Lutech LT-300 SD User manual

LT-300 SD and LT-300 HD
Digital Video Colposcope
Operator’s Manual
Lutech Industries, Inc.
Version 5.2 – 210423

Page 1 of 60
Table of Contents
Key Information....................................................................................................................................................4
1. Product Information .................................................................................................................................4
2. Manufacturer ............................................................................................................................................4
3. EU Representative....................................................................................................................................4
4. Version......................................................................................................................................................4
5. Markings...................................................................................................................................................4
6. Classification............................................................................................................................................5
7. Support and Maintenance.........................................................................................................................5
7.1 Warranty..................................................................................................................................................5
7.2 After Sales Service..................................................................................................................................6
8. Indication for Use.....................................................................................................................................6
9. Safety Terminology ..................................................................................................................................6
9.1 Hardware.................................................................................................................................................7
9.2 Software..................................................................................................................................................8
Chapter 1: Introduction......................................................................................................................................10
1.1 Scope........................................................................................................................................................10
1.2 Features....................................................................................................................................................10
1.3 System and Main Components ................................................................................................................10
1.4 Installation Preparation............................................................................................................................11
1.5 Unpacking and Inspecting........................................................................................................................12
1.6 Additional Information.............................................................................................................................12
Chapter 2: Camera and Stand Assembly............................................................................................................13
2.1 Camera Composition ...............................................................................................................................13
2.2 What’s included with the Colposcope......................................................................................................13
2.3 Pre-Assembly Check List ........................................................................................................................14
2.3.1 Vertical Stand Parts List.....................................................................................................................14
2.3.2 Swing Arm Stand Parts List...............................................................................................................14
2.4 Colposcope with Vertical Stand Assembly ..............................................................................................14
2.5 Colposcope with Swing Arm Stand Assembly .........................................................................................21
2.6 Troubleshooting ........................................................................................................................................26
2.6.1 Vertical Stand Assembly Troubleshooting .........................................................................................26
2.6.2 Swing Arm Stand Assembly Troubleshooting ...................................................................................28
2.7 Tips and Suggestions ...............................................................................................................................29
Chapter 3: Colposcope Adjustments..................................................................................................................31
3.1 Camera Angle Adjustment .......................................................................................................................31
3.2 Vertical Stand Adjustment........................................................................................................................31
3.3 Swing Arm Stand Adjustment..................................................................................................................32
3.4 Casters Adjustment ...................................................................................................................................32

Page 2 of 60
3.5 Remote Hanger ........................................................................................................................................33
Chapter 4: TV Screen or Workstation Setup......................................................................................................34
4.1 TV Screen Setup ......................................................................................................................................34
4.2 Computer Setup .......................................................................................................................................35
4.2.1 Connecting the Colposcope to a Computer........................................................................................35
4.3 Colposcope Workstation ...........................................................................................................................37
Chapter 5: Camera Operation ............................................................................................................................38
5.1 Preliminary Check List ............................................................................................................................38
5.2 Function Buttons......................................................................................................................................38
5.3 Tips for Achieving Optimal Image Clarity ..............................................................................................39
Chapter 6: Lutech Viewer ..................................................................................................................................41
6.1 Safety Safety Terminology.......................................................................................................................41
6.1.1 WARNING.........................................................................................................................................41
6.1.2 NOTE................................................................................................................................................41
6.1.3 Copyright ...........................................................................................................................................41
6.2 Installation ................................................................................................................................................41
6.2.1 Computer Specification Requirements ..............................................................................................41
6.2.2 Downloading the Software ................................................................................................................42
6.2.3 Installing the Software .......................................................................................................................42
6.3 Operation ..................................................................................................................................................44
6.3.1 Main Screen.......................................................................................................................................44
6.3.2 Session Window.................................................................................................................................46
6.3.3 Foot Pedal ..........................................................................................................................................46
6.3.4 Full Screen Mode...............................................................................................................................47
6.3.5 Picture Review...................................................................................................................................47
6.3.6 Video Review.....................................................................................................................................48
6.3.7 End Session........................................................................................................................................48
6.3.8 Test Session........................................................................................................................................48
6.4 Lutech Viewer Troubleshooting................................................................................................................48
6.4.1 Video Source Troubleshooting...........................................................................................................48
6.4.2 Foot Pedal Troubleshooting ...............................................................................................................49
6.4.3 Display Troubleshooting....................................................................................................................49
6.4.4 Saving Files Troubleshooting ............................................................................................................50
6.5 Folder Naming Structure...........................................................................................................................50
6.6 Picture and Video Naming Structure.........................................................................................................51
Chapter 7: Cleaning and Maintenance...............................................................................................................52
7.1 Cleaning...................................................................................................................................................52
7.1.1 Cleaning the colposcope enclosure and vertical stand .......................................................................52
7.1.2 Cleaning the colposcope cables .........................................................................................................52
7.1.3 Cleaning the lens, mini LCD screen, and the LED circular light.......................................................53

