OPERATING MANUAL BMG-435WD
VERSION 2.2

2
EC DECLARATION OF CONFORMITY
in accordance with Appendix II sub A of Directive 2006/42/EC
BLASTRAC B.V.
Utrechthaven 12
NL - 3433 PN NIEUWEGEIN
Tel: [phone]
Fax: [phone]
[e-mail]
The Netherlands
Declare under our sole responsibility that the machine as described below
Conforms with the Health and Safety requirements of the European Directive of the machine Safety.
In case of changes to the machine without our written authorization this declaration loses its validity.
Model: BLASTRAC BMG-435WD Serial number: xxxxH
1. satisfies the conditions set out in the Machine Directive (Directive 2006/42/EC); Low voltage directive
(2006/95/EC, as last amended; EMC directive 2004/108/EC, as last amended)
2. satisfies the following harmonized standards:
NEN-EN 349, NEN-EN 418, NEN-EN 294 and NEN-EN 60204
Nieuwegein 01-07-2010

3
Table of contents
EC Declaration of Conformity 02
1. Introduction 04
2. Machine description 04
Application
Accessories
3. Safety 05
Safety precautions
Safety regulations
Safety instructions
4. Initial operation 07
Checkpoints of electrical safety
Checkpoints of machine safety
Removing the diamond wings
Mounting the diamond wings
Diamag
5. Operating 08
Switch on the machine
Switch off the machine
Operating during grinding
6. Maintenance 09
7. Technical data 10
Contact 11

4
1. Introduction
It is important that all persons who are working or maintaining this machine will read the manual carefully and
understand it fully. Keep this manual near to the machine, so it can always be consulted.
Only authorized and trained personnel may operate this machine.
2. Machine description
The BMG-435WD is a small electrical driven planetary grinding machine. This is a three headed machine for
levelling and polishing of floors.
The patented drive system makes sure that this machine is very easy to handle.
The machine is simple to dismantle for ease of transportation.
Due to the water hose connection, it is possible to grind wet.
Application
The BMG-435WD can be used on almost any floor to plane, to make ready for coatings, or to remove coatings
or glue residues.
1
Steer
6
Motor
11
Floating shroud
2
Switch
7
Fill up block
12
Brush for floating shroud
3
Swing arm for hose
8
Drive mechanism
13
Diamond plate holders
4
Steer arm
9
Hinge plate
14
Housing
5
Water hose connection
10
Protection cover
15
Wheel frame
Accessories
There are several types of wings that may be used on this machine.
BG707301 Wing red box 9 pieces 18/20
BG707302 Wing red box 9 pieces 30/40
BG707303 Wing red box 9 pieces 60/80
BG707304 Wing red box 9 pieces 120/150
BG707311 Wing green box 9 pieces 18/20
BG707312 Wing green box 9 pieces 30/40
BG707313 Wing green box 9 pieces 60/80
BG707314 Wing green box 9 pieces 120/150
BG707321 Wing blue box 9 pieces 18/20
BG707322 Wing blue box 9 pieces 30/40
BG200997/set Wing PCD split
BG200999/set Wing PCD 2 x ¼

5
3. Safety
Before operating the machine, the personnel who are going to use it must be familiar with the safety
instructions given in this manual.
Keep this manual near to the machine, so that it may be consulted.
Safety precautions
The surface to be treated must be swept clean to remove stones, screws etc.
Never use the machine when the surface is not clear and if there is a risk of tripping.
Make sure there is not any water on the surface to be treated.
Remove any trailing electrical cables and or dust hoses from the surface to be treated
Always use a dust collector
Don’t get disturbed during the activities.
Safety regulations
Persons who are not operating the machine must not be permitted to stay in the surrounding area of
the machine.
Do not change anything on the machine. Always use cables that are approved and safety earthed.
Make sure that the machine is equipped with an earthed connection, do not change this and always
use earthed cables with an earthed plug.
Connect main power supply cable to an installation with an earth leakage circuit breaker.
Inspect and test the electrical components regularly. The electrical components have to satisfy the
requirements that apply to these components.
Always call a skilled electrician or your distributor when you have questions about the safety of the
electrical components.
Work on electrical equipment or operating materials may only be undertaken by a skilled electrician or
by trained persons under the guidance and supervision of a skilled electrician as well as in accordance
with the electrical engineering regulations.
Pull out the main plug during inspections and maintenance on the machine.
Never operate the machine when the surface is wet.
Never use the machine in the rain.
The machine contains rotating parts; because of this never pull the machine backwards with a turning
motor.
The following sticker is placed on the machine.
Meanings of these symbols are:
Ear protection is obligatory
Safety glasses with lateral protection are obligatory.
CE-mark on this machine
Safety shoes obligatory.
Consult the manual before operating the machine
Personnel must tie back long hair and not wear loose clothing or jewelry including rings.
Wear gloves and dust mask whilst operating the machine.

