Blade FPV Nano QX User manual

RTF
READY-TO-FLY
®

2
EN
WARNING: Read the ENTIRE instruction manual to become familiar with the features of the product before
operating. Failure to operate the product correctly can result in damage to the product, personal property and
cause serious injury.
This is a sophisticated hobby product. It must be operated with caution and common sense and requires some basic
mechanical ability. Failure to operate this Product in a safe and responsible manner could result in injury or damage
to the product or other property. This product is not intended for use by children without direct adult supervision. Do
not use with incompatible components or alter this product in any way outside of the instructions provided by Horizon
Hobby, LLC. This manual contains instructions for safety, operation and maintenance. It is essential to read and follow
all the instructions and warnings in the manual, prior to assembly, setup or use, in order to operate correctly and avoid
damage or serious injury.
The following terms are used throughout the product literature to indicate various levels of potential harm when
operating this product:
NOTICE: Procedures, which if not properly followed, create a possibility of physical property damage AND a little or no
possibility of injury.
CAUTION: Procedures, which if not properly followed, create the probability of physical property damage AND a
possibility of serious injury.
WARNING: Procedures, which if not properly followed, create the probability of property damage, collateral damage,
and serious injury OR create a high probability of superficial injury.
NOTICE
All instructions, warranties and other collateral documents are subject to change at the sole discretion of Horizon
Hobby, LLC. For up-to-date product literature, visit horizonhobby.com and click on the support tab for this product.
Meaning of Special Language
Age Recommendation: Not for children under 14 years. This is not a toy.

3EN
• Always keep a safe distance in all directions around
your model to avoid collisions or injury. This model is
controlled by a radio signal subject to interference from
many sources outside your control. Interference can
cause momentary loss of control.
• Always operate your model in open spaces away from
full-size vehicles, traffic and people.
• Always carefully follow the directions and warnings for
this and any optional support equipment
(chargers, rechargeable battery packs, etc.).
• Always keep all chemicals, small parts and anything
electrical out of the reach of children.
• Always avoid water exposure to all equipment not
specifically designed and protected for this purpose.
Moisture causes damage to electronics.
• Never place any portion of the model in your mouth as it
could cause serious injury or even death.
• Never operate your model with low transmitter
batteries.
• Always keep aircraft in sight and under control.
• Always move the throttle fully down at rotor strike.
• Always use fully charged batteries.
• Always keep transmitter powered on while aircraft is
powered.
• Always remove batteries before disassembly.
• Always keep moving parts clean.
• Always keep parts dry.
• Always let parts cool after use before touching.
• Always remove batteries after use.
• Never operate aircraft with damaged wiring.
• Never touch moving parts.
Safety Precautions and Warnings

4
EN
Li-Po BATTERY PACK
7.4V 760mAh
Box Contents
• Blade®FPV nano QX
• 150mAh 1S 3.7V 45C Li-Po Battery
• 1S USB Li-Po Charger, 350 mAh
• MLP4DSM
• 4 AA Batteries
FPV System:
• Fat Shark Teleporter QVGA Headset
• 720p 30fps 15Mbps Camera
• 5.8GHz Video Transmitter and Receiver
• 760mAh 2S 7.4V Li-Po Battery
• 2S Li-Po DC Charger with AC Power Supply

