Bluegrass Living GN3R111S User manual
www.bluegrassliving.com 200558-05A
1
OWNER’S MANUAL
OUTDOOR GAS FIRE PIT
(BATTERY NOT INCLUDED)
MODEL NO.:GN3R111S
ITEM NO.:140291
IMPORTANT，RETAIN FOR FUTURE REFERENCE:READ CAREFULLY
FOR OUTDOOR USE ONLY.NOT FOR COMMERICAL USE
Questions, problems, missing parts? Before returning to your retailer, call
our customer service department at 1-866-762-4050, 8:00 am - 4:30 pm CST,
www.bluegrassliving.com 200558-05A
2
SAFETY INFORMATION
Please read and understand this entire manual before attempting to assemble, operate or install the
product. This appliance has been tested to and complies with the ANSI Z21.97-2017, Outdoor
Decorative Gas Appliances. When connecting to a fixed piping system, The installation must conform
to local codes or the absence of local codes to the National Fuel Gas Code. ANSI Z223.1.NFPA 54;
National Fuel Gas Code; National Gas and Propane Installation Code, CSA B149.1; or Propane
storage and Handing Code, CSA B149.2, as applicable. This manual contains important information
about the assembly, operation and maintenance of this fire pit. Keep this manual for future reference
and to educate new users of this product. This manual should be read in conjunction with the labeling
on the product. Safety precautions are essential when any mechanical or propane fueled equipment is
involved. These precautions are necessary when using, storing, and servicing. Using this equipment
with the respect and caution demanded will reduce the possibilities of personal injury or property
damage. The following symbols shown below are used extensively throughout this manual. Always
heed these precautions, as they are essential when using any mechanical or fueled equipment.
DANGER
Do not store or use gasoline, or
other flammable vapours and
liquids in the vicinity of this or any
other appliance.
An LP-cylinder not connected for
use shall not be stored in the
vicinity of this or any other appliance.
WARNING:For Outdoor Use Only.
Installation and service must be
performed by a qualified
installer,service agency,or the gas
supplier.
Improper installation, adjustment,
alteration, service or maintenance
can cause property damage, injury
or death. Read the installation,
operation and maintenance
instructions thoroughly before
installing or servicing this
equipment.
DANGER
DANGER
FIRE OR EXPLOSION HAZARD
If you smell gas:
●Shut off gas to the appliance.
●Extinguish any open flame.
●If odour continues,leave the area
immediately
●After leaving the area,call your gas
supplier or fire department.
Failure to follow these instructions
could result in fire or
explosion,which could cause
property damage,personal injury,or
death.
DANGER
CARBON MONOXIDE
HAZARD
This appliance can produce
carbon monoxide which has
no odor. Using it in an
enclosed space can kill you.
Never use this appliance in
an enclosed space such as a
camper, tent or home.
WARNING
!
3www.bluegrassliving.com 200558-05A
SAFETY INFORMATION
DANGER
DANGER
DANGER indicates an imminently
hazardous situation which, if not
avoided, will result in death or serious
injury.
Failure to comply with the
precautions and instructions provided
with this fire pit can result in death,
serious bodily injury and property
loss or damage from hazards of fire,
explosion, burn, asphyxiation, and/or
carbon monoxide poisoning. Only
persons who can understand and
follow the instructions should use or
service this fire pit.
DANGER
Certain materials or items, when stored under the fire
pit, will be subjected to radiant heat and could be
seriously damaged.
Alert children and adults to the hazards of high surface
temperatures. Stay away from these surfaces to avoid
burning skin or igniting clothing.
Carefully supervise young children when in the vicinity
of the fire pit.
Do not hang clothing or any other flammable materials
from the fire pit, or place on or near the fire pit.
Replace any guard or protective device removed for
servicing the appliance prior to placing back in service.
