SHPS-12 FIRE EQUIPMENT MOUNT BOXES
WITH BACKUP BATTERY POWER SUPPLIES
ShPS-12 ShPS-12 mod.01 ShPS-12 mod.02
ShPS-12 mod.10 ShPS-12 mod.11 ShPS-12 mod.12
Operations Manual
1DESCRIPTION AND OPERATION
1.1 Purpose
1.1.1 ShPS-12, ShPS-12 mod.01, ShPS-12 mod.02, ShPS-12 mod.10, ShPS-12 mod.11, ShPS-
12 mod.12 (hereinafter referred to as ShPS-12) are meant to provide power supply for groups of installed fire
control equipment, manual call points, alarm and control panels (modules) and other fire protection equipment
requiring 12V/DC.
ShPS-12 mod.01 boxes differ from ShPS-12 boxes by a transparent window door; ShPS-12 mod.02 boxes
differ from ShPS-12 boxes by IP54 ingress protection rating.
ShPS-12 mod.11 differs from ShPS-12 mod.10 by a transparent window door; ShPS-12 mod.12 differs from
ShPS-12 mod.10 by IP54 ingress protection rating.
ShPS-12 mod.10, ShPS-12 mod.11, ShPS-12 mod.12 differ from ShPS-12, ShPS-12 mod.01, ShPS-12 mod.02
by two separate RS-485 interface lines (instead of one line, see Clause 1.2.9).
An ShPS-12 box can accommodate the following Orion ISS devices: Signal-10, Signal-20P, S2000-4,
S2000-KDL, S2000-KPB, S2000-SP1, S2000-PI, S2000-KDL-2I, Rupor mod.02, S2000-PGE, S2000-PGE
mod.01, S2000-Ethernet, S2000-RPI and other devices mountable on 35 mm top-hat DIN rail in accordance
with GOST R MEK 60715-2003.
1.1.2 ShPS-12 is designed for 24/7 continuous operation with intended output parameters, automatic
monitoring and charging of sealed backup batteries. ShPS-12 provides disconnecting backup batteries from
load circuits to avoid unacceptable discharge. ShPS-12 provides protection against open / short failures for the
battery connection circuit.
1.1.3 ShPS-12 provides visual and audible indication of the following: mains supply status (availability,
high / low voltage), backup battery status, missed batteries, disconnection of low batteries, output short
circuit / overcurrent, charger faults, output overvoltage, status of communications over the RS-485 interface
bus.
1.1.4 Being powered by mains and by batteries, ShPS-12 provides overvoltage and short-circuit protection
for 12V/DC outputs, with the output voltage being restored automatically after repairing an output short-circuit
fault.
1.1.5 ShPS-12 shall be installed in locations protected from atmospheric precipitation and mechanical
damage. ShPS-12 boxes are not designed for operating in locations where they can be exposed to explosion
and / or flammable hazards.
1.1.6 ShPS-12 is classed as recoverable and periodically serviced equipment.
1.2 Specifications
Table 1
No.
Parameter
Val
ue
1.2.1
Power Inputs
2
1.2.2
Primary power supply: The mains utility AC power 50/60 Hz
150…253
V
1.2.3
Backup power supply: Bolid series batteries AB
1207 (the type
С
or
М
)
*
or
similar
12 V, 17 Ah (2 batteries)
1.2.4 Output voltage: while powered by
mains
(13
.
6±0
.
6)
V
ba
tteries
(
13
.
5
…
9
.
5
)
V
1.2.5
Rated
/
maximum load current
3
A
/
3
.
5
A
*
*
1.2.6
Outputs
for
powering
devices
consuming
12
V
and
installed
within ShPS
-
12
7
1.2.7
Maximum current per a single output 12V/dc
0
.
65
A
1.2.8
Outputs
for connecting RS
-
485 interface lines installed w
ithin ShPS
-
12
7
1.2.9
For
ShPS
-
12
,
ShPS
-
12 mod.01
,
ShPS
-
12 mod.02
:
RS-485 port for connecting external devices over the RS-485 interface
For ShPS-12 mod.10, ShPS-12 mod.11, ShPS-12 mod.12:
Separate RS-485 ports for connecting external devices over the RS-485
i
nterface
1
2
1.2.10
Capacity
of
non
-
volatile
event log
95
events
1.2.11
Maximum power
/
current consumed from the mains
1
2
0
V
·
A
/ 0
.
8
A
1.2.12
Current consumed from the batter
ies
by the
ShPS
-
12
itself
40
mA max

