Blomberg SOM 9650 A+ User manual

Instruction manual
SOM 9650 A+
Refrigerator
Køleskab
Kühlschrank
Jääkaappi

EN
1
Please read this manual first!
Dear Customer,
We hope that your product, which has been produced in modern plants and
checked under the most meticulous quality control procedures, will provide you an
effective service.
For this, we recommend you to carefully read the entire manual of your product
before using it and keep it at hand for future references.
This manual
• Will help you use your appliance in a fast and safe way.
• Read the manual before installing and operating your product.
• Follow the instructions, especially those for safety.
• Keep the manual in an easily accessible place as you may need it later.
• Besides, read also the other documents provided with your product.
Please note that this manual may be valid for other models as well.
Symbols and their descriptions
This instruction manual contains the following symbols:
CImportant information or useful usage tips.
AWarning against dangerous conditions for life and property.
BWarning against electric voltage.
This product bears the selective sorting symbol for waste electrical and
electronic equipment (WEEE).
This means that this product must be handled pursuant to European Directive
2002/96/EC in order to be recycled or dismantled to minimize its impact on
the environment. For further information, please contact your local or regional
authorities.
Electronic products not included in the selective sorting process are potentially
dangerous for the environment and human heatlh due to the presence of
hazardous substances.
Recycling

EN
2
CONTENTS
1 Your refrigerator 3
Technical specifications of your refrigerator
4
2 Warnings 5
General safety ........................................5
Starting Up.............................................6
If there are any children at home.............6
Intended use ..........................................6
Safety instructions ..................................6
Things to be done for energy saving.......6
3 Installation 7
Preparation.............................................7
Points to be considered when re-
transporting your refrigerator ..................7
Adjusting the legs ...................................7
Before operating your refrigerator ...........8
Electric connection .................................8
Disposing of the packaging ....................8
Disposing of your old refrigerator ............9
Replacing the interior light bulb ..............9
Reversing the doors ...............................10
4 Using your refrigerator 11
Setting the operating temperature ..........11
The operating temperature is regulated by
the temperature control. .........................11
Using interior compartments...................11
Cooling...................................................12
Defrost ...................................................12
5 Maintenance and cleaning 13
Protection of plastic surfaces .................13
6 Recommended solutions for
the problems 14

EN
3
1Your refrigerator
Front plastic trim1.
Interior light2.
Thermostat knob3.
Movable shelves4.
Wine rack5.
0 °C Compartment6.
CFigures that take place in this instruction manual are schematic and may not
correspond exactly with your product. If the subject parts are not included in the
product you have purchased, then it is valid for other models.
4
6
7
8
2
4
4
4
4
5
1
3
9
10
10
11
12
Crisper7.
Adjustable front feet8.
Dairy compartment9.
Adjustable door shelves10.
Egg compartment11.
Bottle shelves12.

EN
4
A+
158
325
25
-
-
SN-ST
38
350
173
59.5
60
60.5
60
230/50
R600a
Technical specifications of your refrigerator
* (Actual consumption varies depending on where and how the appliance is used)
** (Power failure safety; it is recommended not to consume the food in freezer
compartment after this period.)
CTechnical specifications can be changed to increase the product quality without being
subject to prior notice.
CValues stated on the markings on the product or in the printed materials supplied
with the product are the values obtained in laboratory in accordance with relevant
standards. Such values may vary depending on the usage of the product and the
ambient conditions.
CThe dimensions given on the table describe the minimum required space to place the
unit with doors closed.
Energy Class
Annual Energy Consumption (kWh/year)*
Fridge Compartment Volume (Net-lt)
Total Frozen Food Compartment Volume
(Net-lt)
Star Class
Temperature Increasing Time (hours)**
Freezing Capacity (kg/24 hours)
Climate Class
Noise Level (dB(A))
Total Net Volume (lt)
(H) Height (cm)
(W) Width (cm)
(D) Depth (cm)
Weight (kg)
Total Power (W)
Electric Supply (V/Hz)
Coolant Type

