Blu Stream HEX70HDU-KIT User manual

HEX70HDU-KIT
User Manual
RevA0_HEX70HDU-KIT_Manual_201123

HEX70HDU-KIT USER MANUAL
www.blustream.com.au | www.blustream-us.com | www.blustream.co.uk
02
Surge Protection Device
Recommended
This product contains sensitive
electrical components that may be
damaged by electrical spikes, surges,
electric shock, lightning strikes, etc.
Use of surge protection systems is
highly recommended in order to
protect and extend the life of your
equipment.
Contents
Thank you for purchasing
this product.
For optimum performance and safety,
please read these instructions care-
fully before connecting, operating or
adjusting this product. Please keep this
manual for future reference.
Introduction 03
Features 03
TX Panel Description 04
RX Panel Description 04
USB-C Functionality 05
Front Panel LED’s and Auto Switching 05
EDID Control 05
Automatic System On/O Control 06
Relay Control 06
Infrared (IR) Control 07
CEC Control 07
Terminating CAT Cables for use with HDBT 08
Understanding the HDBaseT™ Status LED’s 08
Schematic 09
Web GUI Control 10-14
IR Commands 15
RS-232 Config & Telnet Commands 16-18
Specifications 19
Package Contents 19
Maintenance 19
Certifications 20

HEX70HDU-KIT USER MANUAL
contact: [e-mail] |[e-mail] |[e-mail] 03
Our HEX70HDU-KIT extender kit is an industry leading 4K HDBaseT™ multi-format
solution delivering HDMI, USB-C and DisplayPort™ up to lengths of 70m at 1080p
(40m at 4K 60Hz 4:4:4) over a single CAT cable.
The HEX70HDU-KIT provides enhanced features including local HDMI input on
the HDBaseT™ Receiver for additional source input, web GUI for control and
configuration, auto display control, audio breakout, bi-directional IR pass-
through, and EDID management.
The HEX70HDU-KIT has multiple control options including buttons on both TX
and RX units, IR, RS-232 and TCP/IP.
Introduction
FEATURES:
• Advanced HDBaseT™ technology oering distribution of video and audio over a single CAT cable
• Features 1 x HDMI, 1 x USB-C, and 1 x DisplayPort™ input on the HDBaseT™ Transmitter with manual or auto source
selection
• Features a local HDMI input on the HDBaseT™ Receiver for connection of a source device local to the display
• Supports 4K 60Hz 4:4:4 UHD video up to 40m
• Extends HDMI 1080p up to a distance of 70m over a single CAT cable
• Supports all known HDMI audio formats including Dolby TrueHD, Atmos, and DTS-HD Master Audio transmission
• Supports USB Type C up to 4K UHD 60Hz 4:4:4* (DP1.2 with 60W charging capability)
• Supports DisplayPort™ up to 4K UHD 60Hz 4:4:4, 4K 30Hz 4:4:4 DP1.2
• Audio breakout to analogue L/R audio** and Coaxial digital (S/PDIF) outputs concurrently
• Supports Bi-directional PoC to power extenders from either Transmitter or Receiver end
• Bi-directional IR pass-through
• Auto display on / o feature allowing control of display at the HDBaseT™ Receiver via CEC, RS-232, or Relay
• Web interface module for control and configuration of the HEX70HDU-KIT
• Control via front panel, IR, RS-232 and TCP/IP
• Advanced EDID and HDCP management
*USB-C video support is limited to 4K 60Hz 4:2:0 when charging feature is activated by the source device
**Analogue audio breakout supports 2ch PCM only

HEX70HDU-KIT USER MANUAL
www.blustream.com.au | www.blustream-us.com | www.blustream.co.uk
04
TX Panel Description
1Power status indicator
2Local HDMI input signal link indicator
3DisplayPort™ input signal link indicator
4USB-C input signal link indicator
5Remote (RX) HDMI input signal link indicator
6Input / Auto select button - press to change source,
hold for 3 seconds to enable / disable auto signal
sense switching
7IR control port (to Blustream 5V 3.5mm IR receiver or
IR control device)
8IR IN (from Blustream 5V 3.5mm IR receiver)
9IR OUT (to Blustream 5V 3.5mm IR emitter)
qRS-232 - 3-pin phoenix connector for RS-232 pass
through, or device control by RS-232 commands
RX Panel Description
12345 6 78 9 10 11 12 13 14 15 16 17 18 19
wUSB Upgrade port
eHDBaseT™ output - connect to Receiver
rHDMI input - connect to source equipment
tDisplayPort™ input - connect to source equipment
using a cable capable of carrying video
yUSB-C input - connect to source equipment
uEDID DIP switch (UP=0, DOWN=1)
iTCP/IP (RJ45) – connect to LAN for TCP/IP control
Default IP of the HEX70HDU-KIT is 192.168.0.200
oReset HEX70HDU to default IP settings
pPower port – use included 24V/5A DC adaptor to
power the device
1 2 3 4 5 6 7 8910 11 12 13 14 15 16
1Power status indicator
2Local HDBaseT™ input signal link indicator
3Local HDMI input signal link indicator
4Auto input signal link indicator
5Input / Auto select button - press to change source,
hold for 3 seconds to enable / disable auto signal
sense switching
6IR IN (from Blustream 5V 3.5mm IR receiver)
7IR OUT (to Blustream 5V 3.5mm IR emitter)
8RS-232 - 3-pin phoenix connector for RS-232 pass
through, or device control by RS232 commands
9USB Upgrade port
qHDBaseT™ input - connect to Transmitter
wHDMI input - connect to local source equipment
eHDMI output - connect to display equipment
rCoaxial digital audio output – extract audio from the
selected input signal
tL/R analogue audio outputs (5-pin phoenix)
extracted audio from the selected input signal
Note: Input signal must be PCM 2ch audio
yRelay - 3-pin phoenix connector
uPower port – use included 24V/5A DC adaptor to
power the device

HEX70HDU-KIT USER MANUAL
contact: [e-mail] |[e-mail] |[e-mail] 05
EDID Control
EDID (Extended Display Identification Data) is a data structure that is used between a display and a source to negotiate
the best audio and video resolutions that are supported in the system. A global EDID of the HEX70HDU-KIT can be
configured using a combination of DIP switch settings (see below), or using IP / RS-232 commands.
Global EDID Settings
DIP switch position ‘0’ = O / Up
DIP switch position ‘1’ = On / Down
EDID DIP Switches
[DIP] = 0000: HDMI 1080p @60Hz, Audio 2ch PCM (default)
[DIP] = 0001: HDMI 1080p @60Hz, Audio 5.1ch PCM/DTS/DOLBY
[DIP] = 0010: HDMI 1080p @60Hz, Audio 7.1ch PCM/DTS/DOLBY/HD
[DIP] = 0011: HDMI 1080i @60Hz, Audio 2ch PCM
[DIP] = 0100: HDMI 1080i @60Hz, Audio 5.1ch PCM/DTS/DOLBY
[DIP] = 0101: HDMI 1080i @60Hz, Audio 7.1ch PCM/DTS/DOLBY/HD
[DIP] = 0110: HDMI 4K @60Hz 4:2:0, Audio 2ch PCM
[DIP] = 0111: HDMI 4K @60Hz 4:2:0, Audio 5.1ch PCM/DTS/DOLBY
[DIP] = 1000: HDMI 4K @60Hz 4:2:0, Audio 7.1ch PCM/DTS/DOLBY/HD
[DIP] = 1001: HDMI 4K @60Hz 4:4:4, Audio 2ch PCM
[DIP] = 1010: HDMI 4K @60Hz 4:4:4, Audio 5.1ch PCM/DTS/DOLBY
[DIP] = 1011: HDMI 4K @60Hz 4:4:4, Audio 7.1ch PCM/DTS/DOLBY/HD
[DIP] = 1100: DVI 1920x1080 @60Hz, Audio None
[DIP] = 1101: DVI 1920x1200 @60Hz, Audio None
[DIP] = 1110: EDID Passthrough
[DIP] = 1111: Soware Controlled EDID (set EDID via TCP/IP or RS-232)
USB-C Functionality
The HEX70HDU-KIT features USB-C input on the transmitter. The USB-C input supports a full 18Gbps 4K 60Hz
4:4:4 video signal. It also supports up to 60W charging, however, when charging is activated, video bandwidth is
automatically limited to 10Gbps and maximum resolution up to 4K 60Hz 4:2:0 video signals.
Front Panel LED’s and Auto Switching
The HEX70HDU-KIT includes LED indicator lights to identify what input is selected. On the Transmitter if an input LED
is solid then it is the selected source and in manual switching mode, if it is flashing then the unit is in auto switching
mode. On the Receiver, there is an input LED for showing whether remote HDBT or local HDMI source is selected, as
well as a dedicated LED indicator that will be solid if auto switching mode is enabled hence the RX LED’s will not flash.
Auto switching is enabled by default on both Transmitter and Receiver. When enabled, if a source is disconnected, the
HEX70HDU-KIT will go back to the previously active input, and if the previously active input isn’t available it will find the
next active input starting from input 1 to input 4.

HEX70HDU-KIT USER MANUAL
www.blustream.com.au | www.blustream-us.com | www.blustream.co.uk
06
Automatic System On/O Control
The HEX70HDU is designed to help automate basic control of AV equipment within a room without the need for a 3rd
party control system. It can control devices via RS-232 and relay outputs. Its key function is to turn the system on when
a video signal is sensed, and turn it o when that signal is lost.
Configuration of this functionality can be completed via RS-232. See the RS-232 Configuration and Telnet Commands
section at the rear of this manual for additional information and command API.
System On:
When the HEX70HDU detects video signal (via TMDS or 5V), the system will start and automatically perform the
following actions at the same time:
• Send RS-232 On Command, then delay (between 1~180s, default 3s), then send user defined RS-232 command
once configured via RS-232
• Toggle the state of relay 1 for a predetermined time (enabled by default, between 3~180s, default 10s, 0 is always
open while the unit is on)
Please note: when setting video signal trigger to TMDS or 5V, please ensure the System On and System O settings
match or the feature may not operate correctly.
System O:
When the controller detects the video signal is lost, and does not receive a signal sense trigger within the delay time
(between 5~180mins, default 10mins), the system will turn o and automatically perform the following actions:
• Send RS-232 O Command, then delay (between 1~180s, default 3s), then repeat the command once configured
via RS-232
• Toggle the state of relay 2 for a predetermined time (enabled by default, between 3~180s, default 10s, 0s will turn
o when the unit turns stops sensing)
Relay Control
The HEX70HDU-RX features relay control to trigger external devices when a HDMI signal is sensed or lost.
By default when the unit is turned on or o, both relay 1 and 2 will open for 10 seconds and then close aerwards.
• For relay 1, the delay time can be set to 0 seconds which will keep the relay open when the unit is turned on, and
close the relay when the unit is turned o
• Relay 2 does not have this feature
For relay API commands, please see the RS-232 Configuration and Telnet Commands section at the rear of this
manual.
MOTORISED PROJECTOR SCREEN
12V
TRIGGER
POWER
SUPPLY
5V/12V

