Blankom BTR-6000 User manual

Transcoder BTR-6000
User Manual

BLANKOM BTR-6000 Transcoder User Manual
Version 1.0 –06-2018 Page - 2 -
Table of Content
Product Outline .....................................................................................................................3
Technical Data:......................................................................................................................3
Statement:.............................................................................................................................4
Application Example..............................................................................................................5
Connecting.............................................................................................................................6
First login and System Menu:................................................................................................6
Network Settings:..................................................................................................................7
Server-Settings: .....................................................................................................................8
IP Input configuration:...........................................................................................................8
Transcoding:........................................................................................................................13
IP Remux- Menu:.................................................................................................................16
IP Backup function:..............................................................................................................20
Example for streaming to VIMEO Live by RTMP by our tiny boxed encoders: ...................23
General notes about Streams: ............................................................................................24
Multicast streams:...............................................................................................................24
Registered port....................................................................................................................26
Range for Ephemeral port...................................................................................................26
Packet structure ..................................................................................................................27
RTP:......................................................................................................................................27
Contact: ...............................................................................................................................29

BLANKOM BTR-6000 Transcoder User Manual
Version 1.0 –06-2018 Page - 3 -
Product Outline
The Transcoder BTR-6000, processes SD/HD efficiently based on the high-performance CPU/GPU designed
specifically for IPTV systems with h.264 AVC and additional HEVC/h.265 low bit rate compression. The TV
Services can be converted to a low bit rate (< 600kbps) while maintaining the image quality. It supports IP
re-multiplexing to MPTS and streaming SPTS. The multiple resolution functions can be used perfectly for
multi- screen serving TVs, Smart phones, tablets, PCs, … . The user friendly network management Web-IF
helps to setup and monitor the working status.
Key Features:
Video compliant with H.265/HEVC Baseline, [email protected] or less
H.264 AVC Baseline, Main&High [email protected] or less
Audio compliant with MPEG-1 Layer II Audio, AAC transcoding, Multi-audio transcoding and pass
through
Resolution from 96*96 to 4096*2160
Bitrate from 200Kbps to 20Mbps
h.265 HEVC capacity: 4K x1/ 1080P x8 / 720P x16 / SD x32 services per chassis
h.264 AVC capacity: HD x16 / SD x32 services per chassis
Support local video transcoding and delivery
Rolling subtitle & Logo insertion
PCR self-correction
PSI/SI edition and PID pass through
Up to 200 MPTS/SPTS output, 100Mbps max for each
1+N output backup system
Web-Interface
Technical Data:
Input
Input Interface
1000M/100M/10M RJ45 x 4pcs Full Duplex
TS/IP Input Bit Rate
800Mbps - RJ45
Data Protocol
UDP, ICMP, IGMP V1, V2, V3, RTP, HTTP, RTSP, FTP, RTMP, HLS (HTTP Live
Streaming)
Transcoder source
IP inputs, Local files (USB 3.0)
IP Protocol
Unicast, Multicast
Video/Audio Format
Video
H.265/HEVC, H.264/AVC, MPEG-2, MPEG-4
Audio
MPEG-1, MPEG-2, MPEG-4, AAC
Re-Multiplex
Input
SPTS / MPTS
Null package
processing
Zero packet PID 8191dec pass through, insertion and filtering
TS Editing
Service editing
PSI/SI editing
PID pass through / remapping