EN
5
2Warnings
Please examine the following
information. In case these are not
followed, personal injury or material
damage may occur. Then all warranty
and reliability commitments will become
invalid.
The usage life of the unit you purchased
is 10 years. This is the period for keeping
the spare parts required for the unit to
operate as described.
General safety
• When you want to dispose/scrap
the product, we recommend you to
consult the authorized service in order
to learn the required information and
authorized bodies.
• Consult your authorized service for all
your questions and problems related to
the refrigerator. Do not intervene or let
someone intervene to the refrigerator
without notifying the authorized
services.
• Do not eat cone ice cream and ice
cubes immediately after you take them
out of the freezer compartment! (This
may cause frostbite in your mouth.)
• Do not put bottled and canned liquid
beverages in the freezer compartment.
Otherwise, these may burst.
• Do not touch frozen food by hand; they
may stick to your hand.
• Vapor and vaporized cleaning materials
should never be used in cleaning
and defrosting processes of your
refrigerator. In such cases, the vapor
might get in contact with the electrical
parts and cause short circuit or electric
shock.
• Never use the parts on your refrigerator
such as the door as a means of
support or step.
• Do not use electrical devices inside the
refrigerator.
• Do not damage the cooling circuit,
where the refrigerant is circulating, with
drilling or cutting tools. The refrigerant
that might blow out when the gas
channels of the evaporator, pipe
extensions or surface coatings are
punctured may cause skin irritations
and eye injuries.
• Do not cover or block the ventilation
holes on your refrigerator with any
material.
• Repairs of the electrical appliances
must only be made by qualified
persons. Repairs performed by
incompetent persons may create a risk
for the user.
• In case of any failure or during a
maintenance or repair work, disconnect
your refrigerator’s mains supply by
either turning off the relevant fuse or
unplugging your appliance.
• Do not pull by the cable when pulling
off the plug.
• Place the beverage with higher proofs
tightly closed and vertically.
• Flammable items or products that
contain flammable gases (e.g. spray) as
well as the explosive materials should
never be kept in the appliance.
• Do not use mechanical devices
or other means to accelerate the
defrosting process, others than those
recommended by the manufacturer.

EN
6
• This appliance is not intended for use
by persons (including children) with
reduced physical, sensory or mental
capabilities, or lack of experience
and knowledge, unless they have
been given supervision or instruction
concerning use of the appliance by a
person responsible for their safety.
• Children should be supervised to
ensure that they do not play with the
appliance
• if the supply cord is damaged, it must
be replaced by the manufacturer,
its service agent or similarly qualified
persons in order to avoid a hazard.
Starting Up
• Do not operate a damaged refrigerator.
Consult your service if you have any
doubts.
• Electrical safety of your refrigerator shall
be guaranteed only if the earth system
in your house complies with standards.
If there are any children at
home...
• Do not allow children play with
your refrigerator. They might harm
themselves and the refrigerator. (E.g.
do not allow them hang from the door.)
Intended use
• This product is designed for domestic
use.
• It should not be used outdoors. It is not
appropriate to use it outdoor even if the
place is covered with a roof.
AYour product is equipped with a natural
cooling system (R600a) which does
not contain CFC and HFC gases.
This gas is flammable. Therefore, pay
attention to not damaging the cooling
system and piping during usage and
transportation. In the event of damage,
do not dispose the product in fire; keep
your product away from potential fire
sources that can cause the product
catch a fire and ventilate the room in
which the unit is placed.
Safety instructions
• Exposing the product to rain, snow,
sun and wind is dangerous with
respect to electrical safety.
• Contact the authorized service when
there is a power cable damage and
etc. so that it will not create a danger
for you.
• Caution: Never plug the refrigerator
into the wall outlet during installation.
Otherwise, risk of death or serious
injury may arise.
Things to be done for energy
saving
CDo not leave the doors of your
refrigerator open for a long time.
CDo not put hot food or drinks in your
refrigerator.
CDo not overload your refrigerator so
that the air circulation inside of it is not
prevented.
CDo not install your refrigerator under
direct sunlight or near heat emitting
appliances such as ovens, dishwashers
or radiators.
CPay attention to keep your food in
closed containers.