Page 3 of 60
7.2 Maintenance.............................................................................................................................................53
7.3 Battery......................................................................................................................................................54
7.4 Storage .....................................................................................................................................................54
7.5 Transportation ..........................................................................................................................................55
7.6 Device Disposal .......................................................................................................................................55
Chapter 8: Troubleshooting................................................................................................................................56
8.1 Troubleshooting .......................................................................................................................................56
Appendix A– Specification.................................................................................................................................58
I. Power Supply/Adapter................................................................................................................................58
II. Battery.......................................................................................................................................................58
III. Grounding ................................................................................................................................................58
IV. Environmental Specifications ..................................................................................................................58
V. Colposcope Specifications.........................................................................................................................59
VI. Monitor....................................................................................................................................................60

Page 4 of 60
Key Information
NOTE: Unless specifically noted for one or the other, the following information is true for
both the LT-300 SD and the LT-300 HD digital video colposcopes.
1. Product Information
Model:
LT-300 SD
LT-300 HD
Product:
Digital Video colposcope
Digital Video colposcope
Applied
Part:
None. Product does not come
into contact with patient.
None. Product does not come into
contact with patient.
Electrical
Class
Class I
Class I
2. Manufacturer
Lutech Industries, Inc.
105 Remington Blvd., Suite C, Ronkonkoma, NY 11779, U.S.A.
T: (631) 676 – 7432
F: (631) 619 – 0723
www.lutechmedical.com
[email protected]
3. EU Representative
Arazy Group GmbH
The Squaire 12, Am Flughafen,
60549 Frankfurt am Main
Deutschland
Tel: [phone]
Fax: [phone]
4. Version
This instruction for use will update without notice.
Version: 5.1
Copyright: © 2021 Lutech Industries, Inc.
5. Markings
The following marks are included on the product:
Mar
k
Description

Page 5 of 60
Protect Against
Water
Fragile Contents
Manufacturer
Serial Number
Rx Only
6. Classification
The following is the classification information:
7. Support and Maintenance
7.1 Warranty
Lutech warrants The LT-300 SD and LT-300 HD digital video colposcopes, when new, to be free of defects
in material and workmanship and to perform in accordance with manufacturer's specifications for a period of
one year commencing on the date of purchase from Lutech or its authorized distributors. Extended warranty
is available. Please ask a Lutech representative or your representative for more information. Lutech, or its
authorized distributor, service center, or agents (collectively, “Repair Center”), will either repair or replace
any components found to be defective or operating outside of manufacturer's specifications within the
warranty period at no cost to the customer. It shall be the purchaser's responsibility to return the colposcope
to the Repair Center. This warranty does not cover breakage or failure due to improper use, modification,
neglect, accidents, or shipping damage. In Addition, this warranty is also void if the instrument is not used in
accordance with the instruction manual or if repaired by someone other than a Lutech Repair Center.
Purchase date determines warranty requirements. No other express warranty is given. Please keep the
packaging material for future transportation and/or storage needs.
WARRANTY LIMITATIONS: THE DURATION OF ANY IMPLIED WARRANTY OR CONDITION, OF
MERCHANTABILITY, FITNESS FOR A PARTICULAR PURPOSE, OR OTHERWISE, ON THIS PRODUCT
Classification Principle
Classification
Type of protection against electric
shock.
Class I
Degree of protection against electric
shock.
Type B
Mode of operation
Continuous operation
Degree of protection against ingress of
water.
Normal device.
Degree of safety in the presence of a
flammable anesthetic mixture with air,
oxygen or nitrous oxide.
Non AP or APG equipment
Type of management
Type II. Classification code 6822

