BlastPro BRB-2800 User manual

BRB-2800
MACHINE MANUAL

BLASTPRO MANUFACTURING, INC. ~ WARRANTY & REGISTRATION CARD
ONE YEAR LIMITED WARRANTY
(1-877-495-6464)
A COPY OF THE WARRANTY CARD ON THE FOLLOWING PAGE, TOGETHER WITH PROOF OF PAYMENT, MUST BE
SUBMITTED WITH ANY SERVICE REQUEST. THIS WARRANTY CARD MUST BE RETURNED TO: BLASTPRO
MANUFACTURING, INC., 6021 MELROSE LANE, OKLAHOMA CITY, OK 73127, WITHIN TEN (10) DAYS OF ACQUIRING
BLASTPRO PRODUCTS IN ORDER TO QUALIFY FOR THE ONE YEAR LIMITED WARRANTY CONTAINED IN THE SALES
AGREEMENT.
BlastPro provides as a limited warranty to Original Purchasers of BlastPro equipment, purchased within and situated within the
United States of America, who notify BlastPro in writing through completion of the BlastPro Equipment Warranty Card within ten
(10) days of acquiring BlastPro Equipment, the following limited warranty.
Subject to the exclusions, limitations and conditions stated above and below, BlastPro will warrant its products against defects in
materials and workmanship, provided the Original Purchaser uses such equipment under normal and proper use, for a period of
one year or 1,000 hours, whichever occurs first, from the date of delivery to the Original Purchaser.
During the applicable limited warranty period and subject to the exclusions, limitations and conditions contained herein, BlastPro
shall, within a reasonable period of time, repair or replace, at its option, any defective components of the equipment. The limited
warranty does not cover wear parts, including but not limited to, tires, magnets, seals, casters, liners, wear plates, bearings, cages,
blast wheels, blades, belts, electrical wiring components and items of a similar nature.
This limited warranty does not cover damage to BlastPro equipment caused by any of the following: the use of the equipment for
purposes other than which the equipment was designed and intended, all external causes such as (without limitation) acts of God,
accidents, dropping, collision, fire, water damage, freezing, striking other objects, misuse or otherwise using the equipment
contrary to the instructions and warnings contained in the User Manual; altering or modifying BlastPro equipment or accessories;
exposure to environmental conditions beyond reasonable limits and the limits stated in the equipment manual; failure to properly
maintain and service the equipment; damage caused by the use of any non-BlastPro parts or attachments on the equipment.
To obtain repair or replacement under this limited warranty, the Original Purchaser must contact BlastPro at 1-877-495-6464. The
Original Purchaser must be prepared to describe any alleged problem, as well as provide proof of purchase and proof of date of
delivery and return of the Equipment Warranty Card. Written authorization from BlastPro must be obtained prior to any BlastPro
equipment being returned to BlastPro.
Once BlastPro provides the Original Purchaser with a written authorization, then the Original Purchaser shall deliver the
equipment as instructed by BlastPro. The Original Purchaser shall pay the cost of shipping and shall also bear any risk of loss
during shipping. Providing the BlastPro equipment is defective and the limited warranty applies, BlastPro shall, within a
reasonable period of time, repair or replace any defective components. The Original Purchaser shall be responsible for picking up
the repaired equipment or may arrange for shipment at Original Purchaser’s expense.
BlastPro’s repair or replacement of any defective parts on the equipment does not extend the term of this limited warranty, which
shall expire on expiration of the period of one year from the date of Original delivery, subject to the further terms of this warranty.
THIS LIMITED WARRANTY IS THE ONLY WARRANTY APPLICABLE TO BLASTPRO EQUIPMENT.
BLASTPRO DISCLAIMS ALL OTHER WARRANTIES, EXPRESS OR IMPLIED, INCLUDING IMPLIED
WARRANTIES OF MERCHANTABLILITY OR FITNESS FOR A PARTICULAR PURPOSE, OTHER
THAN THOSE WARRANTIES IMPLIED AND INCAPABLE OF EXCLUSION, RESTRICTION OR
MODIFICATION UNDER APPLICABLE LAW. ANY SUCH IMPLIED WARRANTIES WHICH MAY BE
REQUIRED BY LAW AND ARE NOT DISCLAIMED HEREBY, ARE LIMITED TO THE EXTENT
ALLOWED BY LAW TO THE APPLICABLE PERIOD OF THIS IMPLIED WARRANTY OR TO THE
APPLICABLE TIME PERIOD PROVIDED BY THE APPLICABLE STATE LAW, WHICHEVER PERIOD
IS SHORTER.
UNDER NO CIRCUMSTANCES SHALL BLASTPRO BE LIABLE TO THE ORIGINAL PURCHASER OR
ANY OTHER PERSON FOR ANY DIRECT, INDIRECT OR CONSEQUENTIAL DAMAGES RESULTING
FROM THE USE OR MISUSE OF THE EQUIPMENT OR ARISING OUT OF ANY BREACH OF ANY
WARRANTY OR FOR ANY SPECIAL OR CONSEQUENTIAL DAMAGES OF ANY CHARACTER,
INCLUDING WITHOUT LIMITATION, DAMAGES FOR ANY LOSS OF GOODWILL, WORK STOPPAGE
OR ANY AND ALL OTHER COMMERCIAL DAMAGES OR LOSSES.
NO CHANGE TO OR ADDITIONAL WARRANTY, NO MATTER BY WHOM MADE OR WHEN MADE,
SHALL APPLY TO ANY EQUIPMENT SOLD BY BLASTPRO.