EN
7
3Installation
BPlease remember that the
manufacturer shall not be held liable if
the information given in the instruction
manual is not observed.
Preparation
• Your refrigerator should be installed at
least 30 cm away from heat sources
such as hobs, ovens, central heater
and stoves and at least 5 cm away
from electrical ovens and should not be
located under direct sunlight.
• The ambient temperature of the room
where you install your refrigerator
should at least be 10°C. Operating your
refrigerator under cooler conditions
than this is not recommended with
regard to its efficiency.
• Please make sure that the interior of
your refrigerator is cleaned thoroughly.
• If two refrigerators are to be installed
side by side, there should be at least 2
cm distance between them.
• When you operate your refrigerator
for the first time, please observe the
following instructions during the initial
six hours.
- The door should not be opened
frequently.
- It must be operated empty without
any food in it.
- Do not unplug your refrigerator. If
a power failure occurs out of your
control, please see the warnings in
the “Recommended solutions for the
problems” section.
• Original packaging and foam
materials should be kept for future
transportations or moving.
Points to be considered
when re-transporting your
refrigerator
1. Your refrigerator must be emptied and
cleaned prior to any transportation.
2. Shelves, accessories, crisper and etc.
in your refrigerator must be fastened
securely by adhesive tape against any
jolt before repackaging.
3. Packaging must be tied with thick
tapes and strong ropes and the rules of
transportation printed on the package
must be followed.
Please remember…
Every recycled material is an
indispensable source for the nature and
for our national resources.
If you wish to contribute to recycling the
packaging materials, you can get further
information from the environmental
bodies or local authorities.
Adjusting the legs
If your refrigerator is unbalanced;
You can balance your refrigerator by
turning the front legs of it as illustrated in
the figure. The corner where the leg exists
is lowered when you turn in the direction
of black arrow and raised when you turn
in the opposite direction. Taking help from
someone to slightly lift the refrigerator will
facilitate this process.

EN
8
Before operating your
refrigerator
Before starting to use your refrigerator
check the following:
1. Is the interior of the refrigerator dry and
can the air circulate freely in the rear of
it?
2. Insert the 2 plastic wedges between
the wires of the condenser as illustrated
in the following figure. Plastic wedges
will provide the required distance
between your refrigerator and the wall
in order to allow the air circulation.
3. Clean the interior of the refrigerator as
recommended in the “Maintenance
and cleaning” section.
4. Plug the refrigerator into the wall outlet.
When the fridge door is open the fridge
compartment interior light will come on.
5. You will hear a noise as the
compressor starts up. The liquid and
gases sealed within the refrigeration
system may also give rise to noise,
even if the compressor is not running
and this is quite normal.
6. Front edges of the refrigerator may
feel warm. This is normal. These areas
are designed to be warm to avoid
condensation.
Electric connection
Connect your product to a grounded
socket which is being protected by a
fuse with the appropriate capacity.
Important:
• The connection must be in compliance
with national regulations.
• The power cable plug must be easily
accessible after installation.
• Voltage and permitted fuse protection
are indicated in the “Specifications”
section.
• The specified voltage must be equal to
your mains voltage.
• Extension cables and multiway plugs
must not be used for connection.
BA damaged power cable must be
replaced by a qualified electrician.
BProduct must not be operated before
it is repaired! There is danger of electric
shock!
Disposing of the packaging
The packing materials may be
dangerous for children. Keep the
packing materials out of the reach of
children or dispose them of by classifying
them in accordance with the waste
instructions. Do not dispose them of
along with the normal household waste.
The packing of your refrigerator is
produced from recyclable materials.
2
1

EN
9
Disposing of your old
refrigerator
Dispose of your old machine without
giving any harm to the environment.
• You may consult your authorized dealer
or waste collection center of your
municipality about the disposal of your
refrigerator.
Before disposing of your refrigerator, cut
out the electric plug and, if there are any
locks on the door, make them inoperable
in order to protect children against any
danger.
Replacing the interior light
bulb
Should the light fail to work, proceed as
follows.
1- Switch off at the socket outlet and pull
out the mains plug.
You may find it useful to remove shelves
for easy access.
2- Use a flat tipped screwdriver to
remove the light diffuser cover.
3- First check that the bulb hasn’t
worked loose by ensuring it is screwed
securely in the holder. Replace the plug
and switch on.
If the bulb works, replace the light cover
by inserting the rear lug and pushing up
to locate the front two lugs.
4- If the light still fails to work, switch
off at the socket outlet and pull out the
mains plug. Replace the bulb with a new
15 watt (max) screw cap (SES) bulb.
5- Carefully dispose of the burnt-out light
bulb immediately.
Replacement light bulb can easily be
obtained from a good local electrical or
DIY store.

