Bluetooth®
True Wireless Earbuds
User Manual
Model No. 035-7309-4
BUILT-IN
MICROPHONE

1. Use the product for its intended purpose only.
2. Do not disassemble product. This product does not contain parts that are
entitled to self-sufficient repair.
3. Keep away from children under the age of 3, as it contains small parts.
4. Avoid use in humid conditions or extreme temperatures. High heat will
shorten lifespan of electronic components, damage battery and deform
some plastic parts. Avoid extreme cold temperatures as damage to the
PCB board may occur.
5. Keep away from vibrations and mechanical stress, which can cause
mechanical damage to the product. In case of mechanical damage,
warranty is voided.
6. Do not use product while driving any vehicle as it may distract your
attention. Check your local laws and regulations.
7. High volume may lead to permanent hearing damage and hearing loss.
Set the volume at a reasonable setting and avoid loud volumes at all
times.
8. Danger of fire, explosion and burns if the operating temperature is
substantially exceeded, if the electronics housing is opened and in case
of battery short-circuit, when touching a leaking battery.
9. Do not charge continuously for more than 10 hours as this will shorten
the lifespan of the product.
Usage precautions

Key Parts Diagram
Battery Level Indicator
Micro USB Charging Port
Charging Pin Charging Pin
Left Earbud Right Earbud
LED Indicator
Power Key
USB Charging Cable 3 Pairs of Earbuds Caps
Earbuds LED Indicator
Earbuds status
In idle mode after paired
Incoming call
Low battery
Charging
Power on
Power off
True Wireless Earbuds pairing
Bluetooth®pairing
LED Indication
Blue light flickers once every 7 seconds
Blue light flickers once every 7 seconds
Red light flickers once every 2 seconds
Red light is on
Blue light flickers once
Red light flickers once
Blue and red light flickers alternatively
Blue and red light flickers alternatively
Charging Case

Sounds & Voice Prompt Functions
Charging Your Earbuds and Charging Case
Function
Powering on your Earbuds
Powering off your Earbuds
Power on and Pairing
Disconnecting from Bluetooth®
Low battery power
True Wireless Earbuds pairing
True Wireless Earbuds connected
Bluetooth®pairing
Bluetooth®connected
Incoming call
Voice Prompt/Audio Tone
Power On
Power Off
Power On, Pairing
Disconnected, Pairing
Please charging
Searching for slave
Pairing success, Connected
Left Channel, Right Channel
Pairing
Pairing success, Connected
You have an incoming call
The Earbuds have an internal,
rechargeable charging case which
must be fully charged before using for
the first time. It takes 1 1/2 hours to
fully charge the unit for the first time.
You can charge the charging case
either by using an AC adaptor (max
output: 5 V 1 A) or a PC.
The charging case can charge the
Earbuds 3 times after fully charged.
When the charging case is fully charged, the four
battery level indicator will turn blue.
Put the Earbuds into the charging case to charge.
During charging, The red charging LED indicator on
the Earbuds will be on. When the battery is fully
charged, the red LED indicator will turn off.
You can charge your Earbuds at any time when you
put them back into the charging case.

Pairing Your Earbuds with a Bluetooth®Device
Note: When the Earbud batteries are out of power, the red LED indicator
starts to flicker every 2 seconds with prompt of "please charging" every 60
seconds. The Earbuds need to be charged as soon as possible.
Put Earbuds on the charging case; the Earbuds can not be operated during
charging.
Once charging case charging has been completed, remove the micro-USB
plug from the charging case.
The charging case is only for charging of the Earbuds. DO NOT recharge
other devices.
PRESS &
HOLD
5 SEC
True Wireless Earbuds Pairing Mode
Red & Blue Flashing LED
①
②True Wireless Earbuds Paired Red &
Blue Flashing LED (Main Earbuds)
③Bluetooth®Connected
Blue Flashing LED
035-7309-4 Connected
MY DEVICES
Bluetooth
Bluetooth
Sengs