Keep this top portion for your record
s
Delivery Date Machine Model No.
Delivering Distributors Name Machine Serial No.
and Address Modifications
Operating Manual Received Training Scheduled
(Please Print)
Company
Address
City State Zip
Phone Number
Contact Person
Purchase Date Delivery Date
Machine Model No.
Distributor Name
BlastPro Warranty Registration Card
NOTICE!
USER'S REFERENCE INFORMATION
WARRANTY REGISTRATION CARD
6021 Melrose Lane, Oklahoma City, OK 73127, or Fax to 405-495-1331
(All boxes must be checked or date filled in)
the attached card COMPLETELY and ACCURATELY and return to BlasPro Mfg.
To ensure the proper warranty coverage is extended to the owner of this machine, fill out
IMPORTANT! To ensure that your BlastPro machine is covered under warranty, please
fill in the following information and mail it to BlastPro Manufacturing, Inc.
Training Complete
CUT HERE

4 24 590 35 Rev. DKohlerEngines.com
Pre-Start Checklist
1. Check oil level. Add oil if low. Do not overfill.
2. Check fuel gauge (if equipped). If propane
tank is low, have it refilled. Check fuel system
components and lines for leaks.
3. Check and clean cooling areas, air intake
areas and external surfaces of engine
(particularly after storage).
4. Check that air cleaner components and all
shrouds, equipment covers, and guards are
in place and securely fastened.
5. Check spark arrestor (if equipped).
Starting
WARNING
Carbon Monoxide can cause
severe nausea, fainting or death.
Avoid inhaling exhaust fumes.
Engine exhaust gases contain poisonous
carbon monoxide. Carbon monoxide is
odorless, colorless, and can cause death if
inhaled.
WARNING
Rotating Parts can cause severe
injury.
Stay away while engine is in
operation.
Keep hands, feet, hair, and clothing away
from all moving parts to prevent injury. Never
operate engine with covers, shrouds, or
guards removed.
NOTE: Do not crank engine continuously for
more than 10 seconds. Allow a 60
second cool down period between
starting attempts. Failure to follow
these guidelines can burn out starter
motor.
NOTE: Upon start-up, a metallic ticking may
occur. Run engine for 5 minutes. If
noise continues, run engine at mid
throttle for 20 minutes. If noise persists,
take engine to your local Kohler
authorized dealer.
1. Place throttle control midway between slow
and fast positions.
2. Slowly turn fuel valve on propane tank to full
open position.
3. Turn key switch to START position. Release
switch as soon as engine starts. If starter
does not turn engine over, shut off key switch
immediately. Do not make further attempts to
start engine until condition is corrected. Do
not jump start. See your Kohler authorized
dealer for trouble analysis.
Cold Weather Starting Hints
1. Use proper oil for temperature expected.
2. Disengage all possible external loads.
Stopping
1. If possible, remove load by disengaging all
PTO driven attachments.
2. Turn fuel valve to full closed position and
allow engine to continue running until it runs
out of fuel. Turn key switch to OFF position.
Angle of Operation
Refer to operating instructions of equipment
this engine powers. Do not operate this engine
exceeding maximum angle of operation; see
specification table. Engine damage could result
from insufficient lubrication.
Engine Speed
NOTE: Do not tamper with governor setting to
increase maximum engine speed.
Overspeed is hazardous and will void
warranty.