EN
10
Reversing the doors
8
5
45 °
(12)
180°
3
2
1
6
4
9
7
10
11
14
12
16
16
13
15
17

EN
11
4Using your refrigerator
Setting the operating
temperature
The interior temperature also
depends on ambient temperature,
the frequency with which the door is
opened and the amount of foods kept
inside.
Frequently opening the door causes
the interior temperature to rise.
For this reason, it is recommended
to close the door again as soon as
possible after use.
Using interior compartments
Freezer compartment : Food that should
be frozen and stored is placed in this
compartment.
Body shelves: Distance between
the shelves can be adjusted when
necessary.
Crisper: Vegetables and fruits can be
stored in this compartment for long
periods without decaying.
Bottle shelf: Bottles, jars and tins can be
placed in these shelves.
The operating temperature is regulated
by the temperature control.
1 = Lowest cooling setting
(Warmest setting)
5 = Highest cooling setting (Coldest
setting)
(Or)
Min. = Lowest cooling setting
(Warmest setting)
Max. = Highest cooling setting
(Coldest setting)
The average temperature inside the
fridge should be around +5°C.
Please choose the setting according
to the desired temperature.
You can stop operation of your device
by adjusting the thermostat knob to
“0” position.
Please note that there will be different
temperatures in the cooling area.
The coldest region is immediately
above the vegetable compartment.
Warm Cold
1 2 3 4 5
(Or) Min. Max.

EN
12
Cooling
Food storage
The fridge compartment is for the short-
term storage of fresh food and drinks.
Store milk products in the intended
compartment in the refrigerator.
Bottles can be stored in the bottle holder
or in the bottle shelf of the door.
Raw meat is best kept in a polyethylene
bag in the compartment at the very
bottom of the refrigerator.
Allow hot foods and beverages to cool to
room temperature prior to placing them
in the refrigerator.
• Attention
Store concentrated alcohol only standing
upright and tightly closed.
• Attention
Do not store explosive substances or
containers with flammable propellant
gases (canned cream, spray cans etc.)
in the device. There is a danger of
explosion.
Defrost
The fridge compartment defrosts
automatically. The thawing water
flows through the drain channel into a
collection container at the rear of the
device.
During defrosting, water droplets form
at the back of the fridge due to the
evaporator.
If not all of the drops run down, they
may freeze again after defrosting remove
them with a cloth soaked in warm water,
but never with a hard or sharp object.
Check the flow of the thawed water from
time to time.It may become plugged
occasionally.

EN
13
5Maintenance and cleaning
ANever use gasoline, benzene or similar
substances for cleaning purposes.
BWe recommend that you unplug the
appliance before cleaning.
• Never use any sharp abrasive
instrument, soap, household cleaner,
detergent and wax polish for cleaning.
• Use lukewarm water to clean the
cabinet of your refrigerator and wipe it
dry.
• Use a damp cloth wrung out in
a solution of one teaspoon of
bicarbonate of soda to one pint of
water to clean the interior and wipe it
dry.
• Make sure that no water enters the
lamp housing and other electrical
items.
• If your refrigerator is not going to be
used for a long period of time, unplug
the power cable, remove all food, clean
it and leave the door ajar.
• Check door seals regularly to ensure
they are clean and free from food
particles.
• To remove door racks, remove all the
contents and then simply push the
door rack upwards from the base.
Protection of plastic
surfaces
• Do not put the liquid oils or oil-cooked
meals in your refrigerator in unsealed
containers as they damage the plastic
surfaces of your refrigerator. In case of
spilling or smearing oil on the plastic
surfaces, clean and rinse the relevant
part of the surface at once with warm
water.

