bloom zen User manual

TM
user guide
zen
all-terrain stroller / poussette
tout-terrain / cochecito todo terreno

x 2
#01 – frame body #02 – seat
#04 – basket #05 –canopy #06 – canopy ribs #07 – canopy adapters
#03 – seat cushions
i1
part list
illustrations

frame details
a
b
c
d
efgh
i
j
k
l
m
n
o
frame details
a front handle
b headlight
c frame fold lock lever
d connectors for canopy, yoga newborn
nest & car seat
e light-on indicator
f handlebar angle adjustment buttons
g driving light button
h warning light button
i seat recline zippers
j side zippers for folding backrest
k aligning hook
l aligning cap
m parking brake pedals
n anti-slip stopper
o lighting system main power button
i 2

i 3
to unfold
to attach safety harness set to backrest
4
1
3
2

i 4
to install seat
7 8
5 6

i 5
to install seat cushions
to install basket
9
11
10
12

i 6
x 2
to install canopy
2016
1413
15

i 7
to use canopy
to recline backrest
to use harness
17 18
2019

i 8
to use headlight
to brake
23 24
21 22

i 9
to fold
27 28
25 26

i 10
29
31
30

Instructions – eng
Instructions – fr
Instrucciones – es
1-6
7-13
14-20
contents

1
eng
IMPORTANT – RETAIN
FOR FUTURE REFERENCE:
READ CAREFULLY BEFORE
ASSEMBLY AND
USE OF PRODUCT.
Please remove all packaging materials
before use.
Age Recommendation
Recommended for use between newborn and
44lbs / 20kg in weight or 39¼”/ 100cm in height.
Product Information
This stroller has been designed and tested to
ensure compliance with the latest relevant safety
standards.
• Solar energy powered lighting system for
warning light and driving light
• 3 seat recline positions
• designed to use with yoga newborn nest for
children aged between newborn to 6 months
• A range of accessories are available, check with
your nearest bloom retailer for more details.
• car seat adapters are available as an
accessory to use with a range of infant car
seats. check with your nearest bloom retailer
for more details.
Model No.: 10103
Colour & contents may vary
Instructions for Safe Use – Please read
carefully and keep for future reference
The correct use and maintenance of your stroller
will ensure it gives long and trouble-free use. When
somebody else is using your stroller please ensure
they also know how to use it, how to adjust it and
the necessary safety precautions. The safety of your
child is your responsibility.
NOTE: Adult assembly required.
Section A: Installation
To unfold
– (#01 – frame body: c – frame fold lock lever,
a – front handle) Push Frame fold lock lever
outward and turn front handle to allow frame
and wheels to spread open automatically.
(refer to illustration 1)
– Push stroller downward until the seat and
wheel frames click into locking position. You
will hear an audible click. (refer to illustration 2)
– Rotate frame to rest the wheels on the
ground.
– (f – handlebar angle adjustment buttons)
Simultaneously press the two buttons at the
center of handlebar, and rotate handlebar to
desired angle. (refer to illustration 3)
To attach safety harness set to backrest
– (#02 – backrest) Pass either side of waist
straps through the two loops on the lower
part of backrest and the frame anchor strap

2
eng
through the opening on backrest.
– Pass end of the crotch strap through the two
openings in the seat, then pass through the
lower opening on backrest to the rear side.
(refer to illustration 4)
– Connect crotch strap end to frame anchor
strap by threading the fabric loop on anchor
strap to the metal ring. (refer to illustration 5)
– Please make sure harness buckles are in
correct orientation.
To install seat
– Slide the two plastic guiders on either sides
of backrest into the grooves of seat frame
simultaneously all the way to the bottom.
(refer to illustration 6)
– Fasten the two elastic loops on either side
of backrest to the handlebar pivots. (refer to
illustration 7)
– Tug plastic guide on the front edge of seat
fabrics under seat base. (refer to illustration 8)
– Fasten the two buttons on the front side of
seat to footrest. (refer to illustration 8)
– Mount seat fabrics onto stroller seat base by
fastening the three elastic loops onto plastic
hooks located under seat base. (refer to
illustration 9)
– Fasten the elastic on the end of anchor strap
to the plastic hook located under seat base.
(refer to illustration 9)
To attach seat cushions
– (#03 – seat cushions) Place back cushion
on backrest and seat cushion on seat base.
(refer to illustration 10)
– Pass the two shoulder straps through upper
openings and the waist straps through lower
openings of back cushion.
– Pass crotch strap through opening of seat
cushion. (refer to illustration 11)
To install basket
– (#04 – basket) Thread the two elastic loops
on basket through slots located at the back
of the frame’s central node, then fasten onto
catches. (refer to illustration 12)
– Fasten all snap buttons on the basket to
chassis. (refer to illustration 13)
– Use strap underneath the basket to secure
brake cables. (refer to illustration 13)
To install canopy
– (#05 – canopy, #06 – canopy ribs) Insert the
two plastic ribs through channels in canopy
fabric. (refer to illustration 14)
– (#07 – canopy adapters) Insert ends of the ribs
into canopy adapter slots and attach elastic
loops to the reels. (refer to illustration 15)
– Slide canopy adapters onto connectors
located on both sides of seat frame. (refer to
illustration 16)
– On the back of the canopy, fasten the three
snap buttons and fix the four velcro on
canopy to the backrest. (refer to illustration 17)
Section B: On Usage
To use canopy
– The canopy can be adjusted to 3 positions:
retracted, half opened, fully opened. Make

