Blaupunkt MPS 1652 CVW User manual

MPS 1802 CVW
Operating and Installation Instructions
VELOCITY POWER
VOLKSWAGEN PLUG & PLAY
2-WAY COMPONENT SPEAKER UPGRADE
MPS 1652 CVW
MPS 1802 CVW
MPS 1652 CVW

•
Recycling and Disposal
Do not dispose of your old unit in the
household trash!
Use the return and collection systems
available to dispose of the old device.
This manual may be updated from time to time without
any notice.
INTRODUCTION
1
Proper system planning is vital in order to maximize the
device’s performance and road safety. Plan your instal-
lation carefully to avoid compromising performance re-
liability of the system. Consult an authorized Blaupunkt
delaler for installation or reparation. Read the manual
carefullt before operating the device for the rst time.
Safety Notes
Ensure to folow below safety notes during installation
and wiring connection: -
•
•
•
•
Installation and Connection Instructions
•
•
•
Disclaimer
In no event shall Blaupunkt be liable for any direct,
indirect, punitive, incidental, special consequential
damages to property or life and whatsoever arising out
of or connected with the use or misuse of our products.
USA & CANADA: This product is not intended for sale in
the United States and Canada. If purchased in the U.S. or
Canada, this product is purchased on as-is basis. No
warranty, whether expressed or implied is provided in
the U.S. or Canada.
Voltage Supply
•
•
•
Disconnect the negative terminal of the battery. Refer
to the safety notes of the vehcle manufacturer.
Ensure positions of the holes are nowhere near the
vehicle component to avoid any damage during
drilling.
Ensure cross section of the cable is no less than
2.5mm if the positive and negative cables are too
long.
Incorrect installation may result in malfunction of the
device or the car sound system.
Select a dry and well-ventilated location to install the
device.
The device must not be installed in overly exposed
location such on therear shelf, rear seat etc.
The installation location must be suitable for screw
holes and have stable ground support.
Use the supplied power extension cable to connect to
the positive battery terminal.
Firmly and carefully connect the ground lead to a bare
metal point on the vehicle chassis.
The control of the device should be a two-channel
control, either via the preamplier output of the car
sound system.
A control solely via the right or left channel is also
possible since the low-frequency portion of the music
is generally identical on both channels.

Pair of 6.5”Volkswagen plug & play 2-way component speaker to upgrade OE speaker for selected models with
Synthetic Fiberglass Cone including mounting hardware
•
•
•
•
•
•
•
•
•
2
SPECIFICATION
MPS 1652 CVW
Woofer
Tweeter
Max. Power Handling : 120W
Normal Output Power (RMS) : 50W
Voice Coil : 25.5mm
Tweeter Size : 25.4mm
Impedence : 3ohms
Frequency Response : 55.8Hz - 20,000Hz
Sensitivity : 88dB
Mounting Depth : 28mm
Mounting Hole Diameter : 138mm
167.5mm
167.5mm 146mm
28mm
90mm
37.55mm
45.32mm
10.1mm
8.5mm

SPECIFICATION
3
MPS 1802 CVW
Woofer
Tweeter
Pair of 8.0”Volkswagen plug & play 2-way component speaker to upgrade OE speaker for selected models with
Synthetic Fiberglass Cone including mounting hardware
•
•
•
•
•
•
•
•
•
Max. Power Handling : 120W
Normal Output Power (RMS) : 60W
Voice Coil : 30.55mm
Tweeter Size : 25.4mm
Impedence : 3ohms
Frequency Response : 51Hz - 20,000Hz
Sensitivity : 89dB
Mounting Depth : 31mm
Mounting Hole Diameter : 160mm
37.55mm
45.32mm
10.1mm
8.5mm
208mm
200mm
180mm
31mm
100mm

4
INSTALLATION
TROUBLESHOOTING
If any of the following problem occur, please resort to Troubleshooting for the possible solutions. Consult Blaupunkt
authorized dealer if problem persist.
TweeterTweeter
WooferWoofer
Problems
Speaker does not
work
Distorted and hissing
sound
Solutions
Ensure proper wiring connections of speaker.
Repair or replace if the cables are damaged.
Replace with a new speaker.
Replace with a new speaker.
Possible Causes
Incorrect or loose wiring connection.
Fraying or broken cables.
Speaker is damaged.
Voice coil or speaker cone is damaged.

5
COMPATIBILITY LIST
Model
Bettle
POLO
Scirocco
Santana
Jetta
Bora
Lavida
Sagitar
Lamando
Passat
Magotan
Arteon
Golf 6
Golf 7
Golf R-line
Golf GTI
Golf Sportsvan
Golf Variant/SportWagen
Model
Bettle
Magotan
Phideon
Passat(B8) Variant
Tayron
Tiguan
Teramont/Atlas
Touareg
Touran
Sharan
Multivan
Caravelle
Model
Golf Alltrack
Golf R
Gran Santana
C-TREK
Gran Lavida
Cross Lavida
Passat(B8) Variant
Tacqua
T-cross
T-ROC
Tharu
Tayron
Tiguan
Teramont/Atlas
Touran
Sharan
Multivan
Caravelle
Mounting Position
Rear panel
Front/rear door
Front door/rear panel
Front/rear door
Front/rear door
Front/rear door
Front/rear door
Front/rear door
Front/rear door
Front/rear door
Rear door
Front/rear door
Front/rear door
Front/rear door
Front/rear door
Front/rear door
Front/rear door
Front/rear door
Mounting Position
Front door
Front door
Front/rear door
Front door
Front door
Front door
Front door
Front/rear door
Front door
Front door
Front door
Front door
Mounting Position
Front/rear door
Front/rear door
Front/rear door
Front/rear door
Front/rear door
Front/rear door
Rear door
Front/rear door
Front/rear door
Front/rear door
Front/rear door
Rear door
Rear door
Rear door
Rear door
Rear door
Rear door
Rear door
MPS 1652 CVW can be installed in the following list of car models :
MPS 1802 CVW can be installed in the following list of car models :

Designed and engineered by Blaupunkt Competence Centre
MPS 1652 CVW
1 111 21 034 02 01
MPS 1802 CVW
1 111 21 035 02 01