5
24 590 35 Rev. D KohlerEngines.com
Maintenance Instructions
WARNING Before working on engine or equipment, disable
engine as follows: 1) Disconnect spark plug
lead(s). 2) Disconnect negative (–) battery cable
from battery.
Accidental Starts can cause
severe injury or death.
Disconnect and ground spark
plug lead(s) before servicing.
Normal maintenance, replacement or repair of emission control devices and systems may be
performed by any repair establishment or individual; however, warranty repairs must be performed
by a Kohler authorized dealer found at KohlerEngines.com or 1-800-544-2444 (U.S. and Canada).
For safety and health reasons, many states require special licensing or certification for servicing
propane fuel systems. Check local and state regulations before choosing a repair establishment to
perform fuel system repairs.
Maintenance Schedule
Every 25 Hours1
●Service/replace low-profile precleaner (if equipped).
Every 100 Hours1
●Check oil cooler fins, clean as necessary (if equipped).
●Change oil.
●Replace low-profile air cleaner element (if equipped).
●Remove cooling shrouds and clean cooling areas.
Every 150 Hours1
●Check heavy-duty filter minder.
●Inspect heavy-duty air filter paper element and inlet screen area.
Every 200 Hours1
●Change oil filter.
●Replace unique EFI fuel filters.
Every 300 Hours1
●Replace heavy-duty air cleaner element and check inner element.
Every 500 Hours or Annually1
●Check all lines (high pressure/vacuum) including fittings for leaks.
●Drain vaporizer/regulator of accumulated fuel deposits.
●Replace spark plugs and set gap.
Every 500 Hours or Annually1,2
●Inspect lock-off assembly for damage/leakage.
●Have combustion deposits removed if using non-synthetic oil.
Every 600 Hours or Annually1
●Replace heavy-duty air cleaner inner element.
Every 1500 Hours1,2
●Have vaporizer/regulator tested.
1Perform these procedures more frequently under severe, dusty, dirty conditions.
2Must be performed by a Kohler authorized dealer or qualified propane personnel only.

6 24 590 35 Rev. DKohlerEngines.com
Oil Recommendations
Synthetic oil is recommended for use in
propane fueled engines. Non-synthetic oil must
be low ash* rated oil. Oils (including synthetic)
must meet API (American Petroleum Institute)
service class SG, SH, SJ, or SL. Select
viscosity based on air temperature at time of
operation as shown in table below.
*Low ash is defined as less than 1% sulfated
ash.
°F -20 020324060
50 80 100
°C -30 -20 -10 0 10 20 30 40
5W-30
10W-30
SAE 30
Check Oil Level
NOTE: To prevent extensive engine wear or
damage, never run engine with oil level
below or above operating range
indicator on dipstick.
Ensure engine is cool. Clean oil fill/dipstick
areas of any debris.
1. Remove dipstick; wipe oil off.
a. Press-in cap: reinsert dipstick into tube;
press completely down.
or
b. Thread-on cap: reinsert dipstick into
tube; rest cap on tube, do not thread cap
onto tube.
2. Remove dipstick; check oil level. Level
should be at top of indicator on dipstick.
3. If oil is low on indicator, add oil up to top of
indicator mark.
4. Reinstall and secure dipstick.
Change Oil and Filter
Change oil while engine is warm.
1. Clean area around oil fill cap/dipstick and
drain plug. Remove drain plug and oil fill cap/
dipstick. Allow oil to drain completely.
2. Clean area around oil filter. Place a container
under filter to catch any oil and remove filter.
Wipe off mounting surface. Reinstall drain
plug. Torque to 10 ft. lb. (13.6 N·m).
3. Place new filter in shallow pan with open end
up. Fill with new oil until oil reaches bottom of
threads. Allow 2 minutes for oil to be
absorbed by filter material.
4. Apply a thin film of clean oil to rubber gasket
on new filter.
5. Refer to instructions on oil filter for proper
installation.
6. Fill crankcase with new oil. Level should be
at top of indicator on dipstick.
7. Reinstall oil fill cap/dipstick and tighten
securely.
8. Start engine; check for oil leaks. Stop engine;
correct leaks. Recheck oil level.
9. Dispose of used oil and filter in accordance
with local ordinances.
Oil Sentry™(if equipped)
This switch is designed to prevent engine
from starting in a low oil or no oil condition. Oil
Sentry™may not shut down a running engine
before damage occurs. In some applications
this switch may activate a warning signal. Read
your equipment manuals for more information.