Page 6 of 60
SHALL BE LIMITED TO THE DURATION OF THE EXPRESS WARRANTY SET FORTH ABOVE. IN NO
EVENT SHALL LUTECH BE LIABLE FOR ANY LOSS, INCONVENIENCE OR DAMAGE, WHETHER
DIRECT, INCIDENTAL, CONSEQUENTIAL OR OTHERWISE, RESULTING FROM BREACH OF ANY
EXPRESS OR IMPLIED WARRANTY OR CONDITION, OF MERCHANTABILITY, FITNESS FOR A
PARTICULAR PURPOSE OR OTHERWISE WITH RESPECT TO THIS PRODUCT, EXCEPT AS SET
FORTH HEREIN.
7.2 After Sales Service
The standard warranty for the LT-300 SD and LT-300 HD colposcopes is 1 year from the date of purchase.
Warranties may vary from 1-3 years depending on purchase terms. Please ask your Lutech representative
or distributor for more details.
Please contact Lutech if you need technical support or service.
Lutech Industries, Inc.
105 Remington Blvd., Suite C
Ronkonkoma, NY 11779
[phone]
[email protected]
Service hours: 9:00 AM – 5:00 PM EST
Not including holidays or weekends.
Before calling the manufacturer, distributor or authorized service center, please have the following
information on hand:
•Product model number
•Product serial number
•Detailed issue with the product (including how to replicate the issue if available).
Alternatively, you can visit www.lutechmedical.com and fill out a service request form to obtain an RMA
number.
Warranty is not covered if:
•The colposcope frame has been opened or tampered with in any way.
•The damage is caused by misuse, physical damage, or carelessness.
•The damage is caused by lack of proper maintenance.
•The damage is caused by maintenance or repair made by unapproved persons or companies.
•The damage is done by unstable voltage.
•The damage is done by natural disasters.
8. Indication for Use
The LT-300 SD and LT-300 HD digital video colposcopes are intended for the magnified viewing of the
vagina, cervix and external genitalia in order to assist doctors in diagnosing abnormalities and select areas
for biopsy. It is intended to be used only by trained and qualified personnel in hospitals, clinics and private
offices, and not intended for home use.
9. Safety Terminology
The terms “WARNING”, “CAUTION” and “NOTE” are used throughout this manual to point out hazards and
to designate a degree or level of seriousness. Familiarize yourself with their definitions and significance.
CONTRAINDICATIONS: Contraindications indicate a circumstance where the equipment is absolutely
forbidden for use.
WARNING: Warnings indicate a potential hazard or unsafe practice which, if not avoided, could result in
death or serious injury.