HEX70HDU-KIT USER MANUAL
contact: [e-mail] |[e-mail] |[e-mail] 07
The Blustream range of extender products include source switching control via IR.
IMPORTANT: Blustream Infrared products are all 5V and NOT compatible with alternative manufacturers
Infrared solutions. When using third party 12V IR control solutions please use the Blustream IRCAB cable for IR
conversion.
IR Receiver - IRR
Blustream 5V IR receiver to receive
an IR signal for control of the
extender.
IR Control Cable - IRCAB (not supplied)
Blustream IR Control cable 3.5mm Mono to
3.5mm Stereo for linking third party control
solutions to Blustream products.
Compatible with 12V IR 3rd party products.
Please Note: cable is directional as
indicated.
IR Receiver - Stereo 3.5mm
Infrared (IR) Control
Signal
5V
Ground
The HEX70HDU features CEC control of source devices and displays via the products web GUI and RS-232. It is possible
to send CEC commands such as power on / o, input selection, as well as volume up or down.
Please see the RS-232 command list at the end of this document for a full list of CEC commands available.
Please note: CEC is subject to the support of standardised codes for the sources and displays connected to the
extender.
CEC Control

HEX70HDU-KIT USER MANUAL
www.blustream.com.au | www.blustream-us.com | www.blustream.co.uk
08
Terminating CAT Cable for use with HDBaseT™
It is important that the interconnecting CAT cable between Blustream HDBaseT™ products is terminated using the
correct RJ45 pin configuration. The link CAT cable MUST be a ‘straight’ (pin-to-pin) CAT cable, and it is advised that this
is wired to the T568B wiring standard as this format is less prone to EMI (Electro-Magnetic Interference).
When installing CAT cables it is advised that you use the best possible CAT cable quality. HDMI distribution products
will only work if used with CAT5e standard cable or above. Blustream recommends using a CAT6 cable (or better) for
installations, especially when running longer distances, in areas of high EMI, or for 4K signal distribution. It is advised
that using any method of patch panel, wall plate, or join within the CAT cable is avoided as these can add degradation
to the signal. Blustream also recommend using RJ45 connectors that are recommended for use with the choice of CAT
cable.
RJ45 Wiring -
T568B
Understanding the HDBaseT™ Status LED’s
The extender includes status LED indicators on the HDBaseT™ RJ45 ports to show all connections are active, and to
help diagnose potential connectivity issues.
Understanding the Status Lights - HEX70HDU-KIT:
• The yellow HDBaseT™ status link light will be OFF when there is no HDBaseT™ link established with the Blustream
HDBaseT™ receiver
• The yellow HDBaseT™ status link light will be ON when there is a HDBaseT™ link established with the Blusream
HDBaseT™ receiver
• The green HDBaseT™ link light will be OFF when there is no video signal being transmitted between the HDBaseT™
Transmitter and HDBaseT™ receiver
• The green HDBaseT™ link light will be ON when a there is a HDCP enabled video signal being transmitted between
the HDBaseT™ Transmitter and HDBaseT™ receiver
• The green HDBaseT™ link light will BLINK when there is a video signal with no HDCP being transmitted between the
HDBaseT™ Transmitter and HDBaseT™ receiver
The link lights will only serve as an indication to the connectivity between the HDBaseT™ transmiter and receiver units.
The LED’s will not indicate a termination, bandwidth, interference or cable length issues on a CAT cable run. Blustream
always recommend qualifying / verifying / certifying a CAT cable run for suitability prior to the installation of HDBaseT™
equipment.

HEX70HDU-KIT USER MANUAL
contact: [e-mail] |[e-mail] |[e-mail] 09
Schematic
RS-232 HDMI Infrared Cat 6 USB-C DisplayPort™ Analogue Audio Digital Audio
HEX70HDU-KIT Example Schematic
A
C
D
B
HDMI RS-232 IR PoC
A
B
C
D
HDMI, DP & USB-C SOURCES
Projector
Screen
Projector
Local
Source
Amp
Speakers
1Gb Network Switch
Control Processor
HDBaseT™ 1080p up to 70m | 4K up to 40m

HEX70HDU-KIT USER MANUAL
www.blustream.com.au | www.blustream-us.com | www.blustream.co.uk
10
This following pages take you through the operation of the HEX70HDU web GUI. You must connect the TCP/IP RJ45
socket to your local network in order to access the products web GUI.
By default the Transmitter is set to DHCP, however if a DHCP server (eg: network router) is not installed the IP address
will revert to below details:
Default IP Address is: 192.168.0.200 Default Username is: blustream Default Password is: 1234
The web GUI supports multiple users along with multiple user permissions as follows:
Guest Account - This account does not require a user to login. The Guest account can only change sources for each
zone. Guest access can be changed by the Admin, limiting inputs or outputs, or deleting as necessary.
User Accounts - 7x User accounts can be utilised, each with individual login details. User accounts can be assigned
permissions to specific areas and functions. A User must log in to make use of these functions.
Admin Account - This account allows full access to all functions of the kit as well as assigning users with permissions.
Guest Control Page
The Guest Control page allows a guest user to change inputs without needing to be logged into the HEX70HDU. Simply
select the square that corresponds with the input you wish to select.
Web GUI Control

HEX70HDU-KIT USER MANUAL
contact: [e-mail] |[e-mail] |[e-mail] 11
Login Page
The Login page allows a user or admin to login and access additional functionality.
This page also shows you the current firmware version of both the kit and web GUI.
User Control Page - Source
A logged in User or Admin Control Page allows a user to change inputs for the HEX70HDU. Simply select the square
that corresponds with the input you wish to select. You can also enable or disable auto switching mode for both the
transmitter and receiver independently.
A User or Admin also has the ability to send out CEC power toggle command to either the input selected on the
Transmitter or the input connected to the Receiver.
There is also a power button on the lower right corner to turn the unit on or o.