5EN
Table of Contents
First Flight Preparation..................................................... 6
Flying Checklist ............................................................... 6
Charging Warnings........................................................... 6
Low Voltage Cutoff (LVC) .................................................. 7
Installing the Transmitter Batteries (RTF).......................... 7
Flight Battery Charging .................................................... 7
Installing the Flight Battery .............................................. 8
Transmitter and Receiver Binding..................................... 9
Transmitter Control ........................................................ 10
Flight Mode and Rate Selection (RTF)............................. 11
Flight Mode Selection (BNF)........................................... 11
Transmitter Setup Table ................................................. 12
LED Codes..................................................................... 12
Understanding the Primary Flight Controls ..................... 13
4-in-1 Control Unit Function........................................... 14
Headset Battery Charging ............................................. 15
Setting Up the Headset .................................................. 15
Display Adjustment ....................................................... 16
Digital Head Tracking .................................................... 16
Using the Ultra Micro FPV System ................................. 16
Flying the nano QX......................................................... 17
Post-Flight Inspection and Maintenance Checklist.......... 18
Caring for the Video Transmitter Antenna ....................... 19
FPV Troubleshooting ...................................................... 19
SAFE Technology ........................................................... 19
Exploded View ............................................................... 20
Parts Listings................................................................. 21
Optional Parts................................................................ 21
Troubleshooting Guide ................................................... 22
Limited Warranty ........................................................... 24
Warranty and Service Contact Information ..................... 25
FCC Information............................................................. 26
Compliance Information for the European Union............. 27
Length 5.51 in (140mm)
Height 1.18 in (30mm)
Propeller Diameter 1.97 in (50mm)
Flying Weight .63 oz (18 g)
Specifications
Components RTF BNF
Airframe Blade FPV nano QX Included Included
Motors 6mm Brushed Installed Installed
On-board Electronics 4-in-1 mixer/ESCs/Gyro Installed Installed
Battery 150mAh 1S 3.7V 45C Li-Po Included Included
Charger 1S USB Li-Po Charger, 350 mAh Included Included
Transmitter MLP4DSM Included Required
FPV System
Fat Shark Teleporter QVGA Headset Included Required
720p 30fps 15Mbps Camera Included Included
5.8GHz Video Transmitter and Receiver Included Included
760mAh 2S 7.4V Li-Po Battery Included Required
2S Li-Po DC Charger with AC Power Supply Included Required
To register your product online,visit www.bladehelis.com

6
EN
First Flight Preparation
• Remove and inspect contents
• Begin charging the flight battery
• Install the flight battery in the quadcopter
(once it has been fully charged)
• Program your computer transmitter
• Bind your transmitter
• Familiarize yourself with the controls
• Find a suitable area for flying
Flying Checklist
❏Always turn the transmitter on first
❏Plug the flight battery into the lead from the
4-in-1 control unit
❏Allow the 4-in-1 control unit to initialize and
arm properly
❏Fly the model
❏Land the model
❏Unplug the flight battery from the 4-in-1
control unit
❏Always turn the transmitter off last
The battery chargers (EFLC1008 and FSV1802) included
with your quadcopter have been designed to safely charge
the Li-Po batteries.
CAUTION: All instructions and warnings must be
followed exactly. Mishandling of Li-Po batter-
ies can result in a fire, personal injury and/or property
damage.
• By handling, charging or using the included Li-Po
battery, you assume all risks associated with lithium
batteries.
• If at any time the battery begins to balloon or swell,
discontinue use immediately. If charging or discharging,
discontinue and disconnect. Continuing to use, charge
or discharge a battery that is ballooning or swelling can
result in fire.
• Always store the battery at room temperature in a dry
area for best results.
• Always transport or temporarily store the battery in a
temperature range of 40–120º F (5–49° C). Do not store
battery or model in a car or direct sunlight. If stored in a
hot car, the battery can be damaged or even catch fire.
• Always charge batteries away from flammable
materials.
• Always inspect the battery before charging.
• Always disconnect the battery after charging, and
let the charger cool between charges.
• Always constantly monitor the temperature of the
battery pack while charging.
• ONLY USE A CHARGER SPECIFICALLY DESIGNED TO
CHARGE LI-PO BATTERIES. Failure to charge the battery
with a compatible charger may cause a fire resulting in
personal injury and/or property damage.
• Never discharge Li-Po cells to below 3V under load.
• Never cover warning labels with hook and loop strips.
• Never leave charging batteries unattended.
• Never charge batteries outside recommended levels.
• Never charge damaged batteries.
• Never attempt to dismantle or alter the charger.
• Never allow minors to charge battery packs.
• Never charge batteries in extremely hot or cold places
(recommended between 40–120° F (5–49° C) or place in
direct sunlight.
Charging Warnings