Installation and repair should be done by a qualified
service person. The fire pit should be inspected before
use and annually by a qualified service person. More
frequent cleaning may be required as necessary. It is
imperative that the control compartment, burners, and
circulating air passageway of the appliance be kept
clean.
• EXPLOSION - FIRE HAZARD
• Keep solid combustibles,
such as building materials, paper
or cardboard, a safe distance away
from the fire pit as recommended by
the instructions.
• Provide adequate clearances
around air openings into the
combustion chamber.
• Never use the fire pit in spaces
which do or may contain volatile or
airborne combustibles, or products
such as gasoline, solvents, paint
thinner, dust particles or unknown
chemicals
• During operation, this product can
be a source of ignition. Keep fire pit
area clear and free from
combustible materials, gasoline,
paint thinner, cleaning solvents and
other flammable vapors and liquids.
Do not use fire pit in areas with high
dust content. Minimum fire pit
clearances from combustible
materials: three (3) feet from the
sides & tthree (3) feet from the rear,
six(6) feet from ceiling.
•This product is fueled by propane gas. Propane gas is
invisible, odorless, and flammable. An odorant is
normally added to help detect leaks and can be
described as a “rotten egg” smell. The odorant can fade
over time so leaking gas is not always detectable by
smell alone.
•Propane gas is heavier than air and leaking propane
will sink to the lowest level possible. It can ignite by
ignition sources including matches, lighters, sparks or
open flames of any kind many feet away from the
original leak. Use only propane gas set up for vapor
withdrawal.
•Store or use propane gas in compliance with local
ordinances and codes or with ANSI/NFPA 58. Turn off
propane when not in use.
WARNING
WARNING
4www.bluegrassliving.com 200558-05A
SAFETY INFORMATION
WARNING
We cannot foresee every use which may be made of
our fire pit.
Check with your local fire safety authority if you have
questions about fire pit use.
Other standards govern the use of fuel gases and heat
producing products for specific uses. Your local
authorities can advise you about these.
If no local codes exist, follow National Fuel Gas Code,
ANSI Z223.1. In Canada, installation must conform to
local codes. If no local codes exist, follow the current
National standards of CANADA CAN/CGA-B 149.2.
We cannot foresee every use which may be made of
our fire pit.Check with your local fire safety authority
if you have questions about fire pit use.
Other standards govern the use of fuel gases and heat
producing products for specific uses. Your local
authorities can advise you about these.
If no local codes exist, follow National Fuel Gas Code,
ANSI Z223.1. In Canada, installation must conform to
local codes. If no local codes exist, follow the current
National standards of CANADA CAN/CGA-B 149.2.
WARNING
Improper installation, adjustment,
alteration, service or maintenance can
cause property damage, injury or
death. Read the installation, operation
and maintenance instructions
thoroughly before installing or
servicing this equipment.
WARNING
CARBON MONOXIDE HAZARD
This fire pit is a combustion appliance.
All combustion appliances produce
carbon monoxide (CO) during the
combustion process. This product is
designed to produce extremely minute,
non-hazardous amounts of CO if used
and maintained in accordance with all
warnings and instructions. Do not
block air flow into or out of the fire pit.
Carbon Monoxide (CO) poisoning
produces flu-like symptoms, watery
eyes, headaches, dizziness, fatigue and
possibly death. You can't see it and you
can't smell it. It's an invisible killer. If
these symptoms are present during
operation of this product get fresh air
immediately!
For outdoor use only.
Never use inside house, or other
unventilated or enclosed areas.
This fire pit consumes air (oxygen). Do
not use in unventilated or enclosed
areas to avoid endangering your life.
DANGER
Do not store or use gasoline or other flammable vapors
and liquids in the vicinity of this or any other
appliance. An LP-cylinder not connected for use shall
not be stored in the vicinity of this or any other
appliance.
Never leave fire pit unattended when hot or in use.
Keep out of reach of children.