HEX70HDU-KIT USER MANUAL
www.blustream.com.au | www.blustream-us.com | www.blustream.co.uk
12
User Control Page - Display
The User Control Display Page allows you to send CEC commands out to the display device connected to the Receiver,
as well as configuring the 2 relay outputs on the Receiver, by manually opening or closing them, as well as setting the
time the relay is switched for.
Display Setting Page
The Display Setting Page allows you to remotely control a device connected via RS-232 to the Receiver. It is also
possible to automate the display on, input select and display o process via RS-232.
If RS-232 On is enabled, the Display On and Display Input Select commands are sent out of the Receiver, when the
Transmitter senses a signal.
If RS-232 O is enabled, the User O Command will be sent out of the Receiver, when the Transmitter stops sensing a
signal.
You can also specify the Baud Rate and Command Ending (eg: new line, carriage return) to the match the RS-232
device connected to the Receiver.

HEX70HDU-KIT USER MANUAL
contact: [e-mail] |[e-mail] |[e-mail] 13
Configuration Page - Input
The Configuration Page allows you to configure settings to do with both inputs and outputs of the HEX70HDU.
You can select the configuration for either Input or Output at the top of the page.
Within the Input Page, you can enter a Name for each input as well as specify an EDID from the drop down menu.
Configuration Page - Output
The Output Configuration Page allows you to configure settings to do with the output of the Receiver.
You can enter a Name for the output as well as enable or disable the coaxial and analogue outputs.

HEX70HDU-KIT USER MANUAL
www.blustream.com.au | www.blustream-us.com | www.blustream.co.uk
14
Network Page
The Network Page allows you to specify the TCP/IP network port settings. You can choose from Static IP or DHCP, as
well as specific a fixed IP Address, Subnet Mask and Gateway. It is also possible to change or disable the Telnet port.
Admin Page
The Admin Page allows the admin to configure up to 8 users including a guest user. Each user can adjust their
password via this page as well.
The Admin, or Users who have been given Admin permissions, are able to allocate permissions to Users. These
permissions include allowing or disallow access to each page in the Web GUI, as well as allowing or disallowing access
to each input or output in the product.
The Admin Page also allows you to lock or unlock the Front Panel Buttons of the HEX70HDU-KIT as well as Factory
Reset the unit.