7
24 590 35 Rev. D KohlerEngines.com
Fuel Recommendations
WARNING
Explosive Fuel can cause fires
and severe burns.
If a gaseous odor is detected,
ventilate area and contact an
authorized service technician.
Propane is extremely flammable and is
heavier than air and tends to settle in low
areas where a spark or flame could ignite
gas. Do not start or operate this engine in
a poorly ventilated area where leaking gas
could accumulate and endanger safety of
persons in area.
To ensure personal safety, installation and
repair of propane fuel supply systems must
be performed only by qualified propane
system technicians. Improperly installed and
maintained propane equipment could cause
fuel supply system or other components to
malfunction, causing gas leaks.
Observe federal, state and local laws
governing propane fuel, storage, and
systems.
This engine is certified to operate on
commercial propane (per GPA STD 2140). If
you have any questions, contact your propane
supplier.
Propane from an appropriate propane fuel tank
(supplied separately) is required to operate this
engine.
Vaporizer/Regulator
In compliance with government emission
standards, vaporizer/regulator is preset
at factory to provide proper supply of fuel.
No adjustment or resetting of vaporizer/
regulator is to be made. All service relating to
vaporizer/regulator must be performed by a
Kohler authorized dealer or qualified propane
personnel only.
Vaporizer/regulator can change propane from
supply tank to a gaseous/vapor state.
Lock-Off assembly opens and closes controlling
fuel flow from supply tank before reaching
vaporizer/regulator.
Over time, fuel deposits can accumulate inside
vaporizer/regulator. Removing these deposits
is recommended. Follow steps below to drain
vaporizer/regulators.
1. Turn fuel supply valve off, run engine out of
fuel, and turn off ignition switch.
2. Disconnect and ground spark plug leads.
3. Remove drain plug from bottom of vaporizer/
regulator. Remove any accumulated
deposits.
4. Reinstall plug and tighten securely. If
required, a replacement plug can be found at
KohlerEngines.com.
Fuel Line
High pressure fuel line meeting a minimum of
SAE R7 standard must be installed on Kohler
Co. engines equipped with propane EFI system
(from vaporizer/regulator to injectors).
Spark Plugs
CAUTION
Electrical Shock can cause injury.
Do not touch wires while engine
is running.
Clean out spark plug recess. Remove plug and
replace.
1. Check gap using wire feeler gauge. Adjust
gap, see specification table for adjustment.
2. Install plug into cylinder head.
3. Torque plug to 20 ft. lb. (27 N·m).
Electronic Fuel Injection (EFI) System
EFI is an electronically-controlled fuel
management system which is monitored by an
Electronic Control Unit (ECU). A Malfunction
Indicator Light (MIL) will illuminate if problems
or faults are detected. Servicing by a Kohler
authorized dealer is necessary.
Fuel System Components
Engines are equipped with special EFI fuel
filters. See Maintenance Schedule.
Fuse Replacement
This engine has three (3) blade type automotive
fuses. Replacement fuses must have same
rating as blown fuse. Use fuse chart below to
determine correct fuse.
Wire Color Fuse Rating
2 Solid Red Wires 10-amp Fuse
1 Red Wire with Black Stripe
1 Red Wire with White Stripe 10-amp Fuse
2 Purple Wires 30-amp Fuse