EN
14
6Recommended solutions for the problems
Please review this list before calling the service. It might save you time and money. This list includes
frequent complaints that are not arising from defective workmanship or material usage. Some of the
features described here may not exist in your product.
Complaint Possible Reason Solution
The refrigerator does not
operate
Is the refrigerator properly plugged
in? Insert the plug to the wall socket.
Is the fuse of the socket which your
refrigerator is connected to or the
main fuse blown out? Check the fuse.
Condensation on the
side wall of the fridge
compartment.
Very cold ambient conditions.
Frequent opening and closing of
the door. Highly humid ambient
conditions. Storage of food
containing liquid in open containers.
Leaving the door ajar.
Switching the thermostat to a colder
degree.
Decreasing the time the door left open or
using it less frequently.
Covering the food stored in open
containers with a suitable material.
Wipe the condensation using a dry cloth
and check if it persists.
Compressor is not running
Protective thermic of the compressor
will blow out during sudden power
failures or plug-out plug-ins as the
refrigerant pressure in the cooling
system of the refrigerator has not
been balanced yet.
Your refrigerator will start running
approximately after 6 minutes. Please call
the service if your refrigerator does not
startup at the end of this period.
The fridge is in defrost cycle. This is normal for a full-automatically defrosting refrigerator. Defrosting cycle
occurs periodically.
Your refrigerator is not plugged into
the socket. Make sure that he plug is inserted tightly to the wall socket.
Are the temperature adjustments
correctly made?
There is a power failure. Call your electricity supplier.
The fridge is running
frequently or for a long time.
Your new refrigerator may be wider
than the previous one. This is quite normal. Large refrigerators operate for a longer period of time.
The ambient room temperature may
be high. This is quite normal.
The refrigerator might have been
plugged in recently or might have
been loaded with food.
Cooling down of the refrigerator
completely may last for a couple of hours
longer.
Large amounts of hot food might
have been put in the refrigerator
recently.
Hot food causes longer running of the
refrigerator until they reach the safe
storage temperature.
Doors might have been opened
frequently or left ajar for a long time.
The warm air that has entered into the
refrigerator causes the refrigerator to run
for longer periods. Open the doors less
frequently.
Freezer or fridge compartment door
might have been left ajar. Check if the doors are tightly closed.

EN
15
Complaint Possible Reason Solution
The fridge is running
frequently or for a long
time.
The refrigerator is adjusted to a very
low temperature.
Adjust the refrigerator temperature to
a warmer degree and wait until the
temperature is achieved.
Door seal of the fridge or freezer may
be soiled, worn out, broken or not
properly seated.
Clean or replace the seal. Damaged/
broken seal causes the refrigerator to
run for a longer period of time in order
to maintain the current temperature.
The temperatures are too low
The fridge temperature
very low. The fridge temperature is adjusted to a very low temperature. Adjust the fridge temperature to a warmer degree and check.
Food kept in the fridge
compartment drawers are
freezing.
The fridge temperature is adjusted to
a very low temperature. Adjust the fridge temperature to a warmer degree and check.
The temperatures are too high.
Temperature in the fridge
or freezer is very high.
The fridge temperature is adjusted to
a very high degree. Fridge adjustment
has an effect on the temperature of
the freezer.
Change the temperature of the fridge
or freezer until the fridge or freezer
temperature reaches to a sufficient level.
Doors might have been opened
frequently or left ajar for a long time.
Warm air rushes into the fridge or
freezer when the doors are opened.
Open the doors less frequently.
The door might be left ajar. Close the door completely.
Large amounts of hot food might
have been put in the refrigerator
recently.
Wait until the fridge or freezer reaches
the desired temperature.
The refrigerator might have been
plugged in recently.
Cooling down of the refrigerator
completely takes time because of the
size.

EN
16
Complaint Possible Reason Solution
Noise
The operation noise
increases when the
refrigerator is running.
The operating performance
characteristics of the refrigerator
may change according to
the changes in the ambient
temperature.
It is normal and not a fault.
Vibrations or noise.
The floor is not even or it is weak.
The refrigerator rocks when moved
slowly.
Make sure that the floor is level, strong
and capable to carry the refrigerator.
The noise may be caused by the
items put onto the refrigerator. Such items should be removed from the top of the refrigerator.
There are noises
like liquid spilling or
spraying.
Liquid and gas flows happen in
accordance with the operating
principles of your refrigerator. It is normal and not a fault.
There is a noise like
wind blowing.
Air activators (fans) are used in
order to allow the refrigerator to
cool efficiently. It is normal and not a fault.
Water/condensation/ice in the refrigerator.
Condensation on
the inner walls of
refrigerator.
Hot and humid weather increases
icing and condensation. It is normal and not a fault.
The doors are ajar. Make sure that the doors are closed
completely.
Doors might have been opened
very frequently or they might have
been left open for along time. Open the door less frequently.
Water/condensation/ice on the outside of the refrigerator.
Humidity occurs on
the outside of the
refrigerator or between
the doors.
The weather may be humid. This is quite normal in humid weather. When the humidity is less, condensation
will disappear.
Bad odor inside the
refrigerator.
Inside of the refrigerator must be
cleaned. Clean the inside of the refrigerator with a sponge, warm water or carbonated water.
Some containers or packaging
materials might be causing the
smell.
Use a different container or different brand
packaging material.

