Bohmer-AG W Series User manual

W Series Generators
6500W / 6500W-E / 8000W-E / 9000W-E
OPERATION MANUAL
Read this manual carefully before use and keep it for future reference. Failure to do so
may result in injury, property damage and may void the warranty.
Products covered by this manual may vary in appearance, assembly, inclusions,
specications, description or packaging.
V 3.0
English Français Deutsch Italiano Español

W Series
© Böhmer-AG
2
English
02 - Contents
03 - Important safety information
04 - Quick start guide 6500W / 6500W-E
04 - Parts Diagram
05 Assembly
05 Before Starting
06 Starting
07 - Quick start guide 8000W-E / 9000W-E
07 - Parts Diagram
08 Assembly
09 Before Starting
10 Starting
11 - Maintenance
11 Oil change
11 Spark plug
12 Fuel lter
12 Air lter
13 Maintenance schedule
14 - Troubleshooting
15 - Specications
16 - CE Declaration of Conformity
17 - Français
33 - Deutsch
49 - Italiano
65 - Español
Contents Languages

W Series
© Böhmer-AG © Böhmer-AG 3
English
Important safety information
• Do not attempt to modify the product In any way.
• Service regularly and only use replacement parts supplied by the manufacturer.
• Only use fresh, clean and good quality fuel in the engine.
• Never operate the engine without oil.
• Never refuel in close proximity to naked ames, sparks, other sources of ignition e.g. cigarettes, if the
engine is hot or if the engine is still running.
• Do not refuel when the engine it hot or engine is running.
• Wipe up and correctly dispose of any fuel spillage immediately
• Move away from the refuelling areas before restarting the engine. Store fuel for short periods only in a
suitable container away from heat and direct sunlight.
• Clean the generator thoroughly after each use.
• Regularly check external nuts and xings to ensure vibration caused by normal use has not loosened
them.
• Empty the fuel tank before storing in a secure dry location out of reach of children.
• Do not use indoors.
It is essential you fully read this manual to ensure you are familiar with the general safety
features, precautions and functions necessary to operate your generator, failure to do so may
result in injury, damage to your generator or personal items.

W Series
© Böhmer-AG
4
English
Quick start guide 6500W / 6500W-E
The following steps describe the quickest method to get your
generator up and running. Before use, you must ensure the
oil is topped up to the upper limit or the generator’s safety
mechanisms will not allow the engine to start.
1. Engine ON switch (6500W) / ignition key
(6500W-E)
2. Battery (6500W-E)
3. 12V DC outlet
4. Voltmeter
5. 240V AC dual plug outlet
6. Recoil starter
7. Air lter
8. Fuel tap
9. Choke lever
10. Fuel ller cap
11. Fuel gauge
1
3
4
5
6
7
8
10
9
11
2
Parts Diagram

W Series
© Böhmer-AG © Böhmer-AG 5
English
Assembly
Before Starting
The rubber feet are positioned on the two sub frames of the
generator unit. Locate the four pre-drilled holes. Thread the
bolts through the rubber feet and secure using the nuts.
The battery is connected
Black to ‘-’ negative, red to ‘+’
positive. Secure with nut and
bolt then shield with terminal
covers.
Add fuel:
1. Open the ller cap
2. Fill with unleaded petrol up to the lter
3. Replace ller cap
nhk
Fuel gauge / ller cap
Oil ller bung
Add oil:
Note: The generator will automatically shut down if
insufcient oil is detected.
1. Place generator on a level surface
2. Open the oil dipstick
3. Fill with 10W-40 semi-synthetic oil up to the threads
4. Replace oil dipstick