Page 7 of 60
CAUTION: Cautions indicate a potential hazard or unsafe practice which, if not avoided, could result in
minor personal injury or product damage.
NOTE: Notes provide application tips or other useful information to assure the best possible user
experience.
9.1 Hardware
CONTRAINDICATIONS:
There are no known contraindications.
WARNING:
•Please confirm the imaging system is in normal working condition before operation.
•Check all cables before use. Take notice to avoid cables intertwining on the neck of patient and replace any bad
cables and connectors immediately.
•The device can only be used on one patient at a time.
•The device must be grounded to avoid short circuiting the system.
•The device should only be used in the correct patient environment.
•Colposcope must be powered off and disconnected from AC power before cleaning.
•Keep the camera away from extreme humidity. During operation, avoid splashing any liquid near the colposcope.
If liquid is splashed onto the colposcope, it may cause the device to malfunction.
•Never place the camera in an environment where the temperature is higher than 131°F (55C) or under direct
high temperature radiation of thermal therapeutic or microwave devices.
•This device is not meant to be in contact with the patient. Please avoid contact between the device and the
patient during use.
•Make sure the power cord is properly plugged into a power socket with proper ground protection.
•Any peripheral electronics attached to the video colposcope (i.e. monitor, computer, etc.) should comply with IEC
60601-1 (General Requirements for Safety, Medical Electrical Equipment) or other relevant IEC standards
depending on the type of peripheral device used.
•The device should only be connected to parts and accessories that are supplied by Lutech. Lutech cannot
assure the safety of the device when used in conjunction with an unapproved part or accessory. Lutech cannot
assure the safety of the unapproved device that is being connected to The LT-300 SD and LT-300 HD digital
video colposcopes.
•Always turn the colposcope off first before plugging in or unplugging the video cable.
•Never stare at the lights around the lens.
•At any point during the use of the colposcope, if any liquid gets splashed onto the outer casing or the lens of the
colposcope, immediately stop using the device and wipe the liquid off. Please follow the instructions set forth in
chapter 6 of the manual under Cleaning and Maintenance.
•At any point during the use of the colposcope, if any liquid gets splashed onto the colposcope and gets inside the
casing, please turn off the colposcope right away and call your technician or the manufacturer. The device
should be checked by an authorized technician to make certain it is working accurately before being put back to
use.
•Do not attempt to immerse any part of the equipment in cleaning solutions.
•Do not let any liquid enter the inner casing of the camera. If water enters the inner casing of the camera, call
your technician or service center for assistance.
•Do not immerse the cable into any liquid or let any liquid touch or enter the electrical connection portions of the
cable.
•Always disconnect the colposcope from any power source before disassembling any
components or parts.
•The colposcope should always be operated by trained and authorized medical personnel
and according to the requirements of the Operator’s Manual. For any questions or
concerns, please contact the manufacturer or authorized repair/service center.
•Do not use product in anesthetic, flammable and explosive environments due to potential
fires or explosions.
•The LT-300 SD and LT-300 HD digital video colposcopes should not be used adjacent to or stacked with other
equipment. If adjacent or stacked use is necessary, the user must be alert and monitor The LT-300 SD and LT-
300 HD digital video colposcopes to verify it is operating within the manufacturer standards.
•The LT-300 SD and LT-300 HD digital video colposcopes are class I equipment and is intended for use in a
hospital or medical office environment. The LT-300 SD and LT-300 HD digital video colposcopes can encounter