BLANKOM BTR-6000 Transcoder User Manual
Version 1.0 –06-2018 Page - 4 -
Statement:
Text and pictures herein are subject to changes w/o notifications.
The user manual will be updated in real time without special notice.
This user manual is provided only as a reference guide for technicians as examples.
Default Login: Visitor (readonly), admin/admin or root/12345
PCR auto-correction
Maximum bitrate
100Mbps each
Maximum TS count
200 input TS Streams + 200 output TS Streams (with transcoder function disable)
IP Output
Interface
1000M/100M/10M RJ45 x 4pcs Full Duplex
TS/IP Output
Average per port 800Mbps
Protocols
UDP, RTMP, HLS, FTP, RTP (for MUX only)
IP addressing
Unicast, Multicast
Type
IP Streaming or File
Video/Audio Format for Encoding
Video Format
HEVC(h.265)/h.264
Audio Format
MPEG-1 Layer 2, MPEG-2 AAC, MPEG-4 AAC
Package Format
MPEG-TS
Bitrate Control
VBR，CBR
Video resolution
4096*2160, 3840*2160, 2560*1440,1920*1080, 1280*720, 720*576, 720*480,
704*576, 704*288, 640*480, 544*576, 544*480, 480*576, 480*320, 480*270,
360*320, 352*576, 352*288, 320*240, 320*200, 240*160, 192*192, 192*128,
176*144, 128*96, 96*96 …
Video aspect ratio
Auto, 4:3, 16:9
Video frame rate
Auto, 30fps, 29.97fps, 25fps, 24fps, 23.97fps
Video bitrate
200Kbps … 20Mbps
Audio sampling rate
32 KHz, 44.1 KHz, 48 KHz
Audio bit rate
32kbps, 64kbps, 96kbps, 128kbps, 192kbps, 256kbps, 384kbps
Control & Monitoring
Interface
RJ45 x1pcs, 1000M/100M
Protocol
HTTP Web GUI
General
Power Consumption
AC 110V…240V, 6A, 47…63Hz, max. 350W
Operation
temperature
5…45 ºC
Storage temperature
-10…65 ºC
Dimension
430mm x 335mm x 44mm
Gross Weight
8.7Kg

BLANKOM BTR-6000 Transcoder User Manual
Version 1.0 –06-2018 Page - 5 -
Default is: root/12345 or admin/admin
Set the administrator’s computer IP as: 192.168.0.* to avoid IP conflicting with the units own IP
address 192.168.0.103. - Or always shown is the actual IP address of the network management
address ‘Control’ port at the front panel (left) after booting.
192.168.0.*: use an IP setting “*” in the number range 2-254 and except the units default IP.
Remark: .0 is often the network router, .1 often the Gateway of the used router, .255 might be a
network broadcasting address.
Please change these account settings according to your local policy and network. -> Do not forget
to safe and backup the configuration by Web-Interface and its related system-sub-menu.
The encoder can be always set back to factory default settings by using the RESET-swith in Web-IF.
Application Example

BLANKOM BTR-6000 Transcoder User Manual
Version 1.0 –06-2018 Page - 6 -
Connecting
The Transcoder comes with 1x Management RJ45 Interface for Web-access and 3 GbE Ports for the
streaming connection:
The USB ports are equipped for future use.
The rear has only one IEC connector for main voltage 110….230VAC.
First login and System Menu:
After entering username and password (root/12345) you should first enter the System menu:
In the System menu you are getting actual status information about the Transcoder and can safe or
import former stored settings, switch back to factory defaults, reboot and Shutdown. Please do not
disconnect power before using the shutdown button here and wait until it will be ready.
Remark: The language selection Menu in the top right corner depends on regions and might be not
shown while the default language is always english.
Initial we should take care about the Network ports now. Please keep always in mind, to avoid IP
address conflicts with your existing network topology.

BLANKOM BTR-6000 Transcoder User Manual
Version 1.0 –06-2018 Page - 7 -
Network Settings:
Up to 3 x GbE can be connected and selected for IP Inputs and outputs (bi-directional).
Changes can be done by editing the ports:
If DNS addresses are needed, you can add them as well.
Hint: Popup blocker should be disabled in your browser settings.
If you accidently try to move this popup window, you might end up in a not reachable status of this
setup. Please restart a new login again:

BLANKOM BTR-6000 Transcoder User Manual
Version 1.0 –06-2018 Page - 8 -
Selecting Status will popup actual information:
Server-Settings:
In this menu, you can change the http and RTMP ports for streaming to i.e. VIMEO, WOWZA or
catching Http streaming.
IP Input configuration:
Now we start to get some streams in:
Press add- button or insert multiple with the Adds-button:

BLANKOM BTR-6000 Transcoder User Manual
Version 1.0 –06-2018 Page - 9 -
This is an MPTS. Source IP as well as VLAN
ID can be chosen if applicable. Source IP might be to serve the SSM –feature of your streamer
(SSM=Source Specific Multicast).
We add some more SPTS now:

BLANKOM BTR-6000 Transcoder User Manual
Version 1.0 –06-2018 Page - 10 -
Selecting the stream will give you information about the content:
Expanding the view by using the ‘+’:

BLANKOM BTR-6000 Transcoder User Manual
Version 1.0 –06-2018 Page - 11 -
If multiple addresses want to be configured use ADDS:
Get more detailed information of the IP Input stream and even details from the PSI/SI:

BLANKOM BTR-6000 Transcoder User Manual
Version 1.0 –06-2018 Page - 12 -
You’ll get a ‘warning’ if some stream errors occur:
CC errors might come up if the receiver streamer input signal got some input weakness like here
the DVB-S streamer…. Blankom DRD700 SAT-> IP
Streams containing encryption Information will be shown as well:
You can PID filter in a later step…

BLANKOM BTR-6000 Transcoder User Manual
Version 1.0 –06-2018 Page - 13 -
Now that we have some streams coming in we like to transcode them:
Transcoding:
The HDMI/SDI encoding Menu is only for BTR units equipped with either an HDMI Input card or an
SDI Input card (optional). Files adding will be also a future release upgrade.
Different Input methods can be chosen –

BLANKOM BTR-6000 Transcoder User Manual
Version 1.0 –06-2018 Page - 14 -
Set the values according to your needs. Audio, Text Logo Service Informations … and finally the
output stream GbE port (eth1…3) destination and address:
Detailed Information about your transcoded Service can be gathered by selecting the leaf-button:

BLANKOM BTR-6000 Transcoder User Manual
Version 1.0 –06-2018 Page - 15 -
Subtitles can be passed or injected:
LOGO’s ad advertisements or simple Text strings can be added to the transcoded Service as well:
After setting up some encodings, later on they can be changed as well.
ADD by MUX would need an already former configured Remultiplexing Stream by the

BLANKOM BTR-6000 Transcoder User Manual
Version 1.0 –06-2018 Page - 16 -
IP Remux- Menu:
Entering this menu, allows the user to use already incoming streams to be remultiplexed to new
MPTS:
First off all, you need to setup one or more output streams:
Chose DVB-Mode or IPTV. Than save and you can drag and drop services from the left side (Input
streams) to the new mux:
To edit the content just use the PEN:

BLANKOM BTR-6000 Transcoder User Manual
Version 1.0 –06-2018 Page - 17 -
In the PSI/SI submenu you can edit and add i.e. PSI or other NIT table values:

BLANKOM BTR-6000 Transcoder User Manual
Version 1.0 –06-2018 Page - 18 -
As well as inserting descriptors:
and manage i.e. character table corrections:

BLANKOM BTR-6000 Transcoder User Manual
Version 1.0 –06-2018 Page - 19 -
As well as do PID-Remapping:
Or even PID filtering (dropping):
To add zero-packets (PID8191dec) to the output stream, you need to configure DVB-Mode and than
enter a max. Total bitrate in the Mux output Services like:

BLANKOM BTR-6000 Transcoder User Manual
Version 1.0 –06-2018 Page - 20 -
IP Backup function:
Add a stream first or here we are using existing ones just to show how it works…
The Reason of this function is obvious?: If a mayor stream input will fail, the backup address will be
used to process it so the output encoding has still content. Usually as an example: If the HD channel
you are transcoding will be interrupted somehow, you create the backup channel from i.e. an SD
source stream.
A nice feature is the Topology-Overview:
