HMXL44CS-KIT QUICK REFERENCE GUIDE
www.blustream.com.au |www.blustream-us.com |www.blustream.co.uk
• Advanced HDBaseT™ technology oering uncompressed video and audio with zero latency
• Advanced Colour Space Conversion (CSC) supports HDMI 2.0 18Gbps specification including HDR
• Features 4 x HDMI inputs which can be independently routed to 4 x HDBaseT™ outputs
• Output 1 features simultaneous HDMI and HDBaseT™ output
• Video down-conversion on HDBaseT™ output 1 allowing a display only capable of supporting lower video resolutions (4K
60Hz 4:2:0 or 1080p) to receive 4K 60Hz 4:4:4 video content while still showing maximum original 4K UHD resolution on the
remaining video outputs
• Supports 4K 60Hz 4:4:4 UHD video up to 40m
• Extends HDMI 1080p video up to 70m
• HDMI re-clocking on the HEX70CS-RX HDBaseT™ receiver to help solve HDMI HDCP, compatibility and handshaking issues
• Supports all industry standard video resolutions including VGA-WUXGA and 480i-4K
• Supports all known HDMI audio formats including Dolby TrueHD, Dolby Atmos, Dolby Digital Plus and DTS-HD Master Audio
transmission
• HDMI audio breakout to associated analogue L/R audio outputs with pre-amp line level control
• Analogue audio input can be embedded onto any HDMI input
• Web interface module for control and configuration of matrix
• Supports bi-directional IR and RS-232 on all HDBaseT™ outputs
• Supplied with Blustream 5V IR receivers and emitters
• Control via front panel, IR, RS-232, TCP/IP, or iOS / Android App
• Supports PoC (Power over Cable) to power supplied Blustream HDBaseT™ receivers
• 1U design for 19” rack mount integration - mounting kit included
• Advanced EDID management
• HDCP 2.2 compliant
Our Essential 4x4 HDBaseT™ Matrix oers unprecedented performance and value for the
custom installation market. The HMXL44CS-KIT is a HDMI 2.0 4K 60Hz 4:4:4 HDCP 2.2 Matrix
package utilising HDBaseT™ CSC technology to deliver HDMI, bi-directional IR, RS-232
and PoC (Power over Cable) up to lengths of 70m over a single CAT cable. The matrix also
provides advanced features including simultaneous HDBaseT™ / HDMI on output 1, video
down conversion on HDBaseT™ output 1, audio breakout with pre-amp variable line-level
control, and a web browser interface module for control and configuration of the matrix. The
HMXL44CS-KIT is supplied with 4 x HEX70CS-RX HDBaseT™ receivers.
Introduction
HMXL44CS-KIT
Quick Reference Guide
FEATURES:
01

HMXL44CS-KIT QUICK REFERENCE GUIDE
www.blustream.com.au |www.blustream-us.com |www.blustream.co.uk
1L/R In - 3.5mm Analogue audio input
for embedding audio onto HDMI
inputs
2IR Inputs 1 to 4 – 3.5mm stereo jack.
Sends 5V IR out to corresponding
HDBaseT™ zones
3IR Outputs 1 to 4 – 3.5mm mono
jack. Routed IR 5V emitter outputs
for discrete source control
4HDMI Output 1 – Output for HDMI
display (linked to HDBaseT™ Output
1)
5RS-232 Pass-through Port (x4) -
Sends RS-232 out to corresponding
HDBaseT™ zones
6
Coaxial Digital Audio Output (x4) –
Extracted audio will be concurrent
with the corresponding HDMI video
output
7 Variable L/R Line Level Analogue
Audio Outputs (3.5mm stereo
jack) (x4) – Extracted audio will be
concurrent with the corresponding
HDMI video output. Note: input
must be PCM 2ch audio as Matrix
does not down-mix 5.1ch audio
signals
8TCP/IP (RJ45) – Connect to LAN for
TCP/IP control of Matrix and Web GUI
9RS-232 Port – For control of the
Matrix from PC or third party control
processor
qEDID DIP Switch – Used for global
EDID settings
wHDMI Inputs 1 to 4 – Connect HDMI
sources
e
HDBT Outputs 1 to 4 – Output for
displays. Connect to HDBaseT™
Receiver
r IR CTRL Receiver Input – 3.5mm
stereo jack. 5V input for connection
of a remote IR sensor or control
processor for remote IR control of
the matrix
t Power Port – Use included 24V/3.5A
DC adaptor to power the matrix
switcher and HDBaseT™ receivers
Rear Panel
Front Panel
Panel Descriptions
1
10 11 12 13
8 9
4
14
1LCD Display – Shows the status of
input / output selection, EDID etc
2IR Receiver Window
31 / 2 / Le / Up Selection Buttons -
Press select input / output 1 or 2, or
to change segment value
4Menu Button - Press to enter set-up
menu
5Power button – Press to power on /
o the matrix
63 / 4 / Right / Down Selection
Buttons - Press select input / output
3 or 4, or to change segment value
7Enter Button – Press to select or
confirm command / selection
8ESC – Press to quit EDID set mode
2 3 5 6 7
112244
6677
55
88
33
02

HMXL44CS-KIT QUICK REFERENCE GUIDE
Contact: [e-mail] |[e-mail] |[e-mail]
Understanding The Matrix / Receiver Status Lights
The Blustream matrix and HDBaseT™ extender solutions include status LED indicators on both the matrix and receiver products to
show all connections are active and to help diagnose possible problems.
Understanding The Status Lights
Blustream Matrix:
• The Yellow HDBaseT™ status link light will be o when the zone output has been turned o or there is a problem with the
specific matrix output
• The Yellow HDBaseT™ status link light will blink when the zone output is on and working
• The Green HDBaseT™ link light will blink if there is an unstable connection between the Blustream matrix and HDBaseT™
receiver
• The Green HDBaseT™ link light will be lit when there is an active HDBaseT™ receiver connected to the matrix
• The Green HDBaseT™ link light will be o when there is no connection with a HDBaseT™ receiver
Blustream HDBaseT™ Receiver:
• The HDMI link light will be o when there is no connection with a display
• The HDMI link light will be on when there is an active connection with a display (Note: Not all HDBaseT™ RX feature a HDMI
status LED)
• The HDBaseT™ link light will be o when there is no CAT cable / active HDBaseT™ connection on the RJ45 HDBaseT™ input
• The HDBaseT™ link light will blink if there is an unstable connection between the Blustream matrix and HDBaseT™ receiver
• The HDBaseT™ link light will be lit when a CAT cable is connected to the HDBaseT™ RJ45 output on the matrix and an active
connection is achieved with the Blustream HDBaseT™ receiver
EDID (Extended Display Identification Data) is a data structure that is used between a display and a source. This data is used by
the source to find out what audio and video resolutions are supported by the display.By pre-determining the video resolution and
audio format of the source and display device you can reduce the time need for EDID hand shaking thus making switching quicker
and more reliable.
Configuration of Matrix EDID settings can be achieved in one of four ways:
1Using Matrix menu (for further details see ‘HMXL44CS-KIT User Manual’)
2Using EDID dip-switches located on the rear of the Matrix - see below
3Using supplied Blustream Matrix IR remote control (for further details see ‘HMXL44CS-KIT User Manual’)
4Using HMXL44CS web browser interface (for further details see ‘HMXL44CS-KIT User Manual’)
EDID Control
Global EDID Settings DIP ON ▼/OFF▲ SWITCHING POSITIONS
EDID TYPE
3 2 1 0
OFF OFF OFF OFF 1080p/2.0ch
OFF OFF OFF ON 1080p/5.1ch
OFF OFF ON OFF 1080p/7.1ch
OFF OFF ON ON 1080i/2.0ch
OFF ON OFF OFF 1080i/5.1ch
OFF ON OFF ON 1080i/7.1ch
OFF ON ON OFF 4K60Hz 4:2:0/4K30Hz 4:4:4/2.0ch
OFF ON ON ON 4K60Hz 4:2:0/4K30Hz 4:4:4/5.1ch
ON OFF OFF OFF 4K60Hz 4:2:0/4K30Hz 4:4:4/7.1ch
ON OFF OFF ON 4K60Hz 4:4:4/2.0ch
ON OFF ON OFF 4K60Hz 4:4:4/5.1ch
ON OFF ON ON 4K60Hz 4:4:4/7.1ch
ON ON OFF OFF DVI 1280x1024ch
ON ON OFF ON DVI 1920x1080ch
ON ON ON OFF DVI 1920x1200ch
ON ON ON ON Soware / GUI Controlled EDID
Dip-switch Position ‘0’ = O
Dip-switch Position ‘1’ = On
03

HMXL44CS-KIT QUICK REFERENCE GUIDE
Contact: [e-mail] |[e-mail] |[e-mail]
Specifications
Video Input Connectors: 4 x HDMI Type A, 19-pin, female, locking
Video Output Connectors: 1 x HDMI Type A, 4 x HDBaseT™ RJ45 connector
Audio Input Connectors: 1 x 3.5mm stereo jack (L/R)
Audio Output Connectors: 4 x RCA (S/PDIF), 4 x 3.5mm stereo jack (L/R)
RS-232 Serial Port: 1 x DB 9 connector (control), 4 x 3-pin Phoenix (pass-through)
TCP/IP Control: 1 x RJ45, female
IR Input Ports: 5 x 3.5mm stereo jack
IR Output Ports: 4 x 3.5mm mono jack
Dimensions (W x H x D): 440mm x 245mm x 52mm
Case Dimensions (W x H x D): 440mm x 235mm x 44mm
Shipping Weight: 2.7Kg
Operating Temperature: 32°F to 104°F (0°C to 40°C)
Storage Temperature: -4°F to 140°F (-20°C to 60°C)
Power Supply: 1 x 24V DC/3.5A
Note: Specifications are subject to change without notice.
Package Contents
• 1 x HMXL44CS Matrix
• 4 x HEX70CS-RX Receivers
• 1 x 19” Rack Mounting Kit
• 4 x Mounting Kits for HEX70CS-RX
• 1 x 24V/3.5A Power Supply
• 1 x Remote Control
• 5 x IRR Blustream 5V IR Receivers
• 4 x IRE1 Blustream 5V IR Emitters
• 4 x IR-CAB IR Control Cable - 12V to 5V
IR Cable
• 1 x Quick Reference Guide
Maintenance
Clean this unit with a so, dry cloth. Never use alcohol, paint thinner or benzene to clean this unit.
For the full Blustream HMXL44CS-KIT User Manual please visit the product page on the Blustream website.
RevA7_QRG_HMXL44CS-KIT_170321
04
Web GUI Control
The HMXL44CS-KIT features an in-built Web GUI which can be used for control and configuration of the matrix. By default the
matrix is set to DHCP, however if a DHCP server (eg: network router) is not installed the matrix IP address will revert to below
details:
Default Username is: blustream Default Password is: 1234 Default IP Address is: 192.168.0.200
For further information please see the HMXL44CS-KIT User Manual - available to download from the Blustream website.
FCC NOTICE
This equipment has been tested and found to comply with the
limits for a Class B digital device, pursuant to part 15 of the FCC
Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This
equipment generates, uses, and can radiate radio frequency
energy and, if not installed and used in accordance with the
instructions,
may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be
determined by
turning the equipment o and on, the user is encouraged to try to
correct the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit dierent from
that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for
help.
CAUTION - changes or modifications not expressly approved
by the party responsible for compliance could void the user’s
authority to
operate the equipment.
CANADA, INDUSTRY CANADA (IC) NOTICES
This Class B digital apparatus complies with Canadian ICES-003.
Operation is subject to the following two conditions: (1) this device
may not cause interference, and (2) this device must accept any
interference, including interference that may cause undesired
operation of the device.
CORRECT DISPOSAL OF THIS PRODUCT
This marking indicates that this product should not be disposed
with other household wastes. To prevent possible harm to the
environment or human health from uncontrolled waste disposal,
recycle it responsibly to promote the sustainable reuse of material
resources. To return your used device, please use the return and
collection systems or contact the retailer where the product was
purchased. They can take this product for environmentally safe
recycling.
