blossom-ic MAGELAN Sensor User manual
MAGELAN Sensor
Assembly instructions
intelligent | economic | cost-saving | individual | exible | user-friendly | smart | protable | innovative
1.0
Version
blossom-ic radio and app controlled motion detector.
The motion Sensor is used to monitor individual rooms against the or for
circulation pump control. For additional coverage of individual rooms, if
there are no blossom-ic thermostats should be installed there. Can be used
in combination with the Magelan Siren for an in-house alarm system. In
combination with Gateway GT-100.
Brief description:
blossom-ic GmbH & Co. KG |Intelligent Controls
2
Contents...
Connection of the Gateway GT-100 ............3
Registration of the Sensor .......................3
Control via blossomic app ........................ 4
Technical data...................................... 5
Safety instructions ............................... 5
Declaration of conformity ........................ 5
Warning notice .................................... 5
Intended Use....................................... 5
Assembly instructions: Magelan Sensor 3
Connection of the Gateway GT-100
Screw on the antenna Connect power supply unit Connect the network cable
Both diodes light up
permanently: Gateway active
Check status
Green diode lights up constantly: Internet
connection is establishing.
Green diode lights up constantly: Internet
connection is successfully established
1. 2. 3.
4. 5. Hint:
Functionality in the home safe area. Internet
connection is used for convenient setting
and control via smartphone.
The system functionality is guaranteed even
if no Internet connection is available.
Registration of the Sensor
Press the „Register“ button on
the gateway
Press the „Register“ button on
the Sensor for 3 seconds
LED on Sensor starts flashing,
Sensor registers
1. 2. 3.
blossom-ic GmbH & Co. KG |Intelligent Controls
4
LED on the Sensor lights up
continuously => The registration
was successful
4. Note:
If the LED on the Sensor goes o => The reg-
istration has failed
1
2
3
4
1
2
3
4
5
6
Security system
When a Siren is registered, this icon
appears in the system overview
Note
When the security system is activat-
ed and movement is detected, the
Siren will sound a warning signal for
15 seconds. If the security system is
not deactivated during this time, the
alarm will sound.
Activate / deactivate
Naming the Siren
Alarm was triggered
Living room is active, no
movement in the room
Detection
Selection of devices (thermostat,
motion Sensor) for detection
Save changes
Overview of all
available thermostats
Activate devices for
alarm function
Device is ONLINE and
therefore available for
alarm system
Save changes
All changes must always be con-
firmed
System overview
Device control
Radiator Underfloor Boiler
Leakage
system
Security
system
PI-SensorBlinds Socket
Help
PDF Manuals
system Fan-Coil
Security system
Security system On
Bedroom ID: 1
Alarm
Living room ID: 8
Submit
Online On
Siren
House 2 ID: 13
6
3
1
2
4
5
Submit
Top floor Marius ID: 1
PI-Sensor / Living room ID: 3
Bathroom ID: 8
Kitchen ID: 3
Online
Online
Online
Online
4
3
1
2
Control via blossomic app
Assembly instructions: Magelan Sensor 5
Attention! Important Note:
Installation and assembly of electrical devices may only be carried out by a qualified electrician. Failure to observe the assembly and installa-
tion instructions can result in fire or other dangers.
Safety instructions
Hereby blossom-ic GmbH & Co. KG hereby declares that the following product: Magelan Sensor MSE-3967 is in conformity with the essential
requirements and the other relevant provisions of Directive 2014/53/EU. The complete declaration of conformity can be found at the following
address: www.blossomic.de/downloads Declaration of Conformity.
Declaration of conformity
The Sensor is not suitable for children and must not be used as a toy. Store and dispose of packaging materials in a child-resistant manner.
Do not disassemble the Sensor, as it does not contain any user-serviceable parts. If defects occur, please return the Sensor to the dealer. This
device can be used by children over 8 years of age and by persons with reduced physical, Sensory or mental abilities or lack of experience and
knowledge, if they have been supervised or instructed in the safe use of the device and understand the resulting dangers. Children must not
play with the device. Cleaning and user maintenance must not be performed by children without supervision.
Warning notice
The Sensor is only suitable for additional monitoring of large rooms and as a Sensor in rooms in which no blossom-ic thermostats are installed.
Intended Use
Technical data
Technical data - Magelan Sensor
Ambient temperature
Ambient humidity
Power
Dimension
Wireless frequency
Protection class
RF-Test
CE
RoHs
Type of antenna
0 ~ 50°C
90% (non-condensing)
10-year-battery Lithium 3.6V
Ø 75 mm x H37 (mm)
2.4GHz, ISM Band, 16 channels
IP 30
RED 2014/53/EU
Available
Available
PCB antenna
blossom-ic GmbH & Co. KG |Intelligent Controls
6
Notes
Assembly instructions: Magelan Sensor 7
Notes
blossom-ic GmbH & Co. KG
Oberer Buxheimer Weg 60, 87700 Memmingen, Germany
P: +49 8331-756 965 80 E: [email protected]
W: www.blossomic.de