8 24 590 35 Rev. DKohlerEngines.com
Air Cleaner
NOTE: Operating engine with loose or
damaged air cleaner components
could cause premature wear and
failure. Replace all bent or damaged
components.
NOTE: Paper element cannot be blown out
with compressed air.
Low-Profile
Loosen knob and remove air cleaner cover.
Precleaner:
1. Remove precleaner from paper element.
2. Replace or wash precleaner in warm water
with detergent. Rinse and allow to air dry.
3. Saturate precleaner with new engine oil;
squeeze out excess oil.
4. Reinstall precleaner over paper element.
Paper Element:
1. Clean area around element. Remove wing
nut, element cover, and paper element with
precleaner.
2. Separate precleaner from element; service
precleaner and replace paper element.
3. Check condition of rubber seal and replace if
necessary.
4. Install new paper element on base; install
precleaner over paper element; reinstall
element cover and secure with wing nut.
Reinstall air cleaner cover and secure with
knob.
Heavy-Duty
1. Unhook retaining clips and remove end
cap(s).
2. Check and clean inlet screen (if equipped).
3. Pull air cleaner element out of housing and
replace. Check condition of inner element;
replace when dirty.
4. Check all parts for wear, cracks, or damage,
and that ejector area is clean.
5. Install new element(s).
6. Reinstall end cap(s) with dust ejector valve/
screen down; secure with retaining clips.
Breather Tube (if equipped)
Ensure end of breather tube is properly
connected.
Oil Cooler (if equipped)
1. Clean fins with a brush or compressed air.
2. Remove two screws securing oil cooler, and
tilt to clean back side.
3. Reinstall oil cooler.
Air Cooling
WARNING
Hot Parts can cause severe
burns.
Do not touch engine while
operating or just after stopping.
Never operate engine with heat shields or
guards removed.
Proper cooling is essential. To prevent over
heating, clean screens, cooling fins, and other
external surfaces of engine. Avoid spraying
water at wiring harness or any electrical
components. See Maintenance Schedule.
Repairs/Service Parts
We recommend that you use a Kohler
authorized dealer for all maintenance, service,
and engine parts. To find a Kohler authorized
dealer visit KohlerEngines.com or call 1-800-
544-2444 (U.S. and Canada).
Leakage Check/Testing
With fuel valve fully opened, engine not
running, turn key switch ON. Check all fuel
system connections and lines for leaks using
soapy water. Any leakage must be corrected
before restarting engine. Have service
performed by a Kohler authorized dealer or
qualified propane personnel only.
Storage
If engine will be out of service for 2 months or
more follow procedure below.
1. Change oil while engine is still warm from
operation. Remove spark plug(s) and pour
about 1 oz. of engine oil into cylinder(s).
Replace spark plug(s) and crank engine
slowly to distribute oil.
2. Disconnect negative (-) battery cable.
3. Separate propane tank from unit and store
separately in an area designated for safe
propane tank storage.
4. Store engine in a clean, dry place.

9
24 590 35 Rev. D KohlerEngines.com
Troubleshooting
Do not attempt to service or replace major engine components, or any items that require special timing or adjustment procedures. This work should be performed by a Kohler authorized dealer.
Possible Cause
Problem
No Fuel
Tank
Nearly
Empty
Improper
Fuel
Dirt In
Fuel Line
Broken
Fusible Link
Dirty/
Restricted
Vaporizer/
Regulator
Inlet Filter
Dirty
Debris
Screen
Incorrect
Oil Level
Engine
Overloaded
Dirty Air
Cleaner
Faulty
Spark
Plug
Dirty/
Restricted
Vaporizer/
Regulator
Will Not Start ●●●●●●●●●● Hard Starting ●●● ●●●●●●● Stops Suddenly ●●●●●●●● Lacks Power ●●● ● ● ● ● ●● ● Operates Erratically ●● ● ● ● ●● ● Knocks or Pings ●●●●●● Skips or Misfires ●● ● ● ●● ● Backfires ●● ●●● Overheats ●● ● ● ● ● ● ● High Fuel Consumption ●●

10 24 590 35 Rev. DKohlerEngines.com
Engine Specifications
Model Bore Stroke Displacement Oil Capacity
(Refill) Spark Plug
Gap
Maximum Angle
of Operation
(@ full oil level)*
PCH680
3.27 in.
(83 mm)
2.72 in.
(69 mm)
45.6 cu. in.
(747 cc)
1.7-2.0 U.S. qt.
(1.6-1.9 L) 0.03 in.
(0.76 mm) 25°
PCV680
PCH740
PCV740
*Exceeding maximum angle of operation may cause engine damage from insufficient lubrication.
Additional specification information can be found in service manual at KohlerEngines.com.
Exhaust Emission Control System for propane EFI models PCH680, PCH740, and PCV680,
PCV740 is EM, O2S, ECM, MPI for U.S. EPA, California, and Europe.
Any and all horsepower (hp) references by Kohler are Certified Power Ratings and per SAE J1940
& J1995 hp standards. Details on Certified Power Ratings can be found at KohlerEngines.com.

