids to get into the appliance.
■Use a so, dry cloth to clean the housing. Never use petrol, solvents or cleansers which can
damage plasc.
■If a lithium-ion baery is to be stored for an extended period, the charge level should be
checked regularly. The opmum charge level is between 50% and 80%. The opmum storage
environment is cool and dry.
NOTE
Replacement parts not listed (such as baeries, switches) can be ordered via our service
hotline.