W Series
© Böhmer-AG
6
English
Starting
1. Turn the circuit breaker on and then connect your devices:
• AC: connect device’s plug to 3-pin plug outlet
• DC: connect your device’s black wire to the black negative terminal, the red wire to the red positive
terminal. The DC output can be used to charge the battery (electric start models only)
2. Turn the fuel tap to the ON position
3. Push the choke lever to the left (closed position)
4. 6500W - Turn the engine switch ON, pull recoil handle until engine starts
5. 6500W-E - Turn the ignition key until the engine starts
6. Once warm push choke lever to right (open position)
ON
OFF
ENG.S.W
OFF
ON
ENG.S.W
ON
START
OFF
Fuel tap
Engine switch
Choke lever
Recoil handle
Ignition key

W Series
© Böhmer-AG © Böhmer-AG 7
English
Quick start guide 8000W-E / 9000W-E
The following steps describe the quickest method to get your
generator up and running. Before use, you must ensure the
oil is topped up to the upper limit or the generator’s safety
mechanisms will not allow the engine to start.
Parts Diagram
12
4
5
7
8
9
11
10
3
12
6
1. Engine ON ignition barrel
2. 240V AC 13A plug outlet
3. Battery
4. 12V DC outlet
5. 240V AC 32A plug outlet
6. Voltmeter
7. Recoil Starter
8. Air lter
9. Fuel tap
10. Choke lever
11. Fuel ller cap
12. Fuel gauge

W Series
© Böhmer-AG
8
English
Assembly
Roll the unit to expose
the underside taking care
not to damage any part of
the generators frame and
mechanics.
Slot the wheel over the axle and
secure with the wheel nut.
Loosely attach the two brackets
to the front sub frame using the
provided nuts and bolts.
Once the wheels are tted you
can locate the rear sub frame to
t the rubber feet.
Insert the axle through the
brackets and evenly tighten all
four nuts.
Fix the ‘U’ shaped bracket to the
sub frame.

W Series
© Böhmer-AG © Böhmer-AG 9
English
Attach the rubber feet to the
bracket using the nuts and bolts
provided.
Locate the holes on the frame
either side of the recoil starter.
Position the handle. Secure
using the long bolts.
The Battery is connected
black to ‘-’ negative, red to ‘+’
positive. Secure with nut and
bolt then shield with terminal
covers.
Before Starting
Add fuel:
1. Open the ller cap
2. Fill with unleaded petrol up to the lter
3. Replace ller cap
Add oil:
Note: The generator will automatically shut down if
insufcient oil is detected.
1. Place generator on a level surface
2. Open the oil ller bung
3. Fill with 10W-40 semi-synthetic oil up to the threads
4. Replace oil ller bung
Oil ller bung
Fuel gauge / ller cap

W Series
© Böhmer-AG
10
English
Starting
1. Turn the circuit breaker on and then connect your devices:
• AC: Connect device’s plug to 3-pin plug outlet
• DC: Connect your device’s black wire to the black negative terminal, the red wire to the red psositive
terminal. This can be used to charge the battery (electric start models only)
2. Turn the fuel tap to the ON position.
3. Push the choke lever to the left (closed position)
4. Turn the ignition key until the engine starts
5. Once warm push choke lever to right (open position)
Fuel tap Choke lever Ignition key

W Series
© Böhmer-AG © Böhmer-AG 11
English
Maintenance
Spark plug
Oil change
1. Unscrew the oil bung
2. Undo the oil drain plug and drain the oil
3. Install and tighten the oil drain plug
4. Add 10W-40 semi synthetic oil to the upper
limit of the ller hole
5. Install the oil bung
1. Remove spark plug cap and unscrew the spark
plug using the supplied tool.
2. Carefully clean any carbon build-up on the tip.
3. Check the gap using a gauge. The gap should be
between 0.7-0.8mm.
4. Adjust as necessary then reinstall the plug and
cap taking care not to cross-thread the spark
plug.
toodq?kdudk