Table of Contents
SECTION 1.1: APPLICATIONS...........................................................................4
SECTION 1.2: SPECIFICATIONS.......................................................................4
SECTION 1.3: MANUFACTURER.......................................................................4
SECTION 2.1: GENERAL....................................................................................6
SECTION 2.2: MAINTENANCE AND WEAR PART REPLACEMENT MODES ..6
SECTION 2.3: WORK SITE ASSESSMENT AND INSPECTION........................7
SECTION 2.4: PERSONAL PROTECTIVE EQUIPMENT (PPE).........................9
SECTION 2.5: OPERATIONAL SAFETY...........................................................10
SECTION 3.1: START-UP.................................................................................12
FIGURE 3.1.1..............................................................................................13
SECTION 3.2: SHUT DOWN.............................................................................13
SECTION 3.3: BLADE SELECTION..................................................................14
FIGURE 3.3.1..............................................................................................14
FIGURE 3.3.2..............................................................................................14
FIGURE 3.3.3..............................................................................................15
SECTION 3.4: TRANSPORT.............................................................................15
SECTION 4.1: MAINTENANCE INTERVALS....................................................17
SECTION 4.2: TROUBLESHOOTING...............................................................18
SECTION 4.3: RECOMMENDED SPARE PARTS............................................19
SECTION 4.4: RECOMMENDED TOOLS.........................................................19
SECTION 4.5: HYDRAULIC SCHEMATIC ........................................................20
SECTION 4.6: ELECTRIC SCHEMATIC...........................................................22
SECTION 4.7: PARTS LIST ..............................................................................23
SECTION 4.8: ENGINE OWNER’S AND SERVICE MANUALS........................24

MACHINE MANUAL BRB-2800
SPECIFICATIONS
© 2010 Blastpro Manufacturing Inc.®
3
SECTION 1.1: APPLICATIONS
SECTION 1.2: SPECIFICATIONS
SECTION 1.3: MANUFACTURER

MACHINE MANUAL BRB-2800
SPECIFICATIONS
© 2010 Blastpro Manufacturing Inc.®
4
SECTION 1.1: APPLICATIONS
The BRB-2800 is specifically designed to remove coatings and coverings from
horizontal surfaces. Coatings may include glue, epoxies and cementitious
overlays. Coverings may include carpet, ceramic tile, VCT and wood flooring.
A wide variety of tools are available from Blastpro® for your specific application.
In general, the BRB-2800 uses sharpened spring steel blades along with the
weight of the machine itself to perform the scraping function. The variable angle
of attack allows for a great deal of flexibility when dealing with different floor
coatings.
SECTION 1.2: SPECIFICATIONS
Dimensions (L x W x H) 74” x 30” x 68” (1880mm x 762mm x 1727.5mm)
Weight 2800 lbs (1270 kg)
Fuel Liquid Propane
Fuel Capacity 33 lb.
Engine 27 HP Kohler
Electrical System 12 VDC
Blade Actuation Hydraulic
Steering Hydraulic
Ground Drive Hydraulic
Blade Widths 2” through 36”
SECTION 1.3: MANUFACTURER
Blastpro Manufacturing
6021 Melrose Lane
Oklahoma City, OK 73127
Toll free: 877-495-6464
Phone: [phone]
Fax: [phone]
Website: www.BlastProMfg.com

MACHINE MANUAL BRB-2800
SAFETY
© 2010 Blastpro Manufacturing Inc.®
5
SECTION 2.1: GENERAL
SECTION 2.2: MAINTENANCE AND WEAR PARTS REPLACEMENT MODES
SECTION 2.3: WORK SITE ASSESSMENT AND INSPECTION
SECTION 2.4: PERSONAL PROTECTIVE EQUIPMENT
SECTION 2.5: OPERATIONAL SAFETY