1. Press and hold both Earbuds power keys until the red and blue LED
indicator flickers alternately, with prompt of "Power On" to indicate the
Earbuds are on. The prompts "Connected", "Left Channel", "Right
Channel" will indicate that the left and right true wireless Earbuds are
connected with each other.
2. The red and blue LED indicator flickers alternately, with prompt "pairing"
to indicate your Earbuds are in Bluetooth® pairing mode.
3. Go to the Bluetooth®settings menu on your phone / tablet / Bluetooth®
devices. Make sure that Bluetooth®is turned on. Connect to the device
listed as "035-7309-4". A prompt " Pairing Success, Connected"
indicates your device has been successfully connected and the Earbuds
are ready to use.
Note: If pairing is not completed within 5 minutes, the Earbuds will
automatically power off. If this happens, repeat the pairing steps above.
Using Your Earbuds
The medium size of the Earbud Caps have
been placed on the Earbuds.
Change to another size of caps to fit your ears.
PRESS ONCE
PRESS TWICE
Play / Pause Music
PRESS & HOLD Power On / Power Off
Answer Call / End Call
Redial
Reject a Call

Tips for True Wireless Earbuds Pairing
Specifications
True Wireless Earbuds pairing is a technical term of using the Bluetooth®
product. Two Bluetooth®enable devices can be connected.
It will automatically distinguish between left channel and right channel
Earbuds.
Either one of the Earbuds can be the main one and should be paired and
connected with Bluetooth®mobile phone.
After True Wireless Earbuds connecting, you can play / pause (Power Key)
music through either of the two Earbuds, but only the main Earbud has call
function.
When the True Wireless Earbuds are "On", press and hold Power Key of
either headset for 5 seconds to power both Earbuds off.
If they are not in True Wireless Earbuds connection, you can pair and
connect them respectively with Bluetooth®mobile phone.
Bluetooth®Specifications: V 4.2
Bluetooth®Profiles Supported: HFP / A2DP / AVRCP
Effective Range: Up to 10 m (32')
Each Earbud Battery: 45 mAh
Charger Case Battery: 400 mAh
Charging Time for Earbuds: 1 1/2 hours
Charging Time for Case: 2 1/2 hours
Playing Time: up to 3 hours (at medium volume)
Talking Time: up to 4 hours (at medium volume)
Standby Time: 25 hours
Frequency Response: 20-20k HZ
Includes Charging Cable, 3 ear caps (S,M,L)
Working Temperature: -5°C to 35°C (23°F to 95°F)
Storage Temperature: -5°C to 60°C (23°F to 140°F)

Maintenance and Care
Before using your Earbuds and charging case, examine the Earbud caps to
make sure that they are clean. Similarly, inspect the ports and jacks of your
Earbuds and charging case to make sure that they are clear of dust and
debris before charging.
Use a soft cloth or paper towel to clean your Earbuds and charging case. Do
not allow moisture to get inside the Earbud caps. Never use any harsh
chemicals or detergents for cleaning. Make sure your Earbuds and charging
case are dry before using.
When your Earbuds and charging case are not in use, they should be stored
in a cool, dry place.
Never tug or yank on the USB cable while it is connected to your charging
case. Connect and disconnect cables as carefully as possible.
Never expose your Earbuds and charging case to high temperatures,
extreme cold, high humidity or excessive moisture or water.
The Bluetooth®word mark and logos are registered trademarks owned by
Bluetooth SIG, Inc. and any use of such marks by HANK Electronics Co., Ltd.
is under licence. Other trademarks and trade names are those of their
respective owners.
Made in China
Imported by Trileaf Distribution Toronto, Canada M4S 2B8
Product must be recycled or disposed of properly. Dispose of as per
the requirements of your local municipality.
This Class B digital apparatus complies with Canada ICES-003.
CAN ICES-3(B)/NMB-3(B)
IC: 25177-208T
This device complies with Industry Canada licence-exempt RSSs. Operation
is subject to the following two conditions:
(1) This device may not cause interference; and
(2) This device must accept any interference, including interference that
may cause undesired operation of the device.
The term “IC: ” before the certification/registration number only signifies that
the Industry Canada technical specifications were met. This product meets
the applicable Industry Canada technical specifications.