W Series
© Böhmer-AG
12
English
Fuel lter
1. Switch off the fuel tap.
2. Remove sediment cup and ltering mesh.
3. Clean sediment cup and ltering mesh
4. Install sediment cup and ltering mesh.
Air lter
The air lter is installed on the intake system of the engine. It allows clean air to ow into the engine to
provide the correct air/fuel mixture.
To check/clean
1. Open air lter cover
2. Check air lter to ensure it is free of dirt build-up
3. If dirty, remove lter and clean with a solvent cleaning solution
4. Squeeze to remove water and allow to dry
5. Add a few drops of oil
6. Squeeze tight to distribute oil and remove any excess
7. Install air lter and cover

W Series
© Böhmer-AG © Böhmer-AG 13
English
Maintenance schedule
Component/Task Every use After rst 5
hours use
First month or
20 hours use
Every 3 months
or 50 hours use
Every 6 months
or 100 hours use
Every year or
300 hours use
Engine oil Check Replace Replace
Oil leaks Check / repair
as necessary
Air lter Check Check Clean / replace as
necessary
Clean / replace as
necessary
Valve clearance Adjust as
necessary
Combustion
chamber
De-coke as
necessary
Idle speed Check / adjust as
necessary
Nuts & bolts
Check /
tighten as
necessary
Fuel tank Flush and clean
Fuel line Check Check / clean Replace as
necessary
Clean /
replace as
necessary
Fuel lter Check Check / clean
Clean and
replace as
necessary
Clean and replace
as necessary
Spark plug Check / clean Clean and replace
as necessary
Clean and replace
as necessary

W Series
© Böhmer-AG
14
English
Troubleshooting
Issue Probable Cause Solution
Engine will not start
No fuel in the tank Check / refuel as necessary
Not enough engine oil Check and top up as
necessary
No spark Check spark plug. Clean /
replace as necessary
Fuel not reaching
carburettor Clean fuel sediment cup
No electricity being
produced
AC circuit breaker is OFF Check and ensure DC
circuit breaker is ON
Connected appliances
faulty
Check fuses / test other
equipment

W Series
© Böhmer-AG © Böhmer-AG 15
English
Specications
6500W 6500W-E 8000W-E 9000W-E
Max Output 2800 W 2800 W 7500 W 8500 W
Rated Output 2600 W 2600 W 7000 W 8000 W
Rated AC
Voltage 240 V
240 V 240 V 240 V
Rated DC
Voltage 12 V
12 V 12 V 12 V
Engine
Output 8 HP
8 HP 13 HP 16 HP
Fuel Capacity 11 L 11 L 25 L 25 L
Oil Capacity 0.6 L 0.6 L 0.6 L 0.6 L
Continuous
Runtime 10 Hours
10 Hours 16 Hours 16 Hours
Engine
Displacement 210 CC
210 CC 420 CC 458 CC
Oil Type 10W-30 /
10W-40
10W-30 /
10W-40
10W-30 /
10W-40
10W-30 /
10W-40
Starting Type Recoil
Recoil /
Electric
Recoil /
Electric
Recoil /
Electric

© Böhmer-AG
W Series
© Böhmer-AG
16
English
We hereby declare that the machine described below complies with the relevant basic safety and health
requirements of the EU Directives, both in its basic design and construction as well as in the version put
into circulation by us. This declaration shall cease to be valid if the machine is modied without our prior
approval.
The undersigned: Michael S McQuaide
as authorised by: Union Mart Ltd
Declares that
Description : Petrol Generator
Identication code: 6500W, 6500W-E, 8000W-E, 9000W-E
Conforms to the following directives and standards:
• MD 2006/42/EC Machinery Directive
• EMC 2004/108/EC Annex 11 Electromagnetic Compatibility Directive
--
And Complies with the provisions of the following standards:
EN 12601:2010, EN60204-1:2006/AC:2010, IEC 60034-1:2010, EN
55012:2007+A1:2009.
--
Notied body: CNAS – China National Accreditation Service of Conformity Assessment
The technical documentation is kept by: Union Mart Ltd
Date: 15/02/2017
Signed:
Michael S McQuaide
Chief Executive Ofcer
Name and address of the manufacturer:
Union Mart Ltd, Company No. 8384155. Registered address: Unit 4 Mauretania Road,
Nursling Industrial Estate, Southampton, SO16 0YS, United Kingdom.
CE Declaration of Conformity