Page 8 of 60
difficulties in ensuring electromagnetic compatibility in other environments because of both conducted and
radiated disturbances.
•Electromagnetic fields may interfere with the normal function of the system. Therefore, make sure that the
external device complies with EMC requirements. X-ray machine or magnetic resonance devices may possibly
cause interference, because they can produce high intensity electromagnetic radiation.
CAUTION:
•Federal law restricts the sale of this device to, or by the order of, a physician or other licensed medical
professional.
•Without the written approval of the manufacturer, user shall not remove or modify the colposcope or any of its
attachments and accessories. Nor shall the user use any accessories which do not comply with the
manufacturer’s requirements.
•When not in use, the colposcope should be turned off and the camera should be covered to prevent dust
accumulation.
•To prevent accidental power failure and other potential accidents, use UPS (uninterruptible power source)
systems with the colposcope.
•Do not disconnect from AC power without first turning the camera and the power box off or you may damage the
camera or power box components.
•Do not disconnect any cables without first turning the camera and the power box off or you may damage the
camera or power box components.
•Do not use the device with other electrical devices.
•Keep cellular phones and other communication devices away from the colposcope.
•If the user suspects that the colposcope is not functioning properly, please contact Lutech for support.
•To ensure safe usage of this device, please follow all instructions contained within this manual. The information
contained is not a substitute for current medical requirements and/or regulations. The manual cannot replace
actual experience of a doctor or nurse.
•Always take notice of the warnings, cautions and notes provided throughout this manual.
•Do not use strong solvents such as acetone to clean any part of the colposcope.
•Do not use abrasive materials (such as steel wool) to clean the colposcope.
•Do not leave any solvent residue on the device. If residue is present, wipe it off quickly with a cloth damp with
distilled water. Then pat dry with a dry cloth.
•The outer shell of the colposcope may not be opened by anyone other than a trained Lutech technician/engineer
or a Lutech approved technician/engineer. Approval from Lutech must be obtained in writing and signed by the
Management. Opening the outer shell of the colposcope without proper training may put the person in risk of an
electrical shock.
NOTE:
•Video colposcope is not a treatment device. It is a non-contact examination device. Use only as directed.
•This manual should be placed near the device for easy user reference. Read the manual thoroughly before
using the device to ensure proper operation and safety.
•Assembly and disassembly of the colposcope should only be performed by trained and authorized personnel.
•The lens of the camera should always be covered when not in use.
•The LT-300 SD and LT-300 HD digital video colposcopes meet the requirements of the electromagnetic
compatibility in IEC60601-1-2.
•Portable and mobile RF communication devices should be kept away from The LT-300 SD and LT-300 HD digital
video colposcopes as it may influence performance.
•A colposcope examination is only a secondary means of examination and the results found through colposcopy
are not the end result. Other tests should be conducted to determine the result, ultimately confirming a diagnosis.
•Colposcope lenses are precision optical instruments and must be handled with care. Gently use the colposcope
and avoid collision with anything that may move the lens. Offsetting the lens would result in a deterioration of the
image quality.
•Avoid using the colposcope in bright environments as it will decrease image quality.
•When using the colposcope, stay away from RF lines whenever possible. This includes audio or video sources.
•If the power is suddenly turned off during normal use, it will not injure the operator or the patient. Please follow
the user manual to properly power off the device. When power is restored, operate the equipment normally in
accordance with the user manual.
•Removable power cables that are not part of the original system or additional extension cords should not be
used with the colposcope.
9.2 Software

Page 9 of 60
NOTE:
•The LT-300 SD and LT-300 HD digital video colposcopes can be used with various viewing or video editing
software. It is the end user’s responsibility to choose the software that works best for them as well as complies
with all regulatory requirements within their territory.
•The LT-300 SD and LT-300 HD may also be integrated into telemedicine and hospital EMR software systems as
an add on hardware device depending on their software. In most cases, the colposcopes will work with any
software that allows video input and file attachments.

Page 10 of 60
Chapter 1: Introduction
NOTE: Unless specifically noted for one or the other, the following information is true for
both the LT-300 SD and the LT-300 HD digital video colposcopes.
Thank you for choosing the LT-300 SD and LT-300 HD digital video colposcope!
The LT-300 SD and LT-300 HD digital video colposcopes are a video colposcope with advanced electronic
imaging technology. This technique is different from traditional optical colposcope as it does not have
eyepieces. Doctors may use the mini LCD screen to focus in on the target area and then observe the patient
on a monitor. The LED light source and continuously magnified image will allow the presentation of subtle
details. In addition, The LT-300 SD and LT-300 HD digital video colposcopes can be used for diagnosis
and/or guiding treatment.
1.1 Scope
The LT-300 SD and LT-300 HD digital video colposcopes are a device designed to permit direct viewing of
the tissues of the vagina and cervix by a telescopic system located outside the vagina. It is used to
diagnose abnormalities and select areas for biopsy.
The LT-300 SD and LT-300 HD digital video colposcopes can be used for the clinical examination of the
cervix, vulva and vagina as well as for guiding medical procedures. It is composed of a light source, cables
and component parts.
1.2 Features
•The LT-300 SD and LT-300 HD digital video colposcopes have high quality color image display technology.
•Advanced color image module, circular LED group light source, and control circuit all integrate into one
handheld camera.
•The LT-300 HD digital video colposcope displays crystal clear imaging in high definition.
•Button control is provided for the convenient operation of zoom in/out, focus, freeze, green filter, and more.
•The remote control operates the colposcope without shaking the unit, allowing stability of image and faster
exam times.
•The LT-300 SD and LT-300 HD digital video colposcopes allows the image to be displayed onto a monitor,
allowing the doctor as well as the patient to observe the examination. In this manner, the doctor is able to
explain the diagnosis, such as cervical lesions, and suggest treatment to the patient.
•The LT-300 SD and LT-300 HD digital video colposcopes also displays the image on a small LCD screen on
the rear of the colposcope to aid in focusing and visual diagnosis.
•The LT-300 SD and LT-300 HD digital video colposcopes are great teaching tools and may be used in
classrooms and teaching hospitals to train residents and other medical professionals.
1.3 System and Main Components
The basic LT-300 SD and LT-300 HD digital video colposcopes are composed of a camera, image
processing unit, and a vertical stand. The swing arm stand is an optional feature.
Camera: The camera is composed of a high-resolution color SONY image module, circular LED group light
source, control circuit, batteries, and power adapter. It is mainly used to control the zoom in, zoom out,
focus, green filter, timing and freeze functions.
Camera Specifications:
LT-300 SD
LT-300 HD
Camera
IMX322 1/2.8-type CMOS
Sony 1/2.8-type Exmor
CMOS