HEX70HDU-KIT USER MANUAL
contact: [e-mail] |[e-mail] |[e-mail] 15
IR Commands NEC Customer Code = 1898
Advanced features are not available via IR commands
COMMAND NEC HEX
POWER
TOGGLE 0x14 0000 0069 0000 002a 0150 00a8 0015 0015 0015 0015 0015 0015 0015 003f 0015 003f 0015 0015 0015 0015 0015 003f 0015 0015 0015 0015 0015 0015
0015 003f 0015 003f 0015 0015 0015 0015 0015 0015 0015 0015 0015 0015 0015 003f 0015 0015 0015 003f 0015 0015 0015 0015 0015 0015 0015 003f 0015
003f 0015 0015 0015 003f 0015 0015 0015 003f 0015 003f 0015 003f 0015 05d3
OUTPUT 0x09 0000 0069 0000 002a 0150 00a8 0015 0015 0015 0015 0015 0015 0015 003f 0015 003f 0015 0015 0015 0015 0015 003f 0015 0015 0015 0015 0015 0015
0015 003f 0015 003f 0015 0015 0015 0015 0015 0015 0015 003f 0015 0015 0015 0015 0015 003f 0015 0015 0015 0015 0015 0015 0015 0015 0015 0015
0015 003f 0015 003f 0015 0015 0015 003f 0015 003f 0015 003f 0015 003f 0015 05d3
INPUT 1 0x50 0000 0069 0000 002a 0150 00a8 0015 0015 0015 0015 0015 0015 0015 003f 0015 003f 0015 0015 0015 0015 0015 003f 0015 0015 0015 0015 0015 0015
0015 003f 0015 003f 0015 0015 0015 0015 0015 0015 0015 0015 0015 0015 0015 0015 0015 0015 0015 003f 0015 0015 0015 003f 0015 0015 0015 003f 0015
003f 0015 003f 0015 003f 0015 0015 0015 003f 0015 0015 0015 003f 0015 05d3
INPUT 2 0x55 0000 0069 0000 002a 0150 00a8 0015 0015 0015 0015 0015 0015 0015 003f 0015 003f 0015 0015 0015 0015 0015 003f 0015 0015 0015 0015 0015 0015
0015 003f 0015 003f 0015 0015 0015 0015 0015 0015 0015 003f 0015 0015 0015 003f 0015 0015 0015 003f 0015 0015 0015 003f 0015 0015 0015 0015 0015
003f 0015 0015 0015 003f 0015 0015 0015 003f 0015 0015 0015 003f 0015 05d3
INPUT 3 0x48 0000 0069 0000 002a 0150 00a8 0015 0015 0015 0015 0015 0015 0015 003f 0015 003f 0015 0015 0015 0015 0015 003f 0015 0015 0015 0015 0015 0015
0015 003f 0015 003f 0015 0015 0015 0015 0015 0015 0015 0015 0015 0015 0015 0015 0015 003f 0015 0015 0015 0015 0015 003f 0015 0015 0015 003f 0015
003f 0015 003f 0015 0015 0015 003f 0015 003f 0015 0015 0015 003f 0015 05d3
INPUT 4 0x4a 0000 0069 0000 002a 0150 00a8 0015 0015 0015 0015 0015 0015 0015 003f 0015 003f 0015 0015 0015 0015 0015 003f 0015 0015 0015 0015 0015 0015
0015 003f 0015 003f 0015 0015 0015 0015 0015 0015 0015 0015 0015 003f 0015 0015 0015 003f 0015 0015 0015 0015 0015 003f 0015 0015 0015 003f 0015
0015 0015 003f 0015 0015 0015 003f 0015 003f 0015 0015 0015 003f 0015 05d3
INPUT ALL 0x47 0000 006D 0000 0022 0157 00AC 0016 0016 0016 0016 0016 0016 0016 003F 0016 003F 0016 0016 0016 0016 0016 0016 0016 0016 0016 0016 0016 0016
0016 003F 0016 003F 0016 0016 0016 0016 0016 003F 0016 003F 0016 003F 0016 003F 0016 0016 0016 0016 0016 0016 0016 003F 0016 0016 0016 0016
0016 0016 0016 0016 0016 003F 0016 003F 0016 003F 0016 0016 0016 003F 0016 0689
INPUT
DOWN 0x07 0000 006D 0000 0022 0157 00AC 0016 0016 0016 0016 0016 0016 0016 003F 0016 003F 0016 0016 0016 0016 0016 0016 0016 0016 0016 0016 0016 0016
0016 003F 0016 003F 0016 0016 0016 0016 0016 003F 0016 003F 0016 003F 0016 003F 0016 0016 0016 0016 0016 0016 0016 0016 0016 0016 0016 0016
0016 0016 0016 0016 0016 003F 0016 003F 0016 003F 0016 003F 0016 003F 0016 0689
INPUT UP 0x40 0000 006D 0000 0022 0157 00AC 0016 0016 0016 0016 0016 0016 0016 003F 0016 003F 0016 0016 0016 0016 0016 0016 0016 0016 0016 0016 0016 0016
0016 003F 0016 003F 0016 0016 0016 0016 0016 003F 0016 0016 0016 0016 0016 0016 0016 0016 0016 0016 0016 0016 0016 003F 0016 0016 0016 003F
0016 003F 0016 003F 0016 003F 0016 003F 0016 003F 0016 0016 0016 003F 0016 0689
1080i 0x18 0000 006D 0000 0022 0157 00AC 0016 0016 0016 0016 0016 0016 0016 003F 0016 003F 0016 0016 0016 0016 0016 0016 0016 0016 0016 0016 0016 0016
0016 003F 0016 003F 0016 0016 0016 0016 0016 003F 0016 0016 0016 0016 0016 0016 0016 003F 0016 003F 0016 0016 0016 0016 0016 0016 0016 003F
0016 003F 0016 003F 0016 0016 0016 0016 0016 003F 0016 003F 0016 003F 0016 0689
1080p 0x44 0000 006D 0000 0022 0157 00AC 0016 0016 0016 0016 0016 0016 0016 003F 0016 003F 0016 0016 0016 0016 0016 0016 0016 0016 0016 0016 0016 0016
0016 003F 0016 003F 0016 0016 0016 0016 0016 003F 0016 0016 0016 0016 0016 003F 0016 0016 0016 0016 0016 0016 0016 003F 0016 0016 0016 003F
0016 003F 0016 0016 0016 003F 0016 003F 0016 003F 0016 0016 0016 003F 0016 0689
3D 0x0f 0000 006D 0000 0022 0157 00AC 0016 0016 0016 0016 0016 0016 0016 003F 0016 003F 0016 0016 0016 0016 0016 0016 0016 0016 0016 0016 0016 0016
0016 003F 0016 003F 0016 0016 0016 0016 0016 003F 0016 0016 0016 0016 0016 003F 0016 0016 0016 0016 0016 0016 0016 003F 0016 0016 0016 003F
0016 003F 0016 0016 0016 003F 0016 003F 0016 003F 0016 0016 0016 003F 0016 0689
4K 0x51 0000 006D 0000 0022 0157 00AC 0016 0016 0016 0016 0016 0016 0016 003F 0016 003F 0016 0016 0016 0016 0016 0016 0016 0016 0016 0016 0016 0016
0016 003F 0016 003F 0016 0016 0016 0016 0016 003F 0016 003F 0016 0016 0016 0016 0016 0016 0016 003F 0016 0016 0016 003F 0016 0016 0016 0016
0016 003F 0016 003F 0016 003F 0016 0016 0016 003F 0016 0016 0016 003F 0016v0689
2.0ch
AUDIO 0x0a 0000 006D 0000 0022 0157 00AC 0016 0016 0016 0016 0016 0016 0016 003F 0016 003F 0016 0016 0016 0016 0016 0016 0016 0016 0016 0016 0016 0016
0016 003F 0016 003F 0016 0016 0016 0016 0016 003F 0016 0016 0016 003F 0016 0016 0016 003F 0016 0016 0016 0016 0016 0016 0016 0016 0016 003F
0016 0016 0016 003F 0016 0016 0016 003F 0016 003F 0016 003F 0016 003F 0016 0689
5.1ch
AUDIO 0x1e 0000 006D 0000 0022 0157 00AC 0016 0016 0016 0016 0016 0016 0016 003F 0016 003F 0016 0016 0016 0016 0016 0016 0016 0016 0016 0016 0016 0016
0016 003F 0016 003F 0016 0016 0016 0016 0016 003F 0016 0016 0016 003F 0016 003F 0016 003F 0016 003F 0016 0016 0016 0016 0016 0016 0016 003F
0016 0016 0016 0016 0016 0016 0016 0016 0016 003F 0016 003F 0016 003F 0016 0689
7.1ch
AUDIO 0x0e 0000 006D 0000 0022 0157 00AC 0016 0016 0016 0016 0016 0016 0016 003F 0016 003F 0016 0016 0016 0016 0016 0016 0016 0016 0016 0016 0016 0016
0016 003F 0016 003F 0016 0016 0016 0016 0016 003F 0016 0016 0016 003F 0016 003F 0016 003F 0016 0016 0016 0016 0016 0016 0016 0016 0016 003F
0016 0016 0016 0016 0016 0016 0016 003F 0016 003F 0016 003F 0016 003F 0016 0689
COPY EDID 0x1a 0000 006D 0000 0022 0157 00AC 0016 0016 0016 0016 0016 0016 0016 003F 0016 003F 0016 0016 0016 0016 0016 0016 0016 0016 0016 0016 0016 0016
0016 003F 0016 003F 0016 0016 0016 0016 0016 003F 0016 0016 0016 003F 0016 0016 0016 003F 0016 003F 0016 0016 0016 0016 0016 0016 0016 003F
0016 0016 0016 003F 0016 0016 0016 0016 0016 003F 0016 003F 0016 003F 0016 0689
USER 1 0x53 0000 006D 0000 0022 0157 00AC 0016 0016 0016 0016 0016 0016 0016 003F 0016 003F 0016 0016 0016 0016 0016 0016 0016 0016 0016 0016 0016 0016
0016 003F 0016 003F 0016 0016 0016 0016 0016 003F 0016 003F 0016 003F 0016 0016 0016 0016 0016 003F 0016 0016 0016 003F 0016 0016 0016 0016
0016 0016 0016 003F 0016 003F 0016 0016 0016 003F 0016 0016 0016 003F 0016 0689
USER 2 0x52 0000 006D 0000 0022 0157 00AC 0016 0016 0016 0016 0016 0016 0016 003F 0016 003F 0016 0016 0016 0016 0016 0016 0016 0016 0016 0016 0016 0016
0016 003F 0016 003F 0016 0016 0016 0016 0016 003F 0016 0016 0016 003F 0016 0016 0016 0016 0016 003F 0016 0016 0016 003F 0016 0016 0016 003F
0016 0016 0016 003F 0016 003F 0016 0016 0016 003F 0016 0016 0016 003F 0016 0689