7EN
Low Voltage Cuto (LVC)
When a Li-Po battery is discharged below 3V, the battery may become damaged and may no longer accept a charge.
The nano QX 4-in-1 control unit protects the flight battery from over-discharge using Low Voltage Cutoff (LVC). Before the
battery charge decreases too much, LVC becomes active. Power to the motors decrease and the LED on the 4-in-1 control
unit blinks, showing some battery power is reserved for flight control and safe landing.
When the motor power decreases, please land the aircraft immediately and recharge the flight battery.
Disconnect and remove the Li-Po battery from the aircraft after use to prevent trickle discharge. During storage, make
sure the battery charge does not fall below 3V.
NOTICE: Repeated flying to LVC will damage the battery.
Installing the Transmitter Batteries (RTF)
Install 4 AA batteries into the transmitter, noting polarity. Replace the
transmitter batteries when the power LED flashes and the transmitter
beeps.
Flight Battery Charging
Your aircraft comes with a 1S 3.7V DC Li-Po battery
charger and 1S 3.7V 150mAh 45C Li-Po battery.
Refer to the charging warnings. It is recommended
to charge the battery pack while you are inspecting
the aircraft. The flight battery will be required to
confirm proper aircraft operation in future steps.
NOTICE: Charge only batteries that are cool to the touch and are not damaged. Look at the battery to make sure it is not
damaged e.g., swollen, bent, broken or punctured.
1. Insert the charger into a USB port. The charger only uses power from the USB port, it will not connect to your computer.
USB power supplies, such as those used to charge cellular phones, can also be used.
2. Slide the battery into the slot on the charger and press it into the charge jack/connector located at the bottom of the slot.
The end cap of the battery is specifically designed to allow the battery to fit into the slot one way (usually with the label
on the battery facing outward) to prevent reverse polarity connection, however, check for proper alignment and polarity.
USB Li-Po
Charger
EFLC1008
SOLID RED LED
–Charging
DC Input:5.0V 350mA
DC Output:4.2V 300mA
LED OFF
–Charge
Complete

8
EN
1. Lower the throttle and throttle trim to the lowest settings.
2. Power on the transmitter.
3. Install the battery by sliding it into the battery mounting slot below the 4-in-1 control unit. Slide the battery into the
slots with the label facing downward so that the battery key, molded into the battery end-cap, comes in contact with
the key on the battery slot.
4. Connect the battery cable to the 4-in-1 control unit, matching the red mark on the battery to the red mark on the
connector.
5. Place the nano QX on its skids on a flat surface and leave the aircraft still until the LED on the 4-in-1 control unit is
solid blue (not blinking).
CAUTION: Always disconnect the Li-Po battery from the aircraft when not flying to avoid over-discharging the
battery. Batteries discharged to a voltage lower than the lowest approved voltage may become damaged,
resulting in loss of performance and potential fire when batteries are charged.
Installing the Flight Battery
th b tt i t
th
12 3
4
3. Always disconnect the flight battery from the charger immediately upon completion of charging.
CAUTION: Only use chargers specifically designed to charge the included Li-Po battery. Failure to do so could
result in fire, causing injury or property damage.
CAUTION: Never exceed the recommended charge rate.
LED Indications
When you make the connection successfully, the LED on the charger turns solid red, indicating charging has begun. Charging
a fully discharged (not over-discharged) 150mAh battery takes approximately 30–40 minutes. The light goes out when the
charge is complete.
Solid Red: Charging
OFF: Max Charge
CAUTION: Once charging is complete, immediately remove the battery. Never leave a battery connected to the charger.

