Blonder tongue MRT1000 User manual

MRT1000MRT1000
Stock # Model Name Description
1002661A MRT1000 Modular Receiver Trancoder
All Rights Reserved. Specifications subject to change without notice. All trademarks are property of their respective owners.
© Blonder Tongue Labs, Inc. ISO 9001:2015 Certified P/N: 651243900B |Rev: 122019

2MRT1000
User Manual
Returning Product for Repair (or Credit)

 Before returning product, please contact the Blonder Tongue Service
Department at 1-800-523-6049, Ext. 4256 or visit our website: 








located beneath the product image. 





Blonder Tongue Laboratories, Inc.
One Jake Brown Road
 

Printed in the United States of America.

be the proprietary property of the registered owners.

intellectual property rights. Reverse engineering or disassembly is prohibited.




3MRT1000
User Manual

 4
 6
 .............................................................................................................................. 6
................................................................................................................... 6
.................................................................................................................................... 
 8
 ............................................................................................................................................................. 8
 ............................................................................................................................ 8
............................................................................................................................ 8
.............................................................................. 9
 
.......................................................................................................................................................... 10
..................................................................................................................................................... 11
................................................................................................................................................... 12
........................................................................................................................................................ 12
 
......................................................................................................................................................... 13
 ....................................................................................................................................................... 14
 ............................................................................................................................................................... 15
.................................................................................................................................... 16
 ............................................................................................................................................ 

4MRT1000
User Manual

product is operated.

reference.

adhered to.

—Unplug this product from the wall outlet before cleaning. Do not use liquid
cleaners or aerosol cleansers. Use a damp cloth for cleaning.
-
facturer as they may cause hazards.
—Do not use this product near water—for example, near a bathtub,
wash bowl, kitchen sink or laundry tub; in a wet basement; or near a swimming pool; and
the like.
—Do not place this product on an unstable cart, stand, tripod, bracket, or

to the product. Use only with a cart, stand, tripod, bracket, or table recommended by the


manufacturer.




must not be blocked or covered. The openings should never be blocked by placing the
product on a bed, sofa, rug, or similar surface. This product should not be placed in a built-in
-

—This product should be operated only from the type of power source
indicated on the marking label. If you are not sure of the type of power supplied to your
home, consult your product dealer or local power company. For products intended to oper-

—This product may be equipped with a polarized alternat-

the power outlet only one way. This is a safety feature. If you are unable to insert the plug

electrician to replace your obsolete outlet. Do not defeat the safety purpose of the polarized
plug. Alternate Warnings—If this product is equipped with a three-wire grounding-type

outlet. This is a safety feature. If you are unable to insert the plug into the outlet, contact
your electrician to replace your obsolete outlet. Do not defeat the safety purpose of the
grounding-type plug.
—Power-supply cords should be routed so that they are not


product.
—If an outside antenna or cable system is connected to the


-
-

requirements for the grounding electrode. See Figure A.


disconnect the antenna or cable system. This will prevent damage to the product due to
lightning and power-line surges.
—An outside antenna system should not be located in the vicinity of over-
head power lines, other electric light or power circuits, where it can fall into such power lines
or circuits.
—Do not overload wall outlets, extension cords, or integral convenience

-


-

service personnel.
—Unplug this product from the wall outlet and refer servicing

 When the power-supply cord or plug is damaged,

 If the product has been exposed to rain or water,

-


 If the product has been dropped or damaged in any way, and

service.
—When replacement parts are required, be sure the service techni-
-

hazards.



—The product should be mounted to a wall or ceiling only as
recommended by the manufacturer.
—The product should be situated away from heat sources such as radiators, heat













WIRE








ELECTRIC
SERVICE















CAUTION STATEMENT




literature accompanying the appliance.



persons.
 


 



MRT1000
User Manual


-




suivies.








ou une table instables. L’appareil pourrait tomber, entraînant des blessures graves à un
enfant ou à un adulte, et des dommages importants à l’appareil. Employer seulement avec









-










-






-





-








fatal.


d’une telle surcharge.



l’appareil.



-












-








-
-
teurs) produisant de la chaleur.









Exemple de mise à la terre d’antenne selon le Code É


WIRE






APPAREILS

DE SERVICE

MISE À LA TERRE

MISE À LA TERRE














de l’appareil et le chariot.



ATTENTION DÉCLARATION
 


 







6MRT1000
User Manual




• 
• 
• 


The 


tunes to the Satellite Transponder to provide the required Out-of-Band data.


Electronic Program Guide and other data signaling used in the system.
1 2 3



(i) AC power is not connected, or






Subnet Mask = 255.255.255.0




1
2
3

7MRT1000
User Manual






4
5
7
6
654
7

Satellite Input
Connector:
Frequency Range:
Input Impedance:
Return Loss:
Input Level Range:
Modulation:
Format:
Symbol Rate:
1x “F” Female (Rear-Panel)
950 to 2150 MHz
75 Ω
10 dB
-25 dBm to -65 dBm / Transponder
QPSK, 8PSK
DVB-S2, advanced Turbo modes
2 to 45 MSymbols/sec (Mbaud)
Output Mode:
Symbol Rate:
Frequency Range:
Max. Power Output Level:
Level Adjustment Range:
Phase Noise:
Broadband Noise:
MER:
Channel Frequency Response:
SCTE 55-1
1.024 Ms/s
70-130 MHz (tunable in 50 kHz steps)
+40 dBmv
15 dB
-95 dBc @ 10 kHz offset
-75 dBc @ > ± 12 MHz
> 30 dB equalized
< 1 dB
QPSK Modulator Output
Connector: Not Applicable on this Model.
ASI Output
Alarms/Monitoring/Control
Local Monitoring: 1x Power LED
Local Control: 1x IP Reset Button (Front-Panel)
Remote Monitoring/
Control:
1x RJ45; 10/100/1000Base-T Ethernet
(Front-Panel) (GUI-based menu via Web browser)
General
Dimensions:
(W x D x H)
19.0” x 14.5” x 1.75”
(482.6 mm x 368.3 mm x 44.45 mm)
Weight: 8.35 lbs (3.79 kg)
Power Requirements: 100-120 VAC/60 Hz, 20 W
Operating Temperature: 32 to 122 ˚F (0 to 50 ˚C)
Storage Temperature: -13 to 158 ˚F (-25 to 70 ˚C)
Operating/Storage Humidity: 0 to 95% RH @ 35 ˚C max
non-condensation

8MRT1000
User Manual



• 
• 

(Chrome or Firefox
is recommended)

Connect one end of the Ethernet cable to the 
other end of the Ethernet cable to your computer.


The following steps explain how to do this for a computer with ,  or 

(Note: It can be found using the search box in the Start Menu or for Windows 8.x, the Start Screen)










1
2






1
2




9MRT1000
User Manual
Open a web browser on your computer (Chrome or Firefox is recommended)
and enter the following URL address 
(Figure 3.4a) will appear.

click on the [
 When logged in as Admin, the user has read and write permission. Only

Username =  (case-sensitive)
Password =  (case-sensitive)
1
2

 before proceeding as follows:


in Figure 3.4b
• 
• 
• 
alongside the [




{

 MRT1000
User Manual





1
2
3
5
6
4
Secon 6

 Displays the modules installed for each slot. (
 Displays the module type that is installed into each slot. For the MRT1000, the module installed in Slot 1 is SDM1000.

not appear, refresh the page)

Secon 5.3
1
2
5
6
3
4