HEX70HDU-KIT USER MANUAL
www.blustream.com.au | www.blustream-us.com | www.blustream.co.uk
16
RS-232 Configuration and Telnet Commands
The Blustream HDBaseT™ kit can be controlled via serial and TCP/IP.
The RS-232 port is used for configuration and control of the product, as well as pass through of RS-232 commands to
the Blustream HDBaseT™ receiver.
The default RS-232 communication settings are:
Baud rate: 57600
Data bit: 8
Stop bit: 1
Parity bit: none
The following pages list all available serial commands.
Commonly used Serial Commands
There are several commands that are commonly used for control and testing:
STATUS Status will give feedback on the kit such as input signals, type of connection etc...
PON Power on
POFF Power o
OUTxxFRyy (xx is the zone out, yy is the input)
Example:- OUT01FR04 (This would switch output 1 to source input 4)
Common Mistakes
• Carriage return – Some programs do not require the carriage return where as other will not work unless sent
directly aer the string. In the case of some Terminal soware the token <CR> is used to execute a carriage return.
Depending on the program you are using this token maybe dierent. Some other examples that other control systems
deploy include \r or 0D (in hex)
• Spaces – Blustream commands do not require space between commands unless specified. There may be some
programs that require spacing in order to work.
- How the string should look is as follows OUT01ON
- How the string may look if spaces are required: OUT{Space}01{Space}ON
• Baud rate or other serial protocol settings not correct

