Blu Stream Multicast ACM200 User manual

Blustream Multicast
ACM200 - Advanced Control Module
User Manual
Video LAN(PoE) Control LAN IR Ctrl
IR
5V 12V DC 12V
Power
Link Link
PoE
IO Level
Reset
VOut
IO4 IO3 IO2 IO1
5VNormal
RS-232
MCU
12V
ACM200
Yellow Green Yellow Green
MULTICAST
Revision 1.0 - January 2019

ACM200 USER MANUAL
02 www.blustream.co.uk / www.blustream.com.au
Surge protection device
recommended
This product contains sensitive electrical
components that may be damaged
by electrical spikes, surges, electric
shock, lightning strikes, etc. Use of
surge protection systems are highly
recommended in order to protect and
extend the life of your equipment.
Safety and performance notice
Do not substitute or use any other power
supply other than approved PoE network
products or approved Blustream power
supplies.
Do not disassemble the ACM200 unit
for any reason. Doing so will void the
manufacturer’s warranty.
Contents
Thank you for purchasing
this Blustream product
For optimum performance and safety,
please read these instructions carefully
before connecting, operating or adjusting
this product. Please keep this manual for
future reference.
Introduction 03
Features 03
Panel Descriptions - ACM200 04
ACM200 Control Ports 05
ACM200 Control Ports - IR Control 06
ACM200 Network Connection - Schematic Diagram 07
Web-GUI Guide Overview 08
Web-GUI - Log In 08
Web-GUI - New Project Set-up Wizard 09 - 13
Web-GUI - Menu Overview 14
Web-GUI - Drag & Drop Control 15
Web-GUI - Video Wall Control 16
Web-GUI - Preview 17
Web-GUI - Project Summary 18
Web-GUI - Transmitters 19 - 20
Web-GUI - Transmitters - EDID Help & EDID Copy 21
Web-GUI - Receivers 22 - 23
Web-GUI - Receivers - Scaling Help & OSD Help 24
Web-GUI - Fixed Signal Routing 25
Web-GUI - Fixed Routed Audio & IR 26
Web-GUI - Fixed Routed USB / KVM & CEC 27
Web-GUI - New Video Wall Configuration 28 - 32
Web-GUI - Existing Video Wall Configuration 33
Web-GUI - Users 34 - 35
Web-GUI - Settings 36 - 37
Web-GUI - Update Firmware 38 - 40
Web-GUI - Update Admin Password 40
RS-232 (Serial) Routing 41
Specifications, Package Contents & Maintenance 42
Blustream IR, RS-232 & Telnet Commands 43 - 52
Troubleshooting 53
Computer Settings - enabling TFTP & Telnet 54 - 57
Notes 58

ACM200 USER MANUAL
03contact [e-mail] / [e-mail]
Introduction
Impotant Note:
The Blustream Multicast system distributes HDMI video over Layer 3 Managed network hardware. It is advised that
Blustream Multicast devices are connected on an independent network switch to prevent unnecessary interference,
or reduction in signal performance due to other network devices bandwidth requirements.
Please read and understand the instructions in this manual and ensure that the network switch is configured
correctly prior to connecting any Blustream Multicast devices. Failure to do so could result in problems with
configuration of the system and video performance.
• Web interface module for configuration and control of the Blustream Multicast system
• Intuitive 'Drag & Drop' source selection with video preview feature for active monitoring of system status
• Advanced signal management for independent routing of Video, Audio, IR, RS-232, USB/KVM & CEC.
• Auto system configuration
• 2x RJ45 LAN connections to bridge existing network to Multicast video distribution network, resulting in:
- Better system performance as network traic is separated
- No advanced network setup required
- Independent IP address per LAN connection
- Allows simplified TCP / IP control of Multicast system
• RS-232 integration for control of Multicast system
• IR integration for control of Multicast system
• PoE (Power over Ethernet) to power ACM200 from PoE switch
• Local 12V power supply (optional) should switch not support PoE
• Support for iOS and Android App control (not available at initial release)
• 3rd party drivers available for major home control brands
The Blustream UHD Multicast distribution platform allows distribution of HDMI video over a 1Gb Network switch.
The ACM200 Control Module allows advanced third party control of the Multicast system using TCP / IP, RS-232 and
IR.
The ACM200 includes a web interface module for control and configuration of the Multicast system and features
'Drag & Drop' source selection with media preview and independent routing of Video, Audio, IR, RS-232, and USB /
KVM.
Pre-built Blustream device drivers simplify Multicast installation and negate the need for an understanding of
complex network infrastructures.
Features