2
No.
Parameter
Val
ue
1.2.13 Ripples of the output voltage (peak-to-peak) at rated load current
100
mV max
(VR1 class
as per GOST R 51179
-
98
)
1.2.14
Low
-
battery
shutdown
voltage
(10
.
2
±
0
.
6)
V
1.2.15
The ShPS
-
12 backup time when started with full
-
charged batteries at 3
A
load current and temperature of 298
К
(+25
°
C)
8 hours at least
1.2.16
Time to charg
e fully discharged batter
ies
Maximum charging rate for each battery
36
hours max
0
.
7
A
1.2.17
Maximum
current
available
for
additional
consumers
of
mains
power
2
2
0
V
/
50
H
z
10 A
1.2.18
Electric
shock
protection
class
as
per
GOST
12.2.007.0
-
75
I
1.2.19
Enclosure protection degree as per GOST 14254-2015
•ShPS-12, ShPS-12 mod.01, ShPS-12 mod.10, ShPS-12 mod.11
•ShPS-12 mod.02, ShPS-12 mod.12
IP41
IP
54
1.2.20
Resistance to mechanical exposure as per OST 25 1099
-
83
Arrangement Category III
1.2.21
Vibration exposure
:
- Frequency range
-
Ma
x acceleration
1-35 Hz
0
.
5
g
1.2.22
Environmental category as per OST 25 1099
-
83
О
3
1.2.23
Operating temperature range
Minus 10 through +40 °
С
1.2.24
S
h
PS
-
12
weight without batteries
/
with batteries
1
5
/
27
kg
1.2.25
Overall dimensions
650
mm
×
500
mm
×
220
mm
1.2.26
Non
-
stop op
eration
Round
-
the
-
clock
1.2.27
MTBF
40000
h
1.2.28
Survival probability over
a
period
of
1000
hours
0
.
975
1.2.29
Expected service life of ShPS
-
12
10
years
* The letters Сand Мdefine the battery service life as 12 and 15 years respectively.
** The maximum load current is 3.5 A (for short-duration periods of up to 2 minutes at intervals of at least one hour
provided that the mains power is available and batteries are connected). When the output current is over 3.5 A, the ShPS-12
box turns off the charger. When the output current is over 4A, ShPS-12 disables the output voltage.
1.2.30 ShPS-12 provides monitoring mains voltage, output voltage, and battery voltage with automatic
sending of messages about presence of relevant voltages / faults, battery discharge, bad battery health or battery
disablement, and tampering over the RS-485 interface.
1.2.31 The built-in PSU of ShSP-12 is ready to operate after 6 seconds upon powering up.
1.2.32 ShPS-12 features a Remote Fault Output – a solid state relay with the following parameters:
maximum switched voltage / current is 80 V / 50 mA; maximum resistance of closed relay circuit is 50 Ohm;
maximum open circuit leakage current at 80 V is 1 uA.
1.2.33 In terms of immunity to electromagnetic interference, the ShPS-12 meets the requirements of Test
Severity Level III as per the relevant standards listed in Appendix ‘Б’ to GOST R 53325-2012.
1.2.34 ShPS-12 passes the industrial interference standards prescribed for Class ‘Б’ equipment as per
GOST R 30805.22.
1.2.35 ShPS-12 design provides protection against unauthorized access inside the box by means of the key
lockable door. There are no control elements outside the ShPS-12 box.
1.2.36 ShPS-12 provides tamper monitoring by means of a tamper switch with contacts closed when the box door is
closed and open when the box door is open.
1.2.37 In case of malfunction or misuse, the design of ShPS-12 provides fire safety in accordance with
GOST 12.1.004-91.
1.2.38 Insulation strength of live parts of the ShPS-12 box is not less than 2,000 V (50 Hz) between circuits
linked to 220V AC and the enclosure as well as between circuits linked to 220V AC and any circuits not linked
to 220V AC.
1.2.39 Insulation strength of separate interface lines and other circuits for ShPS-12 mod.10, ShPS-12
mod.11, and ShPS-12 mod.12 is at least 500 V, 50 Hz.
1.2.40 The electrical insulation resistance between the circuits mentioned above in the para 1.2.38 is at
least 20 mega ohms (in normal conditions as defined in Clause 5.14.6 of GOST 52931-2008).