HEX70HDU-KIT USER MANUAL
contact: [e-mail] |[e-mail] |[e-mail] 17
RS-232 Configuration and Telnet Commands
COMMAND ACTION
?Print Help Information
HELP Print Help Information
STATUS Print System Status And Port Status
INSTA Print All Inputs Status
OUTSTA Print Outputs Status
CTRLSTA Print All Controls Status
PON Set System Power On
POFF Set System Power O
KEY ON/OFF Set System Key Control On Or O
IR ON/OFF Set system IR Control On or O
NOSIGDLY xxx Set No Signal Delay Timeout To xxx
(Default 0s, Range From 0s To 1800s)
RESET Reset System To Default Setting
(Type ‘Yes’ To Confirm, ‘No’ To Discard)
REBOOT Reboot System
POCOUT ON Set PoC Output On
POCOUT OFF Set PoC Output O
COAX ON/OFF Set Coax Audio Out On Or O
COMMAND ACTION
ANALOGUE ON/OFF Set Analogue Audio Out On Or O
BALANCEDAUD ON Set Analogue Audio Out To Balanced
BALANCEDAUD OFF Set Analogue Audio Out To Unbalanced
TX SWITCH aa Set Transmitter Switching To aa
RX SWITCH aa Set Receiver Switching To aa
TX TRGON x
Set The Trigger Method x On Transmitter Input To
Perform System On
x = 1 - HDMI (5V)
x = 2 - HDMI (TMDS)
RX TRGON x
Set The Trigger Method x On Receiver Input To
Perform System On
x = 1 - HDMI (5V)
x = 2 - HDMI (TMDS)
OUT xx FR yy
Set Output From Input:yy
xx = 00 : All RX Outputs
xx = 01 : RX Output 1
yy = 01 : TX HDMI Input
yy = 02 : TX USB-C Input
yy = 03 : TX DisplayPort Input
yy = 04 : RX HDMI Input
EDID xx DF zz
Set Input xx EDID To Default EDID zz (EDID Dip Switch
Must Be Switched To EDID Soware)
xx = 00: Select All Input Port
xx = [01...04]: Select One Input Port
zz = 00: HDMI 1080p@60Hz, Audio 2CH PCM (default)
01: HDMI 1080p@60Hz, Audio 5.1CH DTS/DOLBY
02: HDMI 1080p@60Hz, Audio 7.1CH DTS/DOLBY/HD
03: HDMI 1080i@60Hz, Audio 2CH PCM
04: HDMI 1080i@60Hz, Audio 5.1CH DTS/DOLBY
05: HDMI 1080i@60Hz, Audio 7.1CH DTS/DOLBY/HD
06: HDMI 1080p@60Hz/3D, Audio 2CH PCM
07: HDMI 1080p@60Hz/3D, Audio 5.1CH DTS/DOLBY
08: HDMI 1080p@60Hz/3D, Audio 7.1CH DTS/DOLBY/HD
09: HDMI 4K@30Hz 4:4:4, Audio 2CH PCM
10: HDMI 4K@30Hz 4:4:4, Audio 5.1CH DTS/DOLBY
11: HDMI 4K@30Hz 4:4:4, Audio 7.1CH DTS/DOLBY/HD
12: HDMI 4K@60Hz 4:2:0/4K@30Hz 4:4:4, Audio 2CH PCM
13: HDMI 4K@60Hz 4:2:0/4K@30Hz 4:4:4, Audio 5.1CH
DTS/DOLBY
14: HDMI 4K@60Hz 4:2:0/4K@30Hz 4:4:4, Audio 7.1CH
DTS/DOLBY/HD
15: HDMI 4K@60Hz 4:4:4, Audio 2CH PCM
16: HDMI 4K@60Hz 4:4:4, Audio 5.1CH DTS/DOLBY
17: HDMI 4K@60Hz 4:4:4, Audio 7.1CH DTS/DOLBY/HD
18: DVI 1280x1024@60Hz, Audio None
19: DVI 1920x1080@60Hz, Audio None
20: DVI 1920x1200@60Hz, Audio None
21: HDMI 1920x1200@60Hz, Audio 2CH PCM/6CH PCM
22: User EDID 1
23: User EDID 2
24: EDID Passthrough

HEX70HDU-KIT USER MANUAL
www.blustream.com.au | www.blustream-us.com | www.blustream.co.uk
18
COMMAND ACTION
EDID xx CP yy Set Input xx EDID Copy From Output yy
EDID SAVE zz Save EDID File From PC Into User Slot zz zz=22: User EDID 1
zz=23: User EDID 2
RELAY xx MODE yy
Set Relay xx to Mode yy
xx = 00 : All Relays
xx = 01 : Relay 1
xx = 02 : Relay 2
yy = 01 : Disable NO And Enable NC
yy = 02 : Enable NO And Disable NC
RELAY1 xxx
Set The Relay Delay 1 Time To xxx.(Default 10s,
Range From 3s To 180s) Triggered When System On.
If xxx = 000 Relay 1 Will Remain Active Until System
O(For Fixed 5V/12V Signal Sensing).
RELAY2 xxx Set The Relay Delay 2 Time To xxx.(Default 10s,
Range From 3s To 180s) Triggered When System O.
OUT xx PON Send Output xx CEC And RS232 Power On Command
OUT xx POFF Send Output xx CEC And RS232 Power O Command
OUT xx VOLUP Send Output xx CEC And RS232 Vol Up Command
OUT xx VOLDOWN Send Output xx CEC And RS232 Vol Down Command
OUT xx MUTE Send Output xx CEC And RS232 Mute Toggle
OUT xx INPUT yy
Send Output xx CEC Input Channel yy
xx = 01 : RX HDMI Output
yy = 00 : Next HDMI Channel
yy = [01...15] : HDMI Channel 01 To HDMI Channel 15
IN xx CEC POWER
Send Input xx CEC Power Toggle Command
xx = 01 : TX HDMI Input
xx = 02 : RX HDMI Input
RS232BAUD z Set RS232 Baud Rate To z z = 1 2400, 2 4800, 3 9600, 4 19200, 5 38400, 6 57600
(default), 7 115200"
COMMAND ACTION
RS232ON x:y:z:a
Send y Type Of Command a Stored In Slot x Whose
Baud Rate Is z
x = 1 Send RS232 Display On
x = 2 Send RS232 Display Input Select
x = 3 Send RS232 User Command 1
x = 4 Send RS232 User Command 2
x = 5 Send RS232 Volume Up
x = 6 Send RS232 Volume Down
x = 7 Send RS232 Volume Mute
y = a ASCII, h HEX
z = 1 2400, 2 4800, 3 9600, 4 19200, 5 38400, 6 57600
(Default), 7 115200
a = RS232 Command
RS232OFF y:z:a
Set RS232 O Command a Of y Type Whose Baud
Rate Is z
y = a ASCII, h HEX
z = 1 2400, 2 4800, 3 9600, 4 19200, 5 38400, 6 57600
(Default), 7 115200
a = RS232 command
RS232ON DISABLE Disable Auto RS232 Commands When Detecting A
Signal
RS232OFF DISABLE Disable Auto RS232 Commands When Not Detecting
A Signal
RS232RPT x
Set x Number Of Times RS232 OFF Command Is
Repeated (Default 1 Time, Range From 1 Time To 2
Times)
RS232RPTDLY xx
Set The Sending Interval Time In xx Second(s)
Between RS232 OFFs (Default 2s, Range From 1s To
10s)
RS232INPUTDLY xx
Set The Sending Interval Time In xx Second(s)
Between RS232 ONs (Default 10s, Range From 1s To
30s)
NET IP
xxx.xxx.xxx.xxx Set IP Address
NET GW
xxx.xxx.xxx.xxx Set Gateway Address
NET SM
xxx.xxx.xxx.xxx Set Subnet Mask Address
NET RB Set Network Reboot and Apply New Config
NET TN xxxx Set Telnet Port
NET DHCP ON/OFF Set Auto IP(DHCP) ON Or OFF
RS-232 Configuration and Telnet Commands