ACM200 USER MANUAL
04 www.blustream.co.uk / www.blustream.com.au
ACM200 - Front Panel
2
14
9
8
7
6
1RS-232 Control Port – connect to a third party
control device for control of the Multicast system
using RS-232.
2MCU Upgrade Switch - use when upgrading MCU
firmware only. Leave in normal position for
standard operation.
3Reset Switch - short press resets the ACM200, long
press (10 seconds) factory defaults the ACM200.
4IO Level Switch - reserved for future use.
5IO Level Phoenix Connector - reserved for future
use.
6Video LAN (PoE) Port - connect to the network
switch that the Blustream Multicast components
are connected to.
7Control LAN Port - connect to existing network
that a third party control system resides on. The
Control LAN port is used for Telnet/IP control of the
Multicast system. Not PoE.
8IR Ctrl (IR Input) – 3.5mm stereo jack. Connect to
third party control system if using IR as the chosen
method of controlling the Multicast system. When
using the included 3.5mm stereo to mono cable,
ensure the cable direction is correct.
9IR Switch - adjust IR input voltage level between 5V
or 12V input for IR Ctrl.
qPower LED Indicator - LED is on when the device is
powered on.
wPower Port – use 12V 1A DC adaptor (sold
separately) if not using a PoE network switch.
ACM200 - Rear Panel
Panel Descriptions - ACM200
Video LAN(PoE) Control LAN IR Ctrl
IR
5V 12V DC 12V
Power
Link Link
PoE
IO Level
Reset
VOut
IO4 IO3 IO2 IO1
5VNormal
RS-232
MCU
12V
ACM200
Yellow Green Yellow Green
5
Video LAN(PoE) Control LAN IR Ctrl
IR
5V 12V DC 12V
Power
Link Link
PoE
IO Level
Reset
VOut
IO4 IO3 IO2 IO1
5VNormal
RS-232
MCU
12V
ACM200
Yellow Green Yellow Green
11
3
10

ACM200 USER MANUAL
05contact [e-mail] / [e-mail]
The ACM200 communication ports are located on both end panels and include the following connections:
Connections:
A. TCP/IP – for full Multicast system control (RJ45 Connector)
B. Infrared (IR) Input* - for Multicast switching control only (3.5mm stereo jack)
C. RS-232 – for full Multicast system control / RS-232 guest mode (DB9)
* Please note: the ACM200 can be used with both 5V and 12V IR systems. Please ensure that the IR switch (adjacent
to the IR port) is correctly selected to the specification of the IR input voltage required.
TCP/IP:
The Blustream ACM200 can be controlled via TCP/IP.
For the full list of protocols please see ‘RS-232 & Telnet Commands’ located at the rear of this manual.
A ‘straight-through’ RJ45 patch lead should be used when connected to a network switch.
Control Port: 23
Default IP: 192.168.0.225
Default Username: admin
Default Password: 1 2 3 4
RS-232:
The Blustream ACM200 can be controlled via serial using the serial DB9 connector. Default settings below:
For the full list of command protocols please see ‘RS-232 & Telnet Commands’ located at towards rear of this
manual.
Baud Rate: 57600
Data Bit: 8-bit
Parity: None
Stop Bit: 1-bit
Flow Control: None
The Baudrate for the ACM200 can be adjusted using the ACM200 built-in web-GUI, or by issuing the following
command via RS-232 or Telnet:
RSB x : Set RS-232 Baud Rate to Xbps
Where X= 0 : 115200
1 : 57600
2 : 38400
3 : 19200
4 : 9600
ACM200 Control Ports
AC B
Video LAN(PoE) Control LAN IR Ctrl
IR
5V 12V DC 12V
Power
Link Link
PoE
IO Level
Reset
VOut
IO4 IO3 IO2 IO1
5VNormal
RS-232
MCU
12V
ACM200
Yellow Green Yellow Green
Video LAN(PoE) Control LAN IR Ctrl
IR
5V 12V DC 12V
Power
Link Link
PoE
IO Level
Reset
VOut
IO4 IO3 IO2 IO1
5VNormal
RS-232
MCU
12V
ACM200
Yellow Green Yellow Green