3
eng
press button marked with a road light sign.
(refer to illustration 23)
To brake
– (m – parking brake pedals) To engage parking
brakes, push down either left or right pedal.
– To disengage parking brakes, push up either
left or right pedal. For safety, lock parking
brakes when placing or removing your child,
or when installing accessories. (refer to
illustration 24)
To fold
– Unhook the two elastic loops on handlebar
pivots and pull down the two zippers
completely. Fold down upper part of backrest
along with canopy. (refer to illustration 25)
– Hold loose fabrics and seat cushions in place
by connecting the elastic strap under seat to
elastic strap on the back of backrest. If folding
without canopy on, hold loose fabrics in place
by connecting the elastic strap under seat
direct to the catch on the back of backrest.
(refer to illustration 26 & 27)
– Simultaneously press the two buttons at the
center of handlebar, and rotate handlebar
down all the way. (refer to illustration 28)
– (a – front handle, n – anti-slip stopper) Using
front handle, rotate stroller frame, so that the
back wheels and anti-slip stoppers are on the
ground. (refer to illustration 29)
– Standing on the seat frame side, push the white
unlocking lever outward then hold bottom of
footrest and lean the seat frame towards you,
until seat frame is leaning approximately 30
sure the button on top of the canopy is
undone before fully opening canopy. (refer to
illustration 18)
To use and adjust safety harness
– To lock harness, push the tongues on ends
of waist straps, connected with the ends of
shoulder straps, into the buckle on crotch
strap.
– To unlock harness, press the central button.
(refer to illustration 19)
– NOTE: Every time you place your child in the
stroller or whenever you alter the position
of the seat, always check that the harness
is correctly fitted. Tighten harness until it fits
snugly around your child.
To recline backrest
– (i – seat recline zippers) Unzip the pair of
zippers on both sides of backrest for half
recline position. (refer to illustration 20)
– Unzip the inner pair of zippers for full recline
position. (refer to illustration 21)
To use headlight
– (o – lighting system main power button) To
turn lighting system power on, press button
located underneath the frame’s central node.
Press again to turn off. (recommended after
each usage). (refer to illustration 22)
– (h – warning light button, g – driving light
button) To use warning light, on handlebar,
press button marked with parking light sign
(triangle). To use driving light, on handlebar,

