PARTS LIST
STATIONARY GAS SELF-CONTAINED STEAM KETTLES
MODELS: KLS-20G
KLS-40G
KLS-60G
April 6, 2007
BLODGETT OVEN CO ▪44 lakeside Ave
▪Burlington, VT 05446
Tel. [phone] ▪Fax [phone] ▪
www.blodgett.com

2 2007-06-25
FIGURE 1

FIGURE 1
ITEM Part Number DESCRIPTION 20 40 60
1 40453 Elbow 1/4 C X 1/4 FPT 1 1 1
2 40542 Level Control 1 1 1
3 41333 Component Mounting Bracket 1 1 1
4 41861 Fuse, 3 Amp. 250V 1 1 1
5 41863 Fuse Holder 1 1 1
6 40046 Thermostat 1 1 1
7 40033 Recess Control Panel 1 1 1
* ** 42548 Control Decal - English 1 1 1
* ** 42475 Control Decal - French 1 1 1
8 41889 Power Switch 1 1 1
9 43391 Pilot Light - 28 Volt, Red Cooking 1 1 1
10 42429 Pilot Light - Amber - Low Water 1 1 1
11 41006 Thermostat Dial 1 1 1
12 40815 Pressure Gauge Bracket 1 1 1
13 40907 Pressure Gauge 1 1 1
14 40022 Support Bracket 1 1 1
15 42443 Pressure Switch 1 1 1
16 40456 Tee 1/4 C. x 1/8 MPT 1 1 1
17 41077 Sight Glass Assembly 1 1 1
41877 Sight Glass 1 1 1
42434 Washer 2 2 2
18 42440 Tee, 3/8" - 3000 lbs. 1 1 1
19 40425 Connector 1/4 C x 3/8 MPT 1 1 1
20 41474 Adjustable Foot 3 3 3
21 40058 Door Knob 1 1 1
22 40038 Access Door Assembly 1
40039 Access Door Assembly 1

4 2007-06-25
ITEM Part Number DESCRIPTION 20 40 60
40040 Access Door Assembly 1
23 40049 Door Hinge 1 1 1
24 40062 Corner Front Panel 1
40063 Corner Front Panel 1
40064 Corner Front Panel 1
25 40663 Cord Set 120V 1 1 1
26 41241 Front Shield 1
41245 Front Shield 1 1
27 40035 Manifold Assembly 1 1 1
28 41813 Pipe Plug, 1/8 NPT 1 1 1
29 40709 Pilot Bracket 1 1
40723 Pilot Bracket 1
** 30 42349 Ignitor/Sensor Pilot Natural 1 1 1
42350 Ignitor/Sensor Pilot L.P. 1 1 1
31 41039 Ignitor Cable 1 1 1
** 32 42401 Burner Orifice # 29, Natural Gas 2 2
42402 Burner Orifice # 44, LP 2 2
42403 Burner Orifice # 21, Natural Gas 2
42404 Burner Orifice # 39, LP 2
33 41797 Union, ½ NPT 1 1 1
** 34 41108 Combination Gas Control, Natural Gas 1 1 1
41109 Combination Gas Control, LP 1 1 1
35 40320 Burner 2
40321 Burner 2
40322 Burner 2
36 41773 Close Nipple ½ 1 1 1
37 40431 Connector, 3/8 C x 3/8 MPT 2 2 2
38 40417 Connector, 3/8 C x 3/8 FPT 2 2 2
39 40708 Terminal Block 2 2 2

ITEM Part Number DESCRIPTION 20 40 60
40 40707 End Section 1 1 1
41 42269 Gas Flex Hose 1 1 1
42 40466 Probe, 9 1/4" 1
40467 Probe, 9 3/4" 1 1
43 41794 Tee, 3/4 x 3/4 x 3/8 1 1 1
44 41791 St. Elbow, 3/4" 1 1 1
45 41044 Down Tube 1 1 1
46 43392 Air Vent 1 1 1
47 40613 Relief Valve 1 1 1
* 48 40287 Flue Box 1
40288 Flue Box 1
40289 Flue Box 1
* 49 40054 Faucet Bracket 1 1 1
50 41885 Transformer, 115/230 - 24V, 50/60 Hz,
50 VA 111
51 42351 Ignition Module 1 1 1
* 52 43393 Lighting Instructions 1 1 1

6 2007-06-25
FIGURE 2
DRAW-OFF VALVES
ITEM Part Number DESCRIPTION QUANTITY
40553 1-1/2" DRAW-OFF VALVE
ASSEMBLY
1 41809 Acorn Nut 10-24 UNC 1
2 40662 Handle, Stainless Steel 1
3 40559 Gland Nut 1
4 40560 Bonnet 1
5 40562 “O” Ring 1
6 40561 Stem Assembly 1
7 43246 Valve Body 1

ITEM Part Number DESCRIPTION QUANTITY
40554 2" DRAW-OFF VALVE ASSEMBLY
1 41809 Acorn Nut 10-24 UNC 1
2 40662 Handle, Stainless Steel 1
3 40563 Gland Nut 1
4 40564 Bonnet 1
5 40566 “O” Ring 1
6 40565 Stem Assembly 1
7 42481 Valve Body 1
ITEM Part Number DESCRIPTION QUANTITY
40556 3" DRAW-OFF VALVE ASSEMBLY
1 40567 Acorn Nut, 7/16-14 UNC 1
2 40568 Handle, Stainless Steel 1
3 40569 Gland Nut 1
4 40570 Bonnet 1
5 40572 “O” Ring 1
6 40571 Stem Assembly 1
7 43248 Valve Body 1

8 2007-06-25
FIGURE 3

HINGE ASSEMBLY
ITEM Part Number DESCRIPTION QUANTITY
1 40259 Knob 1
* * 2 42167 Handle Assembly, 20 Gallon Kettle 1
42168 Handle Assembly, 40 Gallon Kettle 1
3 40109 Bolt 2
4 40133 Fibre Washer 4
5 40111 Nut 2