ACM200 USER MANUAL
06 www.blustream.co.uk / www.blustream.com.au
The Multicast system can be controlled using local IR control from a third party control system. Source selection is
the only feature available when using local IR control - advanced features of the ACM200 such as video wall mode,
audio embedding etc. can only be achieved using RS-232 or TCP/IP control.
Blustream have created 16x input & 16x output IR commands allowing source selection of up to 16x IPxxxUHD-TX
Transmitters on up to 16x IPxxxUHD-RX Receivers. For systems larger than 16x source devices (IPxxxUHD-TX) RS-232
or TCP/IP control will be required.
ACM200 Control Ports - IR Control
Link
RXTX CH Select
IR IR
Rx Tx Gnd
RS-232 CH
IP100UHD-RXMULTICAST UHD
1 2 3 4
41 42 43 44 45 46 47 48 49 50 51 52 53 54 55 56 57 58 59 60 61 62 63 64 65 66 67 68 69 70 71 72 73 74 75 76 77 78 79 80
5 6 7 8 9 10 11 12
13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 32 33 34 35 36 37 38 39 40
MULTICAST
IR Receiver - IRR - stereo 3.5mm jack (optional)
Blustream 5V IR receiver to receive an IR signal and
distribute through Blustream products
Wiring pin - IR-CAB - stereo 3.5mm jack:
Signal
5V
Ground
The ACM200 is compatible with both 5V and 12V IR equipment. When the ACM200 is being used to receive an IR
input into the IR Ctrl port, the adjacent switch must be toggled correctly to suit the IR voltage line of the chosen
control system before connection.
Please note: Blustream IR accessories are all 5V
Third Party Control System
(source selection only) Video LAN(PoE) Control LAN IR Ctrl
IR
5V 12V DC 12V
Power
Link Link
PoE
IO Level
Reset
VOut
IO4 IO3 IO2 IO1
5VNormal
RS-232
MCU
12V
ACM200
Yellow Green Yellow Green
3.5mm Stereo to Mono Cable - IR-CAB (included)
Blustream IR Control cable 3.5mm Mono to 3.5mm
Stereo for linking third party control solutions to
Blustream products.
Compatible with 12V IR third party products.
Please note: Cable is directional as indicated
Wiring pin - IR-CAB - mono 3.5mm jack:
Signal
Ground

ACM200 USER MANUAL
07contact [e-mail] / [e-mail]
ACM200 Network Connection
The ACM200 acts as a bridge between the control network and video network to ensure that the data travelling
between the two networks are not mixed. The ACM200 must be connected via CAT cable up to 100m in length in
accordance with typical networking requirements.
Example Schematic
EX40B-Kit
RS-232
LAN Cable
IR Cable
Example Schematic
ACM200
IO Level
Reset
VOut
IO4 IO3 IO2 IO1
5VNormal
RS-232
MCU
12V
ACM200
Video LAN(PoE) Control LAN IR Ctrl
IR
5V 12V DC 12V
Power
Link Link
PoE
Yellow Green Yellow Green
Reserved for future update
Control Processor
Optional 12V PSU
where no PoE is available
Multicast UHD
Network Switch
Customer Home / Business
Network Switch
1G Managed Network Switch
1G Managed Network Switch
Example Schematic
EX40B-Kit
RS-232
LAN Cable
IR Cable
Example Schematic
ACM200
IO Level
Reset
VOut
IO4 IO3 IO2 IO1
5VNormal
RS-232
MCU
12V
ACM200
Video LAN(PoE) Control LAN IR Ctrl
IR
5V 12V DC 12V
Power
Link Link
PoE
Yellow Green Yellow Green
Reserved for future update
Control Processor
Optional 12V PSU
where no PoE is available
Multicast UHD
Network Switch
Customer Home / Business
Network Switch
1G Managed Network Switch
1G Managed Network Switch