4
eng
degrees. (refer to illustration 30)
– (k – aligning hook, l – aligning cap) Press
down gently on front handle until all three
wheels fold entirely flat. You will hear an
audible click. Make sure that the two fold
locks located on either sides are securely
fitted to ensure stroller is folded properly. The
fold lock has two parts with white markings.
The hook on the seat frame must fit into the
cap by back wheel. (refer to illustration 30 &
31)
WARNING:
• WARNING: Failure to follow these
warnings and the instructions could result in
serious injury or death.
• WARNING: Never leave child unattended.
• WARNING: To avoid serious injury from
falling or sliding out, always use the safety
harness.
• never attach any bags, packages or similar
items to your zen stroller frame, other than
products that are recommended by bloom,
as this may cause the stroller to become
unstable. Do not hang items or loads to the
handlebars or carry shopping bags on the
stroller except in the strollers basket.
• Maximum load of basket is 4.4lbs / 2kg.
Overloading may cause the stroller to
become unstable, and may damage the
stroller.
• For child aged from newborn to 6 months,
always use yoga newborn nest with the
stroller.
• Always use the crotch strap harness in
combination with the waist and shoulder
belt. Make sure the harness is correctly
fitted before use.
• Do not use any spare parts or accessory
other than those approved or provided by
bloom.
• Always make sure all locking devices are
properly engaged before use.
• Always activate the parking brake when the
stroller is standing still.
• This product is not suitable for running and
skating.
• To prevent any risk of strangulation, keep
any loose cords away from child.
• When folded, make sure the stroller is
stored in a place where it does not risk to
fall over a child.
• STRANGULATION HAZARD:
– Strings can cause strangulation! Do not
place items with a string around a child’s
neck, such as hood strings or pacifier
cords.
– Never leave child in carrier when straps
are loose and undone.
• caution: to prevent finger trap during folding
and unfolding, an extra care must be taken.
WARNING for stroller:
• Do not carry additional children.
• Never use the stroller for child over 44lbs /
20kg in weight or 39¼”/ 100cm in height.
• Do not use this stroller if any part is
damaged or broken.

5
eng
• Keep the stroller away from open fire,
heaters and other sources of strong heat.
WARNING for newborn nest:
• yoga newborn nest is designed for one child
only.
• yoga newborn nest is suitable for children
up to 20 lbs / 9 kg.
• Never use for a child able to sit up
unassisted.
• FALL HAZARD
– To help prevent falls, do not use this
product when the infant begins to push
up on hands and knees or has reached
20 lbs / 9kg, whichever comes first.
– Child’s activity may move bouncer. Use
only on floor. Never use on any elevated
surface.
• SUFFOCATION HAZARD
– Infants can suffocate: In gaps between an
extra pad and side of yoga newborn nest
and on soft bedding .
– NEVER add a mattress, pillow, comforter,
or padding. Use ONLY the pad provided
by bloom.
– Never use on a soft surface (bed, sofa,
cushion), as seat may tip over and cause
suffocation.
• To reduce the risk of SIDS, pediatricians
recommend healthy infants be placed
on their backs to sleep, unless otherwise
advised by your physician.
• If a sheet is used with the pad, use only the
one provided by bloom or one specifically
designed to fit the dimension of the bassinet
or cradle mattress.
• yoga newborn nest can be used only in
combination with zen stroller.
• yoga newborn nest is not intended for
prolonged periods of sleeping.
• Never use yoga newborn nest as a means
to transport an infant in a motor vehicle.
• Do not use yoga newborn nest if fail to
follow the accompanying instruction exactly.
• To prevent finger entrapment, care must be
taken when folding and unfolding the yoga.
• Check yoga newborn nest regularly before
using it and do not use it if any parts are
loose or missing or if there are any signs of
damage. Do not substitute parts. Contact
bloom if replacement parts or additional
instructions are needed.
Care & Maintenance
When cleaning your stroller, use a non-toxic,
non-abrasive cleaner. Mix a solution of water
with a small amount of a mild, non-toxic
detergent. Apply to stroller surface with a damp
cloth. Never use strong detergents or solvents for
cleaning.
If you need to put your stroller in storage for any
period of time, do not store them in a damp
or hot environment. Allow air flow around the
stroller and do not stack anything on it.
In case of rain, use the rain cover. Carefully wipe
the stroller dry before storing it.
Check List
The stroller is ready for use only when the

6
eng
locking mechanisms are engaged. Please check
carefully that they are fully engaged before
using the stroller.
Always check the frame is free from damage
before use. Do not use product if any part is
damaged or broken.
Regularly check that all assembly fittings are
always tightened properly and retighten as
necessary.
After Sales Service
When you receive your bloom product, if you
need assistance, spare parts or if you have
any comments with respect to any aspect of
the goods please contact bloom by email at
[e-mail]. Our trained advisors
will be able to help. You can also visit our
website at bloombaby.com for latest product
information.
Your feedback and input enables bloom to
continue to make improvements. Please send
your comments regarding this product to
[e-mail].