HEX70HDU-KIT USER MANUAL
contact: [e-mail] |[e-mail] |[e-mail] 19
Package Contents
Specifications
• 1 x HEX70HDU-TX
• 1 x HEX70HDU-RX
• 1 x 24V/5A DC Power Supply
• 1 x IR Emitter
• 1 x IR Receiver
• 1 x RS-232 Control Cable
• 2 x Mounting Kits
• 1 x Quick Reference Guide
Acknowledgements
DisplayPort™ and the DisplayPort™ logo are trademarks owned by the Video Electronics Standards Association (VESA®)
in the United States and other countries.
NOTE: Specifications are subject to change without notice. Weights and dimensions are approximate.
HEX70HDU-TX Transmitter
• Video Input Connectors: 1 x HDMI Type A, 19-pin, female; 1 x USB Type C; 1 x DisplayPort™
• Video Output Connectors: 1 x HDBaseT™ RJ45 connector
• RS-232 Serial Port: 1 x 3-pin phoenix connector
• TCP/IP Control: 1 x RJ45, female
• IR Input Ports: 2 x 3.5mm stereo jack
• IR Output Port: 1 x 3.5mm mono jack
• EDID: 4-pin DIP switch
• Product Upgrade: 1 x Micro USB, female
• Local Power Input: 1 x 24V/5A 4-PIN DIN connector
• Casing Dimensions (W x H x D): 180mm x 23.5mm x 155mm
HEX70HDU-RX Receiver
• Video Input Connectors: 1 x HDMI Type A, 19-pin, female; 1 x HDBaseT™ RJ45 connector
• Video Output Connectors: 1 x HDMI Type A, 19-pin, female
• Audio Output Connectors: 5-pin phoenix connector (2ch balanced / unbalanced analogue audio); 1 x RCA (S/PDIF)
• RS-232 Serial Port: 1 x 3-pin phoenix connector
• Relay Control: 2 x 3-pin Phoenix connectors
• IR Input Port: 1 x 3.5mm stereo jack
• IR Output Port: 1 x 3.5mm mono jack
• Product Upgrade: 1 x Micro USB, female
• Local Power Input: 1 x 24V/5A 4-PIN DIN connector
• Casing Dimensions (W x H x D): 180mm x 23.5mm x 155mm
• Operating Temperature: 32°F to 104°F (-5°C to +55°C)
• Storage Temperature: -4°F to 140°F (-25°C to +70°C)
• Shipping Weight: 2.3kg
• Power Supply: 24V/5A DC
REVA5_HEX70HDU-KIT_QRG_260520

HEX70HDU-KIT USER MANUAL
www.blustream.com.au | www.blustream-us.com | www.blustream.co.uk
20
FCC Notice
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of
the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used
in accordance with the instructions, may cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference
to radio or television reception, which can be determined by turning the equipment o and on, the user is encouraged
to try to correct the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit dierent from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
CAUTION - changes or modifications not expressly approved by the party responsible for compliance could void the
user’s authority to operate the equipment.
CANADA, INDUSTRY CANADA (IC) NOTICES
This Class B digital apparatus complies with Canadian ICES-003.
Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this device
must accept any interference, including interference that may cause undesired operation of the device.
CANADA, AVIS D’INDUSTRY CANADA (IC)
Cet appareil numérique de classe B est conforme aux normes canadiennes ICES-003.
Son fonctionnement est soumis aux deux conditions suivantes : (1) cet appareil ne doit pas causer d’interférence et (2)
cet appareil doit accepter toute interférence, notamment les interférences qui peuvent aecter son fonctionnement.
CORRECT DISPOSAL OF THIS PRODUCT
This marking indicates that this product should not be disposed with other household wastes. To
prevent possible harm to the environment or human health from uncontrolled waste disposal, recycle it
responsibly to promote the sustainable reuse of material resources. To return your used device, please
use the return and collection systems or contact the retailer where the product was purchased. They
can take this product for environmentally safe recycling.
Certifications