DANGER
Don’t burner solid fuels in
this appliance
WARNING
5www.bluegrassliving.com 200558-05A
OPERATION CHECKLIST
Operation Checklist
For a safe and pleasurable heating experience, perform this check before each use.
Before Operating:
1. I am familiar with entire owner’s manual and understand all precautions noted.
2. All components are properly assembled, intact and operable.
3. No alterations have been made.
4. All gas connections are secure and do not leak.
5. Wind velocity is below 10 mph.
6. Unit will operate at reduced efficiency below 40°F/4.44°C
7. Fire pit is outdoors (outside any enclosure).
8. There is adequate fresh air ventilation. Do not use this appliance if any part has been under
water. Immediately call a qualified service technician to inspect the appliance and to replace any
part of the control system and gas control which has been under water.
9. Fire pit is away from gasoline or other flammable liquids or vapors.
10. Fire pit is away from windows, air intake openings, sprinklers and other water sources.
11. Fire pit is at least 36 in. on rear and at least 36 in. on sides from combustible materials.
12. Fire pit is on a hard and level surface.
13. There are no signs of spider or insect nests.
14. All burner passages are clear.
15. All air circulation passages are clear.
16. Children and adults should be alerted to the hazards of high surface temperatures and should
stay away to avoid burns or clothing ignition.
17. Young children should be carefully supervised when they are in the area of the fire pit.
18. Clothing or other protective material should not be hung from the fire pit, or placed on or near
the fire pit.
19. Any guard or other protective device removed for servicing the fire pit must be replaced prior
to operating the fire pit.
20. Installation and repair should be done by a qualified service person. The fire pit should be
inspected before use and at least annually by a qualified service person.
21. More frequent cleaning may be required as necessary. It is imperative that control
compartment, burner and circulating air passageways of the fire pit be kept clean.
22. Do not use this appliance if any part has been under water. Immediately call a qualified service
technician to inspect the appliance and to replace any part of the control system and any gas control
that has been under water.
After Operation
1. Gas control is in OFF position.
2. Gas Tank valve is OFF.
3. Disconnect LP/NG Gas.
4. After each use, replace cap on tank.
7www.bluegrassliving.com 200558-05A
PART LIST
PART NO.
PRODUCT NO.
DESCRIPTION
QTY
A
140291-1
Lid
1
B
140291-2
Table top
1
C
140291-3
Table base left side panel
1
D
140291-4
Table base back panel
1
E
140291-5
Table base right side panel
1
F
140291-6
Door
1
G
140291-7
Tank shelf
1
H
140291-8
Door support
2
I
140291-9
Glass beads
1
J
140291-10
Rain Cover
1
K
140291-11
Burning system
1 Set
SCREW PACKAGE
PART NO.
Description
QTY
①
M6 Washer
20
②
Screw M6*15mm
2
③
Screw M6*20mm
16
④
Screw M6*35mm
2
⑤
Screw M4 *10mm
4
⑥
M4 Washer
4
⑦
Allen Key
1
15 www.bluegrassliving.com 200558-05A
INSTALLING LP GAS TANK
Connect LP Gas Tank
Before connecting, be sure that there is no debris
caught in the head of the LP gas tank, head of the
regulator valve or in the head of the burner and
burner ports.
Connect regulator/hose assembly to tank by
turning knob clockwise stops.
Disconnect LP Gas Tank
Before disconnecting make sure the LP gas tank
valve is "CLOSED".
Disconnect regulator/hose assembly from LP gas
tank by turning knob counterclockwise until it is loose.
Caution: LP gas tank must be properly disconnected
and removed prior to moving this pit.
Connect NG
1. A professionally-installed shut-off valve between the supply
piping and the socket is recommended, but not required, by the
National Fuel Gas Code. Socket connection must be made outdoors.
2. Coat the gas supply pipe nipple with gas resistant pipe dope or approved teflon tape. Screw socket onto gas
supply pipe (house gas source), and wrench-tighten.