Page 11 of 60
Camera Resolution
Standard
High
No. of Effective Pixels
2 .0 MegaPixels
2.13 MegaPixels
Focus
Manual/Auto
Manual/Auto
Lens
5.35mm-96.3mm
4.3mm-129.0mm
Optical Magnification
1～20
1～30
Digital Magnification
1～20
1～120
TVL
≥1000
≥1000
Light Source
Circular cool led group
light
Circular cool led group light
Brightness
Adjustable
Adjustable
Green Filter
Adjustable
Adjustable
Output
HDMI(1080P60),
USB3.0(1080P60)
HDMI(1080P60),
USB3.0(1080P60)
Image Freeze
Yes
Yes
Working Distance
7.1 – 14.9 inch
5.1-15.7 inch
Horizontal Angle
54.67°(wide end) -
3.91°(tele end)
63.7°(wide end) - 2.3°(tele
end)
Remote
Yes
Yes
Color Temperature
5000～5500 K
5000～5500 K
White Balance
Auto/Adjustable
Auto/Adjustable
Illuminance
Max 3000 lx
Max 3000 lx
UV Filter
No
Yes
Focusing Distance
Setup
Yes
Yes
Timer
Yes
Yes
Safety
IEC 60601-1
IEC 60601-1
Battery Power
4.5 Hours
4.5 Hours
Charging Time
3 Hours
3 Hours
Image Quality
High
Super
Capture Card
High
High
Camera Mount
Standard
high
Vertical and Swing Arm Stand: The vertical and swing arm stand is used to support the camera and
connect with the video cable.
Vertical Stand Specifications:
Measurement of the vertical stand is taken with the camera base mount on and the colposcope off.
LT-300 SD
LT-300 HD
Max. Height
42 in (106 cm)
42 in (106 cm)
Min. Height
31 in (78 cm)
31 in (78 cm)
Wheel Base
Four 360° swivel casters with locking mechanisms.
Remote Control: The remote control must be attached to the colposcope camera. It allows control for
zoom, freeze, manual focus and change of color filters. It obtains power from the colposcope camera.
There are no batteries within the remote.
Foot Pedal: The foot pedal is optional and will only work if the colposcope is used in conjunction with a
computer and a compatible video viewing/editing software, EMR software, or telemedicine software.
Image Processing Unit: The Image Processing Unit (IPU) includes the power supply and the image
processing module. The IPU converts video signals for output from the colposcope to a monitor or
computer.
Mini LCD Screen: The colposcope has a 2.5-inch color LCD screen on the back of the camera for real time
observation.
1.4 Installation Preparation
To ensure electric assembly safety, please place the colposcope in an environment that is reasonably dust

