Project
Item No.
Quantity
Model KPS-20E - 20 gallon (76 litres) electric pedestal stationary kettle
Model KPS-30E - 30 gallon (114 litres) electric pedestal stationary kettle
Model KPS-40E - 40 gallon (151 litres) electric pedestal stationary kettle
Model KPS-60E - 60 gallon (227 litres) electric pedestal stationary kettle
Model KPS-80E - 80 gallon (303 litres) electric pedestal stationary kettle
Model KPS-100E - 100 gallon (379 litres) electric pedestal stationary kettle
CONSTRUCTION
304 stainless steel construction
316 stainless steel liner for 20, 30 & 40 gallon
2/3 jacketed with factory sealed distilled water enclosure
Hemispherical design on bottom of kettle for superior heat circulation
Stainless steel pedestal base with four 7/16” holes evenly spaced for
securing to the floor
Stainless steel control housing
Removable elements
OPERATION
Electrically self-generated closed steam system
Integrally mounted controls
Power switch
Thermostat
Cook indicator light
Pressure gauge
Safety valve
Low water light
Low water shut off
165-275°F (74-140°C) temperature range
STANDARD FEATURES
Manual control
2” tangent draw off
Hinged cover for 20, 30 & 40 gallon
Spring assist hinged stainless steel cover for 60, 80 and 100 gallon
Stainless steel faucet bracket
Standard voltage options
208 VAC, 3 phase, 60 Hz
240 VAC, 3 phase, 60 Hz
208 VAC, 1 phase, 60 Hz ( 20 & 30 gallon models only)
240 VAC, 1 phase, 60 Hz ( 20 & 30 gallon models only)
One year parts and labor warranty*
* For all international markets, contact your local distributor.
BLODGETT
44 Lakeside Avenue, Burlington, VT 05401
Toll Free: [phone] • Phone: [phone] • Fax: [phone]
OPTIONS AND ACCESSORIES
(AT ADDITIONAL CHARGE)
Voltage options
220 VAC, 1 phase, 60 Hz (20 & 30 gallon only)
220 VAC, 3 phase, 60 Hz
380 VAC, 3 phase, 60 Hz
415 VAC, 3 phase, 60 Hz
480 VAC, 3 phase, 60 Hz
220/380 VAC, 3 phase, 4 wire
240/415 VAC, 3 phase, 4 wire
600 VAC, 3 phase, 60 Hz
Power increase options
24 kW elements for 40, 60 & 80 gallon
33 kW elements for 60, 80 & 100 gallon
Faucets
Single pantry faucet with swing spout
Double pantry faucet with swing spout
Covers
Two piece stainless steel hinged covers for
60, 80 & 100 gallon
Spring assist hinged stainless steel cover for
20, 30 & 40 gallon
Draw Off valves and accessories
3” (76mm) draw off valve
2” (50mm) dairy valve
3” (76mm) dairy valve
Perforated strainer for draw off
Solid stainless steel disc for draw off valve
Etched markings
Gallons
Litres
Correctional package
316 stainless steel liner for 60, 80 & 100 gallon
Tri-basket assembly
Graduated measuring strip
Strainer hook
KPS-E
Electric Pedestal Base Stationary Kettle
KPS-E PEDESTAL STATIONARY KETTLE

BLODGETT
www.blodgett.com 44 Lakeside Avenue, Burlington, VT 05401 Toll Free: [phone] • Phone: [phone] • Fax: [phone]
KPS-E PEDESTAL STATIONARY KETTLE
SHORT FORM SPECIFICATIONS
Provide Blodgett model KPS-20E (20 gallon), KPS-30E (30 gallon), KPS-40E (40 gallon), KPS-60E (60 gallon), KPS-80E (80 gallon) or KPS-100E (100 gallon) electrically heated pedestal
base stationary kettle. The unit shall have a double wall interior to form a steam jacket around the lower 2/3 of the kettle. The jacket enclosure shall contain distilled water which is facto-
ry sealed. The bottom of the kettle shall be of hemispherical design for superior heat circulation. The kettle shall be supported on stainless steel pedestal base with four 7/16” holes even-
ly spaced for securing to the floor. Construction shall be of all welded #4 satin finish 304 stainless steel. The interior of 20 through 40 gallon models shall be standard stainless steel type
316 for high acid content cooking. The controls shall be integrally mounted and shall include a power switch, thermostat with range of 165-275°F (74-140°C), a cook indicator light, pres-
sure gauge, safety valve, low water light and low water shut off. The elements shall be removable. Unit shall have a 2” draw off valve. 20, 30 and 40 gallon units shall have hinged, stain-
less steel domed cover. 60, 80 and 100 gallon units shall have a spring assist hinged stainless steel domed cover. Unit shall be ASME code stamped and National Board registered.
Provide options and accessories as indicated.
Printed in U.S.A. NOTE: FOR COMMERCIAL USE ONLY
NOTE: The company reserves the right to make substitutions of components without prior notice.
APPROVAL/STAMP
P/N S00026 Rev E (12/06)
POWER CONNECTION:
Refer to data plate.
MAXIMUM PRESSURE:
All models 50 PSI (345 kPa)
SHIPPING INFORMATION:
Approx. Weight:
KPS-20E 250 lbs. (113 kg)
KPS-30E 275 lbs. (125 kg)
KPS-40E 305 lbs. (138 kg)
KPS-60E 440 lbs. (200 kg)
KPS-80E 495 lbs. (225 kg)
KPS-100E 530 lbs. (240 kg)
MODEL A B C D E F (2”) F (3”) G (2”) G (3”) H J K
KPS-20E 21[533] 18[457] 38[965] 23.75[629] 18.5[470] 14.75[375] 15.5[394] 18[457] 17.5[445] 14[356] 21[533] 60.5[1537]
KPS-30E 24[610] 20[508] 38[965] 27.75[705] 20[508] 16[406] 16.5[419] 15.75[400] 15.25[387] 12.5[318] 19[483] 63.5[1613]
KPS-40E 26[660] 22.5[572] 38[965] 29.75[756] 21[533] 17[432] 18[457] 13.5[343] 13[330] 9[229] 17[432] 65[1651]
KPS-60E 29.5[749] 26[660] 42[1067] 33.75[857] 19[483] 18[457] 19.25[489] 14[356] 13.5[343] 11[280] 17.25[438] 75[1905]
KPS-80E 33[838] 28[711] 45[1143] 36.75[933] 20.5[521] 19.5[495] 20.5[521] 15[381] 14.5[368] 12.75[324] 18[458] 81[2058]
KPS-100E 35.5[902] 30[762] 48[1219] 40[1016] 22[559] 21.5[546] 22.5[572] 15[381] 14.5[368] 13[330] 20.5[521] 87[2210]
AVAILABLE kW
MODEL STD OPT
KPS-20E 12 N/A
KPS-30E 15 N/A
KPS-40E 18 24
KPS-60E 18 24, 33
KPS-80E 18 24, 33
KPS-100E 24 33
AMPS PER LINE
KW PHASE 208V 220V 240V 380V 415V 480V
12 1 57.7 54.4 50.0 N/A N/A N/A
3 33.3 31.5 28.9 18.2 16.7 14.4
15 1 72.1 68.2 62.5 N/A N/A N/A
3 41.6 39.4 36.1 22.8 20.9 18.0
18 3 50.0 47.2 43.3 27.3 25 21.7
24 3 66.6 63.0 57.7 36.5 33.4 28.9
33 3 91.6 86.6 79.4 50.1 45.9 39.7