9EN
Transmitter and Receiver Binding
General Binding Procedure
1. Disconnect the flight battery from the quadcopter.
2. Refer to the Transmitter Setup Table to correctly setup your transmitter.
3. Center all trims on your transmitter.
4. Power off the transmitter and move all switches to the 0 position. Move the throttle to the low/off position.
5. Connect the flight battery in the quadcopter. The blue LED on the 4-in-1 control unit flashes after 5 seconds.
6. Put the transmitter into bind mode while powering on the transmitter.
7. Release the bind button/switch after 2–3 seconds. The quadcopter is bound when the blue LED on the
4-in-1 control unit turns solid.
8. Disconnect the flight battery and power the transmitter off.
CAUTION: When using a Futaba®transmitter with a Spektrum™ DSM2®/DSMX®module, you must reverse
the throttle channel and rebind. Refer to your Spektrum module manual for binding and failsafe instructions.
Refer to your Futaba transmitter manual for instructions on reversing the throttle channel.
MLP4DSM Binding Procedure
1. Disconnect the flight battery from the quadcopter.
2. Center all trims on your transmitter.
3. Power off the transmitter and move the throttle stick to the down/off position.
4. Connect the flight battery in the quadcopter. The LED on the 4-in-1 control unit flashes red during initialization, then flashes
blue when it is ready to bind.
5. When the blue light is flashing, push in and hold down the left stick while powering on the transmitter (you will hear a ‘click’).
6. Release the left stick. The transmitter will beep and the power LED will blink.
7. The quadcopter is bound when the LED on the 4-in-1 control unit is solid blue (not blinking).
8. Disconnect the flight battery and power the transmitter off.
If you encounter problems, obey binding instructions and refer to the troubleshooting guide for other instructions. If needed, con-
tact the appropriate Horizon Product Support office. For a list of compatible DSM®transmitters, please visit www.bindnfly.com.
To bind or re-bind your FPV nano QX to your chosen transmitter, please follow the directions below.
Your RTF transmitter comes prebound to the model. If you need to re-bind, follow the directions below.

10
EN
RTF Transmitter Control
F
G
H
E
A
D
C
B
Dual rate
selection
HA B CDEFG H
Mode 1 Power LED/
flight mode
indicator
Aileron (Left/Right)
Throttle (Up/Down)
Throttle
Trim
Aileron
Trim
ON/OFF
Switch
Rudder
Trim
Eleva-
tor Trim
Rudder (Left/Right)
Elevator (Up/Down)
Mode 2 Power LED/
flight mode
indicator
Aileron (Left/Right)
Elevator (Up/
Down)
Eleva-
tor Trim
Aileron
Trim
ON/OFF
Switch
Rudder
Trim
Throttle
Trim
Rudder (Left/Right)
Throttle (Up/Down)
When pressed down, trim buttons make a sound that increases or decreases in pitch at each pressing. The middle or
neutral trim position is heard as a middle tone in the pitch range of the sounds. The end of the control range is sounded
by a series of beeps.
C
Du
se
G
Bind/
Flight mode
selection

11 EN
RTF
Flight Mode and Rate Selection – RTF
The nano QX RTF model comes with the Blade®MLP4DSM transmit-
ter. This transmitter’s flight mode selection feature lets the pilot
change between stability mode and agility mode.
• When powered on, this transmitter is automatically in
stability mode and high rate.
• Change flight modes by pressing and releasing the left control stick
while the transmitter is powered on. Change rates by pressing and
releasing the right control stick.
• In low-rate mode, the controls cannot reach their maximum values.
This mode is typically preferred by pilots looking for smoother/
easier control response during first time use.
• In high-rate mode, the controls can reach their maximum values. This mode is typically preferred by experienced
pilots who are ready for fast forward flight and aerobatic maneuvers (loops, rolls, etc.).
• Stability mode is shown by the flight control board on the quadcopter glowing solid blue. When flown in stability
mode, the nano QX will limit the bank angle with full control input and return the aircraft to a neutral flight position
when you release the elevator/aileron stick. This mode is typically preferred by pilots during first time use.
• Agility mode is shown by the flight control board on the quadcopter glowing solid red. When flown in agility mode,
the model will not return to a neutral flight position when you release the controls. This mode is typically preferred
by experienced pilots who are ready for fast forward flight and aerobatic maneuvers (loops, rolls, etc.).
Flight Mode Selection – BNF
If you purchased a BNF nano QX, the channel 6 switch on your transmitter will select flight modes. When the flight
control board on the quadcopter is solid blue, the flight mode is set to self-stabilizing mode. When the light is solid red,
the quadcopter is in agility mode. See the table on the following page for specific setup information.