Page 12 of 60
free, without corrosive or combustible gas, or extreme temperature or humidity.
Carefully unpack all the components of the colposcope and check it with the packing list. Ensure that all
components are present and in good working order.
When using the colposcope with a monitor, keep a space of at least 5cm between the monitor and the wall
to ensure good air ventilation.
When using the colposcope with a computer system, please reference the minimum requirements below.
Minimum computer requirements:
•Type: PC
•CPU dual-core above 2.4GHz CPU
•Internal storage at least 4G
•Hard disk space of 200 GB or more
•Motherboard with PCI-E slot, HD products should have HDMI interface.
•Monitor: with wall-mount Dimension
•SD: not less than 1920×1080 dpi; 1080P, with HDMI interface
•HD: not less than 1920 x 1080 dpi; 1080P, with HDMI interface
•USB3.0 high speed interface
•Operating System: WINDOWS 7 or WINDOWS 10
Please keep the room clean and avoid static discharge directed at the unit, noise interference, and direct
sun. Extreme temperature can affect the accuracy of the monitor and damage accessories or circuits.
When the device is transported from one location to the next, please take note of the environment. Water
condensation might result due to exposure to humidity and temperature difference. Please ensure that there
is no water condensing in the device before use.
Operating rooms should be ventilated, and protected from static discharge, noise interference, and strong
power surges.
To ensure safety during use, the user must use proper grounding for the colposcope, especially when used
together with any microwave machine or high frequency device.
1.5 Unpacking and Inspecting
Make sure the proper side is facing up when opening the box by following the markings on the packaging.
After unpacking the camera and accessories, keep the packing materials properly stored for return service if
necessary. Keep packing material away from children.
Carefully check the device and the accessories against the packing list supplied by the manufacturer and
see if there is anything missing or damaged. If anything is damaged or missing, please contact the
manufacturer or distributor immediately.
Disposal of packaging material should be done according to local waste disposal rules.
1.6 Additional Information
This manual explains the performance, operation and maintenance of the system. If schematic diagrams,
key component lists or any other materials are needed by an authorized technician, please contact the
manufacturer.
NOTE: This manual should be placed near the device for easy user reference. Read the manual thoroughly
before using the device to ensure proper operation and safety.

Page 13 of 60
Chapter 2: Camera and Stand Assembly
NOTE: Unless specifically noted for one or the other, the following information is true for
both the LT-300 SD and the LT-300 HD digital video colposcopes.
This chapter explains the camera composition and installation process.
2.1 Camera Composition
The LT-300 SD and LT-300 HD digital video colposcopes includes a camera, circular LED group light
source, control circuit, enclosure and remote.
Diagram 2.1-1
2.2 What’s included with the Colposcope
Depending on the colposcope configuration you have purchased, you will receive the following standard
1.
Lens Cap
2.
LED Group Light
3.
Enclosure
4.
Mini LCD Screen
5.
Function Buttons
6.
Battery Compartment
7.
Remote Hook
8.
Remote with Function Buttons

Page 14 of 60
components:
LT-300 SD Digital Video Colposcope with Vertical Stand
LT-300 SD Colposcope Camera
1
Remote (no battery required)
1
Power Box SD (Includes box, 2 attachment rings, 4 screws and allen wrench)
1 set
Power Adapter(15V)
1
HDMI Cable (approx. 9.8 feet (3M))
1
USB3.0 Cable (approx. 6.5 feet (2M))
1
Vertical Stand (Includes: Camera Base Mount, Wheel Base, 4 Casters with locks
and pre-threaded SD Main Cable)
1
3-Pedal Foot Switch
1
USB drive loaded with the Lutech Viewer
1
LT-300 HD Digital Video Colposcope with Vertical Stand
LT-300 HD Colposcope Camera
1
Remote (no battery required)
1
Power Box HD (Includes box, 2 attachment rings, 4 screws and allen wrench)
1 set
Power Adapter(15V)
1
HDMI Cable (approx. 9.8 feet (3M))
1
USB3.0 Cable (approx. 6.5 feet (2M))
1
Vertical Stand (Includes: Camera Base Mount, Wheel Base, 4 Casters with locks
and pre-threaded HD Main Cable)
1
3-Pedal Foot Switch
1
USB drive loaded with the Lutech Viewer
1
NOTE: For replacement cables or other accessories, please contact your distributor or Lutech
representative.
2.3 Pre-Assembly Check List
Ensure all parts are present before assembly.
2.3.1 Vertical Stand Parts List
The colposcope with vertical stand configuration will come with the following parts:
•Colposcope camera
•Camera base mount with camera base plate attached
•Vertical tube with the power box attached and the main cable pre-threaded
•Anti-roll wheel base with 4 casters with locking mechanisms
•Wheel base screw set, including: 1 screw, 1 locking washer, 1 regular washer, 1 allen wrench
2.3.2 Swing Arm Stand Parts List
The swing arm stand is an optional accessory for the colposcope. It will come with the following parts:
•Colposcope camera
•Camera base mount with camera base plate attached
•2 swing arm sections with wire management caps, power box attached and the main cable pre-threaded
•Anti-roll wheel base with 4 casters with locking mechanisms
•Wheel base screw set, including: 1 screw, 1 locking washer, 1 regular washer, 1 allen wrench
2.4 Colposcope with Vertical Stand Assembly
To assemble the colposcope on the vertical stand, follow the steps below.