3. Pull back the sleeve on the quick disconnect socket and insert the unattached end of the gas hose into the
socket. Release the sleeve and continue pushing the hose into the socket until the sleeve snaps into the locked
position.
4. When the quick disconnect socket and the gas hose are connected, a valve in the socket opens automatically
to permit full gas flow. When the gas hose is disconnected, the valve in the socket instantly and positively shuts
off the flow of gas, the grill can be disconnected from the gas source by disconnecting the gas hose from the
quick disconnect socket. The socket should be left attached to the gas source (hose piping).
Disconnect NG
With proper assembly, the gas hose cannot be removed without pushing the quick disconnect sleeve back. To
disconnect, push sleeve back and pull plug out of sleeve (this automatically shuts off gas).
The appliance and its individual shut off valve must be disconnected from the gas supply piping system during
any pressure testing on that system at test pressures in excess of 1/2 psi(3.5kPa).
The appliance must be isolated from the gas supply piping system by closing its individual manual shutoff valve
during any pressure testing of the gas supply piping system at test pressures equal to or less than1/2psi(3.5kPa).
This appliance can use two fuel gas: LPG-Propane OR Natural Gas
Suitable LP gas tank size for this appliance is 20IB(9.1KG)
Do not fill the LP gas tank with more than 80% liquid gas
The in let gas supply pressure for the purpose of input adjustment pressure:
LPG-Propane 11”in w.c.(2.74kPa)
Natural Gas 7”in w.c.(1.74kPa)
The appliance must be isolated from the gas supply piping system by closing its individual
manual shutoff valve during any pressure testing of the gas supply piping system at test
pressures equal to or less than 1/2psi (3.5kPa)
The LP-gas supply cylinder to be used must be: constructed and marked I accordance with the
U.S. Department of Transportation (D.O.T.) Specifications for LP-Gas Cylinders. Provided with a
listed overfilling prevention device, and provided with a cylinder connection device compatible
with the connection for the appliance.
WARNING: Make sure LP gas tank valve is closed.
Close by turning valve clockwise.
Place the LP gas tank upright into the tank tray and secure the tank by screw.
LP GAS
NG
16 www.bluegrassliving.com 200558-05A
LEAK TESTING
WARNING: Before using this outdoor fire pit, make sure you have read, understand and
are following all information provided in the Dangers and Warnings. Failure to follow
those instructions can cause death ,serious injury or property damage.
WARNING Never use your fire pit without leak testing all gas connections, hoses and propane tank.
DANGER To prevent fire or explosion hazard:
♦ DO NOT smoke or permit ignition sources in the area while conducting a leak test.
♦ Perform test OUTDOORS in a well-ventilated area that is protected from the wind.
♦ Never perform a leak test with a match or open flame.
♦ Never perform a leak test while the fire pit is in use or while the fire pit is still hot.
WHEN TO PERFORM A LEAK TEST:
● After assembling your fire pit and before lighting for the first time, even if purchased fully-assembled.
● Every time the LP gas cylinder is refilled, exchanged or if any of the gas components are disconnected or
replaced.
● Any time your fire pit has been moved.
● At least once per year or if your fire pit has not been used for more than 60 days.
CAUTION Strong odors, colds, sinus congestion, etc. May prevent the detection of propane
by smell. Use caution and common sense when testing for leaks.
Note: The leak test must be performed in an area that has adequate lighting in order to see if bubbles are
developing and not in a windy or noisy area so larger leaks can be detected by smell or sound.
1.Create a mixture of 50% water and 50% liquid dishwashing soap.
2.Ensure all control knobs are set to the ‘OFF’position.
3.Turn on the gas at the cylinder valve. Turn the cylinder valve knob counter-clockwise until fully
opened. If you hear a rushing sound or smell gas, turn the gas off. Tighten any leaking
connections. If leak is detected at connection nut and tightening does not stop leak, re-inspect
propane tank rubber seal.