ACM200 USER MANUAL
08 www.blustream.co.uk / www.blustream.com.au
Web-GUI Guide Overview
The web-GUI of the ACM200 allows for full configuration of a new system, as well as on-going maintenance and
control of an existing system through a web portal. The ACM200 can be accessed on any internet connected device
including: tablets, smart phones and laptops that are on the same network.
Web GUI - Log In
Before logging in to the ACM200, ensure that the control device (i.e. laptop / tablet) is connected to the same
network as the ACM200's Control Port. There are instructions of how to amend the static IP address of a PC at the
rear of this manual.
To log in, open a web browser (i.e. Firefox, Internet Explorer etc.) and navigate to the default static IP address of the
ACM200 which is:
192.168.0.225
The sign in page is presented on connection to the ACM200. Once Users have been created within the system, this
screen will be populated with the Users previously configured for future log ins. The default Admin password is:
1 2 3 4
Please note: the Admin password can be changed once logged in using the 'Update Password' option located in
the main menu options.

ACM200 USER MANUAL
09contact [e-mail] / [e-mail]
On first log in of the ACM200, a Set-up Wizard for configuring all components of the Multicast system will be
presented. This has been designed to speed up new system configuration as all default / new Multicast Transmitters
& Receivers can be connected to the network switch at the same time, whilst not resulting in an IP conflict during
the system configuration. This results in a system in which all components are automatically and sequentially
assigned a name and IP address ready for basic system use.
Web-GUI - New Project Set-up Wizard
The ACM200 Set-up Wizard can be cancelled by clicking 'Close'. Please be aware that the system will not be
configured at this point, but can be continued by visiting the 'Project' menu (see page 18). If a project file is already
available (i.e. replacing an ACM200 on an existing site), this can be imported by using the .json file by clicking
'Import Project'.
Click 'Next' to continue set-up:
If at this point the Network Switch is not configured for use with the Blustream Multicast system, click on the
hyperlink 'network switch setup guides' to navigate to a centralised webpage containing common Network Switch
Guides.
An example schematic diagram for the connections of the ACM200 can be accessed by clicking the hyperlink
marked 'diagram'. This will ensure the ACM200 is connected correctly to the wider Multicast system before the
Set-up Wizard begins. Once the connections of the ACM200 are confirmed click 'Next'. The connections diagram is
included on page 07 of this guide.

ACM200 USER MANUAL
10 www.blustream.co.uk / www.blustream.com.au
Web-GUI - New Project Set-up Wizard - continued...
There are two methods for adding new Multicast Transmitter and Receiver devices to a system, please choose one
before clicking 'Start Scan':
Method 1: connect ALL Blustream Multicast Transmitter's and Receiver's to the network switch with their factory
default IP addresses (169.254.100.254). This method will quickly configure all devices with their own individual IP
addresses based on the following:
Transmitters:
The first Transmitter will be given the IP address of 169.254.3.1.
The next Transmitter will be assigned an IP address of 169.254.3.2 and so on....
Once the IP range of 169.254.3.x is filled (254 units), the ACM200 will auto assign an IP address of
169.254.4.1 and so on...
Once the IP range of 169.254.4.x is filled the ACM200 will auto assign an IP address of 169.254.5.1 and so on until
169.254.4.254
Receivers:
The first Receiver will be given the IP address of 169.254.6.1. The next Receiver will be assigned an IP address of
169.254.6.2 and so on....
Once the IP range of 169.254.6.x is filled (254 units) the ACM200 will auto assign an IP address of
169.254.7.1 and so on...
Once the IP range of 169.254.7.x is filled the ACM200 will auto assign an IP address of 169.254.8.1 and so on until
169.254.8.254
Once complete, devices will need to be identified manually - this method will auto-assign IP addresses and ID's to
each device connected to the network switch randomly (not by switch port).
Method 2: connect each Blustream Multicast Transmitter and Receiver to the network one-by-one. The Set-up
Wizard will configure the units sequentially as they are connected / found. This method allows for the control of
the sequential assigning of IP addresses and ID's of each device - the Transmitter / Receiver units can therefore be
labelled accordingly.

