BodiMetrics O2 Vibe User manual

O2 Vibe Wrist Pulse Oximeter
Quick Start Guide
The O2 Vibe Pulse Oximeter can monitor whole night blood oxygen
saturation (SpO2) and heart rate and detect oxygen drops. The built-in
vibrator can help people to overcome the oxygen shortage period,
therefore to improve their sleep quality. O2 Vibe can also be used for
fitness monitoring and activity tracking.
Caution
This product is not a medical device, DO NOT use it for the diagnosis
and treatment of any medical condition.
Package content
1 O2 Vibe Main Unit
1 Ring Sensor
1 USB Cable (Micro D)
1 Start Quick Guide
Using O2 Vibe Pulse Oximeter
Charge the battery before the first use
Connect the battery using the USB cable provided for about 2 hours or
until the screen shows fully charged icon .
Install O2 VIBE APP
Download and install the app O2 Vibe from the Apple APP Store or
Google Play Store.
Power on/off
Press and hold the button for 1 second to power on the device, 3
seconds to power off the device.
View results and set preferences via APP
After each measurement or when you turn on the device, the results
can be provided in the APP on your phone via Bluetooth. Turn on the
Bluetooth of your phone, enter the O2 Vibe app and choose the right
device, then the device and your phone will connect successfully. You
can switch on/off vibration, adjust intensity and threshold (SpO2) of
vibration, and set steps goal in the app.
Note: The device Bluetooth will automatically turn on within the first
2 minutes. Or it turns on after measurement complete until power off.
Get it work
1. Connect the ring sensor to the connector on
the device.
2. Wear the ring sensor into your thumb as
picture or other finger in the case of not fitting
well.
3. Press the button to turn on the device,
change the mode by press the button in the first
4 seconds if necessary. After a few seconds, your
SpO2reading will appear on the screen.
About O2 Vibe screens
SpO2Percent oxygen saturation
Heart rate
Insert the plug into the connector on the device
Slide your finger into the sensor
O2 score and Drop times (SpO2lower than threshold)
Steps
O2 Score range in the APP

Switching operation mode
The device has 2 operation modes, Sleep mode and Fitness mode,
press the button can switch between this two modes within 4 seconds
after power on.
Sleep Mode
Fitness mode
Symbol
Screen
Go black 2 minutes later
Always on
Pedometer
No
Yes
Vibrate when
SpO2<threshold
SpO2<threshold
or
meet steps goal
Recording time
10 hours
5 hours
Sleep Mode
The screen will go black automatically in 2 minutes after power on.
Press the button can wake screen up and show measurement results,
seconds later the screen goes black again when there is no operation.
Fitness mode
Press the button can change display among measurement results, step
numbers and device status.
Specifications
Weight
35g (main unit)
Size
44×25×15 mm (main unit)
Display
0.69"OLED
Battery
Rechargeable Lithium-polymer
Charge time
2 hours
Wireless
Bluetooth 4.0 BLE
SpO2 range
70% to 100%
Heart Rate range
30 to 250 bpm
Pedometer range
0-99999 steps
Activity Gauge
Yes
Vibrator
Trigged by low oxygenation and steps
goal
Recording time
Sleep Mode: 10 hours
Fitness Mode: 5 hours
Recorded
parameters
SpO2, heart rate, activity
Troubleshooting
Problem
Possible Cause
Possible Solution
Device
does not
turn on.
Battery may be
low.
Charge battery and try again.
Device might be
damaged.
Please contact your local
distributor.
The app
cannot
find O2
device.
Bluetooth of O2
device is off.
Press the button for 8 seconds
to restart. Connect the device
within 2 minutes after power
on, or after measurement
complete.
SpO2or
heart rate
does not
play.
Finger positioned
wrong.
Reposition or replace finger.
Thumb is recommended.
Finger is cold.
Warm finger by rubbing.

How to contact us?
Shenzhen Viatom Technology Co., Ltd
4E,Building 3, Tingwei industrial Park, Honlang North 2nd Road,
Xin’an Street, Baoan District, 518101 Shenzhen, P.R.China
www.viatomtech.com
PN：255-00917-00 Version: A
Contents of this manual are subject to changes without prior notice.
©Copyright 2016 Shenzhen Viatom Technology Co., Ltd. All rights
reserved.
FCC Statement
1. This device complies with Part 15 of the FCC Rules. Operation is
subject to the following two
conditions:
(1) This device may not cause harmful interference.
(2) This device must accept any interference received, including
interference that may cause
undesired operation.
2. Changes or modifications not expressly approved by the party
responsible for compliance could
void the user's authority to operate the equipment.
NOTE: This equipment has been tested and found to comply with the
limits for a Class B digital device, pursuant to part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against
harmful interference in a residential installation.
This equipment generates uses and can radiate radio frequency
energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined
by turning the equipment off and on, the user is encouraged to try to
correct the interference by one or more of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
-Connect the equipment into an outlet on a circuit different from that
to which the receiver is connected.
-Consult the dealer or an experienced radio/TV technician for help