4.Apply the soapy water mixture to the following:
A Supply tank(cylinder) welds. B Connection nut to tank valve.
C Back side of connection nut to brass nipple. D Brass nipple connection into regulator.
E Regulator connections to gas supply hoses. F Hose connection to gas manifold.
G The full length of gas supply hose. H Tank valve to cylinder.
5.Check each place listed(A-H) for growing bubbles, which indicates a leak. Large leaks may not be
detected by bubbles but should produce a rushing sound or gas smell.
6.Turn off gas supply at cylinder valve.
7.Turn on control knobs to release gas pressure in hose.
8.Turn control knobs to ‘OFF’position.
9.Tighten any leaking connections. If leak is detected at connection nut and tightening does not
stop leak, re-inspect propane tank rubber seal.
10.Repeat soapy water test until no leaks are detected.
11.Turn off gas supply at cylinder valve until you are ready to use your fire pit.
12.Wash off soapy residue with cold water and towel dry.
CAUTION: Natural Gas leak testing is similar to LP Gas leak testing, the different is you need to
apply the soapy water mixture to the gas supply pipe nipple.
19 www.bluegrassliving.com 200558-05A
LIGHTING INSTRUCTIONS
Caution: Keep outdoor gas cooking appliance area clear and free from combustible materials,
gasoline and other flammable vapors and liquids.
Caution: Do not obstruct the flow of combustion and ventilation air.
Caution: Check and clean burner/venturi tubes for insects and insect nests. A clogged tube can lead to
a fire beneath the grill.
Caution: Attempting to light the burner with the lid closed may cause an explosion.
Lighting
1. Read instructions before lighting.
2. Control knob must be in the "OFF" position.
3. Connect propane cylinder/open the gas supply line.
4. Push and turn control knob couter clockwise to "LOW". Hold the knob, until the flame doesn't go out.
5. Press the IGNITION button and hold for up to 5 seconds to light burner.
6. Release control knob after 45 seconds.
7. If ignition does not occur in 45 seconds, push and turn burner control knob to "OFF" wait 5 minutes,
and repeat lighting procedure.
8. If igniter does not light burner, use a long match or long butane lighter.
9. Adjust flame to desired flame with the control knob.
90cm/36in/36po
90cm/36in/36po
Minimum clearance:Top:6Ft.(72")sides:2ft.(36")
Minimum clearance from sides and back of unit to adjacent combustible construction below top
of unit,36 inches from sides 36 inches from back.
CAUTION:20lb LP cylinder only.
20 www.bluegrassliving.com 200558-05A
TROUBLESHOOTING
PROBLEM
POSSIBLE CAUSE
CORRECTIVE ACTION
Propane cylinder is empty
Replace propane cylinder
Burner won’t light
Blockage in orifice
Clear blockage
Control knob is not in ON position
Turn control knob to ON
Gas pressure is low
Turn cylinder valve OFF and fill the
cylinder
Burner flame is low
Outdoor temperature is less than 40ºF and
Use a full cylinder
tank is less than 1/4 full
Control knob fully ON
Check burner and orifices for
blockage
Carbon build-up
Dirt or film on reflector and burner screen
Clean reflector and burner screen
Thick black smoke
Blockage in burner
Remove blockage and clean burner
inside and outside
This manual suits for next models
1
Table of contents
Other Bluegrass Living Outdoor Fireplace manuals
Bluegrass Living
Bluegrass Living HF36177 Quick start guide
Bluegrass Living
Bluegrass Living BFPW30RH User manual
Bluegrass Living
Bluegrass Living BFPR-33 User manual
Bluegrass Living
Bluegrass Living HF26900 Quick start guide
Bluegrass Living
Bluegrass Living HF42708 Quick start guide
Bluegrass Living
Bluegrass Living GN1Q121S User manual
Bluegrass Living
Bluegrass Living FP-004T User manual
Bluegrass Living
Bluegrass Living PAG-1106FI User manual