ACM200 USER MANUAL
11contact [e-mail] / [e-mail]
Once the set-up method to configure the system has been chosen, hit the 'Start Scan' button.
The ACM200 will search for new Blustream Multicast devices on the network and will continue to search for new
devices until such time as:
- The 'Stop Scan' button is pressed
- The 'Next' button is clicked to progress the Set-up Wizard aer all units have been found
Web-GUI - New Project Set-up Wizard - continued...
As new devices are found by the ACM200, the units will populate to the relevant columns marked Receivers or
Transmitters. It is recommended to label the individual units at this point.
Once all units have been found and configured, click 'Stop Scan', then 'Next'.

ACM200 USER MANUAL
12 www.blustream.co.uk / www.blustream.com.au
Web-GUI - New Project Set-up Wizard - continued...
The device setup page allows for naming of Transmitter and Receiver products and for EDID and Scaler settings to
be adjusted. EDID and Scaler settings for the individual Transmitters or Receivers can be set as required. For help
with EDID and Scaler settings, click the relevant buttons marked 'EDID Help' (for help wth EDID settings, see page
21), or 'Scaling Help', refer to page 24.
Features of the Device Set-up page include:
1. Name of Devices - during configuration the Transmitters / Receivers are automatically assigned default names
i.e. Transmitter 001 etc. Transmitter / Receiver names can be amended by typing in the corresponding box.
2. EDID - fix the EDID value for each Transmitter (source). This is used to request specific video and audio
resolutions for the source device to output. Basic help with EDID selection can be obtained by clicking the
button marked 'EDID Help'. See page 19 for a full list of EDID settings that can be applied.
3. View - opens the following pop-up:
This pop-up shows an image preview of the media currently being streamed by the Transmitter unit. The ability to
identify the unit by flashing the front panel LED's on the unit, and the ability to Reboot the unit.

ACM200 USER MANUAL
13contact [e-mail] / [e-mail]
Web-GUI - New Project Set-up Wizard - continued...
This pop-up gives you the ability to display the product ID on the connected screen / display by way of an OSD
(On Screen Display) as an overlay to the media being accepted the by Receiver. The ability to identify the unit by
flashing the front panel LED's, and the ability to Reboot the unit is contained here.
7. Turn OSD On / O - toggles the product ID onto the connected screen / display by way of an OSD.
8. Next - continues to the Set-up Wizard Completion page
The Wizard Completion page finalises the basic configuration process and provides links for advanced set-up
options for Video Walls, Fixed Signal Routing (IR, RS-232, Audio etc), and the ability to back-up to a configuration file
(recommended).
Click 'Finish' once done to continue to the 'Drag & Drop Control' page, logged in as Administrator (see page 15).
4. Scaler - adjust the output resolution using the built-in video scaler of the Multicast Receiver. The scaler is
capable of both upscaling and downscaling the incoming video signal. See page 22 for a full list of Scaler output
settings that can be applied.
5. Refresh - click here to refresh all current information on the products within the system.
6. Actions - opens the following pop-up:

ACM200 USER MANUAL
14 www.blustream.co.uk / www.blustream.com.au
Web-GUI - Menu Overview
The 'User Interface' menu gives an end user the ability to switch and preview the Multicast system without
allowing access to any settings that can change the overall infrastructure of the system.
1. Drag & Drop Control - used for ‘Drag & Drop’ control of source selection for each Multicast Receiver including
image preview of source devices.
2. Video Wall Control - used for ‘Drag & Drop’ control of source selection for each video wall array within the
system, including image preview of source devices.
3. Preview - used to show the active video stream from any connected Multicast Transmitter or Receiver
4. Project - used to configure a new or existing Blustream Multicast system.
5. Transmitters - shows a summary of all Multicast Transmitters installed, with options for EDID management,
checking FW version, updating settings, adding new TX’s, replacing or rebooting devices.
6. Receivers - shows a summary of all Multicast Receivers installed, with options for resolution output (HDR
/ scaling), function (video wall mode / matrix), updating settings, adding new RX’s, replacing or rebooting
devices.
7. Fixed Signal Routing - used for signal routing allowing independent routing of IR, RS-232, USB / KVM, CEC,
Audio and Video signals.
8. Video Wall Configuration - used for the set-up and configuration of Multicast receivers to create a video wall
array of up to a size of 9x9, including: bezel / gap compensation, stretch / fit, and rotation.
9. Users - used to set-up or manage users of the system.
10. Settings - access to various system settings including: network and resetting devices.
11. Update Devices - used for applying the latest firmware updates to the ACM200 and connected Blustream
Multicast Transmiters and Receivers.
12. Update Password - used to update the Administrator password for access to the ACM200 web-GUI.
13. Log Out - log out the current User / Administrator.
1. Drag & Drop Control - used for ‘Drag & Drop’ control of source selection for each Multicast Receiver including
image preview of source devices throughout.
2. Video Wall Control - used for ‘Drag & Drop’ control of source selection for each video wall array within the
system, including image preview of source devices throughout. This icon will only display if there are video
walls configured in the project.
3. Log In - used to log into the system as a User or Administrator
The Administrator menu is accessed from a single password (see page 08 to log in). This menu allows to the
Multicast system to be completely configured with access to all settings and features of the system.
Please note: it is not recommended to leave Administrator access or the Administrator password with an end user.

ACM200 USER MANUAL
15contact [e-mail] / [e-mail]
Web-GUI - Drag & Drop Control
The ACM200 Drag & Drop Control page is used to quickly and intuitively change a source input (Transmitter) for
each display (Receiver). This page has been designed to allow the User to quickly switch the I/O configuration of the
system.
Once the system has been fully configured the Drag & Drop Control page will show all online Multicast Transmitters
and Receivers. All Multicast devices will display the active stream which refreshes every few seconds.
Due to the size of the display window on certain phones, tablets or laptops, should the number of Transmitters and
Receivers be larger than the size available on screen, the User is given the ability to scroll or swipe through available
devices (le to right).
To switch sources, click on the required source and ‘Drag & Drop’ the Transmitter preview onto the required
Receiver product. The Receiver preview window will update with the new live stream of the source selected.
The Drag & Drop switch will amend the Video/Audio stream from Transmitter to Receiver, but not alter any fixed
routing of control signals that have been configured in the ACM200 (see page 25).
Should ‘No Signal’ be displayed in the Transmitter preview window, please check the HDMI source device is
powered on, outputting a signal and is connected via HDMI cable to the Multicast Transmitter unit. Check also
the EDID settings of the Transmitter device (Multicast will not accept 4K60 4:4:4 signals). Should ‘No Signal’ be
displayed inside the Receiver preview window, check the unit is connected and powered from the network (switch)
and has a valid connection to a working Transmitter unit.
There is an 'All Receivers' window located on the le of the Receivers window. Dragging and dropping a Transmitter
onto this window will change the routing for ALL Receivers within the system to watch the source selected. Should
the preview of this window show the Blustream logo, this signifies that there is a mixture of sources being watched
across the range of Receivers within the system. The note underneath 'All Receivers' will display: 'TX: Dierent'.
Please note: the Drag & Drop Control page is also the home page for Guest Users of the Multicast system - only
sources that the Guest or User have permission to view will be visible. For User set-up and permissions, see page 34.
Receivers in Video Wall Mode are not displayed on the Drag & Drop page.