W Series
© Böhmer-AG © Böhmer-AG 17
Français
© Böhmer-AG
Lisez attentivement ce manuel avant toute utilisation et conservez-le à titre de référence. Dans le cas contraire,
vous risquez de vous blesser, d’endommager des biens matériels et d’annuler la garantie.
Les produits présentés dans ce manuel peuvent présenter une apparence, un assemblage, des inclusions, des
spécifications, une description ou un emballage différent.
Générateurs Série W
6500W / 6500W-E / 8000W-E / 9000W-E
FRANÇAIS

W Series
© Böhmer-AG
18
Français
Sommaire
18 Sommaire
19 Consignes de sécurité importantes
20 Guide de démarrage rapide 6500W / 6500W-E
20 Schéma des pièces
21 Assemblage
21 Avant de commencer
22 Démarrage
23 Guide de démarrage rapide 8000W / 9000W-E
23 Schéma des pièces
24 Assemblage
25 Avant de commencer
26 Démarrage
27 Maintenance
27 Vidange d’huile
27 Bougie d’allumage
28 Filtre à carburant
28 Filtre à air
29 Calendrier de maintenance
30 Dépannage
31 Spécications
32 Déclaration de conformité CE

W Series
© Böhmer-AG © Böhmer-AG 19
Français
Consignes de sécurité importantes
• N’essayez en aucun cas de modier la machine.
• Faites régulièrement l’entretien selon le calendrier d’entretien.
• Mettez uniquement du carburant neuf, propre et de bonne qualité dans le moteur.
• Ne faites jamais fonctionner le moteur sans huile.
• Ne faites jamais le plein d’essence à proximité de ammes, d’étincelles ou d’autres sources
d’inammation, comme des cigarettes par exemple.
• Ne faites pas le plein lorsque le moteur est chaud ou que le moteur tourne.
• Essuyez et éliminez correctement et sans attendre tout déversement de carburant conformément aux
directives.
• Éloignez-vous des zones de ravitaillement en carburant avant de redémarrer le moteur. Stocker le
carburant pendant de courtes périodes uniquement dans un récipient approprié, à l’abri de la chaleur
et des rayons directs du soleil.
• Nettoyez le générateur à fond après chaque utilisation.
• Vériez régulièrement les écrous et les xations externes an de vous assurer que les vibrations
(causées par une utilisation normale) ne les aient pas desserrés.
• Videz le réservoir de carburant avant stockage dans un endroit sec et sécurisé, hors de portée des
enfants.
• Ne pas utiliser à l’intérieur.
Merci de lire attentivement le manuel pour vous familiariser avec les caractéristiques de sécurité
générales, les précautions et les fonctions nécessaires au fonctionnement de votre groupe
électrogène. Dans le cas contraire, vous risquez d’engendrer des blessures, ou de provoquer des
dommages à votre générateur ou à vos objets personnels

W Series
© Böhmer-AG
20
Français
Guide de démarrage rapide 6500W / 6500W-E
Les étapes suivantes décrivent la méthode la plus rapide
pour mettre votre groupe électrogène en marche. Avant toute
utilisation , vous devez vous assurer que l’huile est remplie
jusqu’au niveau maximum, sinon les mécanismes de sécurité
du générateur ne permettront pas au moteur de démarrer.
1. Interrupteur moteur en marche (6500W) / clé de
contact (6500W-E)
2. Batterie (6500W-E)
3. Prise 12V DC
4. Voltmètre
5. Double prise de courant 240V AC
6. Démarreur à rappel
7. Filtre à air
8. Robinet d’essence
9. Levier de starter
10. Bouchon de remplissage
11. Jauge de carburant
1
3
4
5
6
7
8
10
9
11
2
Schéma des pièces