7
fr
IMPORTANT – CONSERVEZ
CE MANUEL POUR
CONSULTATIONS
FUTURES: LISEZ CE
MANUEL ATTENTIVEMENT
AVANT ASSEMBLAGE
ET UTILISATION DE CE
PRODUIT.
Enlevez tout emballage avant utilisation.
Recommandations d’âge et de poids
Recommandé pour des enfants de la naissance
jusqu’à 44lbs / 20kg, ou d’une taille supérieure
à 39¼”/ 100cm.
Informations produit
Cette poussette a été conçue et testée pour être
en conformité avec les normes de sécurité en
vigueur.
– Système d’éclairage LED avec fonction
clignotante, breveté internationalement,
fonctionnant à l’énergie solaire.
– Dossier inclinable 3 positions.
– Conçue pour être utilisée avec la nacelle pour
nouveau-né yoga, pour les enfants de la
naissance à 6 mois.
– Pour découvrir la gamme d’accessoires
disponibles, adressez-vous à votre revendeur
bloom.
– Des adaptateurs pour siège auto sont fournis
en option (plusieurs modèles disponibles).
Liste des composants (cf. page i1):
#01 – cadre
#02 – l’assise
#03 – coussins d’assise
#04 – panier
#05 – capote
#06 – arceaux de capote
#07 – adaptateurs de capote
Eléments du cadre (cf. page i2):
a Poignée frontale
b Eclairage
c Levier de déverrouillage
d Connecteurs pour la capote, la nacelle yoga
ou un siège auto
e Voyant d’allumage de l’éclairage
f Boutons de réglage du guidon
g Bouton d’éclairage fixe
h Bouton d’éclairage clignotant
i Fermetures à glissière pour l’inclinaison du
dossier
j Fermetures à glissière latérales pour rabattre
le dossier
k Crochet d’alignement
l Capuchon d’alignement
m Pédales de frein
n Patin anti-dérapant
o Interrupteur du système d’éclairage
Numéro de modèle: 10103

fr
8
Fixation du harnais de sécurité au dossier
– (#02 – dossier) Faire passer l’une des
extrémités de la sangle de ceinture au travers
des deux passants situés dans la partie
inférieure du dossier, et faire passer le bout
de sangle en partie inférieure à travers la
boutonnière la plus haute située dans le
dossier.
– Faire passer l’extrémité de la sangle
d’entrejambe à travers les deux boutonnières
de l’assise, puis la faire ressortir à l’arrière du
dossier à travers la boutonnière la plus basse.
(cf. illustration 4)
– Relier l’extrémité de la sangle d’entrejambe
à la sangle de fixation au cadre, en enfilant
la boucle de cette dernière dans l’anneau
métallique. (cf. illustration 5)
– S’assurer que les boucles du harnais sont
orientées correctement.
Installation de l’assise
– Faire glisser les deux guides en plastique
situés de part et d’autre du dossier à
l’intérieur des gorges situées à l’arrière
des montants du cadre, simultanément et
jusqu’en bas (cf. illustration 6).
– Fixer les deux élastiques de chaque côté du
dossier aux pivots du guidon (cf. illustration 7).
– Insérer sous le siège rigide la bande plastique
bordant l’avant de l’assise textile. (cf.
illustration 8)
– Fixer au repose-pied les deux boutons
pression situés de chaque côté de l’assise (cf.
illustration 8).
– Recouvrir le siège rigide de la poussette avec
Les couleurs et les contenus peuvent varier
Conseils de sécurité – Lire
attentivement et garder pour une
consultation future.
La bonne utilisation et le bon entretien de votre
poussette vous garantiront une utilisation de
longue durée et sans problèmes. Si une autre
personne utilise votre poussette, assurez-vous
qu’elle sache également comment l’utiliser et la
configurer, et qu’elle ait connaissance de toutes
les consignes de sécurité. La sécurité de votre
enfant est de votre responsabilité.
NOTE: Montage par un adulte nécessaire.
Section A: Mise en service
Dépliage
– (#01 – cadre : c- levier de déverrouillage,
a – poignée frontale) Ecarter le levier
de déverrouillage blanc, et faire pivoter
la poignée frontale, afin de permettre
au cadre et aux roues de se déployer
automatiquement. (cf . illustration 1)
– Reposer la poussette sur le sol jusqu’à
entendre un click, indiquant que le cadre et
le châssis sont correctement verrouillés. (cf.
illustration 2)
– Faire basculer la poussette sur ses roues
– (f – boutons de réglage du guidon) Presser
simultanément les deux boutons au centre
du guidon, et faire pivoter jusqu’à la position
souhaitée. (cf. illustration 3)