ACM200 USER MANUAL
16 www.blustream.co.uk / www.blustream.com.au
Web-GUI - Video Wall Control
To assist wth simplified Video Wall switching control, there is a separate Video Wall Drag & Drop Control page. This
menu option is only available once a Video Wall has been configured into the ACM200 / Multicast system.
The source (Transmitter) preview windows are shown at the top of the page with the graphical representation of the
Video Wall displayed below.
To switch sources, click on the required source and ‘Drag & Drop’ the Transmitter preview onto the Video Wall array
underneath. The Video Wall will switch all screens within the Video Wall configuration to the selected source. Repeat
this process if dierent groups have been configured within the Video Wall.
Blustream Multicast systems can have multiple Video Walls. Selecting a dierent Video Wall array, or to deploy a
pre-defined Configuration / preset for each Video Wall can be carried out by using the drop down boxes above the
graphical representation of the Video Wall. This graphical representation will automatically update as you select a
dierent Video Wall or Configuration.
Should a screen within a Video Wall display on the GUI show 'RX Not Assigned', this means that the Video Wall does
not have a Blustream Multicast Receiver unit assigned to the array. Please revert back to Video Wall set up to assign
the Receiver accordingly.
For the advanced API commands for control of Video Wall arrays within a Blustream Multicast system, please refer
to the API Commands section at the rear of this manual.

ACM200 USER MANUAL
17contact [e-mail] / [e-mail]
Web-GUI - Preview
The Preview feature is a quick way to view the media being streamed through the Multicast system once configured.
Used to preview the stream from any HDMI source device into the Multicast Transmitter, or the stream being
received by any Receiver in the system concurrently. This is particularly helpful for debugging and checking source
devices are powered on and outputting a HDMI signal, or to check the I/O status of the system:
The Preview windows show a live grab of the media which automatically updates every few seconds. To select
the Transmitter or Receiver to preview, use the drop down box to select the individual Transmitter or Receiver to
preview.

ACM200 USER MANUAL
18 www.blustream.co.uk / www.blustream.com.au
Web-GUI - Project Summary
Outlines the units that are currently set-up in the Multicast system as an overview, or for scanning the network for
new devices to assign to the project:
Options on this page:
1. Toggle OSD: turn On / O the OSD (On Screen Display). Toggling the OSD On shows the ID number (i.e. ID
001) of the Multicast Receiver on each display as an overlay to the media being distributed. Toggling OSD O
removes the OSD. See page 24 for more information on the use of OSD.
2. Export Project: create a save file (.json) for the configuration of the system.
3. Import Project: import an already configured project into the current system. This is particularly helpful when
setting up a secondary system or expansion to a current system o-site where the two systems can be merged
into one.
4. Clear Project: resets the ACM200 removing all Transmitters, Receivers and Video Wall Configurations from the
project, reverting the ACM back to the initial wizard configuration. Please note: when 'Clear Project' is applied
only the ACM200 network settings will remain.
5. Continuously Scan & Auto Assign: continuously scan the network and auto assign new Multicast devices to
the next available ID and IP address as connected. If only connecting one new Multicast device, use the 'Scan
Once' option. The ACM200 will continue to scan the network for new Multicast devices until found, or select this
button again to stop the scan.
6. Scan Once: scan the network once for any new Multicast device connected. Once discovered you will be
presented with the option to: 1. manually assign a new device, or: 2. auto assign a new unit to the next available
ID and IP address as connected.