EN
17
Complaint Possible Reason Solution
Opening and closing of
the doors
The door(s) is (are) not
closing.
Food packages may prevent the
door’s closing. Replace the packages that are obstructing the door.
The refrigerator is probably not
completely vertical on the floor and
it might be rocking when slightly
moved.
Adjust the elevation screws.
The floor is not level or strong. Make sure that the floor is level and capable
to carry the refrigerator.
Crisper(s) are stuck.
The food might be touching the
ceiling of the drawer. Rearrange food in the drawer.

DA
1
Læs venligst denne vejledning først!
Kære kunde
Vi håber, at dit produkt, der er produceret i moderne produktionsanlæg og
kontrolleret under de grundigste kvalitetskontrolprocedurer, vil give yde dig en effektiv
service.
Derfor anbefaler vi dig grundigt at læse hele vejledningen for produktet, inden du
tager det i anvendelse, og gemmer det tilgængeligt for fremtidige opslag.
Denne vejledning
• Vil hjælpe dig med at bruge køleskabet hurtigt og sikkert.
• Læs denne vejledning, inden du installerer og betjener produktet.
• Følg instruktionerne, især sikkerhedsinstruktionerne.
• Opbevar denne manual på et nemt tilgængeligt sted, da du kan få brug for den
senere.
• Derudover skal du også læse de andre dokumenter, der er fulgt med produktet.
Bemærk at denne vejledningen også kan være gældende for andre modeller.
Symboler og deres beskrivelse
Denne brugsvejledning indeholder følgende symboler:
CVigtige informationer eller brugbare tips.
AAdvarsel mod farlige forhold for liv og ejendom.
B Advarsel mod strømspænding.
Dette produkt bærer symbolet for selektiv sortering af affald fra elektrisk og elektronisk
udstyr (WEEE).
Det betyder, at dette produkt skal håndteres i henhold til det Europæiske Direktiv
2002/96/EC for at blive genanvendt eller afmonteret for at minimere påvirkningen af
miljøet. For yderligere information bedes du kontakte de lokale myndigheder.
Elektroniske produkter, der ikke er omfattet af den selektive sorteringsproces, er potentielt
farlige for miljøet og menneskets sundhed pga. af tilstedeværelsen af farlige substanser.
Genvinding

DA
2
INDHOLD
1 Køleskabet 3
Tekniske specifikationer for køleskabet...4
2 Advarsler 5
Generel sikkerhed...................................5
Opstart...................................................6
Hvis der er børn hjemme... .....................6
Tilsigtet brug...........................................6
Sikkerhedsinstruktioner...........................6
Energibesparende foranstaltninger..........6
3 Installation 7
Tilberedning............................................7
Punkter, der skal tages hensyn til, hvis
køleskabet skal transporteres igen..........7
Justering af fødder..................................7
Inden køleskabet betjenes ......................8
Elektrisk tilslutning ..................................8
Bortskaffelse af emballagen....................8
Bortskaffelse af det gamle køleskab........9
Udskiftning af den indvendige lyspære ...9
Vende dørene.........................................10
4 Anvendelse af køleskabet 11
Indstilling af driftstemperaturen ...............11
Driftstemperaturen reguleres ved
temperaturstyringen................................11
Anvendelse af de indvendige rum ...........11
Køling.....................................................12
Afrimning................................................12
5 Vedligeholdelse og
rengøring 13
Beskyttelse af plasticoverflader ..............13
6 Anbefalede løsninger på
problemerne 14
