Blaupunkt ATOMIK User manual

ATOMIK PARTY BOOMBOX
USER MANUAL
Dear Customer
Thank you for choosing our product, please read all the instructions carefully
and retain the manual for future use.

Function Operation and Features:
1. MODE : Short press for switching among BT, TF CARD, USB, LINE IN, FM Long press
for LED lights on/off
2. : Play the previous music under BT, TF card and USB mode, Play previous radio
station under FM mode.
3. : Short press for music play/pause
Long press for radio station automatic searching under FM mode
4. : Play to next music under BT, TF card and USB mode Play next radio station under FM mode.
5. DC 5V : Charge Jack for built in battery. When DC 5V cable plugs in, The LED lights up
6. Mic : Support 6.5mm wired microphone input
7. OFF/ON : Speaker power off/ Speaker power on

Specifications
Charging instructions
8. USB Port : Support USB and can play MP3 and WAV format music in U disk
Connect the charging cable to the DC5V＝1A adapter, plug it into the charging port after the machine
is turned off; red light will be on when charging, red light will be off when it is fully charged.
Care and Maintenance
Read the following recommendations before using the wireless speaker, following these you will be
able to enjoy the product for many years
9. TF card Port : Support TF CARD and can play MP3 and WAV format music in CARD10.Mic
Plug the microphone input the port to enjoy the music
10. BT Connection : -Power on the product or press MODE button to enter into BT mode.
-Turn On BT in your Bluetooth device, search for BT devices ,when it appears the
item pairing name- BLAUPUNKT PS15
- After the device has been paired successfully for the first time, it will connect automatically
around 10 seconds to the devices which connected before when next time use.
(Note: Each product could connect to one Bluetooth device only.)
Speaker Size
Built-In Rechargeable Battery
Bluetooth Version
FM Frequency Range
Input Power
S/N
Led Light
Screen
External Music File Format
Inputs
Functions
4”x2
1200mAh Battery
5.0
87.5-108MHz
DC 5V, 1A
≧80dB
Colorful Flame Lamp
Digital Screen Display
MP3
3.5mm Aux input, 6.5mm microphone output
Bluetooth, FM radio, USB, micro SDcard ,TWS, Microphone

• Do not expose the unit of liquid, moisture, or humidity to avoid the product’s internal circuit
being affected.
• Don’t use abrasive cleaning solvents to clean the unit.
• Do not expose the unit to extremely high or low temperature as this will shorten the life of
electronic devices, destroy the battery, or distort certain plastic parts
• Don’t dispose of the unit in fire as it will result in an explosion
• Don’t expose the unit to contact with sharp objects as this will cause scratches and damage
• Don’t let the unit fall onto the floor, the internal circuit might get damaged
• Don’t attempt to disassemble the unit as it may get damaged if you are not professional
Warranty Information 1 Year*
If you have issue with our product please contact our service center Service Centre.
Authorized Service Center Blaupunkt Speakers
Address: Envent World Wide Pvt Ltd.
Khasra. No- 15/15(4-16), Village Samalkha, Tehsil Vasant
Vihar, New Delhi- 110037
E-Mail: [email protected]
Tel. [phone]
Please prepare & submit the following information during the telephone or e-mail notification to
facilitate the process:
• Serial Number
• Date of purchase
• A copy of proof of purchase in case of warranty
Note- Important Information
Please use the original packaging or other suitable
packaging to protect the unit in transit.
