BLUM TANDEMBOX intivo User manual

Assembly instruction 安裝說明
TANDEMBOX intivo BOXCOVER - 配插板扣碼
Pull-out
高抽屜
Inner pull-out
內高抽屜
TANDEMBOX intivo BOXCOVER
Adjustment 調節
BAU0042174262 IDX:01 IDNR:032.711.56 MA-654/0ML 09.16
Copyright Blum
Blum Furniture Hardware
Hongkong Limited
Tel.: [phone]
Fax: [phone]
E-Mail: [email protected]
www.blum.com.hk
Inner pull-out 內高抽屜
Removal 拆卸
1
2
3
1
3
2
Pull-out 高抽屜
4
3
3
4
1
2
2
1
Space requirement and installation dimensions 所需空間及安裝尺寸
Attention:
Avoid dust get into the cabinet
profile during installation
請注意：
安裝時請避免木屑掉進路軌
- Wipe using lightly damp soft cloth
用微濕的軟布抹擦
- Only use clean water, do not use chemical cleaners
使用淸水便可，請勿使用化學淸潔劑
Cleaning Instructions 淸潔指引

2
TANDEMBOX intivo BOXCOVER
KB Cabinet width 櫃體淨闊
LW Internal cabinet width 櫃體內闊
A
B
LW
KB
NL Nominal Length 標稱長度
A
B
Base with chipboard back 底板深度
NL - 24 mm
Back height 背板高度
D 高度 = 199 mm
LW - 87 mm
LW - 75 mm
3
Cutting dimensions for 16mm components 使用16mm 刨花板裁切尺寸
Cabinet profile screw positions 導軌固定螺絲位置
Cabinet profile 導軌 558 - 30kg
Cabinet profile 導軌 556 - 65kg
A Chipboard screws 木工螺絲 Ø 4 x 15 mm
B System screws 系統螺絲 Part no. 661.145
96
37
192
320
9
96
32
3232
480
32
3232
32
450
500
550
600
650
400
350
300
270
NL Nominal Length 標稱長度 (mm)
Min. internal cabinet depth = nominal length NL + 3 mm
最小櫃體淨深 = 標稱長度 + 3 mm
A
B
*
*
*
*
*
270
300
450
400
500
optional – guarantees optimum stability 可選 - 確保最佳穩定性
*
A
B
Pull-out 高抽屜
Planning information 計劃
Space requirement in cabinet
櫃體內所需空間
Back installation dimensions
背板安裝尺寸
Front drilling dimensions - EXPANDO front
前面板鑽孔尺寸- 脹塞脹緊式固定件
Assembly 安裝
2
3
Front stabilisation piece assembly
前板穩定件 - 安裝於抽屜底部
Z96.10E1
Pull-out 高抽屜Inner pull-out 內高抽屜
Inner pull-out front assembly please refer to appendix
內高抽�前面板裝配請參閱附錄
Pull-out 高抽屜
Inner pull-out 內高抽屜
6
7
8
4 5
4
5
6
7
8