Page 15 of 60
1. Take out the vertical tube and inspect it. The vertical tube should have the main cable pre-threaded inside
and the power box attached on the lower portion of the tube. If the main cable or the power box is not
already assembled, please see section 2.6 Troubleshooting.
Diagram 2.4-1
2. Place the Wheel Base in front of you with the longer legs toward you.
Diagram 2.4-2
3. Insert the tube into the Wheel Base with the extension knob toward you.
Diagram 2.4-3
4. Place the split lock washer onto the screw first. Then place the tooth lock washer on as shown in diagram
2.4-4.

Page 16 of 60
Diagram 2.4-4
5. Place the screw into the bottom of the wheel base in the center. Attach the vertical tube to the wheel base
by tightening the screw using the 6mm allen key provided as show in diagram 2.4-5.
Diagram 2.4-5
6. Take the main cable connector coming out of the bottom hole on the vertical tube and connect it to the
bottom of the power box.
Diagram 2.4-6
NOTE: There is a bump on top of the red dot on the main cable connector. This bump will fit into the notch
located on the power box connector. Make sure to match the bump to the notch. The cable will plug in
easily. Do not force it in.
Diagram 2.4-7
7. The Camera Base Plate should already be attached to the bottom of the colposcope. If that is the case, skip
to step 10. If not, detach the camera base plate from the camera base mount by turning the knob located at
the top of the Camera Base Mount counterclockwise.

Page 17 of 60
Diagram 2.4-8
8. Align the screw on the camera base plate to the hole on the bottom of the camera head.
Diagram 2.4-9
9. Turn the camera base plate over and pull out the ring on the other side. Place the camera base plate screw
over the hole under the colposcope camera. Turn the ring clockwise to attach the camera base plate onto
the bottom of the camera. Press the ring back when done to tuck it out of the way.

Page 18 of 60
Diagram 2.4-10
10. Place the camera mount on the vertical stand and turn clockwise to tighten as shown below.
Diagram 2.4-11
11. There are 2 phases to opening the Stand Mount release knob. Turn the Base Plate Release Knob
counterclockwise until it cannot turn anymore. Pull the knob outward to allow it to continue turning. Continue
turning counterclockwise until it stops. The base mount is now fully open and is ready to receive the
Camera, which is attached to the camera base plate.
Diagram 2.4-12
12. Plug the main cable coming out of the top of the vertical tube into the connector located on the bottom of the
colposcope camera.
NOTE: There is a bump on top of the red dot on the main cable connector. This bump will fit into the notch

Page 19 of 60
located on the connector located on the bottom of the colposcope camera. Make sure to match the bump
to the notch. The cable will plug in easily. Do not force it in.
13. Slide the camera base plate onto the camera mount and tighten the base plate release knob clockwise to
secure the colposcope.
Diagram 2.4-13
CAUTION:
•Do not let go of the colposcope camera without ensuring that the base plate release knob is
tightened correctly, and the camera head is stable.
•Do not let go of the colposcope camera until the ball lock is tightened. The ball lock and friction
control knob both adjust the tension on the ball socket and can both be used to customize the
movement of the camera.
Diagram 2.4-14