12
EN
LED Codes
Transmitter Setup Table
Equipment LED Color LED Status Operation
Quadcopter
Blue
Rapid Blink Bind Mode
Slow Blink No Link To Transmitter
Solid Stability Mode
Red Blink Low Battery
Solid Agility Mode
RTF Transmitter Red Blink Low Rate
Solid Hi Rate
Transmiter "Model
Type"
Stability to
Agility Switch
Stability to
Agility TX Setup
Dual Rate
Switch
Aux1
Reverse
High Rate Low Rate
MLP4DSM N/A Depress Left Stick N/A Depress Right
Stick N/A N/A N/A
DX4e N/A Trainer/Bind N/A Rate N/A N/A N/A
DX5e N/A Trainer/Bind N/A Rate N/A N/A N/A
DX6i Acro
Cycle Flaps Pos
first time 0-1, each
time after 1-0-1
In FLAPS Menu:
Set NORM FLAP
to Down 20
ELEV-AIL D/R N/A 100% 70%
DX7 Acro
Cycle Flaps Pos
first time 0-2, each
time after 2-0-2
N/A ELEV-AIL D/R N/A 100% 70%
DX7S/8 Acro Trainer/Bind
In Switch Select
Menu: Set Flap to
Inh, Set Trainer to
Aux1
ELEV-AIL D/R Rev 100% 70%
DX6, DX9,
DX18 Acro Trainer/Bind
In Channel Assign
Menu Go to Next:
Set 6 AUX1: to I
ELEV-AIL D/R Rev 100% 70%
Using 30% exponential on aileron and elevator is recommended.

13 EN
Elevator
ForwardElevator down Elevator up Backward
Rudder
Rudder left Rudder right
Understanding the Primary Flight Controls
Throttle
Throttle down
Throttle up
Left Side View Left Side View
Descend
Climb
Left Side View Left Side View
Nose Yaws RightNose Yaws Left
If you are not familiar with the controls of your nano QX, take a few minutes to familiarize yourself with them before
attempting your first flight.

14
EN
Aileron
Aileron left Left Aileron right Right
Rear ViewRear View
4-in-1 Control Unit Function
The unique Control Unit installed in your nano QX is a lightweight combination of main motor electronic speed controls
(ESCs), mixers, the SAFE™ sensor unit, and a DSM2/DSMX receiver. The 4-in-1 unit is also equipped with blue and red
status indicator LEDs.
• Before each flight, ALWAYS power on the transmitter before connecting the flight battery to the 4-in-1 unit. After each
flight, disconnect the flight battery from the 4-in-1 unit before powering off the transmitter.
Connecting the flight battery before powering on the transmitter can start the binding process. Please see the Transmitter
and Receiver Binding section of this manual for more information.
• The 4-in-1 unit will arm the motors when the throttle stick is in the lowest possible position and the throttle trim is at
the middle or a lower than middle position (the middle position is indicated by a longer than usual beep/tone). If this is
the first test flight, or a test flight following repairs, also center the rudder, aileron and elevator trims.
• With the transmitter turned on and the transmitter LED glowing solid RED, connect the flight battery to the 4-in-1 unit.
• After the flight battery is connected, place the nQX on a level surface. The 4-in-1 unit status LED should glow solid
BLUE within a few seconds.
• DO NOT move, sway or pretend to fly the quadcopter after connecting the flight battery. Movement can stop unit initial-
ization and SAFE calibration. If the quadcopter is moved before the 4-in-1 unit status LED glows solid BLUE, disconnect
then connect the flight battery to the 4-in-1 unit.
• When the 4-in-1 unit status LED glows solid BLUE, the control unit is initialized and ready for flight.
• As long as you set the throttle stick and trim to the correct positions during the initialization process, the ESC or motors
will be armed. Use caution after arming, as the propellers will turn at throttle stick input.