ACM200 USER MANUAL
19contact [e-mail] / [e-mail]
Web-GUI - Transmitters
The Transmitter summary page is an overview of all Transmitter devices that have been configured within the
system, with the ability to update the system as required.
Features of the Transmitter summary page include:
1. ID / Input - the ID / Input number is used for control of the Multicast system when using third party drivers.
2. Name - the name of the Transmitter (typically the device attached to the Transmitter).
3. IP Address - the IP address assigned to the Transmitter during configuration.
4. MAC Address - shows the unique MAC address of the Transmitter.
5. Firmware - displays the firmware version currently loaded onto the Transmitter. For more information on
firmware updating, please see 'Update Devices' on page 37.
6. Status - shows the online / oline status of each Transmitter. Should a device show as 'Oline', check the units
connectivity to the network switch.
7. EDID - fix the EDID value for each Transmitter (source). This is used to request specific video and audio
resolutions for the source device to output. Basic help can be obtained on EDID selection by clicking the button
at the top of the page marked 'EDID Help'. For further help on EDID settings, see page 21. EDID selections as
follows:
- Default EDID - the default EDID is for the Transmitter to request a 1080p / 2ch signal from the source device
- 1080i @ 60Hz 2ch - 4K2K 4:2:0 2ch
- 1080i @ 60Hz 5.1ch - 4K2K 4:2:0 5.1ch
- 1080i @ 60Hz 7.1ch - 4K2K 4:2:0 7.1ch
- 1080p @ 60Hz 2ch - 4K2K 4:4:4 2ch
- 1080p @ 60Hz 5.1ch - 4K2K 4:4:4 5.1ch
- 1080p @ 60Hz 7.1ch - 4K2K 4:4:4 7.1ch
- 1080p @ 60Hz / 3D 2ch - DVI 1280 x 1024 @ 60Hz (no audio)
- 1080p @ 60Hz / 3D 5.1ch - DVI 1920 x 1080 @ 60Hz (no audio)
- 1080p @ 60Hz / 3D 7.1ch - DVI 1920 x 1200 @ 60Hz (no audio)
8. Audio Selection - selects either original HDMI audio, or replaces the embedded audio with a local analogue
audio input on the Transmitter. Default setting will be ‘Auto’. Please note: in 'Auto' mode the audio will be
switched to the local analogue audio input of the Transmitter when the 3.5mm audio jack is inserted. This will
only revert back to HDMI audio when the 3.5mm audio jack is removed.
9. Actions - opens a pop-up window with advanced configuration settings. See following page for further
information.
10. Refresh - refresh all current information on the devices within the system.

ACM200 USER MANUAL
20 www.blustream.co.uk / www.blustream.com.au
Web-GUI - Transmitters - Actions
The 'Actions' button allows for
advanced features of the units to be
accessed and configured.
Features of the Actions menu include:
1. Name - Transmitter names can be amended by entering a name into the free-form text box. Please note: this is
limited to 16 characters in length, and some special characters may not be supported.
2. Update ID - the ID of a unit is set as default to the same number as the last 3 digits of the units IP address i.e.
Transmitter number 3 is assigned an IP address of 169.254.3.3 and will have an ID of 3. Amending the ID of the
unit is not normally recommended.
3. CEC Pass-through (On / O) - allows for CEC (Consumer Electronic Command) to be sent through the Multicast
system to and from the source device connected to the Transmitter. Please note: CEC must be enabled on the
Receiver unit also for the CEC commands to be sent between. Default setting for this feature is O. If more than
one Blustream Receiver is viewing a Transmitter, the CEC is passed between all devices. Because of this it is
advised to leave CEC disabled on all products unless required.
4. Front Panel Display (On / O) - use this to enable / disable the dual 7-segment LED displays on the front of the
Transmitter. The front panel display of the Multicast unit will automatically time-out aer 90 seconds and turn
o.
5. Front Panel Power LED Flash (On / O / On 90 Seconds) - will flash the power LED on the front panel of
the Transmitter to help identify the device following auto configuration. Options are: flash the power light
continuously, or flash the LED for 90 seconds before the LED goes back to being permanently lit. Please note:
the front panel LED's will automatically time-out aer 90 seconds with the front panel display. Press one of the
CH buttons to wake the unit.
6. Copy EDID - see page 21 for further information on Copy EDID.
7. Serial Settings - turn on serial 'Guest Mode' and set the individual serial port settings for the device (i.e. Baud
Rate, Parity etc).
8. Preview - displays a pop-up window with live a screen grab of the source device connected to the Transmitter.
9. Reboot - reboots the Transmitter.
10. Replace - used to replace an oline Transmitter. Please note: the Transmitter to be replaced must be oline
for this feature to be utilised, and the new Transmitter must be a factory default unit with default IP address:
169.254.100.254.
11. Remove from Project - removes the Transmitter device from the current project.
12. Factory Reset - restores the Transmitter to its original default settings and sets the IP address to:
169.254.100.254.