MACHINE MANUAL BRB-2800
SAFETY
© 2010 Blastpro Manufacturing Inc.®
6
SECTION 2.1: GENERAL
Read and understand this Machine Manual prior to operating or performing
maintenance on the BRB-2800.
This Machine Manual has been developed as a guideline for machine operation.
It is not a substitute for proper organizational training and management.
All machine operators and maintenance personnel should be properly trained in
operation and safety features of the BRB-2800.
Make these operating instructions accessible to all operating and maintenance
personnel.
Never weld, modify, cut or grind components of the BRB-2800 without prior
written consent from the manufacturer.
Never use aggressive cleaning chemicals to clean the machine.
All operators and maintenance personnel should receive training on the dangers
of carbon monoxide, or CO. All personnel should be able to identify signs and
symptoms of CO poisoning. Common signs associated with overexposure
include headache, nausea, weakness, dizziness, lethargy, visual disturbances,
and changes in personality and/or loss of consciousness.
SECTION 2.2: MAINTENANCE AND WEAR PART REPLACEMENT MODES
Maintenance mode is defined as placing the machine in a configuration, which
minimizes potential electric, hydraulic or stored energy hazards.
In general, the machine should be placed in Maintenance Mode prior to
performing any maintenance and/or troubleshooting activities.
MAINTENANCE MODE:
1. Move the machine to a level surface.
2. Reduce machine RPM to low idle.
3. Turn key switch to “OFF” position.
4. Remove key from switch to prevent accidental or unintended starting.
5. Block wheels to prevent the machine from moving.
6. Turn the LP bottle valve to “CLOSED” position.
7. Allow engine and exhaust tube to cool down prior to carrying out any
maintenance work.

MACHINE MANUAL BRB-2800
SAFETY
© 2010 Blastpro Manufacturing Inc.®
7
In general, the machine should be placed in Wear Parts Replacement Mode prior
to changing the blade(s).
WEAR PARTS REPLACEMENT MODE:
1. Move the machine to a level surface.
2. Raise the blade holder so the blade is off of the ground.
3. Reduce machine RPM to low idle.
4. Turn key switch to “OFF” position.
5. Remove key from switch to prevent accidental or unintended starting.
6. Loosen appropriate bolts and replace blade(s).
After performing any maintenance or repair work verify that all safety labels,
guards, lids and bolted connections are properly and securely installed on the
machine.
SECTION 2.3: WORK SITE ASSESSMENT AND INSPECTION
Before starting scrapping operations, a site assessment must be performed.
During the site assessment verify the following:
Work area is flat, clean, and dry, free of debris, frost-free, and has no
flammable liquids nearby. Also, make sure that the machine will be able
to clear all obstructions. NEVER SCRAPE OVER BOLTS, NUTS,
SCREWS, NAILS, OR OTHER DEBRIS AS THIS MAY RESULT IN
SIGNIFICANT DAMAGE TO THE MACHINE AND SERIOUS INJURY TO
THE OPERATOR.
Work area is well ventilated. IF WORK AREA IS ENCLOSED OR
PARTIALLY ENCLOSED (WAREHOUSE, PARKING GARAGE,
TUNNELS, ETC.), this is because carbon monoxide, which is a byproduct
all internal combustion engines, can be extremely hazardous when
allowed to accumulate in an area. An odorless, tasteless, and non-
irritating gas, carbon monoxide can quickly become lethal. As a result,
liquid propane must be used in all instances when the work area is
enclosed or partially enclosed
Each worker has a carbon monoxide monitor on their persons. These
carbon monoxide monitors should be calibrated, in working order, and
should be equipped with audible alarms that will warn workers if carbon
monoxide levels become too high. IF CARBON MONOXIDE LEVELS
EXCEED 35 PARTS PER MILLION, ALL WORK MUST CEASE
IMMEDIATELY! THIS REPRESENTS A POTENTIALLY DEADLY
SITUATION WHICH NECESSITATES AN IMMEDIATE SHUTDOWN!
All workers have received training on the dangers of overexposure to
carbon monoxide. Staff members must also be able to identify all of the

MACHINE MANUAL BRB-2800
SAFETY
© 2010 Blastpro Manufacturing Inc.®
8
signs and the symptoms associated with carbon monoxide poisoning.
This training should ensure that work would stop immediately and
emergency medical personnel would be notified promptly if one or more
workers exhibited or complained of any of the common signs and
symptoms associated with carbon monoxide overexposure, including:
headache, nausea, weakness, dizziness, lethargy, visual disturbances,
changes in personality, and/or loss of consciousness.
All operators and other personnel within the work area have received
training on proper ventilation procedures and on proper operation
procedures for the engine and for other types of equipment.
FLOORS HAVE BEEN THOROUGLY INSPECTED. SOME FLOOR OR
DECK SURFACES MAY BE COATED WITH OR CONTAMINATED BY
DANGEROUS MATERIALS SUCH AS:
oPCBs
oLEAD
oASBESTOS
oPESTICIDES
oSOLVENTS
oCLEANING FLUIDS
oAND/OR OTHER HARMFUL CHEMICALS
DISTURBING SUCH SURFACES CAN CREATE A SERIOUS HEALTH
THREAT TO THOSE WHO INHALE OR COME INTO CONTACT WITH
THE DUST. THE WORK AREA MUST BE CHECKED FOR THESE
MATERIALS BEFORE WORK CAN BEGIN. BLASTPRO
MANUFACTURING, INC. DOES NOT WARRANT ITS EQUIPMENT TO
BE SUITABLE FOR, OR APPROVED FOR, REMOVING DANGEROUS
MATERIALS. IT IS THEREFORE THE RESPONSIBILITY OF THE
CONTRACTOR TO CONFIRM THE SAFETY OF THE WORK AREA
AND THE EQUIPMENT WITH THE PROPER AUTHORITIES. IT IS
ALSO THE RESPONSIBILITY OF THE CONTRACTOR TO WARN ALL
STAFF MEMBERS OF ALL THE POTENTIAL SHORT-TERM AND
LONG-TERM HEALTH RISKS ASSOCIATED WITH INHALING AND
COMING INTO CONTACT WITH DANGEROUS MATERIALS. THE
CONTRACTOR IS RESPONSIBLE FOR PROTECTING ALL WORKERS
FROM BEING EXPOSED TO DANGEROUS MATERIALS.
Operator and any other personnel in the work area are wearing safety
glasses with side shields, dust masks, ear plugs, hard hats, steel toed
work boots, long sleeved shirts, tight fitting clothing, and gloves. It is also
imperative for staff to tie back long hair and to remove all jewelry.
Work area has been blocked off to pedestrians, unprotected personnel,
and untrained personnel. In the event pedestrians, unprotected

MACHINE MANUAL BRB-2800
SAFETY
© 2010 Blastpro Manufacturing Inc.®
9
personnel, or untrained personnel enter the work area, blasting operations
are to be stopped immediately.
Fire extinguishers are nearby. Also, take note of the location and the contact
information of fire departments close to the work site.
Belt guards are in working order and are present on the machine where needed.
All glass and equipment, including vehicles, are protected from debris. This can
be done by loosely hanging a sheet of visqueen or other protective material in
front of the glass or equipment in a curtain-like fashion.
Plug or cover all floor drains to prevent steel shot from falling into the drains.
The operator must be aware of their surroundings and use common sense. THE
OPERATOR IS NOT TO OPERATE THE EQUIPMENT IF HE IS TIRED,
DISTRACTED, OR UNDER THE INFLUENCE OF DRUGS, ALCOHOL,
OR MEDICATION THAT DECREASES AWARENESS!
SECTION 2.4: PERSONAL PROTECTIVE EQUIPMENT (PPE)
All personnel working with, or in the vicinity of the BRB-2800 should, at a
minimum, utilize the following PPE:
Protective boots or shoes
Eye protection with side shields
Hearing protection
Appropriate respiratory protection
Protective leather gloves for handling blades
Additionally, all personnel should utilize a carbon monoxide monitor while
working indoors. The BRB-2800 utilizes an internal combustion engine, which
produces carbon monoxide, or CO. CO can be fatal at high exposure levels. In
addition to CO monitoring equipment, the work site should be properly ventilated
to minimize exposure potential.
All personnel should observe PPE requirements particular to each job site.

MACHINE MANUAL BRB-2800
SAFETY
© 2010 Blastpro Manufacturing Inc.®
10
SECTION 2.5: OPERATIONAL SAFETY
Support personnel must keep a safe distance from the machine while it is
in operation. Do not stand in front of, or behind the machine while in
operation.
The blade should only be actuated up and down with the operator properly
seated on the machine.
Do not drive the machine with the scraper blade more than ½” off of the
floor.
Verify that the LP tank is properly seated on the brackets, with the
alignment pin properly located in slot or hole on tank.
The operator must be aware of their surroundings. No personnel should
operate or perform maintenance on the machine if they are tired,
distracted or under the influence of drugs, alcohol or medication that
decreases awareness.
Verify that all protective guards and covers are properly installed and
secured.
Verify that there is sufficient light for the operator to view the work surface.
The machine is equipped with headlights to provide additional lighting.