15 EN
LED Indications
Solid Red: Charging
Solid Green: Max Charge
CAUTION: Only use a charger specifically designed
to charge a Li-Po battery. Failure to do so could
result in fire, causing injury or property damage.
CAUTION: Always disconnect the battery from the
charger immediately upon completion of charging.
Low Battery Warning
The headset will beep when the battery voltage is low.
As the headset battery voltage continues to drop, the beep
rate will increase. Recharge the headset battery as soon as possible.
Headset Battery Charging
Li-Po BATTERY PACK
7.4V 760mAh
Setting Up the Headset
CAUTION: Do not power the headset or downlink kit without the antenna attached. Doing so will damage the
transmitter and receiver amplifiers. Amplifier damage is not covered by warranty.
NOTICE: Do not leave the headset exposed to direct sunlight. Sunlight is magnified by the optics and will burn holes in the
LCD color filter (appears as white open areas). This is not covered by warranty.
Keep the headset in its protective case
when not in use.
1. Attach the antenna to the headset.
2. Connect the fully-charged Li-Po battery
pack to the headset.
3. Look through the headset and press
the Channel Up/Down buttons.
Clean channels will have a consistent
static background. Channels with
interference will display horizontal
static lines. Select one of the clean
channels. A long beep sounds on channels 1 and 7.
4. Once you have chosen a clean channel in the headset, select the same channel on the video receiver.
Spektrum Ultra Micro
FPV Transmitter Channels
Channel 1 5470 MHz
Channel 2 5760 MHz
Channel 3 5780 MHz
Channel 4 5800 MHz
Channel 5 5820 MHz
Channel 6 5840 MHz
Channel 7 5860 MHz

16
EN
Display Adjustment
• Press Left or Right on the Display Button to adjust the video contrast in the headset.
• Press Forward or Back on the Display Button to adjust the video brightness in the headset.
• Press Down on the Display Button to change the video zoom in the headset. The normal
display (16:9) shows the entire image with black bars on the top & bottom. The zoom
display (4:3) maximizes the image in the headset and is used with digital head tracking.
Digital Head Tracking
• Long Press: Depressing the Display Button toggles head tracker mode (active/deactivate). With digital head tracking active,
the image will zoom in and the image will digitally pan and tilt in response to head motion.
• Short Press: Resets center reference position (both analog/digital).
Refer to the SPMVR1100 or SPMVS1100 headset manual for more information about head tracker functions.
Using the Ultra Micro FPV System
Consult local laws and ordinances before operating FPV equipment. In some areas, FPV operation may be limited or
prohibited. You are responsible for operating this product in a legal and responsible manner.
1. Power on your radio transmitter, then power on the aircraft.
2. Power on the headset to make sure the channel is clear and then the video transmitter.
3. Perform a range test before flying.
Tip: If you are prone to motion sickness, sit in a chair. If you start to suffer from motion sickness while flying, lower your
chin against your chest.
Fly in open areas, away from people, trees, cars, and buildings. The range of the system can be impacted by any obstruc-
tions blocking your signal. It is normal to see break up in the video going behind trees and other obstacles.
NOTICE: We do not recommend using the ultra micro FPV system in low light.
Display button

17 EN
• After confirming the rotor blades rotate in the correct direction, test the motor response controls.
• Adjust the throttle to a low level of power where the quadcopter begins to get “light” on its landing skids.
• Move the rudder stick a small amount to the right. The nose of the quadcopter should start to rotate
to the right (clockwise).
• Move the rudder stick a small amount to the left. The nose of the quadcopter should start to rotate to the left
(counter-clockwise). If the nose moves to the right, please refer to the Troubleshooting Guide.
• Move the elevator control stick forward. The two REAR landing skids should lift from the floor.
• Move the elevator control stick backward. The two FRONT landing skids should lift from the floor.
• Move the aileron stick right. The two LEFT landing skids should lift from the floor.
• Move the aileron stick left. The two RIGHT landing skids should lift from the floor.
• When rotors turn correctly and respond correctly to controls, your nano QX is ready for its first flight!
First Flight
• Increase the throttle until the model is approximately 2 ft. (600mm) off the ground in a low-level hover and concentrate
on balancing the throttle stick’s position so that the nano QX holds a steady hover altitude. In some cases, you may
need to make a few short “hops” to an altitude of just a few inches until you become familiar with the control inputs
and trim settings required to maintain a steady hover and altitude.
The nano QX requires minor throttle adjustments to maintain its altitude in hover. Remember to keep these throttle
adjustments as minimal as possible. Large adjustments could result in a loss of control and/or a possible crash.
• While attempting to establish a low-level hover, check to see if any trim adjustments are required to help keep the
nano QX from constantly drifting in various directions. If you find that it constantly drifts without any directional control
input, land the model before making any adjustments to the trim settings. Additional details regarding the
location and function of the trim buttons are in the “Understanding the Primary Flight Controls” section of this manual.
– If the nose of the nano QX rotates to the left or right, adjust the rudder trim.
– If the nano QX continually drifts forward or backward, adjust the elevator trim.
– If the nano QX continually drifts to the left or right, adjust the aileron trim.
Continue making minor trim adjustments until the machine hovers at a low altitude with very little drifting and directional
control input. If the nano QX is your first multicopter or helicopter, seek the help of an experienced pilot to trim the model
for you before making your first flight.
• With your nano QX properly trimmed and maintaining a stable low-level hover, practice using the rudder, elevator and
aileron controls to familiarize yourself with the machine’s responses to control inputs. Remember to keep the control
inputs as minimal as possible.
Flying the nano QX