6
Safety instructions
Make sure the machine is clean and that the handgrips are dry and free of grease and oil.
Make sure the dust seal is in good condition, this to reduce the dust.
Pull out the main plug when changing the diamond wings
The BMG-435WD weights 115 kilogram. Use appropriate appliances as a lift or crane.
Lift the machine with a rope on the frame (8)
Or detach the machine into parts and lift these parts.

7
4. Initial operations
Before using the machine it is important to inspect the machine.
It is not permitted to use the machine if the machine safety is not according the checkpoints below.
Checkpoints of electrical safety
Use only extension cables for extending the main cable that are sized and marked in accordance with
the overall power consumption of the machine.
Electrical cables must be rolled entirely off of the reels.
Any damage to electric cables is not permitted
Use an electrical power supply connection with earth connection
Checkpoints of machine safety
Check if:
The safety functions and operating functions work correct.
The flexible coupling is not deformed or damaged
The diamond / multiflail disc is not damaged
There are no damages on the electrical components.
There are not any loose nuts or bolts
There is not any damage to the dust hose and if it is connected correctly.
Removing the diamond wings
Make sure the power supply plug is out of the machine
Lay down the machine so it is lying on the handle. Make sure the machine will not fall back down. A
second person can stands on the handle to make sure it will not fall back down.
Loose the adapter plates (9) from the diamond plate holders (1) and remove the 9 bolts (3) with an
appropriate key so the diamond wings (4) can be removed.
Mounting the diamond wings
Make sure the power supply plug is out of the machine
Lay down the machine so it is lying on the handle. Make sure the machine will not fall back down. A
second person can stands on the handle to make sure it will not fall back down.
Mount the diamond wings (4) to the adapter plates (9) with an appropriate key and fix the adapter
plate (9) to the diamond plate holder (1)
DIAMAG
When using DIAMAG adapter plates, you can replace the diamond wings without
using any tools!
Because of the specially designed heat resistant magnets
and fixation pins, the diamond tools are fixed onto the
plate, but can still very simply be replaced by hand.
Contact your Blastrac distributor for more information
or check WWW.DIAMAG.EU

8
5. Operating
During operating the BMG-435WD, the following additional safety instructions must be followed closely.
Switch on the machine
Turn on the dust collector before switching on the machine and connect the dust hose to the machine.
Connect the power supply to the machine (1)
Stand behind the machine.
Push down the handle of the machine (2) so that the machine is off the ground.
Push the green button (3) on the electrical box.
Check the direction of rotation of the 400 volt version. The machine must turn counter clockwise. (the
fan of the motor is turning clockwise if the motor turns counter clockwise)
If the motor turns the wrong direction, turn the switch in the electrical inlet (1) and restart the
machine.
Let down the machine till the diamond wings hit the floor
Start grinding
Switch off the machine
Push the red button (4) on the electrical box
Wait until the machine stops rotating before laying down
the machine on the handle
Pull out the power supply
Shut down the dust collector.
Operating during grinding
This machine will always have an even grinding result because of the planetary system.
However it is advised to keep the machine constantly in movement for an optimum grinding result.

9
6. Maintenance
Work only with original Blastrac parts.
Check regularly to see if the diamond wings are in good condition. Replace immediately when these are
damaged or worn out.
Prevent premature wear by keeping the machine as dust free as possible, for this reason clean the machine
regularly with a dust collector (vacuum cleaner) especially the upper drive.
Clean the machine every day with air and non-aggressive materials. Never use a high pressure water cleaner
to clean the machine.
Store the cleaned and dry machine in a dry and humid free room. Protect the electrical motor from moisture,
heat, dust and shocks.
All repair work must to be done by qualified Blastrac personnel, this to guarantee a safe and reliable machine.
Any guarantee on the machine is automatically void when:
Non original Blastrac parts and or diamond discs have been used
Repair work is not done by qualified Blastrac personnel
Changes, add on’s or conversions are undertaken without the written permission from Blastrac BV.

10
7. Technical data
Design and specifications are subject to change without notice by Blastrac BV
BMG-435WD
1x230V
BMG-435WD
3x230V
BMG-435WD
3x400V
BMG-435WD
1x110V
Power consumption
2,2 kW
3,0 kW
3,0 kW
2,2 kW
Electrical
connection
230V / 50 Hz
3x230V
50/60Hz
400V / 50Hz
110V / 50 Hz
Amperage
12,9A
11,8A
6,0A
28,0A
Diameter diamond
disc
Ø 155 mm
Ø 155 mm
Ø 155 mm
Ø 155 mm
Working width
435 mm
435 mm
435 mm
435 mm
Rotation speed
720 min-1
720/860min-1
720 min-1
720 min-1
Length
1310 mm
1310 mm
1310 mm
1310 mm
Width
460 mm
460 mm
460 mm
460 mm
Height
930 mm
930 mm
930 mm
930 mm
Weight
115 kg
115 kg
115 kg
115 kg
Noise level
75dB(A)
75dB(A)
75dB(A)
75dB(A)
Dust hose
connection
51 mm Ø
51 mm Ø
51 mm Ø
51 mm Ø
Suitable filter unit
Contact Blastrac BV
We will assist you with a good advice

11
Headquarter