3
1.3 Scope of Delivery
Table 2 presents the delivery scope for the ShPS-12.
Table 2
Item
Q
-
ty
,
pcs
.
S
hPS
-
12
ShPS-12 mod.01
ShPS-12 mod.02
ShPS-12 mod.10
ShPS-12 mod.11
ShPS
-
12
mod
.12
1
Accessory Kit
:
Fasteners
:
(
eye bracket
,
bolt
,
nut
,
screw
,
wall plug
)
4
Rubber cable gland
:
ShPS-12; ShPS-12 mod.01
ShPS-12 mod.10; ShPS-12 mod.11
ShPS
-
12 mod.02
;
ShPS
-
1
2
mod
.12
6
6
4
For ShPS
-
12 mod.10
,
ShPS
-
12 mod.11
,
ShPS
-
12 mod.12:
Jumper
MJ
-
0
-
6 (2
.
54
×
6
mm
)
2
Key
2
Packaging
1
Documentation
ShPS
-
12,
ShPS
-
12
mod
.01,
ShPS
-
12
mod
.02,
ShPS
-
12
mod
.10,
ShPS
-
12
mod
.11,
ShPS
-
12
mod
.12
Operations Manual
1
Note. No battery is included in the standard delivery!
2INTENDED USAGE
2.1 The product design meets the requirements of fire and electric safety including emergency operation in
accordance with Russian standards GOST 12.2.007.0-75 and GOST 12.1.004-91.
2.2 The ShPS-12 shall be wired as shown in the connection diagram located on the inside of the ShPS-12’s
cover.
2.3 Do shut off the mains power from the ShPS-12 before mounting, installing, and
maintaining this one.
2.4 Operating restrictions, design, mounting, connecting, settings, testing and operation
procedures for the ShPS-12 are defined in details in its User’s Manual (the full version),
which is available online at bolid.ru in the section Products on the page of ShPS-12 or using
the mobile app ‘Mobile Product Catalogue’ https://bolid.ru/support/mobile-catalogue/.
2.5 If a technical failure of the product has been found, the equipment shall be taken out
of operation and sent for repair in accordance with Section 4.
3MAINTENANCE
3.1 The ShPS-12 shall be maintained by persons qualified for Electrical Safety of Level III or higher.
3.2 Maintenance works for the ShPS-12 are described in its User’s Manual (the full version, see Section 2.4
of this manual).
4REPAIR
4.1 Repair of faulty equipment is to be performed by the manufacturer or in authorized repair centers. The
equipment shall be sent for repair in compliance with Company Standard QMS 8.5.3-2015, which can be found
online at our website https://bolid.ru/support/remont/.
4.2 A product’s failure resulted from consumer’s not observing rules of mounting and operation is not a
reason for claims and warranty repair.
4.3 Claims should be submitted to the following address:
NVP BOLID, #4 Pionerskaya Str., Korolyov, Moscow Region, 141070, Russia
Phone/fax: [phone] (PBX). E-mail: inf[email protected]
4.4 In case of any issue related to use of the product, please contact the technical support: [phone]-
55 or e-mail: suppor[email protected].
5STORAGE
5.1 In a transport container the equipment can be stored at ambient temperatures ranged from minus 30°С
to +50°Сand relative humidity of 95% at +35°С.
5.2 In consumer packages the equipment can be stored only in heated premises at ambient temperatures
+5°Сthrough +40°Сand relative humidity up to 80% at +20°С.
Attention
!
The equipment shall be submitted for repair being assembled and clean and along with all the
parts listed in the documentation.
Claims are accepted only if a reclamation report describing the failure is applied to the submitted
equipment.

4
5.3 Batteries shall be stored in accordance with rules and storage conditions established by the battery
manufacturer.
6TRANSPORTING
The ShPS-12 can be transported in a transport container at ambient temperatures ranged from minus 50°Сto
+50°Сand relative humidity of 95% at +35°С.
7DISPOSAL
7.1 The ShPS-12 is to be disposed of considering that there are no toxic components in it.
7.2 Batteries are classed as hazardous waste of Class II, so used up batteries shall be disposed of by a
specialized company that is licensed for this activity.
7.3 The content of precious materials: does not require accountability for storage, retirement and disposal
(Clause 1.2 of GOST 2.608-78).
7.4 The content of non-ferrous metals: does not require accountability for retirement and further disposal.
8MANUFACTURER WARRANTY
8.1 The manufacturer guaranties the ShPS-12 meets with technical requirements stated in the manuals if the
user follows the instructions for transportation, storage, installation, and usage.
8.2 The warranty period is 18 months since putting the product into operation but no more than 24 months
from the manufacturer’s date of production.
9CERTIFICATES
For certification information, please refer to ShPS-12 User’s Manual (the full version, see Section 2.4 of this
manual).
10 ACCEPTANCE AND PACKAGING CERTIFICATE
The fire equipment mount box with battery backed power supply

ShPS
-
12

ShPS
-
12
mod
.10

ShPS
-
12
mod
.01

ShPS
-
12
mod
.11

ShPS
-
12
mod
.02

ShPS
-
12
mod
.12
with Factory No. __________________ is manufactured, accepted in line with mandatory requirements of
national standards and applicable technical documentation, approved as ready for use, and packaged by the
Bolid Company.
Responsible for acceptance and packaging
QCD ______________________________ ________________________
Full Name Date/Month/Year