18
EN
TIP: These are all possible with the RTF transmitter. When using a computer transmitter, however, increase the
travel beyond 100% on aileron, elevator or rudder for maximum control authority.
• Forward Flight
• Backward Flight
• Skidding Takeoffs
• Pirouettes
• Spot Landings
• Skidding Landings
• Circuits (Circles)
• Figure 8s
• Flips and Rolls
Once you have gained experience and confidence in hovering the nano QX, you can attempt more advanced
maneuvers including:
• When comfortable with low-level hovering, you can transition to hovering and flying the nano QX at higher altitudes of
three to four feet. At these higher altitudes, you will become comfortable with the flight characteristics of the aircraft.
• Don’t be afraid to set the nano QX down on the ground quickly by lowering the throttle when approaching walls or
other obstacles to help prevent propeller strikes.
Post-Flight Inspection and Maintenance Checklist
√
Cleaning Make sure the battery is not connected before cleaning. Remove dust and debris with a soft brush or
a dry, lint-free cloth.
Motors Replace the motor when the model will not fly steady or veers off when doing a climb out.
Wiring Make sure the wiring does not block moving parts. Replace damaged wiring and loose connectors.
Fasteners
Make sure there are no loose screws, other fasteners or connectors. Do not over-tighten metal
screws in plastic parts. Tighten screws so the parts are mated together, then turn screw only 1/8th
of a turn more.
Propellers Make sure there is no damage to the propellers or other parts that move at high speed. Damage to
these parts includes cracks, burrs, chips or scratches. Replace damaged parts before flying.

19 EN
Caring for the Video Transmitter Antenna
If your video transmitter antenna gets bent or flattened as a
consequence of a hard landing, bend the antenna so the lobes
are at a 45° angle to the bottom plane of the antenna, as shown
at the right.
Problem Possible Cause Solution
No image, display is
completely dark
No power supplied to the video transmitter
or headset
Check the power connections.
Make sure the battery is fully charged
No image, display is
glowing dark gray
Video source switch is set to external receiver
mode
Ensure the video source switch is switched to headset
mode
Static on all channels Video transmitter power is off Make sure the video transmitter LED is on
Horizontal lines in the
headset display Digital interference on the selected channel Choose a cleaner channel
Head tracking is not
moving in correct
direction
Digital head tracking is reversed
Refer to the SPMVR1100 or SPMVS1100 headset
manual for more information on how to reset digital
head tracking
45° 45°
FPV Troubleshooting
Revolutionary SAFE™ (Sensor Assisted Flight Envelope) technology uses an innovative combination of multi-axis sensors
and software that allows model aircraft to know its position relative to the horizon. This spatial awareness is utilized to create
a controlled flight envelope the aircraft uses to maintain a safe region of bank and pitch angles so you can fly more safely.
Far beyond stability, this level of protection offers multiple modes so the pilot can choose to develop his or her skills with a
greater degree of security and flight control that always feels crisp and responsive.
SAFE technology delivers:
• Flight envelope protection you can enable at the flip of a switch.
• Multiple modes let you adapt SAFE technology to your skill level instantly.
Best of all, sophisticated SAFE technology doesn’t require any work to enjoy. Every aircraft with SAFE installed is ready to use
and optimized to offer the best possible flight experience. FlySAFERC.com
Technology
™

20
EN
1
8
24
10 10
11
9
9
12
7
6
3
5
Exploded View
